Dell EMC DSS8440 Manual

Dell EMC DSS8440
Installation and Service Manual
Regulatory Model: B21S Series
Regulatory Type: B21S001

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks
may be trademarks of their respective owners.
2019 - 04
Rev. A00

Contents
1 About this document...................................................................................................................................... 7
2 Dell EMC DSS8440 system overview.............................................................................................................8
DSS8440 system feature overview................................................................................................................................. 9
Front view of the system............................................................................................................................................ 9
Rear view of the system............................................................................................................................................10
3 Technical specications................................................................................................................................ 11
Chassis dimensions...........................................................................................................................................................12
Chassis weight.................................................................................................................................................................. 12
Processor specications.................................................................................................................................................. 12
PSU specications............................................................................................................................................................13
Cooling fans specications.............................................................................................................................................. 14
System battery specications......................................................................................................................................... 14
Expansion card riser specications.................................................................................................................................14
Memory specications..................................................................................................................................................... 14
Drive specications...........................................................................................................................................................14
Ports and connectors specications.............................................................................................................................. 14
USB ports specications............................................................................................................................................14
COM port specications............................................................................................................................................14
VGA port specications............................................................................................................................................. 15
LOM port specications............................................................................................................................................ 15
Environmental specications...........................................................................................................................................15
System diagnostics and indicator codes........................................................................................................................15
NIC indicator codes.................................................................................................................................................... 16
Power supply unit indicator codes............................................................................................................................ 17
4 Initial system setup and conguration.......................................................................................................... 19
Setting up your system.................................................................................................................................................... 19
iDRAC conguration.........................................................................................................................................................19
Options to set up iDRAC IP address...............................................................................................................................19
Log in to iDRAC.................................................................................................................................................................19
5 Pre-operating system management applications..........................................................................................20
Options to manage the pre-operating system applications........................................................................................20
System Setup................................................................................................................................................................... 20
Viewing System Setup.............................................................................................................................................. 20
System Setup details.................................................................................................................................................20
System BIOS............................................................................................................................................................... 21
iDRAC Settings utility................................................................................................................................................ 40
Device Settings.......................................................................................................................................................... 40
Dell Lifecycle Controller...................................................................................................................................................40
Contents 3

Embedded system management............................................................................................................................. 40
Boot Manager.................................................................................................................................................................. 40
Viewing Boot Manager..............................................................................................................................................40
Boot Manager main menu......................................................................................................................................... 41
One-shot UEFI boot menu........................................................................................................................................ 41
System Utilities........................................................................................................................................................... 41
PXE boot............................................................................................................................................................................41
6 Installing and removing system components................................................................................................ 42
Safety instructions...........................................................................................................................................................42
Before working inside your system................................................................................................................................ 42
After working inside your system...................................................................................................................................42
Recommended tools........................................................................................................................................................42
System cover....................................................................................................................................................................43
Removing the system cover..................................................................................................................................... 43
Installing the system cover....................................................................................................................................... 43
Front bezel........................................................................................................................................................................ 44
Removing the front bezel..........................................................................................................................................44
Installing the front bezel............................................................................................................................................45
Air shroud..........................................................................................................................................................................46
Removing the air shroud........................................................................................................................................... 46
Installing the air shroud..............................................................................................................................................47
Drives.................................................................................................................................................................................48
Removing a drive carrier and drive.......................................................................................................................... 48
Installing the drive and drive carrier.........................................................................................................................49
Drive backplane................................................................................................................................................................50
Removing the drive backplane.................................................................................................................................50
Installing the drive backplane.................................................................................................................................... 51
Power supply unit............................................................................................................................................................ 52
Removing a power supply unit................................................................................................................................. 52
Installing a power supply unit....................................................................................................................................53
Expansion cards and expansion card risers ................................................................................................................. 53
Removing a GPU........................................................................................................................................................53
Installing a GPU..........................................................................................................................................................54
Removing a GPU support bracket...........................................................................................................................55
Installing a GPU support bracket............................................................................................................................. 56
Removing the PCIe switch board.............................................................................................................................57
Installing the PCIe switch board...............................................................................................................................59
Removing a GPU power interposer board...............................................................................................................61
Installing a GPU power interposer board................................................................................................................ 62
Removing a buttery module and riser 3 board..................................................................................................... 62
Installing the riser 3 board and buttery module....................................................................................................64
Processor and heat sink..................................................................................................................................................65
Removing the processor and heat sink...................................................................................................................65
Installing the processor............................................................................................................................................. 66
System memory............................................................................................................................................................... 67
4Contents

