Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Dell
Business Client
Re-Image “How-To” Guide
Latitude Ultrabook, E-Family &
Mobile Precision Notebook
Revision 9.0
A09
June 15th, 2013

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
Contents
1 Overview........................................................................................................................................................................................................4
2 “How-To” .......................................................................................................................................................................................................5
2.1 Supported Operating Systems ....................................................................................................................................................5
2.2 Latitude E-Family & Mobile Precision New Features & Image Impact .....................................................................6
2.3 Latest Drivers / Applications and Utilities...............................................................................................................................8
2.4 Installation Sequence......................................................................................................................................................................9
2.5 BIOS...................................................................................................................................................................................................... 12
2.6 Recommended Drivers / Applications Installation Order ............................................................................................ 14
Appendix A - .NET Requirements ............................................................................................................................................................. 33
Appendix B - 512e / 4KBe HDD Re-image Guidelines ..................................................................................................................... 34
Appendix C - FAQs........................................................................................................................................................................................... 39
Appendix D - Tables........................................................................................................................................................................................ 41
- Control Point System Manager Features - Table B1................................................................................................................ 41
- Control Point Security Manager Features –Table B2............................................................................................................. 42
- Dell Data Protection | Access, DDPA –Table B3....................................................................................................................... 42
- Control Point Connection Manager Features –Table B4..................................................................................................... 43
Appendix E - E-Docks.....................................................................................................................................................................................44

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
1Overview
The purpose of this document is to detail the required steps for reimaging Dell Latitude Ultrabook, E-
Family & Mobile Precision notebooks.
Dell Latitude Ultrabook , E-Family & Mobile Precision notebooks systems ship with Microsoft operating
systems (see Chapter 2.1 for detail). These images include the Dell recommended software stack and
settings, drivers, and applications which are tested and validated with the system.
Drivers and applications must be installed on Dell Latitude E-Family & Mobile Precision systems in a
prescribed order to ensure optimal performance. Failure to install drivers and applications as detailed in
this document may result in undesirable performance.
Dell provides drivers and applications that are not included in Microsoft Operating Systems. These drivers
are required to enable the new technologies and features of Dell Latitude E-Family & Mobile Precision
products, including the 512e Advanced Format HDD (See appendix –B). Reinstalled images should be
built from a clean hand installed OS load and following the steps in this guide. Dell does not recommend
starting from an image built on previous generations of products or other computer systems.
Dell recommends ensuring BIOS settings (including SATA configurations modes) are correctly set and
using the latest device drivers and applications when imaging their systems.
This “How-To” guide applies to the following Latitude systems:
Product
1st Generation
2nd Generation
3rd Generation
4th
Generation/Ultrabook
5th
Generation/Ultrabook
Latitude E-Family, Ultrabook and
other series
E4200
-
E6220
E6230
E4300
E4310
E6320
E6330/3330
E5400
E5410
E5420/E5420m
E5430
E5500
E5510
E5520/E5520m
E5530
E6400
E6410
E6420
E6430/E6430s/6430u
E6540
E6400 ATG
E6410 ATG
E6420 ATG
E6430 ATG
E6500
E6510
E6520
E6530
Precision
Mobile
Workstations
M2400
-
-
M4400
M4500
M4600
M4700
M6400
M6500
M6600
M6700

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2“How-To”
2.1 Supported Operating Systems
The following Microsoft operating systems have been validated for use on Dell Latitude E-Family &
Mobile Precision notebook computers:
Note: Not all generation notebook computers can ship with below Microsoft operating
systems. XP only available via CFI service on 3
rd and 4 th Generation systems except Latitude
3330
Microsoft Windows XP 32 Bit: Validated on 1st, 2nd, 3rd and 4th Generation systems.
Vista 32 & 64-Bit: Validated on 1st, 2nd, and 3rd Generation systems.
Windows 7 32 & 64-Bit: Validated on 2nd, 3rd,4th and 5th Generation systems.
Windows 8 32 -Bit: Validated on 3rd , and 4th Generation systems
Windows 8 64-Bit: Validated on 3rd , 4th Generation systems, Latitude 3440 and Latitude
3540

