Dell Latitude E6410 Manual

Setup and Features Information
Latitude E6410 — Front View
7
8
1ambient light sensor 2microphone
3camera LED
(optional)
4camera (optional)
5microphone 6display latch
7volume control
buttons
8Latitude ON™ button
9power button 10 right speaker
11 USB 2.0
connectors (2)
12 audio connectors
13 wireless switch 14 optical drive removal
button
15 optical drive 16 PC card or Express
card slot
17 IEEE 1394 connector 18 fingerprint reader
(optional)
19 contactless smart
card reader (optional)
20 Secure Digital (SD)
and MMC card slot
21 display latch release
button
22 touchpad buttons
23 touchpad 24 trackstick buttons
25 trackstick 26 left speaker
27 keyboard 28 device status lights
29 keyboard status light
2
6
4
3
12
13
10
15
19
18
29
28
17
21
23
24
1
9
11
25
26
16
14
20
5
22
27
Regulatory Model: PP27LA Regulatory Type: PP27LA001
Dell™Latitude™E6410/E6410 ATG
About Warnings
WARNING: A WARNING indicates a potential
for property damage, personal injury, or death.
February 2010
NC7NVam0.fm Page 1 Tuesday, February 16, 2010 4:39 PM

Latitude E6410 — Back View
WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow
environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the
fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.
1modem connector (optional)
2network connector
3power and battery status lights
4multimode DisplayPort connector
5AC adapter connector
6security cable slot
7video connector (VGA)
8e-SATA/USB 2.0 connector
9powered USB 2.0 connector
10 cooling vent
11 smart card slot
9
11
8
10
7
6
5
4
2
1
3
NC7NVam0.fm Page 2 Tuesday, February 16, 2010 4:39 PM

Latitude E6410 ATG — Front View
1ambient light sensor 2microphone
3camera LED (optional) 4camera (optional)
5microphone 6display latch
7volume control buttons 8Latitude ON button
9power button 10 right speaker
11 USB 2.0 connectors (2) 12 audio connectors
13 wireless switch 14 optical drive remov
button
15 optical drive 16 PC card or Express
card slot
17 IEEE 1394 connector 18 fingerprint reader
(optional)
19 contactless smart card
reader (optional)
20 Secure Digital (SD)
and MMC card slot
21 display latch release
button
22 touchpad buttons
23 touchpad 24 trackstick buttons
25 trackstick 26 keyboard
27 left speakers 28 device status light
29 keyboard status lights
11
7
8
2
6
3
12
13
19
18
22
21
24
1
9
25
26
15
10
16
17
14
20
5
28
27
23
29
4
NC7NVam0.fm Page 3 Tuesday, February 16, 2010 4:39 PM

Latitude E6410 ATG — Back View
WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow
environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer
turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.
1modem connector (optional)
2network connector
3power and battery status lights
4multimode DisplayPort connector
5AC adapter connector
6security cable slot
7video connector (VGA)
8eSATA/USB 2.0 connector
9powered USB 2.0 connector
10 cooling vent
11 smart card slot
11
9
10
8
7
6
5
2
1
4
3
NC7NVam0.fm Page 4 Tuesday, February 16, 2010 4:39 PM

1Connect the AC adapter to the
AC adapter connector on the portable
computer and to the electrical outlet.
2Connect the network cable
(optional).
3Connect USB devices, such as a
mouse or a keyboard (optional).
4Connect IEEE 1394 devices, such as
a DVD player (optional).
5Open the computer display and
press the power button to turn on
the computer.
NOTE: It is recommended that you
turn on and shut down your computer
at least once before you install any
cards or connect the computer to a
docking device or other external
device, such as a printer.
Quick Setup
WARNING: Before you begin any of
the procedures in this section, read the
safety information that shipped with
your computer. For additional best
practices information, see
www.dell.com/regulatory_compliance.
WARNING: The AC adapter works with
electrical outlets worldwide. However,
power connectors and power strips vary
among countries. Using an incompatible
cable or improperly connecting the cable
to the power strip or electrical outlet may
cause fire or equipment damage.
CAUTION: When you disconnect the
AC adapter cable from the computer,
grasp the connector, not the cable
itself, and pull firmly but gently to avoid
damaging the cable. When you wrap the
AC adapter cable, ensure that you
follow the angle of the connector on the
AC adapter to avoid damaging the cable.
NOTE: Some devices may not be
included if you did not order them.
NC7NVam0.fm Page 5 Tuesday, February 16, 2010 4:39 PM

