Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Dell
Business Client
Re-Image “How-To” Guide
Latitude Ultrabook, E-Family &
Mobile Precision Notebook
Revision 17.0
A17
Mar 18th, 2016

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Contents
1 Overview.............................................................................................................................................................................................................4
2 “How-To” ............................................................................................................................................................................................................5
2.1 Supported Operating Systems........................................................................................................................................................5
2.2 Latitude E-Family & Mobile Precision New Features & Image Impact .......................................................................6
2.3 Latest Drivers / Applications and Utilities..................................................................................................................................8
2.4 Installation Sequence..........................................................................................................................................................................9
2.5 BIOS........................................................................................................................................................................................................... 12
2.6 Recommended Drivers / Applications Installation Order................................................................................................14
Appendix A - .NET Requirements ................................................................................................................................................................. 33
Appendix B - 512e / 4KBe HDD Re-image Guidelines ........................................................................................................................ 34
Appendix C - FAQs ............................................................................................................................................................................................... 39
Appendix D - Tables .............................................................................................................................................................................................41
- Control Point System Manager Features - Table B1....................................................................................................................41
- Control Point Security Manager Features – Table B2 ............................................................................................................... 42
- Dell Data Protection | Access, DDPA – Table B3.......................................................................................................................... 42
- Control Point Connection Manager Features – Table B4 ....................................................................................................... 43
Appendix E - E-Docks ......................................................................................................................................................................................... 44

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
1Overview
The purpose of this document is for reimaging Dell Latitude Ultrabook, E-Family & Mobile Precision
notebooks. Dell Latitude Ultrabook , E-Family & Mobile Precision notebooks systems ship with Microsoft
operating systems (see Chapter 2.1 for detail). These images include the Dell recommended software
stack and settings, drivers, and applications which are tested and validated with the system.
Drivers and applications must be installed on Dell Latitude E-Family & Mobile Precision systems in a
prescribed order to ensure optimal performance. Failure to install drivers and applications in this
document may result in undesirable performance.
Dell provides drivers and applications that are not included in Microsoft Operating Systems. These
drivers are required to enable the new technologies and features of Dell Latitude E-Family & Mobile
Precision products (e.g., including the 512e Advanced Format HDD (See appendix –B). Reinstalled images
should be built from a clean hand installed OS load and following the steps in this guide. Dell does not
recommend starting from an image built on previous generations of products or other computer
systems.
Dell recommends ensuring BIOS settings (including SATA configurations modes) are correctly set and
using the latest device drivers and applications when imaging their systems.
This “How-To” guide applies to the following Latitude systems:
Product 1st
Generation
2nd
Generation
3rd
Generation
4th Generation/
Ultrabook
5th Generation/
Ultrabook
6th Generation/
Ultrabook
7th Generation/
Ultra book
Latitude E-Family, Ultrabook and other
series
E4200
-
E6220
E6230
E7240
E5250/5250/E7250
E5270/E7270
E4300 E4310 E6320 E6330/3330 3340 3150
E5400 E5410
E5420/E5420m
E5430 E5440/3440 E5450/5450/3450/E74
50
E5470
E5500 E5510
E5520/E5520m
E5530
E5540/3540
E5550/
5550/3550
E5570/
3470/3570
E6400
E6410
E6420
E6430/E6430s/6430u
E6440
E6400 ATG
E6410 ATG E6420 ATG E6430 ATG
E7440 E7270/7370/
E7470
E6500
E6510
E6520
E6530
E6440/E6540
Precision
Mobile
Workstations
M2400 - - M2800 3510/5510
M4400 M4500 M4600 M4700 M4800 M7510
M6400
M6500
M6600
M6700
M6800
M7710

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2“How-To”
2.1 Supported Operating Systems
The following Microsoft operating systems have been validated for use on Dell Latitude E-Family &
Mobile Precision notebook computers:
Note
: Not all generation notebook computers can ship with below Microsoft operating
systems. XP only available via CFI service on 3
rd
and 4
th
Generation systems except Latitude
3330
•Microsoft Windows XP 32 Bit: Validated on 1st, 2nd, 3rd and 4th Generation systems.
•Vista 32 & 64-Bit: Validated on 1st, 2nd, and 3rd Generation systems.
•Windows 7 32 & 64-Bit: Validated on 2nd, 3rd,4th , 5th , 6th and 7th Generation systems except
7370(only support 64-Bit).
•Windows 8 32 -Bit: Validated on 3rd , 4th Generation systems
•Windows 8 64-Bit: Validated on 2nd, 3rd,4th and 5th Generation systems except E6440/E6540
•Windows 8.1 64-Bit: Validated on 6th and 7th Generation systems
•Windows 10 64-Bit: Validated on 7th Generation systems