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.2 Latitude E-Family & Mobile Precision New Features & Image Impact
Dell Latitude E-Family & Mobile Precision systems feature new hardware technologies which
require a new software stack, drivers, and / or applications. These products are not compatible with
previous images built or installed on none Latitude E-Family, Mobile Precision or previous Dell
products. Images between 1st, 2nd, 3rd, 4th and 5th generations Latitude E-Family & Mobile Precision
are also not compatible
Among these new hardware and technologies are:
2.2.1 New Features Offered on Latitude E-Family & Mobile Precision systems, All
Generations:
Note: Not all features are available on all systems
oNew BIOS architecture –Latitude E-Family & Mobile Precision
oChipset
1. Intel Core i3, i5 & i7 Dual Core CPUs that include updated integrated graphics
2. 1st ~ 4th Generation Intel Core i3, i5, i7 CPUs that include updated integrated graphics
oeSATA/SATA3
oIntel Turbo Boost
o512e / 4KBe Sector HDDs
oIntel AMT (Intel Active Management Technology) & vPRO
oIntel RAID Functionality –only for Mobile Precision
oGraphics controller (Intel, nVidia and AMD)
oHDMI Audio
oNetwork LoM (Intel and Broadcom)
oWireless LAN
oWireless WAN
oWiMAX
oBluetooth
oUWB - Latitude E-Family & Mobile Precision 1
st & 2 nd generation
oDell Control Vault
oContactless smartcard / RFID
oWebcam
oUSB 3.0
oFree Fall Sensor on the mother board
oMulti-touch Touchpad
oDell Control Point, 1
st and 2 nd generation Latitude E-Family & Mobile Precision
oDell Feature Enhancement Package(DFEP) - Latitude E-Family & Mobile Precision 3
rd & 4 th
generation
oDell Quickset - Latitude 3440, 3540
oDell Data Protection | Access(DDPA) - Latitude E-Family & Mobile Precision 3
rd
& 4
th
generation

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
o Dell Data Protection | Security Tool(DDPST) - Latitude E-Family & Mobile Precision 5
th
generation except Latitude 3440, 3540
oDell Data Protection | Encryption(DDPE) - Latitude E-Family & Mobile Precision 3
rd , 4 th
and
5
th generation except Latitude 3440, 3540
oPrivacy Panel
oTouch Screen Digitizer- Four Fingers touch with Stylus support on Latitude E-Family &
Mobile Precision 3
rd generation. Ten fingers touch support on Mobile Precision 4 th
generation.
oLatitude On / Precision On - Reader, Flash, and ARM - Latitude E-Family & Mobile Precision 1
st
&2
nd generation
oWiDi display - Latitude E-Family & Mobile Precision 4
th
generation
oIntel® Responsiveness Technologies – Latitude E-Family & Mobile Precision 4
th and 5 th
generation
oDell Battery Management – Latitude E-Family & Mobile Precision 4
th generation
oDell Power Management – Latitude E-Family & Mobile Precision 5
th generation

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.3 Latest Drivers / Applications and Utilities
Dell recommends always obtaining the latest and most updated BIOS, drivers, firmware, and
applications. Dell validated and tested drivers and applications are located on Dell’s support web
site http://support.dell.com/
oEnter the Service Tag or select the product model and the model number
oSelect Operating System (32-Bit or 64-Bit version must be selected)
oChoose drivers and downloads

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.4 Installation Sequence
The list below is a general overview of drivers and applications that must be installed on Dell
Latitude E-Family & Mobile Precision systems in a prescribed order to ensure optimal performance.
Actual system configurations may vary.
Note: Dell Alienware, Inspiron, Studio, XPS and Vostro Laptops may have different installation
sequence. Please refer to Dell Support Website for these Laptops.
2.4.1 Installation Sequence Overview

