Auralex Acoustics SonoFlat System SFS-112 Instruction sheet

Installation Guidelines
Thank you for Purchasing Auralex®Total Sound Control®Products!
SonoFlat SFS-112 System Components
Congratulations on purchasing a SonoFlat™ SFS-112™ System from Auralex®Acoustics.
You’re now on your way to creating a world class listening environment.
SonoFlat Systems offer a sophisticated look by utilizing a specialized flat-faced cut of
Auralex’s industry-leading Studiofoam. The SFS-112 system contains both SonoFlat Panels
and SonoColumns, which when used together, provide incredibly effective broadband
absorption in any room. Use the SFS-112 alone for treatment of small to medium-sized
rooms or in combination with other Auralex products for full control of larger spaces.
Tubetak Pro™
5
SonoFlat Panels™
24
SonoColumns™
4
SonoCollars™
4
SFS-112
SonoFlat Systems™
843-606 | Rev. 1 | 062606 EF

Recommended Additional Installation Materials
• Caulk-gun (for Tubetak Pro) • Tape measure
• Carpenters Level • Small ladder (depending on ceiling height)
• Pencil
SonoFlat SFS-112 General Information
SonoColumn Installation Guide
Optional Additional Installation Materials
• Foamtak Spray Adhesive* • T-Pins
* This system includes Tubetak Pro Adhesive, which is safe to use on all included products. You may wish to use Auralex’s Foamtak Spray Adhesive
for quicker drying times. Foamtak is available through all Auralex authorized dealers.
➋Apply Tubetak Pro to either the back or the
beveled edge of the SonoColumn, depending
on chosen placement.
➊Mark intended location of each SonoColumn.
SonoColumn Placement Options
➋➊ ➍➌
Flush in corner At 45° to corner Side-by-side in corner On wall w/ Collars
Or

SonoFlat Panel Installation Guide
➋Apply Tubetak Pro to the back of the SonoFlat
Panel, as pictured.
➌Carefully press SonoFlat Panel to the marked
location of the wall or ceiling. Maintain continuous
pressure. Depending on environmental and
surface conditions, it will take anywhere from
2-4 minutes to hold.
➊Mark intended location of each SonoFlat
Panel on the wall or ceiling.
SonoColumn Installation Guide Continued
➍Place SonoCollar around SonoColumn, if
desired. The inside section of each SonoCollar
can also be used to increase the height of the
SonoColumn by 6”.
➌Carefully press SonoColumn to the marked
location of the wall or ceiling. Maintain continuous
pressure. Depending on environmental and
surface conditions, it will take anywhere from
2-4 minutes to hold.
TIP
For a stronger hold, with the adhesive applied, press
SonoColumn firmly into place, immediately remove it and
press it firmly again into the same spot.
Or
TIP
You can use T-Pins to temporarily hold the panel in place
while the adhesive sets.

SonoFlat Installations
See the Auralex®Acoustics website, www.auralex.com, for more information
about these and other Total Sound Control®products.
These are general recommendations. Should you have any additional questions about the installation of your
SonoFlat™ System, feel free to contact an Auralex®Application Specialist
via email at [e-mail] or call 1-800-95-WEDGE.
SonoFlat System Installations