Removing a memory module.................................................................................................................................... 67
Installing a memory module...................................................................................................................................... 68
Riser 2 module..................................................................................................................................................................69
Removing the riser 2 module....................................................................................................................................69
Installing the riser 2 module...................................................................................................................................... 70
Riser 1 module...................................................................................................................................................................72
Removing the riser 1 module.....................................................................................................................................72
Installing the riser 1 module.......................................................................................................................................73
Network daughter card................................................................................................................................................... 74
Removing the network daughter card.....................................................................................................................74
Installing the network daughter card.......................................................................................................................75
System board tray module.............................................................................................................................................. 76
Removing the system board tray module................................................................................................................76
Installing the system board tray module..................................................................................................................78
System board and power interposer board...................................................................................................................79
Removing the system board and power interposer board.................................................................................... 79
Installing the system board and power interposer board...................................................................................... 80
Backup battery................................................................................................................................................................. 82
Replacing the backup battery...................................................................................................................................82
Power distribution board.................................................................................................................................................83
Removing the power distribution board..................................................................................................................83
Installing the power distribution board ................................................................................................................... 84
PSB power interposer board.......................................................................................................................................... 85
Removing the PSB power interposer board...........................................................................................................85
Installing the PSB power interposer board............................................................................................................. 86
Front control module ...................................................................................................................................................... 87
Removing the front control module......................................................................................................................... 87
Installing the right control panel............................................................................................................................... 87
Fan louvers........................................................................................................................................................................88
Removing the fan louvers......................................................................................................................................... 88
Installing the fan louvers........................................................................................................................................... 89
Cooling fans.......................................................................................................................................................................91
Replacing a cooling fan.............................................................................................................................................. 91
Fan cage............................................................................................................................................................................92
Removing the fan cage............................................................................................................................................. 92
Installing the fan cage................................................................................................................................................92
Handle............................................................................................................................................................................... 93
Removing the handle.................................................................................................................................................93
Installing the handle................................................................................................................................................... 94
Slide rail installation..........................................................................................................................................................95
7 Cable Routing.............................................................................................................................................100
Dell EMC DSS8440 cable instruction........................................................................................................................... 101
3M cable Installation-Cong A left...............................................................................................................................103
3M cable Installation-Cong A right.............................................................................................................................104
Fan cable assembly to fan bracket ..............................................................................................................................105
Contents 5

Fan cable MB-PDB assembly to MB ........................................................................................................................... 110
Fan cable MB-PDB assembly to PDB .......................................................................................................................... 111
Front control cable assembly control board to MB..................................................................................................... 112
GPU power cable assembly GPU card to PSB............................................................................................................113
IDC cable MB-PDB assembly to PDB...........................................................................................................................114
IDC cable MB-PDB assembly to MB............................................................................................................................ 115
IDC cable PDB-PIB assembly to PIB.............................................................................................................................116
IDC cable PIB-PDB assembly to PDB...........................................................................................................................117
IDC cable Riser1-PDB assembly to PDB.......................................................................................................................118
IDC cable Riser1-PDB assembly to riser board1...........................................................................................................119
IDC cable PIB-PDB assembly to PDB..........................................................................................................................120
IDC cable Riser 2- PDB assembly to riser board 2...................................................................................................... 121
Mini SAS HD cable assembly PERC-HDBP.................................................................................................................122
Mini SAS HD cable assembly HDBP-MB.....................................................................................................................123
Power cable BP-PDB assembly to BP......................................................................................................................... 123
Power cable BP-PDB assembly to PDB.......................................................................................................................124
Power cable assembly to PDB......................................................................................................................................125
Power cable assembly to PIB........................................................................................................................................133
Power cable1 assembly to Riser1.................................................................................................................................. 133
Power cable2 Riser-PDB assembly to PDB.................................................................................................................135
Power cable2 Riser-PDB assembly to Riser................................................................................................................136
8 Jumpers and connectors.............................................................................................................................137
System Board Connectors............................................................................................................................................ 138
System board jumpers settings.................................................................................................................................... 140
Disabling forgotten password........................................................................................................................................140
9 Getting help................................................................................................................................................ 141
Contacting Dell EMC...................................................................................................................................................... 141
Documentation feedback............................................................................................................................................... 141
6Contents