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.4.2 Installation Sequence & Features at a Glance:
2.4.2.1 BIOS, Drivers and Firmware:
oBIOS
oIntel Chipset - Helps Windows control system board components and controllers.
oDell Desktop System Software - A compilation of critical Microsoft QFEs updates
oMedia Memory Card / SmartCard controller - Enables and enhances the Media Memory /
SmartCard controller
oIntel Storage:
1. Intel Matrix Storage Manager –Latitude E-Family & Mobile Precision 1st generation
2. Intel Rapid Storage Technology –Latitude E-Family & Mobile Precision 2nd, 3rd, 4th
and 5th generations
oAudio - Enables and enhances the audio controller
oGraphics:
1. Enhances and optimizes video performance
2. Enables & provides additional functionality that are not included in MS native VGA
driver
User customizable Power Management features
Portability & behavioral profiles
Multiple monitor support
oIntel Turbo Boost (only for E-Family 2nd generation systems. 3rd/4th generation systems
do not need this driver)
1. A driver-based power management mechanism for Intel i3, i5 and i7 processors
2. Intelligent power sharing across cores
3. Budgets power limits available to Processor or graphics turbo Processor
oIntegrated Wired Network Controller & Intel PROSet Utility / Application - Enables and
enhances the network controller
oControl Point Security Driver pack- only for E-Family 1st generation systems
1. Installs and enables the security devices & controllers
2. Even if you do not install the Control Point managers you should install the Control
Point security driver as it contains needed drivers
oNetworking & Communication
1. Wireless Local Area Network Adapters (WLAN) - Enables and enhances the Wireless
LAN network adapter
2. Wireless Personal Area Network Adapter (UWB / WPAN) - Enables and enhances the
UWB or Bluetooth Adapter
3. Mobile Broadband Wireless Wide Area Network Adapter (WWAN) - Enables and
enhances the Broadband wireless Adapter
oTouch Pad / Track Stick / Pointer - Enhances the pointing device features
oFree Fall Sensor
oModem - Enables and enhances the modem
oIntel vPro or AMT –Enhances System Manageability

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
HW based solution using out-of-band communication for management
access to client systems (independent of the system state)
oUSB 3.0
oTouch Screen Digitizer
oControl Vault Driver Update (FingerPrint Reader, Contactless Smart Card reader tied in
DDPA package on E-Family 3rd & 4th generation systems)
2.4.2.2 Applications:
oDell Control Point (DCP)- 1st & 2nd generations Latitude E-Family & Mobile Precision
1. Control Point System Manager
DCP Extended Battery Life –EBL
Requires Dell DCP System Manager ( for all System Manager release )
Requires Security driver ( for System Manager version 1.0 & 1.1 only )
DCP –Ambient Light Sensor
Requires Dell DCP-SM or ALS utility in case DCP-SM is not desired and under
Microsoft Windows Vista only
2. Control Point Connection Manager
3. Control Point Security Manager (Requires Dell Control Point security driver pack)
oDell Feature Enhance Package (DFEP) - 2
nd , 3 rd & 4 th generations Latitude E-Family &
Mobile Precision
oDell Quickset –Latitude 3440, 3540
oDell Data Protection | Access - 3
rd & 4 th generations Latitude E-Family & Mobile Precision
oDell Data Protection | Security Tool –5
th generations Latitude E-Family & Mobile
Precision except Latitude 3440, 3540
oDell Data Protection | Encryption - 3
rd & 4 th generations Latitude E-Family & Mobile
Precision
oLatitude On / Precision On –Reader, Flash, and ARM – 1
st & 2 nd generations Latitude E-
Family & Mobile Precision
1. Communication solution that is designed to provide quick access to business critical
data
oIntel Responsiveness Technology - 4th and 5th generation Latitude E-Family & Mobile
Precision
1. Intel® Smart Response Technology
2. Intel® Rapid Start Technology
3. Intel® Smart Connect Technology
oDell Premier Color application, 3
rd & 4 th
generation Latitude Mobile Precision

