Dell EMC PowerEdge MX740c Manual

Dell EMC PowerEdge MX740c
Installation and Service Manual
Regulatory Model: E04B
Regulatory Type: E04B001

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks
may be trademarks of their respective owners.
2018 - 12
Rev. A01

Contents
1 About this document...................................................................................................................................... 7
2 PowerEdge MX740c sled overview................................................................................................................ 8
Front view of the system.................................................................................................................................................. 9
Inside the system..............................................................................................................................................................10
Locating the Service Tag of your system...................................................................................................................... 10
System information label.................................................................................................................................................. 11
3 Initial system setup and conguration.......................................................................................................... 15
Setting up your system....................................................................................................................................................15
iDRAC conguration.........................................................................................................................................................15
Options to set up iDRAC IP address........................................................................................................................ 15
Log in to iDRAC...........................................................................................................................................................16
Options to install the operating system......................................................................................................................... 16
Methods to download rmware and drivers........................................................................................................... 16
Downloading drivers and rmware........................................................................................................................... 17
4 Pre-operating system management applications.......................................................................................... 18
Options to manage the pre-operating system applications.........................................................................................18
System Setup....................................................................................................................................................................18
Viewing System Setup............................................................................................................................................... 18
System Setup details..................................................................................................................................................19
System BIOS............................................................................................................................................................... 19
iDRAC Settings utility................................................................................................................................................ 39
Device Settings.......................................................................................................................................................... 39
Dell Lifecycle Controller...................................................................................................................................................39
Embedded System Management.............................................................................................................................39
Boot Manager...................................................................................................................................................................39
Viewing Boot Manager..............................................................................................................................................39
Boot Manager main menu........................................................................................................................................ 40
One-shot UEFI Boot menu.......................................................................................................................................40
System Utilities...........................................................................................................................................................40
PXE boot...........................................................................................................................................................................40
5 Installing and removing system components.................................................................................................41
Safety instructions............................................................................................................................................................41
Before working inside your sled...................................................................................................................................... 41
After working inside your sled.........................................................................................................................................41
Recommended tools........................................................................................................................................................42
PowerEdge MX740c sled................................................................................................................................................42
Removing the sled from enclosure.......................................................................................................................... 42
Installing the sled into enclosure...............................................................................................................................44
Contents 3

System cover....................................................................................................................................................................45
Removing the system cover.....................................................................................................................................45
Installing system cover.............................................................................................................................................. 46
Air shroud.......................................................................................................................................................................... 47
Removing air shroud.................................................................................................................................................. 47
Installing air shroud.................................................................................................................................................... 48
Drives.................................................................................................................................................................................49
Removing drive blank................................................................................................................................................ 49
Installing drive blank...................................................................................................................................................50
Removing drive carrier............................................................................................................................................... 51
Installing drive carrier.................................................................................................................................................52
Removing a drive from drive carrier........................................................................................................................ 53
Installing a drive into drive carrier............................................................................................................................ 54
Drive backplane................................................................................................................................................................55
Removing drive backplane........................................................................................................................................56
Installing drive backplane...........................................................................................................................................57
Cable routing.................................................................................................................................................................... 58
Drive cage.........................................................................................................................................................................62
Removing the drive cage.......................................................................................................................................... 62
Installing the drive cage.............................................................................................................................................63
Battery backup unit ........................................................................................................................................................ 64
Removing the battery backup unit.......................................................................................................................... 64
Installing the battery backup unit.............................................................................................................................65
Removing the BBU from the BBU cage................................................................................................................. 66
Installing the BBU into the BBU cage......................................................................................................................67
Control panel.................................................................................................................................................................... 68
Removing the control panel......................................................................................................................................68
Installing the control panel .......................................................................................................................................69
System memory............................................................................................................................................................... 70
General memory module installation guidelines......................................................................................................72
NVDIMM-N memory module installation guidelines ............................................................................................. 73
Mode-specic guidelines...........................................................................................................................................74
Removing a memory module.................................................................................................................................... 77
Installing a memory module.......................................................................................................................................78
Processors and heat sinks.............................................................................................................................................. 79
Removing the processor and heat sink module..................................................................................................... 79
Removing the processor from the processor and heat sink module...................................................................80
Installing the processor into a processor and heat sink module...........................................................................82
Installing a processor and heat sink module........................................................................................................... 84
iDRAC card....................................................................................................................................................................... 85
Removing the iDRAC card........................................................................................................................................85
Installing the iDRAC card...........................................................................................................................................87
PERC card........................................................................................................................................................................ 88
Removing the PERC card.........................................................................................................................................88
Installing the PERC card........................................................................................................................................... 89
4Contents

