Dell Vostro 3710 Operation and maintenance manual

Vostro 3710
Setup and Specifications
Regulatory Model: D17S
Regulatory Type: D17S003
March 2022
Rev. A00

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.

Chapter 1: Set up your computer................................................................................................... 4
Chapter 2: Views of Vostro 3710....................................................................................................8
Front....................................................................................................................................................................................... 8
Back........................................................................................................................................................................................ 9
Back panel............................................................................................................................................................................10
Chapter 3: Specifications of Vostro 3710..................................................................................... 12
Dimensions and weight..................................................................................................................................................... 12
Processor............................................................................................................................................................................. 12
Chipset..................................................................................................................................................................................13
Operating system............................................................................................................................................................... 13
Memory.................................................................................................................................................................................13
Ports and connectors........................................................................................................................................................14
Ethernet............................................................................................................................................................................... 14
Wireless module..................................................................................................................................................................15
Storage................................................................................................................................................................................. 15
GPU—Integrated............................................................................................................................................................... 16
Audio..................................................................................................................................................................................... 16
Power ratings......................................................................................................................................................................16
Operating and storage environment..............................................................................................................................17
Chapter 4: Getting help and contacting Dell.................................................................................18
Contents
Contents 3

Set up your computer
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
1. Connect the keyboard and mouse to the USB ports on the computer. If you have a wireless keyboard and mouse, see the
documentation that shipped with the wireless keyboard and mouse for instructions.
2. Connect to your network using an Ethernet cable. Alternatively, connect to an available wireless network when setting up
the operating system.
1
4 Set up your computer

3. Connect the display. For more information about setting up the display, see the documentation that is shipped with your
display.
NOTE: The location to connect the display cable can vary if your computer has a discrete graphics card installed. For
optimal graphics performance, ensure to connect the display cable to the graphics card if there is one installed.
4. Connect the power cable to the computer and then connect it to the wall outlet.
Set up your computer 5

5. Press the power button at the front of the computer to turn it on. If required, press the power button on the display to turn
it on.
NOTE: For instructions on how to connect speakers, a printer and other accessories, see Me and My Dell at
www.dell.com/manuals.
6. Finish Windows setup.
Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
●Connect to a network for Windows updates.
NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
●If connected to the Internet, sign in with or create a Microsoft account. If not connected to the Internet, create an
offline account.
6Set up your computer

●On the Support and Protection screen, enter your contact details.
7. Locate and use Dell apps from the Windows Start menu—Recommended.
Table 1. Locate Dell apps
Resources Description
My Dell
Centralized location for key Dell applications, help articles, and other important information about
your computer. It also notifies you about the warranty status, recommended accessories, and
software updates if available.
SupportAssist
SupportAssist proactively and predictively identifies hardware and software issues on your
computer and automates the engagement process with Dell Technical support. It addresses
performance and stabilization issues, prevents security threats, monitors, and detects hardware
failures. For more information, see SupportAssist for Home PCs User's Guide at www.dell.com/
serviceabilitytools. Click SupportAssist and then, click SupportAssist for Home PCs.
NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty.
Dell Update
Updates your computer with critical fixes and latest device drivers as they become available. For
more information on using Dell Update, search in the Knowledge Base Resource at www.dell.com/
support.
Dell Digital Delivery
Download software applications, which are purchased but not preinstalled on your computer.
For more information on using Dell Digital Delivery, search in the Knowledge Base Resource at
www.dell.com/support.
Set up your computer 7

Views of Vostro 3710
Front
1. Power button
Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
Press to put the computer in sleep state if it is turned on.
Press and hold to force shut-down the computer.
NOTE: You can customize the power-button behavior in Windows. For more information, see Me and My Dell at
www.dell.com/support/manuals.
2. SD-card slot (optional)
Reads from and writes to the SD card. The computer supports the following card types:
●Secure Digital (SD)
●Secure Digital High Capacity (SDHC)
●Secure Digital Extended Capacity (SDXC)
3. Hard-drive activity light
The activity light turns on when the computer reads from or writes to the hard drive.
2
8 Views of Vostro 3710

4. Global headset jack
Connect headphones or a headset (headphone and microphone combo).
5. USB 2.0 ports (2)
Connect devices such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps.
6. USB 3.2 Gen 1 ports (2)
Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
7. Slim optical drive (optional)
The optical drive reads from and writes to CDs and DVDs.
8. Optical-drive activity light (optional)
The optical-drive activity light turns on when the computer reads from or writes to an optical drive.
9. Optical-drive eject button (optional)
Press to open the optical drive tray.
10. Optical-drive emergency eject pinhole (optional)
Used to eject the optical-drive tray manually if the optical-drive eject button fails.
NOTE: For more information about manually ejecting optical-drive trays, see the knowledge base article 000139665 at
www.dell.com/support.
Back
1. Back panel
Views of Vostro 3710 9