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.5 BIOS
Dell recommends flashing the latest BIOS available to the system. This is posted on Dell’s driver &
downloads support web site (support.dell.com) under the “BIOS”section.
Some of the BIOS settings are critical to Operating System performance and installation. These are
as follows:
Settings System Configuration SATA Operation
Disabled: SATA Controllers are hidden
ATA, Basic Disk Operation mode, does not require additional storage driver.
Note : eSATA is not functional in this mode
AHCI, SATA bus is configured for AHCI mode (Advanced Disk Operation
mode) which offers faster performance, eSATA support, and increased battery
life. This mode requires an additional storage driver provided by Dell
IRRT / RAID On, SATA bus is configured to support IRRT (Intel’s Rapid
Recovery Technology). This mode supports AHCI mode features as well as
disk mirroring (RAID-1). IRRT allows data backup and restoration. This mode
requires an additional storage driver provided by Dell
RAID, SATA bus is configured to support RAID. This mode supports AHCI
mode features as well as disk mirroring (RAID-1). RAID allows data backup
and restoration. This mode requires an additional storage driver provided by
Dell.
Note:
o RAID support requires second hard disk drive.
oIf AHCI, IRRT, RAID On, or RAID modes are selected, Intel’s Matrix Storage Manager / Intel
Rapid Storage Technology driver must be installed in conjunction with the installation of
the Operating System. See section “2.6.4 Intel Storage” of this document

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
TPM Security:
Note:
 This setting is not available for Non-TPM configuration of 4
th generations
Latitude E-Family & Mobile Precision.
These options enable and configure the Trusted Platform Module (TPM). If TPM is to be
deployed, TPM must be enabled in the BIOS Setup program
2. Security TPM Security
TPM Security:
Disabled (Default) : The BIOS will not turn on the TPM during POST.
The TPM will be non-functional and invisible to the Operating System
Enabled: The BIOS will turn the TPM during POST so that it can be used
by the Operating System
Deactivate (Default) = The TPM will be deactivated
Activate = The TPM will be enabled and activated
Clear = The BIOS clears the information stored in the TPM
Intel Responsiveness Technology:
Please refer to Intel Responsiveness Technologies Guide for detail settings of these
features.

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.6 Recommended Drivers / Applications Installation Order
For best results, Dell recommends installing drivers / applications in the following order:
2.6.1 Intel Mobile Chipset Software Installation Utility
oMicrosoft Operating Systems might not include the updated Intel Chipset Mobile driver for
Dell Latitude E-Family & Mobile Precision notebooks, , Ultrabook . The Intel Mobile Chipset
driver is available on Dell’s driver & downloads support web site (support.dell.com) under
the “Chipset” section
2.6.2 Dell System Software for critical Microsoft QFEs
oDell recommends installing all of the latest available fixes specific to the systems
oFor 1st, 2
nd ,
& 3
rd generation Latitude E-Family & Mobile Precision,
these are available through
the Dell System Software utility posted on Dell’s driver & downloads support web site
(support.dell.com) under the “System Utilities”section
oFor 4
th and 5 th generation Latitude E-Family & Mobile Precision,
please enable the Windows
Update and connect to Internet once install the driver of Integrated Wired Network
Controller. (see more detail in chapter 2.6.22)
2.6.3 Media Memory Card Controller
oMicrosoft Operating Systems do not include the Memory Card controller driver. Install the
following driver provided by Dell:
R5C8xx Ricoh driver is available on Dell’s driver & downloads support web site
(support.dell.com) found under the “Chipset” section
PCI8412 TI driver (Applies only for M6500) is available on Dell’s driver & downloads
support web site (support.dell.com) found under the “Chipset” section
O2 Micro driver (Applies for 3rd, 4th and 5th generation Latitude E-Family & Mobile
Precision except Latitude 3440/3540) is available on Dell’s driver & downloads
support web site (support.dell.com) found under the “Chipset” section
Realtek RTS5179 driver (Applies for Latitude 3440/3540) is available on Dell’s driver &
downloads support web site (support.dell.com) found under the “Chipset” section
2.6.4 Intel Storage - Intel Matrix Storage Manager / Intel Rapid Storage Technology
oThe Intel Matrix Storage Manager (IMSM) driver on Dell 1st generation Latitude E-Family &
Mobile Precision or Intel Rapid Storage Technology (IRST) driver on 2nd & 3rd generations
Latitude E-Family & Mobile Precision is required to be installed on Operating Systems in
AHCI, IRRT, RAID On, and RAID SATA modes

