Dell 1525 - Inspiron - Pentium Dual Core 1.86 GHz User manual

SETUP GUIDE
INSPIRON™

Model PP29L
SETUP GUIDE
INSPIRON™

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your
computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you
how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
__________________
Information in this document is subject to change without notice.
© 2008 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text:
Dell , the DELL logo, Inspiron , YOURS IS HERE, WIFi-Catcher, and DellConnect are trademarks
of Dell Inc.;
Intel , Pentium , and Celeron are registered trademarks and Core is a trademark of Intel Corporation in the U.S.
and other countries;
Microsoft , Windows , Windows Vista start button logo , and Windows Vista are either trademarks or
registered trademarks of Microsoft Corporation in the United States and/or other countries.;
Bluetooth is a registered
trademark owned by Bluetooth SIG, Inc. and is used by Dell under license.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and
names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing
uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
October 2008 P/N Y465H Rev. A01

3
Setting Up Your Inspiron Laptop. . . . . . . . . .5
Before Setting Up Your Computer . . . . . . . . . 5
Connect the AC Adapter . . . . . . . . . . . . . . . . 6
Check the Wireless Switch . . . . . . . . . . . . . . 6
Connect the Network Cable (optional) . . . . . 7
Press the Power Button . . . . . . . . . . . . . . . . .7
Microsoft®Windows®Setup . . . . . . . . . . . . . 8
Connect to the Internet (Optional) . . . . . . . . . 8
Using Your Inspiron Laptop. . . . . . . . . . . . .12
Device Status Lights . . . . . . . . . . . . . . . . . . . 12
Right Side Features . . . . . . . . . . . . . . . . . . . . 14
Left Side Features . . . . . . . . . . . . . . . . . . . . . 16
Front Side Features . . . . . . . . . . . . . . . . . . . . 18
Computer Base and Keyboard Features . . . 19
Media Controls. . . . . . . . . . . . . . . . . . . . . . . . 20
Display Features . . . . . . . . . . . . . . . . . . . . . . 21
Removing and Replacing the Battery . . . . . 22
Software Features . . . . . . . . . . . . . . . . . . . . . 23
Solving Problems . . . . . . . . . . . . . . . . . . . . .26
Network Problems . . . . . . . . . . . . . . . . . . . . . 26
Power Problems. . . . . . . . . . . . . . . . . . . . . . . 28
Memory Problems . . . . . . . . . . . . . . . . . . . . . 29
Lockups and Software Problems . . . . . . . . . 30
Dell Support Center . . . . . . . . . . . . . . . . . . . . 33
System Messages . . . . . . . . . . . . . . . . . . . . . 33
Using Support Tools. . . . . . . . . . . . . . . . . . .33
Hardware Troubleshooter. . . . . . . . . . . . . . . 35
Dell Diagnostics . . . . . . . . . . . . . . . . . . . . . . 36
System Restore . . . . . . . . . . . . . . . . . . . . . . . 38
Contents

4
Contents
Restoring Your Operating System . . . . . . .39
Windows XP: Using Dell™PC Restore . . . . . 40
Windows Vista: Dell Factory Image
Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Operating System Reinstallation . . . . . . . . . 43
Technical Support and Customer
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . .46
DellConnect™. . . . . . . . . . . . . . . . . . . . . . . . . 46
Online Services . . . . . . . . . . . . . . . . . . . . . . . 46
AutoTech Service. . . . . . . . . . . . . . . . . . . . . . 47
Product Information. . . . . . . . . . . . . . . . . . . . 48
Returning Items for Repair Under
Warranty or for Credit . . . . . . . . . . . . . . . . . . 48
Before You Call. . . . . . . . . . . . . . . . . . . . . . . . 49
Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . . 50
Finding More Information and
Resources . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Basic Specifications . . . . . . . . . . . . . . . . . .54
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

5
INSPIRON
Setting Up Your Inspiron Laptop
This section provides information about
setting up your Inspiron 1525/1526 laptop and
connecting peripherals.
Before Setting Up Your Computer
When positioning your computer, ensure that
you allow easy access to a power source,
adequate ventilation, and a level surface to
place your computer.
Restricting airflow around your Inspiron
computer may cause it to overheat. To prevent
overheating ensure that you leave at least
10.2 cm (4 in) at the back of the computer and a
minimum of 5.1 cm (2 in) on all other sides. You
should never put your computer in an enclosed
space, such as a cabinet or drawer when it is
powered on.
NOTICE: Placing or stacking heavy or sharp
objects on the computer may result in
permanent damage to the computer.