Removing the Jumbo PERC card............................................................................................................................90
Installing the Jumbo PERC card............................................................................................................................... 91
Optional Internal dual SD module...................................................................................................................................92
Removing the IDSDM card....................................................................................................................................... 92
Installing the IDSDM card......................................................................................................................................... 93
Removing a MicroSD card........................................................................................................................................ 94
Installing a MicroSD card.......................................................................................................................................... 95
M.2 BOSS module........................................................................................................................................................... 96
Removing the M.2 BOSS module............................................................................................................................96
Installing the M.2 BOSS module...............................................................................................................................97
Removing the M.2 BOSS card.................................................................................................................................98
Installing the M.2 BOSS card................................................................................................................................... 99
Mezzanine card.............................................................................................................................................................. 100
Removing the Mezzanine card...............................................................................................................................100
Installing the Mezzanine card.................................................................................................................................. 101
Removing the mini Mezzanine card.......................................................................................................................102
Installing the mini Mezzanine card......................................................................................................................... 103
Removing the mini Mezzanine card blank.............................................................................................................104
Installing the mini Mezzanine card blank............................................................................................................... 105
Optional internal USB memory key.............................................................................................................................. 106
Replacing the optional internal USB memory key................................................................................................ 106
System battery................................................................................................................................................................107
Replacing the system battery - Option A.............................................................................................................. 107
Replacing the system battery - Option B..............................................................................................................108
System board...................................................................................................................................................................110
Removing the system board.................................................................................................................................... 110
Installing the system board.......................................................................................................................................112
Trusted Platform Module............................................................................................................................................... 115
Upgrading the TPM.................................................................................................................................................. 115
Initializing TPM for BitLocker users........................................................................................................................ 116
Initializing the TPM 1.2 for TXT users.....................................................................................................................116
Initializing the TPM 2.0 for TXT users....................................................................................................................116
6 Jumpers and connectors.............................................................................................................................118
System board jumpers and connectors........................................................................................................................118
System board jumper settings.......................................................................................................................................119
Disabling a forgotten password.....................................................................................................................................120
7 Technical specications...............................................................................................................................121
System dimensions..........................................................................................................................................................121
System weight................................................................................................................................................................ 122
Processor specications................................................................................................................................................122
Processor wattage and heat sink dimensions.......................................................................................................122
Intel Quick Assist Technology..................................................................................................................................122
Supported operating systems....................................................................................................................................... 122
System battery specications.......................................................................................................................................122
Contents 5

Memory specications...................................................................................................................................................123
Hard drives...................................................................................................................................................................... 123
Mezzanine and Mini Mezzanine slots specications..................................................................................................123
Storage controller specications.................................................................................................................................. 123
Ports and connectors specications............................................................................................................................123
USB ports.................................................................................................................................................................. 124
Internal Dual SD Module ......................................................................................................................................... 124
Micro SD vFlash connector.....................................................................................................................................124
Video specications .......................................................................................................................................................124
Environmental specications.........................................................................................................................................124
Particulate and gaseous contamination specications ....................................................................................... 125
Standard operating temperature............................................................................................................................ 126
Expanded operating temperature........................................................................................................................... 127
Thermal...................................................................................................................................................................... 127
8 System diagnostics and indicator codes .................................................................................................... 129
Power button LED..........................................................................................................................................................129
Drive indicator codes..................................................................................................................................................... 130
System health and system ID indicator codes.............................................................................................................131
Using system diagnostics............................................................................................................................................... 131
Dell Embedded System Diagnostics........................................................................................................................131
9 Getting help............................................................................................................................................... 133
Contacting Dell EMC......................................................................................................................................................133
Documentation feedback.............................................................................................................................................. 133
Accessing system information by using QRL..............................................................................................................133
Quick Resource Locator for PowerEdge MX740c system..................................................................................134
Receiving automated support with SupportAssist ....................................................................................................134
Recycling or End-of-Life service information..............................................................................................................134
10 Documentation resources......................................................................................................................... 135
6Contents

