SETUP GUIDE
INSPIRON™

SETUP GUIDE
Regulatory model: P08E series Regulatory type: P08E001
INSPIRON™

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your
computer.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells
you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
If you purchased a Dell™n Series computer, any references in this document to Microsoft®Windows®operating systems
are not applicable.
__________________
Information in this document is subject to change without notice.
© 2010 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell , the DELL logo, Inspiron , YOURS IS HERE , Solution Station , and DellConnect are
trademarks of Dell Inc.; Intel , Pentium , and Celeron are registered trademarks and Core is a trademark of Intel
Corporation in the U.S. and other countries; Microsoft , Windows , Windows Vista , and the Windows Vista start button logo
are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries; AMD
and ATI Mobility Radeon are trademarks or registered trademarks of Advanced Micro Devices, Inc.; Blu-ray Disc is a
trademark of the Blu-ray Disc Association; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used
by Dell under license.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and
names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
November 2010 P/N 7HR9P Rev. A03

3
Setting Up Your Inspiron Laptop. . . . . . . . . .5
Before Setting Up Your Computer . . . . . . . . . 5
Connect the AC Adapter . . . . . . . . . . . . . . . . .6
Connect the Network Cable (Optional) . . . . . 7
Press the Power Button . . . . . . . . . . . . . . . . .8
Set Up Microsoft Windows. . . . . . . . . . . . . . . 9
Create System Recovery Media
(Recommended). . . . . . . . . . . . . . . . . . . . . . . 10
Install the SIM Card (Optional). . . . . . . . . . . 12
Enable or Disable Wireless (Optional). . . . . 14
Set Up Wireless Display (Optional) . . . . . . . 16
Connect to the Internet (Optional) . . . . . . . . 18
Using Your Inspiron Laptop. . . . . . . . . . . . .22
Right View Features. . . . . . . . . . . . . . . . . . . . 22
Left View Features. . . . . . . . . . . . . . . . . . . . . 24
Back View Features. . . . . . . . . . . . . . . . . . . . 26
Front View Features. . . . . . . . . . . . . . . . . . . . 27
Status Lights and Indicators. . . . . . . . . . . . . 28
Computer Base and Keyboard
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Touch Pad Gestures. . . . . . . . . . . . . . . . . . . . 32
Multimedia Control Keys. . . . . . . . . . . . . . . . 34
Using the Optical Drive . . . . . . . . . . . . . . . . . 36
Display Features . . . . . . . . . . . . . . . . . . . . . . 38
Removing and Replacing the Battery . . . . . 40
Software Features . . . . . . . . . . . . . . . . . . . . . 42
Dell DataSafe Online Backup . . . . . . . . . . . . 43
Dell Dock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Solving Problems . . . . . . . . . . . . . . . . . . . . .45
Beep Codes . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Network Problems . . . . . . . . . . . . . . . . . . . . . 46
Power Problems. . . . . . . . . . . . . . . . . . . . . . . 47
Contents

4
Contents
Memory Problems . . . . . . . . . . . . . . . . . . . . . 48
Lockups and Software Problems . . . . . . . . . 48
Using Support Tools. . . . . . . . . . . . . . . . . . .52
Dell Support Center . . . . . . . . . . . . . . . . . . . . 52
My Dell Downloads . . . . . . . . . . . . . . . . . . . . 53
System Messages . . . . . . . . . . . . . . . . . . . . . 54
Hardware Troubleshooter. . . . . . . . . . . . . . . 55
Dell Diagnostics. . . . . . . . . . . . . . . . . . . . . . . 56
Restoring Your Operating System . . . . . . .60
System Restore . . . . . . . . . . . . . . . . . . . . . . . 61
Dell DataSafe Local Backup. . . . . . . . . . . . . 62
System Recovery Media . . . . . . . . . . . . . . . . 64
Dell Factory Image Restore . . . . . . . . . . . . . 65
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . .67
Technical Support and Customer
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
DellConnect . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Online Services . . . . . . . . . . . . . . . . . . . . . . . 69
Automated Order-Status Service . . . . . . . . . 70
Product Information. . . . . . . . . . . . . . . . . . . . 70
Returning Items for Repair Under
Warranty or for Credit . . . . . . . . . . . . . . . . . . 71
Before You Call. . . . . . . . . . . . . . . . . . . . . . . . 72
Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . . 74
Finding More Information and
Resources . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Specifications . . . . . . . . . . . . . . . . . . . . . . .78
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Macrovision Product Notice. . . . . . . . . . . . . 85
Information for NOM, or Official Mexican
Standard (Only for Mexico). . . . . . . . . . . . . . 86
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