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.2 Latitude E-Family & Mobile Precision New Features & Image Impact
Dell Latitude E-Family & Mobile Precision systems feature new hardware technologies which
require a new software stack, drivers, and / or applications. These products are not compatible with
previous images built or installed on none Latitude E-Family, Mobile Precision or previous Dell
products. Images between 1st, 2nd, 3rd, 4th , 5th , 6th and 7th generations Latitude E-Family & Mobile
Precision are also not compatible
Among these new hardware and technologies are:
2.2.1 New Features Offered on Latitude E-Family & Mobile Precision systems
Note
:
Not all features are available on all systems
oNew BIOS architecture – Latitude E-Family & Mobile Precision
oChipset
1. Intel Core i3, i5 & i7 Dual Core CPUs that include updated integrated graphics
o1st ~ 7th Generation Intel Core i3, i5, i7 CPUs that include updated integrated
graphicseSATA/SATA3
oIntel Turbo Boost
o512e / 4KBe Sector HDDs
oNVMe SSD on 7th
generation Latitude E-Family & Mobile Precision
oIntel AMT (Intel Active Management Technology) & vPRO
oIntel RAID Functionality – only for Mobile Precision
oGraphics controller (Intel, nVidia and AMD)
oHDMI Audio
oNetwork LoM (Intel and Broadcom)
oWireless LAN
oWireless WAN
oWiMAX
oBluetooth
oUWB -
Latitude E-Family & Mobile Precision 1
st
& 2
nd
generation
oDell Control Vault
oContactless smartcard / RFID
oWebcam
oUSB 3.0
oFree Fall Sensor on the mother board
oMulti-touch Touchpad
oDell Control Point,
1
st
and 2
nd
generation Latitude E-Family & Mobile Precision
oDell Feature Enhancement Package(DFEP) -
Latitude E-Family & Mobile Precision 3
rd
& 4
th
generation
oDell Quickset -
Latitude 3440, 3540

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
oDell Data Protection | Access(DDPA) - Latitude E-Family & Mobile Precision 3
rd
& 4
th
generation
o
Dell Data Protection | Security Tool(DDPST) - Latitude E-Family & Mobile Precision 5
th
, 6th
and 7
th
generation except Latitude 3440, 3540
oDell Data Protection | Encryption(DDPE) -
Latitude E-Family & Mobile Precision 3
rd
, 4
th
, 5th ,
6
th
and 7
th
generation except Latitude 3440, 3540
oPrivacy Panel
oTouch Screen Digitizer- Four Fingers touch with Stylus support on
Latitude E-Family &
Mobile Precision 3rd generation. Ten fingers touch support on Mobile Precision 4th
generation.
oLatitude On / Precision On - Reader, Flash, and ARM - Latitude E-Family & Mobile Precision 1
st
&2
nd
generation
oWiDi display -
Latitude E-Family & Mobile Precision 4
th
generation
oIntel® Responsiveness Technologies –
Latitude E-Family & Mobile Precision 4
th
and 5
th
generation
oDell Battery Management –
Latitude E-Family & Mobile Precision 4
th
generation
oDell Power Management –
Latitude E-Family & Mobile Precision 5
th
generation
oDell Command | Power Manager -
Latitude E-Family & Mobile Precision 6
th
and 7
th
generation
oType C connector , support Dell Dock (WD15) and Dell Thunderbolt Dock(TB15)
– Latitude
E-Family & Mobile Precision 7
th
generation

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.3 Latest Drivers / Applications and Utilities
oDell recommends always obtaining the latest and most updated BIOS, drivers, firmware,
and applications. Dell validated and tested drivers and applications are located on Dell’s
support web site http://www.dell.com/supportEnter the Service Tag or select the
product model and the model number
oSelect Operating System (32-Bit or 64-Bit version must be selected)
oChoose drivers and downloads

