Dell™ LOB™ Latitude XT2
Setup and Features Information
1 grip 2 display
3 ambient light sensor (with
Dual-bulb CCFL LCD option
only)
4 device status lights
1 2
3
4
5
6
7
8
9
10
11
13
12
14
15
16
17
18
Month 2008
0XXXXXAXX
Model PP12S
AMG-Setup and Features Tech Sheet_IR.fm Page 9 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
Left Side View
5 digital array microphone 6 keyboard
7 AC adapter connector 8 USB connectors (2)
9 track stick buttons 10 keyboard
11 track stick 12 rotating hinge
13 digital array microphone 14 power button
15 Windows®security button 16 screen rotate button
17 QuickSet tablet settings button 18 e-mail application shortcut
button
1 pen indicator LED 2 pen
3 external wireless WAN
antenna
NOTE: The external antenna
is provided with WWAN cards
only and is not included in the
standard computer
configuration. The computer
comes with a plug that you
need to remove prior to
installing the antenna and
WWAN card.
4 IEEE 1394 connector
1
23 4 5 6 7
AMG-Setup and Features Tech Sheet_IR.fm Page 10 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
Right Side View
Back View
5 USB connector 6 air vent
7 speaker
1 wireless radio on/off switch 2 Wi-Fi Catcher™ button
3 USB connector 4 ExpressCard slot
5 Secure Digital (SD) card slot 6 headphones connector
7 microphone connector 8 security cable slot
1 AC adapter connector 2 video connector
3 tablet back button 4 scroll control button
134 6 78
5
2
134 6 7 852 9
AMG-Setup and Features Tech Sheet_IR.fm Page 11 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
WARNING: Do not block, push objects into, or allow dust to accumulate in the air
vents. Do not store your Dell™ computer in a low-airflow environment, such as a
closed briefcase, while it is running. Restricting the airflow can damage the computer
or cause a fire. The computer turns on the fan when the computer gets hot. Fan noise is
normal and does not indicate a problem with the fan or the computer.
Quick Setup
WARNING: Before you begin any of the procedures in this section, read the safety information
that shipped with your computer. For additional best practices information see
www.dell.com/regulatory_compliance.
WARNING: The AC adapter works with electrical outlets worldwide. However, power
connectors and power strips vary among countries. Using an incompatible cable or improperly
connecting the cable to the power strip or electrical outlet may cause fire or equipment damage.
CAUTION: When you disconnect the AC adapter cable from the computer, grasp the connector,
not the cable itself, and pull firmly but gently to avoid damaging the cable. When you wrap the AC
adapter cable, ensure that you follow the angle of the connector on the AC adapter to avoid
damaging the cable.
NOTE: Some devices may not be included if you did not order them.
1 Connect the AC adapter to the AC adapter connector on the computer and to the electrical
outlet.
2 Connect the network cable.
5 network connector 6 powered USB connector
7 rotating hinge 8 tablet grip
9 pen tether slot
AMG-Setup and Features Tech Sheet_IR.fm Page 12 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
3 Connect USB devices, such as a mouse or keyboard.
4 Connect IEEE 1394 devices, such as a DVD player.
5 Open the computer display and press the power button to turn on the computer.
AMG-Setup and Features Tech Sheet_IR.fm Page 13 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
NOTE: It is recommended that you turn on and shut down your computer at least once before you
install any cards or connect the computer to a docking device or other external device, such as a
printer.
Power button
Battery charge indicator.
AMG-Setup and Features Tech Sheet_IR.fm Page 14 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
Specifications
NOTE: Offerings may vary by region. For more information regarding the configuration of your
computer, click Start→Help and Support and select the option to view information about your
computer.