5
This section provides information about setting
up your Dell™Inspiron™laptop.
Before Setting Up Your
Computer
When positioning your computer, ensure that
you allow easy access to a power source,
adequate ventilation, and a level surface to
place your computer.
Restricting airflow around your Inspiron
laptop may cause it to overheat. To prevent
overheating ensure that you leave at least
10.2 cm (4 inches) at the back of the computer
and a minimum of 5.1 cm (2 inches) on all other
sides. You should never place your computer in
an enclosed space, such as a cabinet or drawer
when it is powered on.
WARNING: Do not block, push objects
into, or allow dust to accumulate in
the air vents. Do not place your Dell™
computer in a low-airflow environment,
such as a closed briefcase, or on fabric
surfaces, such as carpets or rugs, while
it is powered on. Restricting the airflow
can damage the computer, deteriorate the
computer performance, or cause a fire.
The computer turns on the fan when the
computer gets hot. Fan noise is normal and
does not indicate a problem with the fan or
the computer.
CAUTION: Placing or stacking heavy or
sharp objects on the computer may result
in permanent damage to the computer.
Setting Up Your Inspiron Laptop
INSPIRON

6
Setting Up Your Inspiron Laptop
Connect the AC Adapter
Connect the AC adapter to the computer and then plug it into a wall outlet or surge protector.
WARNING: The AC adapter works with electrical outlets worldwide. However, power
connectors and power strips vary among countries. Using an incompatible cable or
improperly connecting the cable to a power strip or electrical outlet may cause fire or
permanent damage to your computer.
NOTE: Connect the power cable to the adapter firmly and ensure that the light on the adapter is
on when you turn on power.

7
Setting Up Your Inspiron Laptop
Connect the Network Cable (Optional)
To use a wired network connection, connect the network cable.

8
Setting Up Your Inspiron Laptop
Press the Power Button

9
Setting Up Your Inspiron Laptop
Set Up Microsoft Windows
Your Dell computer is preconfigured with the Microsoft®Windows®operating system. To set
up Windows for the first time, follow the instructions on the screen. These steps are mandatory
and may take some time to complete. The Windows setup screens will take you through several
procedures including accepting license agreements, setting preferences, and setting up an Internet
connection.
CAUTION: Do not interrupt the operating system’s setup process. Doing so may render your
computer unusable and you will need to reinstall the operating system.
NOTE: For optimal performance of your computer, it is recommended that you download and
install the latest BIOS and drivers for your computer available at support.dell.com.
NOTE: For more information on the operating system and features, see
support.dell.com/MyNewDell.

10
Setting Up Your Inspiron Laptop
Create System Recovery Media (Recommended)
NOTE: It is recommended that you create a system recovery media as soon as you set up
Microsoft Windows.
The system recovery media can be used to restore your computer to the operating state it was in
when you purchased the computer, while preserving data files (without the need of the Operating
System disc). You can use the system recovery media if changes to the hardware, software, drivers,
or other system settings have left the computer in an undesirable operating state.
You will require the following to create the system recovery media:
Dell DataSafe Local Backup•
USB key with a minimum capacity of 8 GB or DVD-R/DVD+R/Blu-ray Disc• ™
NOTE: Dell DataSafe Local Backup does not support rewritable discs.

11
Setting Up Your Inspiron Laptop
To create a system recovery media:
Ensure that the AC adapter is connected (see “Connect the AC Adapter” on page1. 6).
Insert the disc or USB key in the computer.2.
Click3. Start → Programs→Dell DataSafe Local Backup.
Click4. Create Recovery Media.
Follow the instructions on the screen.5.
NOTE: For information on using the system recovery media, see “System Recovery Media” on
page 64.