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.4 Installation Sequence
The list below is a general overview of drivers and applications that should be installed on Dell
Latitude E-Family & Mobile Precision systems in a prescribed order to ensure optimal performance.
Actual system configurations may vary.
Note
: Dell Alienware, Inspiron, Studio, XPS and Vostro Laptops may have different installation
sequence. Please refer to Dell Support Website for these Laptops.
2.4.1 Installation Sequence Overview

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.4.2 Installation Sequence & Features at a Glance:
2.4.2.1 BIOS, Drivers and Firmware:
oBIOS
oIntel Chipset - Helps Windows control system board components and controllers.
oIntegrated Wired Network Controller & Intel PROSet Utility / Application - Enables and
enhances the network controller
oMicrosoft Windows Update for critical Microsoft QFE or Dell Desktop System Software -
A compilation of critical Microsoft QFEs updates
oGraphics:
1. Enhances and optimizes video performance
2. Enables & provides additional functionality that are not included in MS native VGA
driver
•User customizable Power Management features
•Portability & behavioral profiles
•Multiple monitor support
oAudio - Enables and enhances the audio controller
oIntel Storage controller
oIntel Turbo Boost (only for E-Family 2nd generation systems. 3rd/4th generation systems
do not need this driver)
1. A driver-based power management mechanism for Intel i3, i5 and i7 processors
2. Intelligent power sharing across cores
3. Budgets power limits available to Processor or graphics turbo Processor
oControl Point Security Driver pack- only for E-Family 1st generation systems
1. Installs and enables the security devices & controllers
2. Even if you do not install the Control Point managers you should install the Control
Point security driver as it contains needed drivers
oNetworking & Communication
1. Wireless Local Area Network Adapters (WLAN) - Enables and enhances the Wireless
LAN network adapter
2. Dell WLAN Radio Switch Driver
3. Dell Airplane Mode Switch Driver
4. Wireless Personal Area Network Adapter (UWB / WPAN) - Enables and enhances the
UWB or Bluetooth Adapter
5. Mobile Broadband Wireless Wide Area Network Adapter (WWAN) - Enables and
enhances the Broadband wireless Adapter
oIntel vPro/AMT
oIntel DPTF
oIntel USB3.0/3.1
oMedia Memory Card / SmartCard controller - Enables and enhances the Media Memory /
SmartCard controller
oDriver set for Dell Dock (WD15) and Dell Thunderbolt Dock(TB15) – Latitude E-Family &
Mobile Precision 7th generation
oTouch Pad / Track Stick / Pointer - Enhances the pointing device features

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
oFree Fall Sensor
Modem - Enables and enhances the modem
oTouch Screen Digitizer
oControl Vault Driver Update (FingerPrint Reader, Contactless Smart Card reader tied in
DDPA package on E-Family 3rd & 4th generation systems)
2.4.2.2 Applications:
oDell Control Point (DCP)- 1st & 2nd generations Latitude E-Family & Mobile Precision
1. Control Point System Manager
•DCP Extended Battery Life – EBL
•Requires Dell DCP System Manager ( for all System Manager release )
•Requires Security driver (
for System Manager version 1.0 & 1.1 only )
•DCP – Ambient Light Sensor
•Requires Dell DCP-SM or ALS utility in case DCP-SM is not desired and under
Microsoft Windows Vista only
2. Control Point Connection Manager
3. Control Point Security Manager (Requires Dell Control Point security driver pack)
oDell Feature Enhance Package (DFEP) -
2
nd
, 3
rd
& 4
th
generations Latitude E-Family &
Mobile Precision
oDell Quickset – Latitude 3440, 3540
oDell Data Protection | Access
- 3
rd
& 4
th
generations Latitude E-Family & Mobile Precision
oDell Data Protection | Security Tool
– 5
th
, 6
th
and 7
th
generations Latitude E-Family &
Mobile Precision except Latitude 3440, 3540
oDell Data Protection | Encryption -
3
rd
,4
th
, 5
th
, 6th and 7thgenerations Latitude E-Family
& Mobile Precision
oLatitude On / Precision On – Reader, Flash, and ARM – 1
st
& 2
nd
generations Latitude E-
Family & Mobile Precision
1. Communication solution that is designed to provide quick access to business critical
data
oIntel Responsiveness Technology - 4th ,5th , 6th and 7th
generation Latitude E-Family &
Mobile Precision
1. Intel® Smart Response Technology
2. Intel® Rapid Start Technology
3. Intel® Smart Connect Technology
oDell Premier Color application -
3
rd
, 4th ,5th , 6th and 7th generation Latitude Mobile
Precision