Video
Video type: integrated on system board, hardware accelerated
Data bus integrated video
Video controller Intel Integrated "Cantiga" UMA Graphics
Video memory up to 256 MB shared video memory
Battery
Type 4-cell "smart" lithium ion (28 WHr)
6-cell "smart" lithium ion (42 WHr)
Dimensions:
Depth
96.84 mm (3.81 inches)
Height
13.7 mm (0.54 inch)
Weight 0.26 kg (0.57 lb) (4 cell)
0.34 kg (0.74 lb) (6 cell)
Voltage 11.1 VDC
Temperature range:
Operating 0° to 35°C (32° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Coin-cell battery CR-2032
AC Adapter
Input voltage 90–264 VAC
Input current (maximum) 1.1 A
Input frequency 47–63 Hz
Output current 3.3 A (maximum at 4-second pulse);
2.3 A (continuous)
Output power 45 W, 65W(optional) or 90W(optional)
Rated output voltage 19.5 VDC
AMG-Setup and Features Tech Sheet_IR.fm Page 15 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
Finding Information
NOTE: Some features or media may be optional and may not ship with your computer.
Some features or media may not be available in certain countries.
Dimensions:
Height
16.0 mm (0.63 inches)
Width 63.0mm (2.48 inches)
Depth 88.0 mm (3.46 inches)
Temperature range:
Operating 0° to 40°C (32° to 1.04°F)
Storage –10° to 70°C (–50° to 158°F)
Physical
Height 25.4 mm (1.0 inch)
Width 297.0 mm (11.7 inches)
Depth 218.6 mm (8.6 inches)
Weight 1.62 kg (3.57 lb) (with 4-cell battery/LED
standard configuration)
1.93 kg (4.25 lb) (with 6-cell battery/DLV
standard configuration)
Environmental
Temperature range:
Operating 0° to 35°C (32° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity (maximum):
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
Altitude (maximum):
Operating –15.2 to 3048 m (–50 to 10,000 ft)
Storage –15.2 to 10,668 m (–50 to 35,000 ft)
AC Adapter (continued)
AMG-Setup and Features Tech Sheet_IR.fm Page 16 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
NOTE: Additional information may ship with your computer.
Document/Media/Label Contents
Service Tag/Express Service Code
The Service Tag/Express Service Code is
located on your computer.
• Use the Service Tag to identify your
computer when you use
support.dell.com or contact support.
• Enter the Express Service Code to direct
your call when contacting support
NOTE: Your Service Tag/Express Service
Code is located on your computer.
Drivers and Utilities Media
The Drivers and Utilities media is a CD or
DVD that may have shipped with your
computer.
• A diagnostic program for your computer
• Drivers for your computer
NOTE: Drivers and documentation updates
can be found at support.dell.com.
• Notebook System Software (NSS)
NOTE: Readme files may be included on
your media to provide last-minute updates
about technical changes to your computer
or advanced technical-reference material
for technicians or experienced users.
Operating System Media
The Operating System media is a CD or
DVD that may have shipped with your
computer.
Reinstall your operating system
Safety, Regulatory, Warranty, and Support
Documentation
This type of information may have
shipped with your computer. For
additional regulatory information, see the
Regulatory Compliance Homepage on
www.dell.com at the following location:
www.dell.com/regulatory_compliance.
• Warranty information
• Terms and Conditions (U.S. only)
• Safety instructions
• Regulatory information
• Ergonomics information
• End User License Agreement
Service Manual
The Service Manual for your computer
can be found at support.dell.com.
• How to remove and replace parts
• How to configure system settings
• How to troubleshoot and solve problems
AMG-Setup and Features Tech Sheet_IR.fm Page 17 Friday, October 17, 2008 10:22 AM

FILE LOCATION: N:\systems\amg\SFITS\Source\AMG-Setup and Features Tech Sheet_IR.fm
DELL CONFIDENTIAL – PRELIMINARY 10/17/08 – FOR PROOF ONLY
WARNING: A WARNING indicates a potential for property damage, personal injury, or
death.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
Dell Technology Guide
The Dell Technology Guide is available at
support.dell.com.
• About your operating system
• Using and maintaining devices
• Understanding technologies such as
RAID, Internet, Bluetooth
®
wireless
technology, e-mail, networking, and
more.
Microsoft®Windows®License Labe
Your Microsoft Windows License is
located on your computer.
• Provides your operating system product
key.
Document/Media/Label Contents
