Dell Inspiron 7437 User manual

Inspiron 14
7000 Series
Owner’s Manual
Computer model: Inspiron 7437
Regulatory model: P42G
Regulatory type: P42G001

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better
use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
____________________
© 2013 Dell Inc.
Trademarks used in this text: Dell™, the DELL logo, and Inspiron™ are trademarks of Dell Inc.
2013 - 09 Rev. A00

Contents | 3
Contents
Before Working Inside Your Computer 7
Before You Begin 7
Recommended Tools 7
Safety Instructions 8
After Working Inside Your Computer 9
Removing the Base Cover 10
Procedure 10
Replacing the Base Cover 11
Procedure 11
Removing the Battery 12
Prerequisites 12
Procedure 12
Replacing the Battery 13
Procedure 13
Postrequisites 13
Removing the Speakers 14
Prerequisites 14
Procedure 14
Replacing the Speakers 15
Procedure 15
Postrequisites 15
Removing the Wireless Card 16
Prerequisites 16
Procedure 16
Replacing the Wireless Card 17
Procedure 17
Postrequisites 17

4| Contents
Removing the Coin-Cell Battery 18
Prerequisites 18
Procedure 18
Replacing the Coin-Cell Battery 19
Procedure 19
Postrequisites 19
Removing the Fan 20
Prerequisites 20
Procedure 20
Replacing the Fan 21
Procedure 21
Postrequisites 21
Removing the Power-Adapter Port 22
Prerequisites 22
Procedure 22
Replacing the Power-Adapter Port 24
Procedure 24
Postrequisites 24
Removing the System Board 25
Prerequisites 25
Procedure 25
Replacing the System Board 28
Procedure 28
Postrequisites 28
Entering the Service Tag in the BIOS 28
Removing the mSATA Card 29
Prerequisites 29
Procedure 29
Replacing the mSATA Card 30
Procedure 30
Postrequisites 30

Contents | 5
Removing the Thermal-Cooling Assembly 31
Prerequisites 31
Procedure 31
Replacing the Thermal-Cooling Assembly 33
Procedure 33
Postrequisites 33
Removing the Keyboard 34
Prerequisites 34
Procedure 34
Replacing the Keyboard 36
Procedure 36
Postrequisites. 36
Removing the Display Assembly 37
Prerequisites 37
Procedure 37
Replacing the Display Assembly 41
Procedure 41
Postrequisites 41
Removing the Palm Rest 42
Prerequisites 42
Procedure 42
Replacing the Palm Rest 45
Procedure 45
Postrequisites 46
Flashing the BIOS 47

6| Contents

Before Working Inside Your Computer | 7
Before Working Inside Your Computer
Before You Begin
CAUTION: To avoid data loss, save and close all open files and exit all open
programs before turning off your computer.
1Save and close all open files, exit all open programs, and turn off your computer.
Point to the lower or upper-right corner of the screen to open the Charms sidebar
and click Settings→Power→Shut down.
NOTE: If you use a different operating system, see the documentation of your
operating system for shut-down instructions.
2After the computer shuts down, disconnect it from the electrical outlet.
3Disconnect all cables — such as power and USB cables — from your computer.
4Disconnect all peripherals connected to your computer.
Recommended Tools
The procedures in this document require the following tools:
•Phillips screwdriver
•Torx #5 (T5) screwdriver
•Plastic scribe

8| Before Working Inside Your Computer
Safety Instructions
Use the following safety guidelines to protect your computer from potential damage and
ensure your personal safety.
WARNING: Before working inside your computer, read the safety
information that shipped with your computer. For more safety best practices,
see the Regulatory Compliance home page at dell.com/regulatory_compliance.
WARNING: Disconnect all power sources before opening the computer
cover or panels. After you finish working inside the computer, replace all covers,
panels, and screws before connecting to the power source.
CAUTION: Only a certified service technician is authorized to remove the
computer cover and access any of the components inside the computer. See the
safety instructions for complete information about safety precautions, working
inside your computer, and protecting against electrostatic discharge.
CAUTION: To avoid damaging the computer, make sure that the work surface is
flat and clean.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab,
not on the cable itself. Some cables have connectors with locking tabs or
thumb-screws that you must disengage before disconnecting the cable.
When disconnecting cables, keep them evenly aligned to avoid bending any
connector pins. When connecting cables, make sure that the ports and
connectors are correctly oriented and aligned.
CAUTION: To avoid damaging the components and cards, handle them by
their edges and avoid touching pins and contacts.
CAUTION: Before touching anything inside your computer, ground yourself
by touching an unpainted metal surface, such as the metal at the back of the
computer. While you work, periodically touch an unpainted metal surface to
dissipate static electricity, which could harm internal components.
CAUTION: Press and eject any installed card from the media-card reader.

After Working Inside Your Computer | 9
After Working Inside Your Computer
CAUTION: Leaving stray or loose screws inside your computer may severely
damage your computer.
1Replace all screws and make sure that no stray screws remain inside your
computer.
2Connect any cables, peripherals, and other parts you removed before working on
your computer.
3Connect your computer to the electrical outlet.
4Turn on your computer.

10 | Removing the Base Cover
Removing the Base Cover
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before Working Inside
Your Computer" on page 7. After working inside your computer, follow the
instructions in "After Working Inside Your Computer" on page 9.
For more safety best practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1Close the display, and turn the computer over.
2Loosen the captive screws that secure the base cover to the palm-rest assembly.
3Remove the screws that secure the base cover to the palm-rest assembly.
4Using a plastic scribe, pry the base cover out of the palm-rest assembly.
1screws (6) 2plastic scribe
3captive screws (2) 4base cover
5palm-rest assembly
1
2
3
5
4