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.5 BIOS
Dell recommends flashing the latest BIOS available to the system. This is posted on Dell’s driver &
downloads support web site (dell.com/support)under the “BIOS” section.
Some of the BIOS settings are critical to Operating System performance and installation. These are
as follows:
Settings System Configuration SATA Operation
•Disabled: SATA Controllers are hidden
•ATA, Basic Disk Operation mode, does not require additional storage driver.
Note
: eSATA is not functional in this mode
•AHCI, SATA bus is configured for AHCI mode (Advanced Disk Operation
mode) which offers faster performance, eSATA support, and increased battery
life. This mode requires an additional storage driver provided by Dell
•IRRT / RAID On, SATA bus is configured to support IRRT (Intel’s Rapid
Recovery Technology). This mode supports AHCI mode features as well as
disk mirroring (RAID-1). IRRT allows data backup and restoration. This mode
requires an additional storage driver provided by Dell
•RAID, SATA bus is configured to support RAID. This mode supports AHCI
mode features as well as disk mirroring (RAID-1). RAID allows data backup
and restoration. This mode requires an additional storage driver provided by
Dell.
Note
:
o RAID support requires second hard disk drive.
o For NVMe PCIe SSD support on 7th Generation, see “2.6.6 Intel
Storage” of this document
oIf AHCI, IRRT, RAID On, or RAID modes are selected, Intel’s Matrix Storage Manager / Intel
Rapid Storage Technology driver must be installed in conjunction with the installation of
the Operating System. See section “2.6.6 Intel Storage” of this document
TPM Security:
These options enable and configure the Trusted Platform Module (TPM). If TPM is to be
deployed, TPM must be enabled in the BIOS Setup program
1. Security TPM Security
•TPM Security:
•Disabled
(Default)
: The BIOS will not turn on the TPM during POST.
The TPM will be non-functional and invisible to the Operating System
•Enabled: The BIOS will turn the TPM during POST so that it can be used
by the Operating System
•Deactivate
(Default)
= The TPM will be deactivated
•Activate = The TPM will be enabled and activated
•Clear = The BIOS clears the information stored in the TPM

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Note
: This setting is not available for Non-TPM configuration of 4
th
generations
Latitude E-Family & Mobile Precision.
Intel Responsiveness Technology:
Please refer to Intel Responsiveness Technologies Guide for detail settings of these
features.

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.6 Recommended Drivers / Applications Installation Order
For best results, Dell recommends installing drivers / applications in the following order:
2.6.1 Intel Mobile Chipset Software Installation Utility
Microsoft Operating Systems might not include the updated Intel Chipset Mobile driver for Dell
Latitude E-Family & Mobile Precision notebooks, , Ultrabook . The Intel Mobile Chipset driver is
available on Dell’s driver & downloads support web site (dell.com/support) under the “Chipset”
section
2.6.2 Integrated Wired Network Controller (Ethernet)
Microsoft Operating Systems either do not provide native support or do not include the driver
recommended by Dell. Install the following Dell driver for network connectivity
Network Controller drivers are available on Dell’s driver & downloads support web site
(dell.com/support) under the “Network” section
Note
: To ensure full functionality of the Intel Gigabit Network adapter, Dell recommends
that you install the Intel PROSet available on Dell’s driver & downloads support web site
(dell.com/support) under the “Network” section
2.6.3 Dell System Software for critical Microsoft QFEs
Dell recommends installing all of the latest available fixes specific to the systems
For 1st,
2
nd
, & 3
rd
generation Latitude E-Family & Mobile Precision, these are available through
the Dell System Software utility posted on Dell’s driver & downloads support web site
(dell.com/support) under the “System Utilities” section
For 4
th
,5
th
, 6th and 7
th
generation Latitude E-Family & Mobile Precision, please enable the
Windows Update and connect to Internet once install the driver of Integrated Wired Network
Controller
2.6.4 Windows Update
Dell recommends performing Microsoft Windows updates to ensure the latest security,
reliability, and compatibility updates are installed. These updates can be downloaded from
Windowsupdate.Microsoft.com
2.6.5 Graphics:
oMicrosoft Operating Systems include the VGA graphics drivers only. Therefore for optimum
graphics performance, Dell recommends installing the Dell graphics driver applicable to