12
Setting Up Your Inspiron Laptop
Install the SIM Card (Optional)
CAUTION: Do not insert a SIM card into the SIM card slot if you have not purchased a
computer with a Mobile Broadband card. Doing so may render your computer unusable and
you will need a service technician to fix the computer. Check your purchase invoice to see if
you have purchased a Mobile Broadband card.
NOTE: Installing a SIM is not required if you are using an EVDO card to access the Internet.
Installing a Subscriber Identity Module (SIM) card allows you to browse the Internet, check e-mail,
and connect to a Virtual Private Network. To access these features, you must be within the network
of your cellular service provider.
To install the SIM card:
Turn off your computer.1.
Remove the battery (see “Removing and Replacing the Battery” on page2. 40).
In the battery bay, slide the SIM card into the SIM card slot.3.
Replace the battery (see “Removing and Replacing the Battery” on page4. 40).
Turn on your computer.5.
To remove the SIM card, press and eject the SIM card.

13
Setting Up Your Inspiron Laptop
1battery bay
2SIM card slot
3SIM card
1
2
3

14
Setting Up Your Inspiron Laptop
Enable or Disable Wireless (Optional)

15
Setting Up Your Inspiron Laptop
NOTE: The wireless feature is available on your computer only if you ordered a WLAN card
at the time of purchase. For more information on the cards supported by your computer, see
“Specifications” on page 78.
To enable wireless:
Ensure that your computer is turned on.1.
Press the wireless key2. on the function key row on the keyboard.
A confirmation of your selection appears on the screen.
Wireless enabled
Wireless disabled
To disable wireless:
Press the wireless key on the function key row on the keyboard again to turn off all radios.
NOTE: The wireless key allows you to quickly turn off all wireless radios (Wi-Fi and Bluetooth®)
on your computer, such as when you are asked to disable all wireless radios on an airplane
flight.

16
Setting Up Your Inspiron Laptop
Set Up Wireless Display
(Optional)
NOTE: The wireless display feature may
not be supported on all computers. For
information about the hardware and
software requirements for setting up
wireless display, see www.intel.com.
The Intel wireless display feature allows you
to share your computer display to a TV without
the use of cables. You must connect a wireless
display adapter to your TV before setting up
wireless display.
NOTE: The wireless display adapter does
not ship with your computer and must be
purchased separately.
If your computer supports the wireless display
feature, the Intel Wireless Display icon will
be available on the Windows desktop.
To set up wireless display:
Turn on your computer.1.
Press <Fn> along with the2. key on the
function key row on the keyboard to enable
wireless.
Connect the wireless display adapter to3.
the TV.
Turn on the TV.4.
Select the appropriate video source for your5.
TV, such as HDMI1, HDMI2, or S-Video.
Click the Intel Wireless Display icon6. on
the desktop.
The Intel Wireless Display window appears.
Select7. Scan for available displays.
Select your wireless display adapter from8.
the Detected wireless displays list.
Enter the security code that appears on9.
your TV.

17
Setting Up Your Inspiron Laptop
To enable wireless display:
Click the Intel Wireless Display icon1. on
the desktop.
The Intel Wireless Display window appears.
Select2. Connect to Existing Adapter.
NOTE: You can download and install the
latest driver for “Intel Wireless Display
Connection Manager” from
support.dell.com.
NOTE: For more information about wireless
display, see the wireless display adapter
documentation.

18
Setting Up Your Inspiron Laptop
Connect to the Internet
(Optional)
To connect to the Internet, you need an external
modem or network connection and an Internet
Service Provider (ISP).
If an external USB modem or WLAN adapter
is not a part of your original order, you can
purchase one from www.dell.com.
Setting Up a Wired Connection
If you are using a DSL or cable/satellite•
modem connection, contact your ISP
or cellular telephone service for setup
instructions.
If you are using a dial-up connection,•
connect the telephone line to the optional
external USB modem and to the telephone
wall connector before you set up your
Internet connection.
To complete setting up your wired Internet
connection, follow the instructions in “Setting
Up Your Internet Connection” on page 20.