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
oThe Intel IMSM or IRST application must also be installed
oThe SATA operation modes are configured in the BIOS. Refer to the BIOS section 2.5
oIf the SATA mode is configured in AHCI, IRRT, RAID On, or RAID mode, the IMSM / IRST
driver must be installed during the initial Operating System installation stages. The IMSM /
IRST driver is only available from Dell
-If SATA configuration mode in the BIOS is set to either AHCI, IRRT, RAID On, or RAID, install
the Dell IMSM / IRST driver and application available on Dell’s driver & downloads support
web site (support.dell.com) under the “Serial ATA” section

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
-Follow these steps to install the IMSM / IRST driver:
1. For Microsoft XP 32 & 64-Bit Operating Systems:
Installing the Intel IMSM driver using the Floppy Drive
Boot to the Dell Recovery DVD (RDVD) and select the Create RAID
driver from the list of items. You will need Floppy Disk Drive and a
diskette for this selection. The IMSM / IRST driver must be on the root
of the A:\
Note :the latest IMSM / IRST driver can also be obtained from
support.dell.com under the “SATA Drivers” section
Once the driver is extracted and stored on the target diskette, boot to
the operating system CD and start the installation
In the initial stage of Windows Setup, press <F6> to install the third-
party IMSM SCSI or RAID drivers
When prompted, insert the floppy disk containing the IMSM driver and
follow the instructions provided by Windows Setup
After reading the floppy disk, either choose "Intel(R) ICH9M-E/M SATA
AHCI Controller" if in AHCI mode or "Intel(R) ICH8M-E/ICH9M-eSATA
RAID Controller" if in IRRT mode –select the appropriate driver to
install
2. For Microsoft Vista / Windows 7 /Windows 8(32 & 64-Bit) Operating Systems:
Installing the Intel IMSM / IRST driver after the installation of the
Operating System
Boot to the Operating System DVD or Boot from PXE , then start the OS
installation
After completing the OS installation, insert the Dell RDVD
Select the IMSM / IRST driver and follow the installation procedure
Note: the latest IMSM / IRST driver can also be obtained from
support.dell.com under the “SATA Drivers” section
oIf Intel Rapid Recovery or RAID Technologies is to be used, ensure the following:
1. SATA operation mode in the BIOS is set to the appropriate IRRT, RAID On, or RAID
mode
2. Microsoft Operating System was installed under IRRT, RAID On, or RAID mode and
the latest Intel Storage IMSM / IRST driver is installed
3. Install the following Intel IMSM application provided by Dell:
Intel Matrix Storage Manager Application, or
Intel Rapid Storage Technology Application