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
their system available on Dell’s driver & downloads support web site (dell.com/support)
under the “Video” section
Note
:
For the nVidia Discrete Graphics solution on Latitude E-Family & Mobile Precision 3
rd
above
Generation platforms, the following should be followed:
1.
First, install the Intel Media adapter Graphics driver that applies to the system
2.
Second, install the nVidia Discrete Graphics driver that applies to the system
Note
:
For the AMD Discrete Graphics solution on Latitude E-Family & Mobile Precision 5
th
above
Generation platforms , the following should be followed:
1.
First, install the Intel Media adapter Graphics driver that applies to the system
2.
Second, install the AMD Discrete Graphics driver that applies to the system
Note
:
Both 2
nd
& 3
rd
Generation Intel® Core™ CPUs are available on 4
th
generation Latitude E-
Family & Mobile Precision. Please re-install the Graphics driver when exchange CPU from
2
nd
Generation CPU to 3
rd
Generation CPU and vice versa.
Note
:
Both 3
rd
& 4
th
Generation Intel® Core™ CPUs are available on 5
th
generation Latitude E-
Family & Mobile Precision except Latitude 3440/3540. Please re-install the Graphics driver
when exchange CPU from 3
rd
Generation CPU to 4
th
Generation CPU and vice versa.
Under XP 32-Bit with service packs earlier than Service pack-3 and for Latitude E-Family &
Mobile Precision 1st generation only, the Audio driver must be installed prior to installing the
graphics driver. This applies to Intel graphics solution only. Please refer to the section 2.6.6
Audio in this document.
2.6.6 Audio:
Microsoft Operating Systems do not include the Audio driver recommended by Dell. The HD
Audio driver is available on Dell’s driver & downloads support web site (dell.com/support) under the
“Audio” section
Note
: Under XP 32-Bit only with service packs earlier than Service pack-3 and for Latitude
E-Family & mobile Precision 1st generation only, the Audio driver must be installed prior to
installing the graphics driver. This applies to Intel graphics solution only
2.6.7 Intel Storage - Intel Matrix Storage Manager / Intel Rapid Storage Technology
The Intel Matrix Storage Manager (IMSM) driver on Dell 1st generation Latitude E-Family &
Mobile Precision or Intel Rapid Storage Technology (IRST) driver on following generations of

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Latitude E-Family & Mobile Precision is required to be installed on Operating Systems in AHCI,
IRRT, RAID On, and RAID SATA modes.
The Intel IMSM or IRST application must also be installed
The SATA operation modes are configured in the BIOS. Refer to the BIOS section 2.5
If the SATA mode is configured in AHCI, IRRT, RAID On, or RAID mode, the IMSM / IRST driver
must be installed during the initial Operating System installation stages. The IMSM / IRST driver
is only available from Dell
If SATA configuration mode in the BIOS is set to either AHCI, IRRT, RAID On, or RAID, install the
Dell IMSM / IRST driver and application available on Dell’s driver & downloads support web site
(dell.com/support) under the “Serial ATA” section
Follow these steps to install the IMSM / IRST driver:
3. For Microsoft XP 32 & 64-Bit Operating Systems:
•Installing the Intel IMSM driver using the Floppy Drive
•Boot to the Dell Recovery DVD (RDVD) and select the Create RAID
driver from the list of items. You will need Floppy Disk Drive and a
diskette for this selection. The IMSM / IRST driver must be on the root
of the A:\
Note
:the latest IMSM / IRST driver can also be obtained from
dell.com/support under the “SATA Drivers” section
•Once the driver is extracted and stored on the target diskette, boot to
the operating system CD and start the installation
•In the initial stage of Windows Setup, press <F6> to install the third-
party IMSM SCSI or RAID drivers
•When prompted, insert the floppy disk containing the IMSM driver and
follow the instructions provided by Windows Setup
•After reading the floppy disk, either choose "Intel(R) ICH9M-E/M SATA
AHCI Controller" if in AHCI mode or "Intel(R) ICH8M-E/ICH9M-eSATA
RAID Controller" if in IRRT mode – select the appropriate driver to
install
4. For Microsoft Vista / Windows 7 /Windows 8.1/Win10(32 & 64-Bit) Operating
Systems:
•Installing the Intel IMSM / IRST driver after the installation of the
Operating System
•Boot to the Operating System DVD or Boot from PXE , then start the OS
installation
•After completing the OS installation, insert the Dell RDVD
•Select the IMSM / IRST driver and follow the installation procedure