Connect USB, audio, video, and other devices.
2. Service Tag label
The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware
components in your computer and access warranty information.
3. PCI-Express x1 slot (half-height)
Connect a PCI-express card such as an audio or network card to enhance the capabilities of your computer.
4. PCI-Express X16 slot (half-height)
Connect a PCI-Express card such as graphics, audio, or network card to enhance the capabilities of your computer.
For optimal graphics performance, use a PCI-Express X16 slot for connecting the graphics card.
5. Power port
Connect a power cable to provide power to your computer.
6. Power-supply diagnostics light
Indicates the power-supply state.
7. Padlock rings
Attach a standard padlock to prevent unauthorized access to the interior of your computer.
8. Security-cable slot (wedge-shaped)
Connect a security cable to prevent unauthorized movement of your computer.
Back panel
1. Line-out port
Connect speakers.
2. HDMI 1.4b port
Connect to a TV, external display or another HDMI-in enabled device. Provides video and audio output.
NOTE: The HDMI port can also provide display output to a VGA connector with an HDMI to VGA adapter (sold
separately).
3. Dual-Mode DisplayPort 1.4
Connect an external display or a projector.
10 Views of Vostro 3710

NOTE: The DisplayPort port can also provide display output to a DVI, HDMI or VGA connector with a DisplayPort 1.4
adapter (sold separately).
NOTE: This port is only available on computers that are shipped with an Intel UHD Graphics integrated graphics
processor.
4. Service Tag label
The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware
components in your computer and access warranty information.
5. USB 3.2 Gen 1 ports (2)
Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
6. USB 2.0 ports (2)
Connect devices such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps.
7. Network port (with lights)
Connect an Ethernet (RJ45) cable from a router or a broadband modem for network or Internet access.
The two lights next to the connector indicate the connectivity status and network activity.
Views of Vostro 3710 11

Specifications of Vostro 3710
Dimensions and weight
The following table lists the height, width, depth, and weight of your Vostro 3710.
Table 2. Dimensions and weight
Description Values
Height 290 mm
Width 92.6 mm
Depth 292.80 mm (11.53 in.)
Weight
NOTE: The weight of your computer depends on the
configuration ordered and manufacturing variability.
4.52 kg (9.96 lb)
Processor
The following table lists the details of the processors that are supported by your Vostro 3710 .
Table 3. Processor
Description Option one Option two Option three Option four Option five Option six
Processor type 12th Generation
Intel Core
i3-12100
12th Generation
Intel Core
i5-12400
12th Generation
Intel Core
i7-12500
12th Generation
Intel Core
i7-12700
Intel Pentium Gold
G7400
Intel Celeron
G6900
Processor
wattage
60 W 65 W 65 W 65 W 46 W 46 W
Processor core
count
4 6 6 12 2 2
Processor
thread count
8 12 12 20 4 2
Processor
speed
Up to 4.3 GHz Up to 4.4 GHz Up to 4.6 GHz Up to 4.9 GHz 3.7 GHz 3.4 GHz
Processor
cache
12 MB 18 MB 18 MB 25 MB 6 MB 4 MB
Integrated
graphics
Intel UHD
Graphics
Intel UHD
Graphics
Intel UHD
Graphics
Intel UHD
Graphics
Intel UHD
Graphics
Intel UHD
Graphics
3
12 Specifications of Vostro 3710