About this document
This document provides an overview about the system, information on installing and replacing components, technical specications,
diagnostic tools, and guidelines to be followed while installing certain components.
1
About this document 7

Dell EMC DSS8440 system overview
This chapter briey describes the main features of the Dell EMC DSS8440 system. The chapter includes gures of the products, a list of
the server system features, and diagrams showing the location of the components and connections on the server systems.
Figure 1. Dell EMC DSS8440 front View
Figure 2. Dell EMC DSS8440 rear view
2
8 Dell EMC DSS8440 system overview

DSS8440 system feature overview
The DSS8440 is a 4U PCIe Accelerator Server by PCIe Switch Board(PSB) with PCIe downstream up to 10x general-purpose double width
graphics processing unit (GPGPU), 8x NVMe, 4x (center) + 4x (right, optional) rear-PCIe slots and upstream the 14G leveraged
PowerEdge C4140.
The system contains conguration-A with 8x/10x double width GPGPU, 10x 2.5” hot-swap storage-drives (no expander), single or dual
Skylake processors, 845.4mm maximum length, PCIe slots (through PCIe Switch Board(PSB) and C4140 risers), 24x DIMM slots, quad hot-
plug power-supply units, rNDC, and the ability to use an HBA for the data drives.
Figure 3. DSS8440 system feature overview
Front view of the system
Dell EMC DSS8440 system overview 9

NOTE:
The handles in front control panel are not intended to lift the system.
Control panel
Figure 4. Right control panel view
1 Power-on indicator/power button 2 System-health indicator
3 System identication button
Rear view of the system
Figure 5. Rear view of the system
1Slots-4, 5, 14, 15 2 Slots-[19..16]
3 Drive-[0..9] 4 Slot-1
5 Slot-3 6 ID
7 Power-Jack 8 RJ45
9 DB9 10 DB15
11 2x USB-3.0 12 2x RJ45 + 2xSFP+
13 Power Supply 1 to 4
10 Dell EMC DSS8440 system overview

Technical specications
The technical and environmental specications of your system are outlined in this section.
Topics:
• Chassis dimensions
• Chassis weight
• Processor specications
• PSU specications
• Cooling fans specications
• System battery specications
• Expansion card riser specications
• Memory specications
• Drive specications
• Ports and connectors specications
• Environmental specications
• System diagnostics and indicator codes
3
Technical specications 11

Chassis dimensions
Figure 6. Chassis dimensions
Table 1. Dell EMC DSS8440 chassis dimensions
Xa Xb Y Za Zb Zc
482.0 mm
(18.97 inches)
440.0 mm
(17.32 inches)
172 mm
(6.77 inches)
With bezel: 870 mm
(34.25 inches)
830 mm
(32.67 inches)
845 mm
(33.26 inches)
Chassis weight
Table 2. Chassis weight
System Maximum weight (with all
drives)
DSS8440 (2 CPU/ 10 GPU/ 10 HDD/ 1 H730P+/ 1 CX5) 46.3 Kg (102.07 lb)
Processor specications
TheDell EMC DSS8440 system supports two Intel Xeon Scalable processors with up to 20 cores per processor.
12 Technical specications

NOTE: Ensure that both the processors are populated and both are of the same type or model.
PSU specications
The system supports up to four redundant AC power supply units (PSUs).
Table 3. PSU specications
Functions 2400W Power supply
Input
Input voltage range AC input : 200Vac~240Vac @ High line : 2400W
Frequency 50/60 Hz
Eciency VIN=230Vac
• 89% @ 10% load
• 93% @ 20%load
• 94% @ 50% load
• 100% load @ 91.5% load
Power Factor PF at 230Vac/50,60 Hz
• > 0.88 @ 10% load
• > 0.94 @ 20% load
• > 0.98 @ 50% load
• > 0.99 @ 100% load
iTHD 230Vac/60 Hz
• 25% @ 0% load
• 25% @10% load
• 10% @ 20% load
• 5% @50% load
• 4% @100% load
Hold-up Time 13.5ms @ 100% load
Conducted EMI Class A
Radiated EMI Class A
Output
Main DC Output
Voltage Regulation 12.2V +/-5%
Output current 196.72A @ high line
Standby Output
Voltage Regulation 12V +/-5%
Output current 3.5A
Technical specications 13

