Dell Inspiron 11 3000 2-in-1 Operation and maintenance manual

Inspiron 11 3000 2-in-1
Setup and Specications
Computer Model: Inspiron 11–3168/Inspiron 11–3169
Regulatory Model: P25T
Regulatory Type: P25T001/P25T002

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make
better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or
loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
Copyright ©2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other
trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be
trademarks of their respective owners.
2017-09
Rev. A02

Contents
Set up your computer.................................................... 5
Create a USB recovery drive for Windows..................... 8
Reinstall Windows using a USB recovery drive.......................................... 8
Views............................................................................10
Left..........................................................................................................10
Right........................................................................................................10
Base..........................................................................................................11
Display..................................................................................................... 12
Modes......................................................................................................13
Notebook........................................................................................... 13
Tablet................................................................................................. 13
Stand................................................................................................. 14
Tent....................................................................................................14
3

Specications...............................................................15
Dimensions and weight............................................................................ 15
System Information..................................................................................15
Memory................................................................................................... 16
Ports and Connectors.............................................................................. 16
Communications...................................................................................... 16
Video........................................................................................................17
Audio........................................................................................................17
Storage.................................................................................................... 17
Media-card reader....................................................................................18
Display..................................................................................................... 18
Keyboard..................................................................................................18
Camera.................................................................................................... 19
Touch pad................................................................................................ 19
Battery.....................................................................................................19
Power Adapter........................................................................................ 20
Computer Environment........................................................................... 20
Keyboard shortcuts......................................................22
Getting help and contacting Dell.................................. 24
Self-help resources..................................................................................24
Contacting Dell........................................................................................25
4

Set up your computer
1 Connect the power adapter and press the power button.
NOTE: To save battery power, the battery might enter to power saving
mode. Connect the power adapter and press the power button to turn
on the computer.
5

2 Finish operating system setup.
For Windows:
a) Connect to a network.
NOTE: If you are connecting to a secured wireless network, enter
the password for the wireless network access when prompted.
b) Sign in to your Microsoft account or create a new account.
For Ubuntu:
Follow the instructions on the screen to nish setup.
6

3 Locate Dell apps in Windows.
NOTE: Microsoft Windows 10 S is only supported on Inspiron 11-3168
shipped with Intel Celeron processor with 32 GB storage.
If your computer is running Microsoft Windows 10 S operating system and there
are no Dell apps available, you can download them from the Microsoft Store.
NOTE: Dell apps will be available soon on Microsoft Store.
Table 1. Locate Dell apps
Register your computer
Dell Help & Support
SupportAssist—Check and update your computer
4 Create recovery drive for Windows.
NOTE: It is recommended to create a recovery drive to troubleshoot
and x problems that may occur with Windows.
For more information, see Create a USB recovery drive for Windows.
7

Create a USB recovery drive for
Windows
Dell recommends that you create a recovery drive to troubleshoot and x problems
that may occur with Windows. An empty USB ash drive with a minimum capacity of
16 GB is required to create the recovery drive.
NOTE: The following steps may vary depending on the version of Windows
installed. Refer to the Microsoft support site for latest instructions.
1 Connect the USB ash drive to your computer.
2 In Windows search, type Recovery.
3 In the search results, click Create a recovery drive.
The User Account Control window is displayed.
4 Click Yes to continue.
The Recovery Drive window is displayed.
5 Select Back up system les to the recovery drive and click Next.
6 Select the USB ash drive and click Next.
A message appears, indicating that all data in the USB ash drive will be deleted.
7 Click Create.
NOTE: This process may take several minutes to complete.
8 Click Finish.
Reinstall Windows using a USB recovery drive
CAUTION: This process formats the hard drive and removes all data on your
computer. Ensure that you back up data on your computer before beginning
this task.
NOTE: Before reinstalling Windows, ensure your computer has more than 2
GB of memory and more than 32 GB of storage space.
1 Connect the USB recovery drive to your computer.
2 Restart your computer.
8

3 Press F12 after the Dell logo is displayed on the screen to access the boot menu.
A Preparing one-time boot menu message appears.
4 After the boot menu loads, select the USB recovery device under UEFI BOOT.
The system reboots and a screen to Choose the keyboard layout is displayed.
5 Choose your keyboard layout.
6 In the Choose an option screen, click Troubleshoot.
7 Click Recover from a drive.
8 Choose one of the following options:
–Just remove my les to do a quick format.
–Fully clean the drive to do a complete format.
9 Click Recover to start the recovery process.
This will take several minutes to complete and your computer will restart during
this process.
9

Views
Left
1Power-adapter port
Connect a power adapter to provide power to your computer and charge the
battery.
2HDMI port
Connect a TV or another HDMI‑in enabled device. Provides video and audio
output.
3USB 3.0 port
Connect peripherals such as storage devices, printers, and so on. Provides data
transfer speeds up to 5 Gbps.
4microSD-card slot
Reads from and writes to media cards.
Right
1Power button
Press to turn on the computer if it is turned o, in sleep state, or in hibernate
state.
10

Press to put the computer in sleep state if it is turned on.
Press and hold for 4 seconds to force shut-down the computer.
NOTE: You can customize the power-button behavior in Power
Options. For more information, see Me and My Dell at www.dell.com/
support/manuals.
2Volume-control button
Press to increase or decrease the volume.
3Headset port
Connect a headphone, a microphone, or a headset (headphone and microphone
combo).
4USB 2.0 ports (2)
Connect peripherals such as storage devices, printers, and so on. Provides data
transfer speeds up to 480 Mbps.
5Security-cable slot
Connect a Noble security-cable to prevent unauthorized movement of your
computer.
Base
11