6
Setting Up Your Inspiron Laptop
Connect the AC Adapter
Connect the AC adapter to the computer and
then plug it into a wall outlet or surge protector.
CAUTION: The AC adapter works with
electrical outlets worldwide. However,
power connectors and power strips vary
among countries. Using an incompatible
cable or improperly connecting the cable to
a power strip or electrical outlet may cause
fire or equipment damage.
Check the Wireless Switch
If you plan to use wireless connections, make
sure the wireless switch is in the “On” position.
Using The Wireless Switch
To turn on the wireless switch, slide it from the
rear to the front of the computer until it clicks
into place.
- Off - On
- Momentary

7
Setting Up Your Inspiron Laptop
Connect the Network Cable
(optional)
If you plan to use a wired network connection,
plug in the network cable.
Press the Power Button

8
Setting Up Your Inspiron Laptop
Microsoft®Windows®Setup
Your Dell computer is preconfigured with
Microsoft Windows operating system. To
set up Windows for the first time, follow the
instructions on the screen. These steps are
mandatory and may take up to 15 minutes to
complete. The screens will take you through
several procedures including accepting license
agreements, setting preferences and setting up
an Internet connection.
NOTICE: Do not interrupt the operating
system’s setup process. Doing so may
render your computer unusable.
Connect to the Internet (Optional)
NOTE: ISPs and ISP offerings vary by
country.
To connect to the Internet, you need an external
modem or network connection and an Internet
service provider (ISP).
Setting Up a Wired Internet Connection
If you are using a dial-up connection, connect
the telephone line to the external USB modem
(optional) and to the telephone wall jack
before you set up your Internet connection.
If you are using a DSL or cable/satellite modem
connection, contact your ISP or cellular
telephone service for setup instructions.

9
Setting Up Your Inspiron Laptop
Setting Up a Wireless Connection
Before you can use your wireless Internet
connection, you need to connect to your
wireless router. To set up your connection to a
wireless router:
Save and close any open files, and exit any1.
open programs.
Click2. Start →Connect To.
Follow the instructions on the screen to3.
complete the setup.
Setting Up Your Internet Connection
To set up an Internet connection with a provided
ISP desktop shortcut:
Save and close any open files, and exit any1.
open programs.
Double-click the ISP icon on the Microsoft2. ®
Windows®desktop.
Follow the instructions on the screen to3.
complete the setup.
If you do not have an ISP icon on your desktop
or if you want to set up an Internet connection
with a different ISP, perform the steps in the
following section.
NOTE: If you cannot connect to the Internet
but have successfully connected in the
past, the ISP might have a service outage.
Contact your ISP to check the service
status, or try connecting again later.
NOTE: Have your ISP information ready.
If you do not have an ISP, the Connect to
the Internet wizard can help you get one.
Windows Vista
Save and close any open files, and exit any1.
open programs.
Click2. Start →Control Panel.
Under3. Network and Internet, click Connect
to the Internet.
The Connect to the Internet window appears.

10
Setting Up Your Inspiron Laptop
Click either4. Broadband (PPPoE) or Dial-up,
depending on how you want to connect:
Choosea. Broadband if you will use a
DSL, satellite modem, cable TV modem,
or Bluetooth®wireless technology
connection.
Choseb. Dial-up if you will use an optional
USB dial-up modem or ISDN.
NOTE: If you do not know which type of
connection to select, click Help me choose
or contact your ISP.
Follow the instructions on the screen and5.
use the setup information provided by your
ISP to complete the setup.
Windows XP
Save and close any open files, and exit any1.
open programs.
Click2. Start → Internet Explorer.
The New Connection Wizard appears.
Click3. Connect to the Internet.
In the next window, click the appropriate4.
option:
If you do not have an ISP and want to–
select one, click Choose from a list of
Internet service providers (ISPs).
If you have already obtained setup–
information from your ISP but you did
not receive a setup CD, click Set up my
connection manually.
If you have a CD, click Use the CD I got–
from an ISP.
Click5. Next.
If you selected Set up my connection
manually, continue to step 6. Otherwise,
follow the instructions on the screen to
complete the setup.
NOTE: If you do not know which type of
connection to select, contact your ISP.

11
Setting Up Your Inspiron Laptop
Click the appropriate option under How do6.
you want to connect to the Internet?, and
then click Next.
Use the setup information provided by your7.
ISP to complete the setup.