About this document
This document provides an overview about the PowerEdge MX740c system, information about installing and replacing components,
technical specications, diagnostic tools, and guidelines to be followed while installing certain components.
The PowerEdge MX740c is compatible with the PowerEdge MX7000 enclosure. For more information about the enclosure, refer to the
Installation and Service Manual for the PowerEdge MX7000 at Dell.com/poweredgemanuals.
1
About this document 7

PowerEdge MX740c sled overview
The Dell EMCPowerEdge MX740c is a single width compute sled and supports:
• Up to two Intel Xeon Scalable processors.
• Up to 24 DIMM slots.
• Up to six 2.5-inch SAS, SATA (HDD/SSD), or NVMe drives.
NOTE: All instances of SAS, NVMe, SATA HDDs, and SSDs are referred to as drives in this document, unless specied otherwise.
Topics:
• Front view of the system
• Inside the system
• Locating the Service Tag of your system
• System information label
2
8 PowerEdge MX740c sled overview

Front view of the system
Figure 1. Front view of the 6 drive conguration
1 USB 3.0 port
2 iDRAC direct port
3 Drives
4 Release handle
5 Release handle button
6 Information tag
7 System health and System ID indicator
8 Power button
For more information about the ports, see Technical Specications.
PowerEdge MX740c sled overview 9

Inside the system
NOTE: Components that are hot swappable have orange touch points and the components that are not hot swappable have blue
touch points.
Figure 2. Inside the system
1 Backplane
2 Backplane cable
3 Processor 1 (heat sink)
4 Processor 2 (heat sink)
5 Mezzanine card A1
6 Power connector
7 Mezzanine card B1
8 Mini Mezzanine connector
9 iDRAC card
10 BOSS connector
11 PERC connector
Locating the Service Tag of your system
The System Information Tab contains the system's unique Express Service Code and Service Tag. This information is used by Dell EMC to
identify system conguration, warranty terms, and to route support calls to the appropriate personnel. A Quick Resource Locator (QRL)
label on the System Information Tab links to a web page that shows the exact factory conguration and specic warranty purchased.
10 PowerEdge MX740c sled overview

Figure 3. Locating Service Tag of your system
1 Information tag 2 Service tag
System information label
Figure 4. Mechanical overview
PowerEdge MX740c sled overview 11

Figure 5. Memory information
12 PowerEdge MX740c sled overview

Figure 6. System board
Figure 7. Removal of IDSDM and Internal USB memory key(optional)
PowerEdge MX740c sled overview 13

Figure 8. Removal of BBU module and drive cage
Figure 9. Removal of backplane and Mezzanine card
Figure 10. Removal of PERC cards and Mini Mezzanine card
Figure 11. Removal of Jumbo PERC card
14 PowerEdge MX740c sled overview

Initial system setup and conguration
Setting up your system
Complete the following steps to set up your system:
1 Unpack the system.
2 Remove the I/O connector cover from the system connectors.
CAUTION: While installing the system, ensure that it is properly aligned with the slot on the enclosure to prevent
damage to the system connectors.
3 Install the system in the enclosure.
4 Turn on the enclosure.
NOTE: Wait for the enclosure to initialize before you press the power button.
5 Press the power button on the system.
Alternatively, you can also turn on the system by using iDRAC:
• For more information, see the Log in to iDRAC
• Open OpenManage Enterprise modular(OME modular), after the iDRAC is congured on the OME. For more information, see the
OME-modular User’s Guide at Dell.com/manuals.
iDRAC conguration
The Integrated Dell Remote Access Controller (iDRAC) is designed to make system administrators more productive and improve the overall
availability of Dell systems. iDRAC alerts administrators about system issues and enables them to perform remote system management.
This reduces the need for physical access to the system.
Options to set up iDRAC IP address
You must congure the initial network settings based on your network infrastructure to enable the communication to and from iDRAC.
You can set up the IP address by using one of the following interfaces:
Interfaces Document/Section
iDRAC Settings
utility
See Dell Integrated Dell Remote Access Controller User's Guide at Dell.com/poweredgemanuals
Dell Deployment
Toolkit
See Dell Deployment Toolkit User’s Guide at Dell.com/openmanagemanuals > OpenManage Deployment Toolkit
Dell Lifecycle
Controller
See Dell Lifecycle Controller User’s Guide at Dell.com/poweredgemanuals
OME Modular See Dell OpenManagement Enterprise Modular User’s Guide at Dell.com/openmanagemanuals
iDRAC Direct See Dell Integrated Dell Remote Access Controller User's Guide at Dell.com/poweredgemanuals
3
Initial system setup and conguration 15