Specifications
NOTE: Offerings may vary by region. For more information regarding
the configuration of your computer, click Start→Help and Support
and select the option to view information about your computer.
System Information
Processor type Intel®Core™ i5
Intel Core i7
Chipset Mobile Intel 5 series (QM57)
Video
Video type UMA Discrete (E6410 only)
Data bus PCI-E x16 Gen1
Video controller
UMA
Intel Graphics
Discrete NVIDIA Quadro NVS 3100M
Memory
Type DDR3, 1066 MHz
Memory module connector two SODIMM slots
Memory module capacity 1 GB, 2 GB, or 4 GB
Minimum memory 1 GB
Maximum memory 8 GB
Contactless Smart Card
Supported Smart Cards
and Technologies
ISO14443A — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps
ISO14443B — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps
ISO15693
HID iClass
FIPS201
NXP Desfire
Battery
Type 4-cell "smart" lithium ion (37 WHr)
6-cell "smart" lithium ion (60 WHr)
3-year life-time 9-cell "smart" lithium ion
(81 WHr)
9-cell "smart" lithium ion (90 WHr)
12-cell "smart" lithium ion slice (88 WHr)
Dimensions
4-cell/6- cell
Depth
206.11 mm (8.11 inches)
Height 19.81 mm (0.78 inch)
Width 47.00 mm (1.85 inches)
9-cell
Depth
207.77 mm (8.18 inches)
Height 22.10 mm (0.87 inch)
Width 68.83 mm (2.71 inches)
NC7NVam0.fm Page 6 Tuesday, February 16, 2010 4:39 PM

12-cell
Depth
14.48 mm (0.57 inch)
Height 217.17 mm (8.55 inches)
Width
322.07 mm (12.68 inches)
Weight
4-cell 235.87 g (0.52 lb)
6-cell 326.59 g (0.72 lb)
9-cell 480.81 g (1.06 lb)
12-cell 848.22 g (1.87 lb)
Voltage 11.10 V
Temperature range
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 60 °C (–40 °F to 140 °F)
Coin-cell battery 3 V CR2032 lithium coin cell
AC Adapter
Input voltage 100 V–240 V ~
Input current (maximum) 1.50 A
Input frequency 50–60 Hz
Output power 65 W / 90 W
Output current
65 W (E6410 with
UMA video only)
3.34 A continuous
90 W 4.62 A
Battery (continued)
Rated output voltage 19.50 VDC
Dimensions
65 W
Depth
127.00 mm (4.99 inches)
Height 16.00 mm (0.63 inch)
Width 66.04 mm (2.60 inches)
90 W
Depth
147.00 mm (5.78 inches)
Height 16.00 mm (0.63 inch)
Width 70.00 mm (2.75 inches)
Temperature range
Operating 0 °C to 40 °C (32 °F to 104 °F)
Storage –40 °C to 70 °C (–40 °F to 158 °F)
Physical
Latitude 6410
Depth 238.30 mm (9.38 inches)
Height 25.40 mm–30.99 mm
(1.00 inch–1.22 inches)
Width 334.77 mm (13.18 inches)
Weight (minimum) 1.95 kg (4.30 lb)
AC Adapter (continued)
NC7NVam0.fm Page 7 Tuesday, February 16, 2010 4:39 PM

Finding More Information and Resources
See the safety and regulatory documents that shipped with your computer
and the regulatory compliance website at
www.dell.com/regulatory_compliance for more information on:
• Safety best practices
• Warranty
• Terms and Conditions
• Regulatory certification
• Ergonomics
• End User License Agreement
________________
Information in this document is subject to change without notice.
© 2010 Dell Inc. All rights reserved. Printed in the U.S.A.
Reproduction of these materials in any manner whatsoever without the written
permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Latitude, and Latitude ON
are trademarks of Dell Inc.; Intel is a registered trademark and Core is a
trademark of Intel Corporation in the U.S. and other countries.
Other trademarks and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products.
Dell Inc. disclaims any proprietary interest in trademarks and trade names other
than its own.
Latitude 6410 ATG
Depth
245.62 mm (9.67 inches)
Height 31.24 mm (1.23 inches)
with port cover — 1.55 inches (39.37 mm)
Width 340.87 mm (13.42 inches)
Weight (minimum) 2.68 kg (5.90 lb)
Docking Connector
E-Family dock 144–pin docking connector
Environmental
Temperature range
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity
(maximum)
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
Altitude (maximum)
Operating –15.2 m to 3048 m (–50 ft to 10,000 ft)
Storage –15.2 m to 10,668 m (–50 ft to 35,000 ft)
Physical (continued)
NC7NVam0.fm Page 8 Tuesday, February 16, 2010 4:39 PM