1Left-click area
Press to left-click.
2Touch pad
Move your nger on the touch pad to move the mouse pointer. Tap to left-click.
3Right-click area
Press to right-click.
Display
1Left microphone
Provides high‑quality digital sound input for audio recording, voice calls, and so
on.
2Camera
Allows you to video chat, capture photos, and record videos.
3Camera-status light
Turns on when the camera is in use.
4Right microphone
12

Provides high‑quality digital sound input for audio recording, voice calls, and so
on.
Modes
Notebook
Tablet
13

Stand
Tent
14

Specications
Dimensions and weight
Height 20.90 mm (0.82 in)
Width 291.64 mm (11.48 in)
Depth 201.92 mm (7.95 in)
Weight 1.39 kg (3.07 lb)
NOTE: The weight of your laptop
varies depending on the
conguration ordered and the
manufacturing variability.
System Information
Inspiron 11–3168 Inspiron 11–3169
Processor • Intel Celeron Dual Core
• Intel Pentium Quad
Core
6th generation Intel Core
m3
Chipset Integrated in processor 201.92 mm (7.95 in)
Weight 1.39 kg (3.07 lb)
NOTE: The weight
of your laptop varies
depending on the
conguration
ordered and the
manufacturing
variability.
15

Memory
Slot One SODIMM slot (Only on Inspiron 11–
3168 shipped with Intel Pentium
processor)
Type DDR3L
Speed 1600 MHz
Congurations supported • 2 GB, and 4 GB (Inspiron 11–3168)
• 4 GB (Inspiron 11–3169)
Ports and Connectors
External:
USB • One USB 3.0 port
• Two USB 2.0 ports
Audio/Video • One HDMI port
• One headset (headphone and
microphone combo) port
Internal:
M.2 One M.2 slot for Wi-Fi and Bluetooth
combo card
Communications
Wireless • Wi-Fi 802.11 b/g/n/ac
• Wi-Fi 802.11 ac
• Bluetooth 4.0
• Intel WiDi (optional)
16

Video
Inspiron 11–3168 Inspiron 11–3169
Controller Intel HD Graphics Intel Graphics 515
Memory Shared system memory
Audio
Controller • Realtek ALC3234with Waves
MaxxAudio (Inspiron 11–3168)
• Realtek ALC3246 with Waves
MaxxAudio (Inspiron 11–3169)
Speakers Two
Output • Average 2 W
• Peak 2.5 W
Microphone Digital array-microphones in camera
assembly
Volume controls Media-control shortcut keys and volume-
control buttons
Storage
Interface SATA 6 Gbps
Hard drive • One 2.5-inch drive
• One Solid State Drive (SSD)
• One eMMC card
17

Media-card reader
Type One microSD-card slot
Card supported microSD
Display
Type 11.6–inch HD touch
Resolution (maximum) 1366 x 768
Pixel pitch 0.2265 mm
Refresh rate 60 Hz
Operating angle 0 degrees (closed) to 360 degrees
Controls Brightness can be controlled using
shortcut keys
Height 144 mm (5.67 in)
Width 256.13 mm (10.08 in)
Diagonal 294.64 mm (11.60 in)
Keyboard
Type Chiclet keyboard
Shortcut keys Some keys on your keyboard have two
symbols on them. These keys can be
used to type alternate characters or to
perform secondary functions. To type
the alternate character, press Shift and
the desired key. To perform secondary
functions, press Fn and the desired key.
18

NOTE: You can dene the primary
behavior of the shortcut keys by
pressing Fn+Esc or by changing
Function Key Behavior in System
Setup.
Keyboard shortcuts
Camera
Resolution • Still image: 0.92 megapixel
• Video: 1280 x 720 (HD) at 30 fps
(maximum)
Diagonal viewing angle 74 degrees
Touch pad
Resolution • Horizontal: 1940
• Vertical: 1040
Dimensions • Width: 100 mm (3.94 in)
• Height: 55 mm (2.16 in)
Battery
Type 2–cell prismatic (32 WHr)
Operating time Varies depending on operating conditions
and can signicantly reduce under
certain power-intensive conditions.
Life span (approximate) 300 discharge/charge cycles
Temperature range: Operating 0°C to 35°C (32°F to 95°F)
Temperature range: Storage –40°C to 65°C (–40°F to 149°F)
Coin-cell battery CR-2032
19

Weight (maximum) 0.19 kg (0.42 lb)
Voltage 7.6 VDC
Charging time when the computer is o
(approximate)
Within 4 hours
Width 272.10 mm (10.71 in)
Depth 70.50 mm (2.78 in)
Height 6.82 mm (0.27 in)
Power Adapter
Type 45 W 65 W
Input voltage 100 VAC–240 VAC
Input frequency 50 Hz–60 Hz
Input current (maximum) 1.30 A 1.70 A
Output current
(continuous)
2.31 A 3.34 A
Rated output voltage 19.50 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F)
Temperature range:
Storage
–40°C to 70°C (–40°F to 158°F)
Computer Environment
Airborne contaminant level: G1 as dened by ISA-S71.04-1985
Operating Storage
Temperature range 0°C to 35°C (32°F to
95°F)
–40°C to 65°C (–40°F to
149°F)
Relative humidity
(maximum)
10% to 90% (non-
condensing)
0% to 95% (non-
condensing)
Vibration (maximum)*0.66 GRMS 1.30 GRMS
20