Cooling fans specications
The Dell EMC DSS8440 system supports up to twelve 60 mm x 60 mm (square) cooling fans.
System battery specications
The Dell EMC DSS8440 system supports CR 2032 3.0-V lithium coin cell system battery.
Expansion card riser specications
The Dell EMC DSS8440 system supports up to 10 x Dual Width Full Length PCIe slots and rear I/O 8 x Full Height Half Length PCIe slots.
Memory specications
Table 4. Memory specications
DIMM type DIMM rank DIMM capacity Dual processors
Minimum RAM Maximum RAM
RDIMM Dual rank 32 GB 64 GB 768 GB
RDIMM Dual rank 16 GB 32 GB 384 GB
RDIMM Single rank 8 GB 16 GB 192 GB
NOTE: Ensure that all the memory slots are populated either with DIMMs or DIMM blanks.
NOTE: It is recommended to have all DIMMs of the same type.
Drive specications
The Dell EMC DSS8440 system supports 10 x 2.5 inch hard drives with following congurations:
• Drive 0–1: Support SATA/SAS only
• Drive 2–7: Support SATA/SAS/NVMe only
• Drive 8–9: Support NVMe only
Ports and connectors specications
USB ports specications
Dell EMC DSS8440 system supports two USB 3.0 ports available through back panel and one internal USB 3.0 port on system board.
COM port specications
Dell EMC DSS8440 system supports one 9 pin 16550 compliant com ports available through the back panel.
14 Technical specications

VGA port specications
Dell EMC DSS8440 system supports one 15 pin VGA ports available through the back panel.
LOM port specications
Dell EMC DSS8440 system supports two 10GbE SFP+ ports and two 1GbE RJ-45 ports available through the back panel.
Environmental specications
The following details dene the system level operating and non-operating environmental limits.
Table 5. Maximum Temperature:
Maximum Temperature:
Operation:
Fan normal 10°C–35°C. (Maximum temperature is reduced by 1°C/300m (1°F/547ft) above 950 m (3117 ft)).
One rotor fan failure 10°C -35°C. (Maximum temperature is reduced by 1°C/300m (1°F/547ft) above 950 m (3117 ft)).
Non-Operation -40°C to 65°C
Table 6. Humidity
Humidity
Operation 10% to 80% RH, non-condensing
Non-Operation 5% to 95% RH, non-condensing
Table 7. Maximum Altitude
Maximum Altitude
Operation 10,000 ft
Non-Operation 30,000 ft
System diagnostics and indicator codes
Table 8. System diagnostics and indicator codes
Icon Indicator, button,
or connector
Description
Power-on
indicator, power
button
The power-on indicator lights when the system powered on. The power button controls
the power supply output to the system.
Technical specications 15

Icon Indicator, button,
or connector
Description
NOTE: On APCI-compliant operating system, turning o the system using
power button causes the system to perform a graceful shutdown before power
to the system is turned o.
Health indicator Indicates the health of the system.
• If the system is powered on and in good health, the indicator lights solid blue. No
corrective action is required.
• The indicator blinks amber if the system is on or in standby, and if any error exists (For
example, a failed fan). See the System Event Log or system messages for the specic
issue. For information about the event and error messages generated by the system
rmware and agents that monitor system components, see the Error Code Lookup
page at qrl.dell.comInvalid memory congurations can cause a blank screen or no
video output. See the Getting help section.
System
identication
button
The identication button on the front and back panels can be used to locate a particular
system within a rack. When one of these buttons is pressed, the corresponding system
identication button on the back ashes until one of the buttons is pressed again.
Press the system identication button to turn the system ID on or o.
If the system stops responding during POST, press and hold the system ID button for
more than ve seconds to enter BIOS progress mode.
To reset iDRAC (if not disabled in F2 iDRAC setup), press and hold the button for more
than 15 seconds.
NIC indicator codes
Each NIC on the back panel has an indicator that provides information about the network activity and link status. The activity LED indicates
whether the NIC is connected or not. The link LED indicates the speed of the connected network.
Figure 7. NIC indicators
1link indicator 2 activity indicator
16 Technical specications

Table 9. NIC indicators
Convention Status Condition
A Link and activity indicators are o. The NIC is not connected to the network.
B Link indicator is green. The NIC is connected to a valid network at its maximum
port speed (1 Gbps or 10 Gbps).
C Link indicator is amber. The NIC is connected to a valid network at less than its
maximum port speed.
D Activity indicator is ashing green. Network data is being sent or received.
Power supply unit indicator codes
AC power supply units (PSUs) have an illuminated translucent handle that serves as an indicator. The indicator shows whether power is
present or a power fault has occurred.
Figure 8. AC PSU status indicator
1AC PSU status indicator/handle
Table 10. AC PSU status indicators
Convention Power indicator
pattern
Condition
A Green A valid power source is connected to the PSU and the PSU is operational.
B Flashing green When the rmware of the PSU is being updated, the PSU handle ashes green.
CAUTION: Do not disconnect the power cable or unplug the PSU when updating
rmware. if rmware update is interrupted, the PSUs do not function.
Technical specications 17

