Delfin Santa Fe Bakery Fixed Shelf Unit... User manual

Contents:
A) Single Support
3 pcs B) Double Support 2 pcs
E) Swivel Caster
2 pcs F) Locking Caster
2 pcs
D) Caster Insert (pre-inserted)
4 pcs
G) Signage Arm
1 pcs
H) Acrylic Sign Holder
1 pcs
I) Wrench
1 pcs
C) Acorn Nut
10 pcs
FRONT FRONT
G)
E)
E)
F)
F)
A)
A)
A)
B)
B)
L)
H)
J)
K)
Santa Fe Bakery Fixed Shelf Unit FXBK-291860SF
Assembly Instructions
J) Left Side
1 pcs K) Right Side 1 pcs
L) Shelves
5 pcs

1
2
3
© 2005 Delfín Design & Manufacturing Inc..
A)
B)
B)
J)
K)
A)
A)
F) E)
Slide Double Support (B) into Left Side (J)
Ftting for Signage Arm (G) faces up and to the back
Front pins for shelving face in
Slide Single Supports (A) into Left Side (J)
Slide Right Side (K) on to all Supports (A & B)
4
5
6
7
8
Secure Supports to Sides with Acorn Nuts (C)
Insert Locking Casters (F) into front of Side supports
Insert Swivel Casters (E) into back of Side supports
Signage Arm (G) snaps in to tting
Acrylic Signage Holder (H) slides on Signage Arm (G)
Shelves (L) hook on to back supports and rest on front supportsand pins
Front
Back
F)
E)
E)
C)
C)
C)
C)
C)
C)
F)
C)
C)
G) H)
front pins
face in
front pins
face in
tting for Signage Arm
up
back
Back View
Front View
Side View
