Delfin FXBK-202669SF User manual

Contents:
A) Single Support
3 pcs B) Double Support 1 pcs
E) Swivel Caster
2 pcs F) Locking Caster
2 pcs
D) Caster Insert (pre-inserted)
4 pcs
G) Signage Arm
1 pcs
H) Acrylic Sign Holder
1 pcs
J) Left Side
1 pcs K) Right Side 1 pcs
I) Wrench
1 pcs
C) Acorn Nut
10 pcs
FRONT
FRONT
A)
E)
F)
E)
F)
A)
A)
B)
G)
H)
J) K)
Santa Fe Mobile Merchandiser FXBK-202669SF
Assembly Instructions pg 1 of 2
B) Double Support
Front
J) Left Side
Top View
K) Right Side
Fitting for Sign Holder
Faces up and back
A) Single Support
Pan
Supports

1
2
3
A)
B)
J)
K)
A)
A)
F)
F)
E)
E)
E)
C)
C)
C)
C)
C)
C)
F)
G)
H)
Slide Double Support (B) into Left Side (J)
Fitting for Signage Arm (G) faces up and to the back
Pan supports and scrolls face in
Slide Single Supports (A) into Left Side (J)
Slide Right Side (K) on to all Supports (A & B)
4
5
6
7
8
Secure Supports to Sides with Acorn Nuts (C)
Insert Locking Casters (F) into front of Side supports
Insert Swivel Casters (E) into back of Side supports
Signage Arm (G) snaps in to tting
Acrylic Signage Holder (H) slides on Signage Arm (G)
Top View
Side View
Back View
tting for Signage Arm
tting for
Signage Arm
scrolls facing in
Front
Back
facing back
pan
supports
up
back