Convention Power indicator
pattern
Condition
C Flashing green and
turns o.
When hot-adding a PSU, the PSU handle ashes green ve times at 4 Hz rate and turns
o. This indicates a PSU mismatch with respect to eciency, feature set, health status,
and supported voltage.
CAUTION: If four PSU are installed, the four PSUs must have the same type of
label; for example, Extended Power Performance (EPP) label. Mixing PSU from
previous generations of PowerEdge servers is not supported, even if the PSU
has same power rating. This results in a PSU mismatch condition or failure to
turn the system on.
CAUTION: When correcting a PSU mismatch, replace only PSU with the blinking
indicator. Swapping the PSU to make matched pair can result in an error
condition and unexpected system shutdown. To change from a high output
conguration to a low output conguration or vice versa, you must turn o the
system
CAUTION: The 120 V AC PSU is not recommended for this system. Operating at
120 V AC results in the 2400W PSU de-rating to only 1400W, which can aect
power redundancy policy and possibly system throttling.
CAUTION: If four PSUs are used, they must be of the same type and have the
same maximum output power.
D Flashing amber Indicates a problem with the PSU.
E Not illuminated Power is not connected to the PSU.
18 Technical specications

Initial system setup and conguration
Setting up your system
Complete the following steps to set up your system:
1 Unpack the system.
2 Install the system into the rack.
3 Connect the peripherals to the system.
4 Connect the system to its electrical outlet.
5 Turn the system on by pressing the power button or by using iDRAC.
6 Turn on the attached peripherals.
For more information about setting up your system, see the Getting Started Guide that shipped with your system.
iDRAC conguration
The Integrated Dell Remote Access Controller (iDRAC) is designed to make system administrators more productive and improve the overall
availability of Dell EMC systems. iDRAC alerts administrators to system issues, helps them perform remote system management, and
reduces the need for physical access to the system.
Options to set up iDRAC IP address
You must congure the initial network settings based on your network infrastructure to enable the communication to and from iDRAC. You
must use the default iDRAC IP address 192.168.0.120 to congure the initial network settings, including setting up DHCP or a static IP for
iDRAC. You can set up the IP address by using one of the following interfaces:
NOTE: To access iDRAC, ensure that you connect the Ethernet cable to the iDRAC direct port. You can also access iDRAC
through the shared LOM mode, if you have opted for a system that has the shared LOM mode enabled.
Log in to iDRAC
You can log in to iDRAC as:
• iDRAC user
• Microsoft Active Directory user
• Lightweight Directory Access Protocol (LDAP) user
The default user name and password are root and calvin. You can also log in by using Single Sign-On or Smart Card.
NOTE: You must have iDRAC credentials to log in to iDRAC
NOTE: Ensure that you change the default user name and password after setting up the iDRAC IP address.
4
Initial system setup and conguration 19

Pre-operating system management applications
You can manage basic settings and features of a system without booting to the operating system by using the system rmware.
Options to manage the pre-operating system
applications
Your system has the following options to manage the pre-operating system applications:
• System Setup
• Dell EMC Lifecycle Controller
• Boot Manager
• Preboot Execution Environment (PXE)
System Setup
By using the System Setup screen, you can congure the BIOS settings, iDRAC settings and device settings of your system.
NOTE: Help text for the selected eld is displayed in the graphical browser by default. To view the help text in the text browser,
press F1.
You can access system setup by using two methods:
• Standard graphical browser — The browser is enabled by default.
• Text browser — The browser is enabled by using Console Redirection.
Viewing System Setup
To view the System Setup screen, perform the following steps:
1 Turn on, or restart your system
2 Press F2 immediately after you see the following message:
F2 = System Setup
NOTE: If your operating system begins to load before you press F2, wait for the system to nish booting, and then
restart your system and try again.
System Setup details
The System Setup Main Menu screen details are explained as follows:
Option Description
System BIOS Enables you to congure BIOS settings.
iDRAC Settings Enables you to congure iDRAC settings.
5
20 Pre-operating system management applications