Chipset
The following table lists the details of the chipset supported by your Vostro 3710.
Table 4. Chipset
Description Values
Chipset Intel B660
Processor ●12th Generation Intel Core i3/i5/i7
●Intel Pentium Gold
●Intel Celeron
DRAM bus width 64-bit
Flash EPROM 32 MB + 16 MB
PCIe bus Up to Gen3
Operating system
Your Vostro 3710 supports the following operating systems:
●Windows 11 Home, 64-bit
●Windows 11 Pro, 64-bit
●Windows 11 Pro National Academic, 64-bit
●Ubuntu 20.04 LTS, 64-bit
Memory
The following table lists the memory specifications of your Vostro 3710.
Table 5. Memory specifications
Description Values
Memory slots Two UDIMM slots
Memory type Dual-Channel DDR4
Memory speed 3200 MHz
Maximum memory configuration 4 GB
Minimum memory configuration 64 GB
Memory size per slot 4 GB, 8 GB, 16 GB, or 32 GB
Memory configurations supported ●4 GB, 1 x 4 GB, DDR4, 3200 MHz, UDIMM
●8 GB, 1 x 8 GB, DDR4, 3200 MHz, UDIMM
●8 GB, 2 x 4 GB, DDR4, 3200 MHz, UDIMM, dual-channel
●16 GB, 2 x 8 GB, DDR4, 3200 MHz, UDIMM, dual-channel
●16 GB, 1 x 16 GB, DDR4, 3200 MHz, UDIMM
●32 GB, 1 x 32 GB, DDR4, 3200 MHz, UDIMM
●32 GB, 2 x 16 GB, DDR4, 3200 MHz, UDIMM, dual-channel
●64 GB, 2 x 32 GB, DDR4, 3200 MHz, UDIMM, dual-
channel
Specifications of Vostro 3710 13

Ports and connectors
The following table lists the external and internal ports available on your Vostro 3710.
Table 6. Ports and connectors
Description Values
External:
Network One RJ-45 port
USB ●Four USB 3.2 Gen 1 ports
●Four USB 2.0 ports
Audio ●One global headset jack
●One audio line-out port
Video ●One HDMI 1.4b port
●One DisplayPort 1.4 port
Media-card reader One SD-card slot (optional)
Power port One AC power-supply port
Security ●One security-cable slot (wedge-shaped)
●One padlock ring slot
Internal:
PCIe expansion card slots ●One PCIe x16 half-height expansion card slot
●One PCIe x1 half-height slot
mSATA Not supported
SATA ●One SATA 2.0 slot for slim optical drive
●One SATA 3.0 slot for 3.5-inch/2.5-inch hard drive
M.2 ●One M.2 2230 slot for WiFi and Bluetooth combo card
●One M.2 2230/2280 slot for solid-state drive
NOTE: To learn more about the features of different
types of M.2 cards, see the knowledge base article
000144170.
Ethernet
The following table lists the wired Ethernet Local Area Network (LAN) specifications of your Vostro 3710.
Table 7. Ethernet specifications
Description Values
Model number Realtek RTL8111HSD
Transfer rate 10/100/1000 Mbps
14 Specifications of Vostro 3710

Wireless module
The following table lists the Wireless Local Area Network (WLAN) module specifications of your Vostro 3710.
Table 8. Wireless module specifications
Description Option one Option two Option Three Option Four
Model number Intel AX210 MediaTek MT7921 Realtek RTL8821CE Realtek RTL8822CE
Transfer rate Up to 2400 Mbps Up to 1200 Mbps Up to 433 Mbps Up to 867 Mbps
Frequency bands
supported
2.4 GHz/5 GHz/6
GHz
2.4 GHz/5 GHz 2.4 GHz/5 GHz 2.4 GHz/5 GHz
Wireless standards ●Wi-Fi 802.11
a/b/g
●Wi-Fi 4 (WiFi
802.11n)
●Wi-Fi 5 (WiFi
802.11ac)
●Wi-Fi 6E (WiFi
802.11ax)
●Wi-Fi 802.11 a/b/g
●Wi-Fi 4 (WiFi
802.11n)
●Wi-Fi 5 (WiFi
802.11ac)
●Wi-Fi 6 (WiFi
802.11ax)
●WiFi 802.11a/b/g
●Wi-Fi 4 (WiFi
802.11n)
●Wi-Fi 5 (WiFi
802.11ac)
●WiFi 802.11a/b/g
●Wi-Fi 4 (WiFi 802.11n)
●Wi-Fi 5 (WiFi 802.11ac)
Encryption ●64-bit/128-bit
WEP
●AES-CCMP
●TKIP
●64-bit/128-bit
WEP
●AES-CCMP
●TKIP
●64-bit/128-bit WEP
●AES-CCMP
●TKIP
●64-bit/128-bit WEP
●AES-CCMP
●TKIP
Bluetooth Bluetooth 5.2 Bluetooth 5.2 Bluetooth 5.0 Bluetooth 5.0
Storage
This section lists the storage options on your Vostro 3710.
Your Vostro 3710 supports one of the following storage configurations:
●One 2.5-inch or 3.5-inch hard-drive
●One M.2 2230/2280 solid-state drive
●One 3.5-inch hard-drive and one M.2 2230/2280 solid-state drive
The primary drive of your Vostro 3710 varies with the storage configuration. For computers:
●with a M.2 drive, the M.2 drive is the primary drive
●without a M.2 drive, the 2.5-inch or 3.5-inch hard drive is the primary drive
Table 9. Storage specifications
Storage type Interface type Capacity
2.5-inch hard-disk drive SATA AHCI, up to 6 Gbps Up to 2 TB
3.5-inch hard-disk drive SATA AHCI, up to 6 Gbps Up to 2 TB
M.2 2230 solid-state drive PCIe Gen3 x4 NVMe, up to 32 Gbps Up to 512 GB
M.2 2280 solid-state drive PCIe Gen4 x4 NVMe, up to 64 Gbps Up to 1 TB
M.2 2280 solid-state drive PCIe Gen3 x4 NVMe, up to 32 Gbps,
QLC
Up to 1 TB
Specifications of Vostro 3710 15

