Delfield Shelleybasic SE-ICE1 User manual

Project ________________________________________
Item Number ___________________________________
Quantity ____________Date_______________________
Approval ______________________________________
The Deleld Company,980 S. Isabella Road, Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.deleld.com
Deleld reserves the right to make changes in design or specications without prior notice. ©2004 The Deleld Company. All rights reserved. Printed in the U.S.A.
SE-ICE/SES-ICE
Mobile Ice Cream Counters
Short Form Specications
Exterior Body: Open frame construction with 16-gauge stainless steel corners:
18-gauge stainless steel full bottom shelf and stainless steel C channel front and sides
for optional accent panels.
Exterior Top: Constructed of 16-gauge stainless steel, welded, ground and polished
into one integral unit. Top is fabricated with square exterior corners. Top has die-
stamped openings, with hinged removable lids. Lids are constructed of stainless steel
and have a rubber gasket seal.
Freezer Compartment: A water-tight inner liner constructed of 22-gauge stainless
steel, with radius corners and 1.5” (3.8cm) of polyurethane insulation.
Refrigeration: Copper refrigeration coils are attached to outside of inner liner. Unit
is refrigerated by self-contained, 115 volt, 60 hertz, single phase hermetically sealed
condensing unit with thermostatic control. Unit is wired with a 3-wire, grounded,
maximum 10’ (3m) 120 volt cord and plug.
Casters: Units are mounted on 5” (12.7cm) diameter swivel casters with non-marking
polyolen tires and plate brakes. Overall height of caster assembly is 6” (15.2cm).
Optional Accessories and Modications
SE-A 10" stainless steel fold-down tray slide
SE-D 8” polyethylene fold-down cutting board
SE-E 8” stainless steel fold down work shelf
SE-F Interlock device
SE-Q 115/15A outlet
SE-U 14"x29" stainless steel end drop shelf
SE-V Adjustable stainless steel leg
SE-ICE2
ShelleybasicTM
by Delfield

The Deleld Company,980 S. Isabella Road, Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.deleld.com
Deleld reserves the right to make changes in design or specications without prior notice. ©2004 The Deleld Company. All rights reserved. Printed in the U.S.A.
DSSEICE 02/04
SE-ICE/SES-ICE
Mobile Ice Cream Counters
MODEL NEMA SHIP FRT.
NUMBER CABINET CAP. L D H PLUG VOLTS AMPS HP WT CLASS
ICE CREAM COUNTERS - 0 DEGREES ONLY
SE-ICE1 84 CUPS 39" 29" 36" 5-15P 115/60/1 5.3 1/4 460 100
SE-ICE2 224 CUPS 50" 29" 36" 5-15P 115/60/1 5.3 1/4 505 100
Add S for 30" high models. (example SES-ICE1)
Capacity on 30" high models: SES-ICE1 = 42 and SES-ICE2 = 112
Mechanical Data - Standard Unit
PLAN VIEW
ELEVATION VIEW END VIEW
50.00”
(127cm)
29.00”
(73.66cm)
36.00”
(91.44cm)
