Sister Bay MCUS-B User manual

Hardware and Parts
(8)
Do not use
any hand drill
on this product
Assembly Instructions
ALLEN WRENCH
( included )
B
BACK PANEL
Figure 1
You will also need a phillips-head screwdriver
( not included )
D
(9)
A
I
G
F
1.25
(2)
C
1- Attach part ( E ) , Left panel , and part ( F ), Right panel , to part (D),
Back panel as shown in figure 1, see detail 1 using ( 4 ) of screw s ( A )
2 on each side, tighten screws using an allen wrench . For proper
positioning on ( E ) Left panel and ( F ) Right panel make sure that
shock bracket is located on the inside of the box see detail 2.
Figure 2
2 - Slide part (G) Base, into assembly from figure 1, as shown in Figure 2, see detail 3 and center inside assembly.
E
2.50
SHOCK ABSORBER
RIGHT PANEL
COVER
F
RIGHT PANEL BACK PANEL
D
A
( Detail 1 )
G
BASE
( Detail 3 )
slide & push
slide & push
H
( Shock Bracket )
(RECESS FOR HINGES) ( Detail 2 )
Item No: MCUS-B
Cushion Box
Assembly Instructions
Inside view
Shock Bracket
must be on the
inside
LEFT PANEL
E
FRONT PANEL
BASE
LEFT PANEL

Figure 3
( Detail 4 )
3 - Attach part ( H ) , Front panel , to assembly from
Figure 2, as shown in Figure 3, see detail 4 using
( 4 ) of screw s ( A ) , 2 on each side, tighten screws
using an allen wrench .
A
Figure 4
FRONT PANEL
H
I
COVER
4 a - Attach part ( I ) , Box Cover , to assembly from Figure 3, as shown in Figure 4, see detail 5, using ( 9 ) of screw ( B ) ,
3 on each Hinge, tighten screws using a phillips-head screwdriver.
4 b - Attach part ( C ) , Shock Absorber, to assembly from figure 4 see detail 6. Push the shock absorber adapter onto
the bracket located on the cover and inside the box (1 on each side), repeat for opposite side, see detail 6.
( Detail 5 )
* Note: When attaching the cover, It is recommended to be a ( 2 ) person operation. It is important to
support the cover until hinges and both shock absorbers are installed to avoid damage to hardware.
B
( Detail 6 )
Snap to joint
Shock Absorber
C
CARE AND MAINTENANCE
To clean your product, use mild soap and water. For heavy soil build-ups use any non-abrasive household cleaners
or ask your Sales Representative about Sister Bay Furniture Cleaner.
Please contact our Customer Service Department for assembly assistance, questions or replacement parts at 1-866-947-7632
or email [email protected]. Our Customer Service Department is available Monday - Friday from 8:30 a.m. to 4:30 p.m. EST