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Note: the latest IMSM / IRST driver can also be obtained from
dell.com/support under the “
SATA Drivers
” section
Table : NVMe PCIe SSD support mode on 7th Generation
Latitude
Precision
OS
Win8.1/Win10
Win7
Win7/Win8.1/Win10
Boot Mode
UEFI RAID on
Legacy AHCI
UEFI RAID on
Solution
IRST required
Microsoft Hotfix
KB2990941 required
NOT install IRST
IRST required
2.6.8 Wireless Local Network Adapters (WLAN)
oMicrosoft Operating Systems do not provide native device driver support for WLAN
controllers featured in Dell Latitude E-Family & Mobile Precision systems. To obtain wireless
network functionality, install the Wireless LAN device driver applicable to the WLAN devices
installed in the notebook computer found under the “Network” section posted on Dell’s
driver & downloads support web site (dell.com/support). The installer also provides WLAN
application support which provides additional features including enterprise authentication
enhancements
Note
: Airplane mode is a setting to suspend radio signal transmitting that potentially
impact aircraft avionics or interfere with ground communication. Install Dell Airplane
Mode Switch Driver to support this mode, under the “Network” section posted on Dell’s
driver & downloads support web site (dell.com/support).
Note
: With Intel Wireless Display (WiDi) you can quickly connect your laptop to your
TV and projector using the Intel® Centrino®wireless solution that’s already built into
your laptop. Because it’s based on Wi-Fi*, there are no cables between the laptop and
TV/Projector. To obtain Wireless Display(ONLY applied to Intel WLAN) functionality,
install the Wireless Display Application found under the “Network” section posted on
Dell’s driver & downloads support web site (dell.com/support).
oMicrosoft Windows Operating Systems do not provide native device driver support for
WiMAX controllers featured in Dell E-Family systems. To obtain WiMAX functionality, install
the WiMAX software applicable to the WiMAX device installed in the notebook computer.
This is available on Dell’s driver & downloads support web site (dell.com/support) under the
“Network” section
oCustomers choosing to utilize the Dell Wireless (DW) WLAN Card Utility or Intel PROSet /
Wireless should not install Control Point Connection Manager. If Control Point Connection
Manager is installed, uninstall the existing Intel PROSet / Wireless or Dell Wireless WLAN
entries in Add / Remove Programs (or Programs and Features) before installing this
software. Customers may also choose to uninstall Dell Control Point Connection manager
or uncheck the Wi-Fi control within Dell Control Point Connection Manager

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Note
: With Wireless on 7th Gen platforms, There is a Dell WLAN Radio Switch Driver
that package provides the driver for the Dell WLAN Hot Key and is supported to auto-
disable WLAN/WWAN when LAN cable attached. This driver is under the “Network”
section posted on Dell’s driver & downloads support web site (dell.com/support).
2.6.9 Intel vPro or AMT (
Applicable ONLY to vPro Configurations
)
oIntel Active Management Technology (Intel AMT) allows users to easily manage networked
computers to:
1. Discover computing assets on a network
2. Remotely repair systems even after operating system failures
3. Protect networks from incoming threats while easily keeping software up to date
oEnsure that the following drivers provided by Dell are being installed prior to installing the
AMT drivers:
1. Intel Mobile Chipset driver
2. Intel 825xx Gigabit Platform LAN Network Device
3. Intel Wireless WLAN driver for WLAN AMT manageability via Intel WLAN adapter
oMicrosoft Operating Systems do not include the AMT drivers. The AMT drivers are available
on Dell’s driver & downloads support web site (dell.com/support) under the “Chipset”
section
1. For E-Family 1st generation systems
•Intel AMT HECI
•Intel AMT SOL/ LMS
2. For E-Family 2nd generation systems
•Intel AMT HECI (Unified AMT6 Driver)
3. For E-Family 3rd generation systems,
•Intel Unified AMT 7 Management Interface Driver
•Intel Identity Protection Technology (IPT) feature requires IPT Middleware to be
installed after the AMT Unified driver
4. For E-Family 4th generation systems,
•Intel Unified AMT 8 Management Interface Driver
•Intel Identity Protection Technology (IPT) feature was included in Intel Unified
AMT8 Management Interface Driver already.
5. For E-Family 5th generation systems,
•Intel Unified AMT 9 Management Interface Driver
•Intel Identity Protection Technology (IPT) feature was included in Intel Unified
AMT9 Management Interface Driver already.
6. For E-Family 6th generation systems,
•Intel(R) Management Engine Components Installer
7. For E-Family 7th generation systems,
•Intel(R) Management Engine Components Installer