INSPIRON
12
Your Inspiron 1525/1526 has several indicators,
buttons, and features that provide information
at-a-glance and time-saving shortcuts for
common tasks.
Device Status Lights
The device status lights located at the front left
of the computer provide information for wireless
communication and keyboard input options.
1Power light – Turns on when you
turn on the computer, and blinks when the
computer is in a power management
mode.
2Hard drive activity light – Turns
on when the computer reads or writes
data. A flashing light indicates hard drive
activity.
NOTE: To avoid loss of data, never
turn off the computer while the hard
drive activity light is flashing..
3Battery status light – Turns on
steadily or blinks to indicate battery
charge status.
Using Your Inspiron Laptop
1 2 3 4 5

13
Using Your Inspiron Laptop
4WiFi status light – Turns on when
wireless networking is enabled.
Use the wireless switch located at the,
right side of the computer to quickly turn
all wireless communication on and off.
Using The Wireless Switch
To turn on the wireless switch, slide it
away from the front of the computer until it
clicks into place.
- Off - On
- Momentary
5Bluetooth®status light – Turns on
when a card with Bluetooth wireless
technology is enabled.
NOTE: The card with Bluetooth
wireless technology is an optional
feature.
To turn off Bluetooth wireless, right-click
the bluetooth icon in the notification
area of your desktop, and click Disable
Bluetooth Radio or use the wireless
switch.

14
Using Your Inspiron Laptop
Right Side Features
1
1
23
4
5
67
1Wireless On/Off switch – Use this
switch to rapidly turn all wireless devices
off or on such as WLAN cards and internal
cards with Bluetooth wireless technology.
The wireless switch may be in the Off
position when your computer is shipped to
you. To turn the switch On, slide the switch
away from the front of the computer until it
clicks into place.
- Off - On
- Momentary
NOTE: This switch can be deactivated
through Dell QuickSet or the BIOS
(system setup program).
Off - Disables wireless devices
On - Enables wireless devices
momentary - Scans for WLAN
networks

15
Using Your Inspiron Laptop
2Wi-Fi Catcher™light -
The light operates as follows:
Flashing blue: Searching for networks
Solid blue: Strong network found
Solid yellow: Weak network found
Off: No signal found
3ExpressCard slot – Supports one
ExpressCard. The computer ships with a
plastic blank installed in the slot.
4Optical Drive – Plays or burns only
standard-size and shape (12 cm) CDs, and
DVDs. Ensure that the side with print or
writing is facing upward when inserting
discs.
5Eject Button – Press the eject button to
open the optical drive.
6S-video TV-out connector – Connects your
computer to a TV. Also connects digital
audio-capable devices using the TV/digital
audio adapter cable.
7USB 2.0 connectors (2) – Connects a
USB device, such as a mouse, keyboard,
printer, external drive, or MP3 player.

16
Using Your Inspiron Laptop
Left Side Features
123
45678
9
1Security cable slot – Used to attach a
commercially available antitheft device to
the computer.
NOTE: Before you buy an antitheft
device, ensure that it works with the
security cable slot on your computer.
2AC adapter connector – Connects to
the AC adapter to power the computer and
charge the battery when the computer is
not in use.
3USB connectors (2)– Connects to a
USB device, such as a mouse, keyboard,
printer, external drive, or MP3 player.
4VGA connector – Connects to a
monitor or projector.
5Network connector – If you are
using a cabled network signal, this
connects your computer to a network or
broadband device.

17
Using Your Inspiron Laptop
6Modem connector – Connect the
telephone line to the modem connector.
For information on using the modem, see
the online modem documentation supplied
with your computer.
7HDMI connector – HDMI (High-
Definition Multimedia Interface) connector
carries an uncompressed all digital signal
to produce hi-definition video and audio.
8IEEE 1394 connector – Connects to
high-speed serial multimedia devices,
such as digital video cameras.
9Hard Drive – Stores software and data.

18
Using Your Inspiron Laptop
Front Side Features
1
2
45
4
5
67
3
1Touch pad – Provides the functionality of
a mouse to move the cursor, drag or move
selected items, and left-click by tapping
the surface.
2Touch pad buttons – Provide left- and
right-click functions those on like a mouse
3Consumer IR – Infrared sensor for using
the Dell Travel Remote.
4Audio Out/ Headphone connectors (2)
– Connects one pair of headphones, or
sends audio to a powered speaker or
sound system.
5Audio In/ Microphone connector –
Connects to a microphone or input signal
for use with audio programs.
6Analog Microphone – If you do not have
the optional built-in camera with dual
microphones, this single microphone is
used for conferencing and chat.