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.6.5 Graphics:
oMicrosoft Operating Systems include the VGA graphics drivers only. Therefore for optimum
graphics performance, Dell recommends installing the Dell graphics driver applicable to
their system available on Dell’s driver & downloads support web site (support.dell.com)
under the “Video” section
Note :
For the nVidia Discrete Graphics solution on Latitude E-Family & Mobile Precision 3
rd & 4 th
Generation platforms (refer to the below table), the following should be followed:
1. First, install the Intel Media adapter Graphics driver that applies to the system
2. Second, install the nVidia Discrete Graphics driver that applies to the system
Note :
For the AMD Discrete Graphics solution on Latitude E-Family & Mobile Precision 5
th
Generation platforms (refer to the below table), the following should be followed:
1. First, install the Intel Media adapter Graphics driver that applies to the system
2. Second, install the AMD Discrete Graphics driver that applies to the system
Note :
Both 2
nd & 3 rd Generation Intel® Core™ CPUs are available on 4 th generation Latitude E-
Family & Mobile Precision. Please re-install the Graphics driver when exchange CPU from
2
nd Generation CPU to 3 rd Generation CPU and vice versa.
Note :
Both 3
rd & 4 th Generation Intel® Core™ CPUs are available on 5 th generation Latitude E-
Family & Mobile Precision except Latitude 3440/3540. Please re-install the Graphics driver
when exchange CPU from 3
rd Generation CPU to 4 th Generation CPU and vice versa.
oUnder XP 32-Bit with service packs earlier than Service pack-3 and for Latitude E-Family &
Mobile Precision 1st generation only, the Audio driver must be installed prior to installing the
graphics driver. This applies to Intel graphics solution only. Please refer to the section 2.6.6
Audio in this document.
oThe following table lists the various graphics solutions’ offerings on Dell Latitude E-Family &
Mobile Precision products:

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2.6.6 Audio:
oMicrosoft Operating Systems do not include the Audio driver recommended by Dell. The
HD Audio driver is available on Dell’s driver & downloads support web site (support.dell.com)
under the “Audio” section
Note : Under XP 32-Bit only with service packs earlier than Service pack-3 and for Latitude
E-Family & mobile Precision 1st generation only, the Audio driver must be installed prior to
installing the graphics driver. This applies to Intel graphics solution only
2.6.7 Intel Turbo Boost Driver ( only for 2
nd generation Latitude E-Family & Mobile Precision)
oIntel Turbo Boost driver is required to be installed on platforms meeting both of following
criteria:
1. nVidia or ATI discrete graphics cards
E4200
E4300
E5400
E5500
E6400
E6400 ATG
E6500
M2400
M4400
M6400
E6410
E6410 ATG
E6510
M4500
M6500
E5420 / E5520
E6320
E6420
E6420 ATG
E6520
M4600
M6600
E5430 / E5530
E6230/E6330/E
6430u/3330
E6430/E6430s
E6430 ATG
E6530
M4700
M6700
3440/3540
E6540
Intel GMA 4500MHD Graphics X X X X X X X
Intel GMA HD Graphics X X X X
Intel Media Adapter HD/HD 2000/3000/4000/5000 X X X X X X X X X X X X
Quadro NVS 160M X X X X X
Quadro FX 2700M / 3700M X
Quadro NVS 3100M X X
Quadro FX 880M & 1800M X
Quadro FX 2800M / 3800M X
N12M 512MB DDR3 with Optimus X X X
Quadro 1000M/2000M with 2GB GDDR3 and Opitimus X X
Quadro 3000M/4000M with 2GB GDDR3 and Opitimus X X
Quadro 5000M with 4GB GDDR3 and Opitimus X X
NVS 5200M 1GB DDR3 and Optimus X X X
ATI FirePro M7740 X X
AMD FirePro M5950 Mobility Pro Graphics with 1GB GDDR5 X X X
AMD FirePro M8900 Mobility Pro Graphics with 2GB GDDR5 X
AMD FirePro M4000 Mobility Pro Graphics with 1GB GDDR5 X X X
AMD FirePro M6000 Mobility Pro Graphics with 2GB GDDR5 X
AMD Radeon HD 8850M X
AMD Radeon HD 8790M X
5th Generation
4th Generation
AMD
1st Generation
2nd Generation
3rd Generation
nVidia
Intel
Graphic Solution