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.6.10 DPTF
Microsoft XP 32 & 64-Bit, Vista 32 & 64-Bit, and Win7/8/8.1 32 & 64-Bit Operating Systems do
not include the Intel Dynamic Platform and Thermal Framework (DPTF) driver. Install the DPTF
driver available on Dell’s driver & downloads support web site (dell.com/support) under the
“Chipset” section
2.6.11 USB 3.0/3.1
Microsoft XP 32 & 64-Bit, Vista 32 & 64-Bit, and Win7/8/8.1 32 & 64-Bit Operating Systems do
not include the USB 3.0 driver. Install the Intel(R) USB 3.0 eXtensible Host Controller Driver and
Intel(R) USB 3.1 eXtensible Host Controller and Hub Driveravailable on Dell’s driver & downloads
support web site (dell.com/support) under the “Chipset” section
2.6.12 Media Memory Card Controller
Microsoft Operating Systems do not include the Memory Card controller driver. Install the
following driver provided by Dell:
•R5C8xx Ricoh driver is available on Dell’s driver & downloads support web site
(dell.com/support) found under the “Chipset” section
•PCI8412 TI driver (Applies only for M6500) is available on Dell’s driver & downloads
support web site (dell.com/support) found under the “Chipset” section
•O2 Micro driver (Applies for 3rd, 4th ,5th generation Latitude E-Family & Mobile
Precision except Latitude 3440/3540) is available on Dell’s driver & downloads
support web site (dell.com/support) found under the “Chipset” section
•Realtek driver (Applies for Latitude 3440/3540 and 6th, 7th generation Latitude E-
Family & Mobile Precision) is available on Dell’s driver & downloads support web site
(dell.com/support) found under the “Chipset” section
2.6.13 Dell Dock (WD15) and Dell Thunderbolt Dock (TB15) Driver Set
–
Applies to 7
th
generation Latitude E-Family & Mobile Precision only

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
To fully support new generation Dell Dock and Dell Thunderbolt Dock, DELL highly
recommend installing the following BIOS/Drivers step by step on 64 bit Windows OS
1. Flash the latest BIOS available to the system. This is posted on Dell’s driver &
downloads support web site (dell.com/support) under the “BIOS” section. Restart
system before next step.
2. Install Intel(R) Thunderbolt Controller Driver available to the system. This is
posted on Dell’s driver & downloads support web site (dell.com/support) under
the “Chipset” section. Restart system before next step.
3. Install Intel(R) Thunderbolt 3 Firmware Update available to the system. This is
posted on Dell’s driver & downloads support web site (dell.com/support) under
the “Docks/Stands” section. Restart system before next step.
4. Install Realtek USB GBE Ethernet Controller Driver for Dell Thunderbolt Dock
and Dell Dock available to the system. This is posted on Dell’s driver &
downloads support web site (dell.com/support) under the “Docks/Stands”
section.
5. Install Realtek USB Audio Driver for Dell Wireless Dock, Dell Thunderbolt
Dock, and Dell Dock available to the system. This is posted on Dell’s driver &
downloads support web site (dell.com/support) under the “Docks/Stands”
section.
6. For Windows 8.1 and Windows 10 OS only, install Patch for the USB
audio/mouse issue on Dell Thunderbolt Dock and Dell Dock available to the
system. This is posted on Dell’s driver & downloads support web site
(dell.com/support) under the “Docks/Stands” section. Restart system.
7. For Dell Thunderbolt Dock only, install ASMedia USB 3.0 Extended Host
Controller Driver for Dell Thunderbolt Dock available to the system. This is
posted on Dell’s driver & downloads support web site (dell.com/support) under
the “Docks/Stands” section. Restart system
NOTE:
Dock is required to connect to system during driver installation
NOTE:
Graphic driver should be also installed by following section 2.6.5