Log in to iDRAC
You can log in to iDRAC as:
• iDRAC user
• Microsoft Active Directory user
• Lightweight Directory Access Protocol (LDAP) user
If you have opted for secure default access to iDRAC, you must use the iDRAC secure default password available on the system
Information tag. If you have not opted for secure default access to iDRAC, then use the default user name and password –root and
calvin. You can also log in by using your Single Sign-On or Smart Card.
NOTE: You must have the iDRAC credentials to log in to iDRAC.
NOTE: Ensure that you change the default user name and password after setting up the iDRAC IP address.
NOTE: The Intel Quick Assist Technology (QAT) on the Dell EMC PowerEdge MX740c is supported with chipset integration and
is enabled through an optional license. The license les are enabled on the sleds through iDRAC.
For more information about drivers, documentation, and white papers on the Intel QAT, see https://01.org/intel-quickassist-technology.
For more information about logging in to the iDRAC and iDRAC licenses, see the latest Integrated Dell Remote Access Controller User's
Guide at Dell.com/poweredgemanuals.
You can also access iDRAC by using RACADM. For more information, see the RACADM Command Line Interface Reference Guide at
Dell.com/poweredgemanuals.
Options to install the operating system
If the system is shipped without an operating system, install the supported operating system by using one of the following resources:
Table 1. Resources to install the operating system
Resources Location
iDRAC Dell.com/idracmanuals
Lifecycle Controller Dell.com/idracmanuals
OpenManage Deployment Toolkit Dell.com/openmanagemanuals > OpenManage Deployment Toolkit
Dell certied VMware ESXi Dell.com/virtualizationsolutions
Installation and How-to videos for supported operating systems on
PowerEdge systems
Supported Operating Systems for Dell PowerEdge Systems
NOTE: Virtual Media is optional for integrated Dell Remote Access Controllers (iDRAC) with an Enterprise license (iDRAC 7, 8
and 9) or module (iDRAC 6).It allows the usage of software image les (ISO-les), which can be used for installing operating
systems or updating servers.
Methods to download rmware and drivers
You can download the rmware and drivers by using any of the following methods:
16 Initial system setup and conguration

Table 2. Firmware and drivers
Methods Location
From the Dell EMC support site Dell.com/support/home
Using Dell Remote Access Controller Lifecycle Controller (iDRAC
with LC)
Dell.com/idracmanuals
Using Dell Repository Manager (DRM) Dell.com/openmanagemanuals > Repository Manager
Using Dell OpenManage Essentials (OME) Dell.com/openmanagemanuals > OpenManage Essentials
Using Dell Server Update Utility (SUU) Dell.com/openmanagemanuals > Server Update Utility
Using Dell OpenManage Deployment Toolkit (DTK) Dell.com/openmanagemanuals > OpenManage Deployment Toolkit
Using iDRAC virtual media Dell.com/idracmanuals
Downloading drivers and rmware
Dell EMC recommends that you download and install the latest BIOS, drivers, and systems management rmware on your system.
Prerequisite
Ensure that you clear the web browser cache before downloading the drivers and rmware.
Steps
1 Go to Dell.com/support/home.
2 In the Drivers & Downloads section, type the Service Tag of your system in the Enter a Service Tag or product ID box, and then click
Submit.
NOTE: If you do not have the Service Tag, select Detect Product to allow the system to automatically detect the
Service Tag, or click View products, and navigate to your product.
3 Click Drivers & Downloads.
The drivers that are applicable to your system are displayed.
4 Download the drivers to a USB drive, CD, or DVD.
Initial system setup and conguration 17