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
2. Core i7 and i5 Dual Core CPUs
oMicrosoft Operating Systems do not include the Intel Dual-Core Turbo Boost driver. Install
the following driver provided by Dell:
Dual-Core Turbo Boost driver is available on Dell’s driver & downloads support web
site (support.dell.com) found under the “CPU” section
2.6.8 Integrated Wired Network Controller (Ethernet)
-Microsoft Operating Systems XP 32 & 64-Bit, Vista 32 & 64-Bit, and Win7/8 32 & 64-Bit either
do not provide native support or do not include the driver recommended by Dell. Install the
following Dell driver for network connectivity
-Network Controller drivers are available on Dell’s driver & downloads support web site
(support.dell.com) under the “Network” section
Note : To ensure full functionality of the Intel Gigabit Network adapter, Dell recommends
that you install the Intel PROSet available on Dell’s driver & downloads support web site
(support.dell.com) under the “Network” section
2.6.9 Dell Control Point –DCP , (applies to 1
st & 2 nd generations Latitude E-Family &
Mobile Precision only)
2.6.9.1 Control Point Security Device Driver
Note :for 2nd generation Latitude E-Family & Mobile Precision, the Control Point
Security Device driver needs to be applied only if the Control Point Security Manager
is used, it is not required for the Dell Data Protection | Access suite.
oMicrosoft Operating System does not have the desired drivers and applications
necessary for the security functions offered on Latitude E-Family & Mobile
Precision
E4200
E4300
E5400
E5500
E6400
E6400 ATG
E6500
M2400
M4400
M6400
E4310
E5410
E5510
E6410
E6410 ATG
E6510
M4500
M6500
E5420 /
E6320
E6420
E6420 ATG
E6520
M4600
M6600
E5430 /
E6230/E6330/
E6430/E6430s
/E6430u
E6430 ATG
E6530
M4700
M6700
E5430 /
3440/3540
E6540
Intel 825xx Gigabit
Platform LAN Network
X X X X X X X X X X X X X X X X X X X X X X X X
Broadcom 57XX Gigabit
Integrated Controller
X X X X X X X X X
Realtek RTL8111G LAN
Network
X
5th Generation
Solution
1st Generation
2nd Generation
3rd Generation
4th Generation

Dell Latitude Ultrabook, E-Family & Mobile Precision Reimage “How-To” Guide
oThe driver will install the device driver for the security devices installed in the Dell
E-Family notebook computer. In addition, it will install Microsoft Net framework
2.0 SP1 and any relevant Microsoft QFEs required allowing these security devices
to operate correctly
oThe driver supports the following Security devices:
1. Broadcom Trusted Platform Module
2. Atmel Trusted Platform Module
3. STMicroelectronics Trusted Platform Module
4. Winbond Trusted Platform Module
5. O2Micro Smart Card Reader
6. Dell Smart Card Keyboard
7. UPEK TouchChip Fingerprint Reader
8. Authentec Fingerprint Reader
9. Broadcom Unified Security Hub
10. Vista Storage driver Update (for ATAPI.SYS)
oThe Control Point Security Device Driver is available on Dell’s driver & downloads
support web site (support.dell.com) under the “Control Point” section
2.6.9.2 Control Point System Manager
oDell Control Point System Manager module is a Dell developed modular
application providing a complete set of power management configuring and
alerting capabilities:
oBattery Status
oPower Scheme and Sleep Mode
oDisplay and Devices
oKeyboard Backlighting and Hotkeys Customization
oExtended Battery Life / All Day Battery Life
oThe Control Point System Manager Application is available on Dell’s driver &
downloads support web site (support.dell.com) under “Control Point” section
-Refer to Table B1 under Appendix-B for DCP System Manager features
-For Extended Battery Life feature (EBL), install the Dell Control Point components
offered by Dell in addition to the System Manager Module( version 1.2 & 1.3)
oControl Point System Security Manager driver ( applies to Control Point System
Manager 1.0 and 1.1 )
oControl Point System Manager XML file ( applies to Control Point System
Manager 1.0, 1.1, 1.2 and 1.3. Not required for 1.4 and beyond )
oFor Ambient Light Sensor (ALS), install the Dell Ambient Light Sensor Utility
component of Control Point in addition to the System Manager Module. This