GPU—Integrated
The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Vostro 3710.
Table 10. GPU—Integrated
Controller External display support Memory size Processor
Intel UHD Graphics ●One HDMI 1.4b port
●One DisplayPort 1.4 port
Shared system memory ●12th Generation Intel Core
i3/i5/i7
●Intel Pentium Gold
●Intel Celeron
Audio
The following table lists the audio specifications of your Vostro 3710.
Table 11. Audio specifications
Description Values
Audio type Cirrus
Audio controller CS8409, CS42L42 (headphone codec)
Internal audio interface High definition audio interface
External audio interface ●One Global headset jack (front)
●One Line-out port (rear)
NOTE: 3.5 mm Global headset jack functionality varies
by model configuration. For best results, use Dell
recommended audio accessories.
Power ratings
The following table lists the power rating specifications of Vostro 3710.
Table 12. Power ratings
Description Option one
Type 180 W Bronze
Input voltage 90 VAC–264 VAC
Input frequency 47 Hz–63 Hz
Input current (maximum) 3 A
Output current (continuous) Operating:
●12 VA - 15 A
●12 VB – 14 A
Standby:
●12 VA - 1.50 A
●12 VB – 3.30 A
Rated output voltage ●12 VA
16 Specifications of Vostro 3710

Table 12. Power ratings (continued)
Description Option one
●12 VB
Temperature range:
Operating 5°C to 45°C (41°F to 113°F)
Storage -40°C to 70°C (-40°F to 158°F)
Operating and storage environment
This table lists the operating and storage specifications of your Vostro 3710.
Airborne contaminant level: G1 as defined by ISA-S71.04-1985
Table 13. Computer environment
Description Operating Storage
Temperature range 10°C – 35°C (32°F – 95°F) -40°C - 65°C (-40°F - 149°F)
Relative humidity (maximum) 20% to 80% (non-condensing, Max dew
point temperature = 26°C)
5% to 95% (non-condensing, Max dew
point temperature = 33°C)
Vibration (maximum)*0.26 GRMS random at 5 Hz to 350 Hz 1.37 GRMS random at 5 Hz to 350 Hz
Shock (maximum) 40 G† 105 G†
Altitude range -15.2 m - 3048 m (-49.86 ft -10,000 ft) -15.2 m - 10,668 m (-49.86 ft - 35,000
ft)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse.
Specifications of Vostro 3710 17

Getting help and contacting Dell
Self-help resources
You can get information and help on Dell products and services using these self-help resources:
Table 14. Self-help resources
Self-help resources Resource location
Information about Dell products and services www.dell.com
My Dell app
Tips
Contact Support In Windows search, type Contact Support, and press
Enter.
Online help for operating system www.dell.com/support/windows
www.dell.com/support/linux
Access top solutions, diagnostics, drivers and downloads, and
learn more about your computer through videos, manuals and
documents.
Your Dell computer is uniquely identified by a Service Tag or
Express Service Code. To view relevant support resources for
your Dell computer, enter the Service Tag or Express Service
Code at www.dell.com/support.
For more information on how to find the Service Tag for your
computer, see Locate the Service Tag on your computer.
Dell knowledge base articles for a variety of computer
concerns
1. Go to www.dell.com/support.
2. On the menu bar at the top of the Support page, select
Support > Knowledge Base.
3. In the Search field on the Knowledge Base page, type the
keyword, topic, or model number, and then click or tap the
search icon to view the related articles.
Contacting Dell
To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell.
NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.
NOTE: If you do not have an active Internet connection, you can find contact information about your purchase invoice,
packing slip, bill, or Dell product catalog.
4
18 Getting help and contacting Dell