Pre-operating system management applications
You can manage basic settings and features of a system without booting to the operating system by using the system rmware.
Topics:
• Options to manage the pre-operating system applications
• System Setup
• Dell Lifecycle Controller
• Boot Manager
• PXE boot
Options to manage the pre-operating system
applications
Your system has the following options to manage the pre-operating system applications:
• System Setup
• Dell Lifecycle Controller
• Boot Manager
• Preboot Execution Environment (PXE)
System Setup
By using the System Setup screen, you can congure the BIOS settings, iDRAC settings, and Device settings of your system.
NOTE: Help text for the selected eld is displayed in the graphical browser by default. To view the help text in the text browser,
press F1.
You can access system setup by using two methods:
• Standard graphical browser—The browser is enabled by default.
• Text browser—The browser is enabled by using Console Redirection.
Viewing System Setup
To view the System Setup screen, perform the following steps:
1 Turn on, or restart your system.
2 Press F2 immediately after you see the following message:
F2 = System Setup
NOTE: If your operating system begins to load before you press F2, wait for the system to nish booting, and then
restart your system and try again.
4
18 Pre-operating system management applications

System Setup details
The System Setup Main Menu screen details are explained as follows:
Option Description
System BIOS Enables you to congure BIOS settings.
iDRAC Settings Enables you to congure the iDRAC settings.
The iDRAC settings utility is an interface to set up and congure the iDRAC parameters by using UEFI (Unied
Extensible Firmware Interface). You can enable or disable various iDRAC parameters by using the iDRAC settings
utility. For more information about this utility, see Integrated Dell Remote Access Controller User’s Guide at
Dell.com/idracmanuals.
Device Settings Enables you to congure device settings such as network cards or storage controllers.
System BIOS
You can use the System BIOS screen to edit specic functions such as boot order, system password, setup password, set the SATA and
PCIe NVMe RAID mode, and enable or disable USB ports.
Viewing System BIOS
To view the System Setup screen, perform the following steps:
1 Turn on, or restart your system.
2 Press F2 immediately after you see the following message:
F2 = System Setup
NOTE: If your operating system begins to load before you press F2, wait for the system to nish booting, and then
restart your system and try again.
3 On the System Setup Main Menu screen, click System BIOS.
System BIOS Settings details
The System BIOS Settings screen details are explained as follows:
Option Description
System Information Species information about the system such as the system model name, BIOS version, and Service Tag.
Memory Settings Species information and options related to the installed memory.
Processor Settings Species information and options related to the processor such as speed and cache size.
SATA Settings Species options to enable or disable the integrated SATA controller and ports.
NVMe Settings Species options to change the NVMe settings. If the system contains the NVMe drives that you want to
congure in a RAID array, you must set both this eld and the Embedded SATA eld on the SATA Settings menu
to RAID mode. You might also need to change the Boot Mode setting to UEFI. Otherwise, you should set this eld
to Non-RAID mode.
Boot Settings Species options to specify the Boot mode (BIOS or UEFI). Enables you to modify UEFI and BIOS boot settings.
Pre-operating system management applications 19

Option Description
Network Settings Species options to manage the UEFI network settings and boot protocols.
Legacy network settings are managed from the Device Settings menu.
Integrated Devices Species options to manage integrated device controllers and ports, species related features and options.
Serial
Communication
Species options to manage the serial ports, its related features and options.
System Prole
Settings
Species options to change the processor power management settings, memory frequency.
System Security Species options to congure the system security settings, such as system password, setup password, Trusted
Platform Module (TPM) security, and UEFI secure boot. It also manages the power button on the system.
Redundant OS
Control
Sets the redundant OS info for redundant OS control.
Miscellaneous
Settings
Species options to change the system date and time.
System Information
You can use the System Information screen to view system properties such as Service Tag, system model name, and the BIOS version.
Viewing System Information
To view the System Information screen, perform the following steps:
1 Turn on, or restart your system.
2 Press F2 immediately after you see the following message:
F2 = System Setup
NOTE: If your operating system begins to load before you press F2, wait for the system to nish booting, and then
restart your system and try again.
3 On the System Setup Main Menu screen, click System BIOS.
4 On the System BIOS screen, click System Information.
System Information details
The System Information screen details are explained as follows:
Option Description
System Model
Name
Species the system model name.
System BIOS
Version
Species the BIOS version installed on the system.
System
Management
Engine Version
Species the current version of the Management Engine rmware.
System Service Tag Species the system Service Tag.
System
Manufacturer
Indicates the name of the Original Equipment Manufacturer (OEM).
20 Pre-operating system management applications
