Dell Precision M6600 User manual

Dell Precision M6600 Owner's Manual
Regulatory Model P10E
Regulatory Type P10E001

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your
computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal injury, or
death.
Information in this publication is subject to change without notice.
©2011 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is
strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, Dell Precision™, Precision ON™,ExpressCharge™,
Latitude™, Latitude ON™, OptiPlex™, Vostro™, and Wi-Fi Catcher™are trademarks of Dell Inc. Intel®,
Pentium®, Xeon®, Core™, Atom™, Centrino®, and Celeron®are registered trademarks or trademarks of Intel
Corporation in the U.S. and other countries. AMD®is a registered trademark and AMD Opteron™,
AMD Phenom™, AMD Sempron™, AMD Athlon™, ATI Radeon™, and ATI FirePro™are trademarks of
Advanced Micro Devices, Inc. Microsoft®, Windows®, MS-DOS®, Windows Vista®, the Windows Vista start
button, and Office Outlook®are either trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries. Blu-ray Disc™is a trademark owned by the Blu-ray Disc Association
(BDA) and licensed for use on discs and players. The Bluetooth®word mark is a registered trademark and
owned by the Bluetooth®SIG, Inc. and any use of such mark by Dell Inc. is under license. Wi-Fi®is a
registered trademark of Wireless Ethernet Compatibility Alliance, Inc.
Other trademarks and trade names may be used in this publication to refer to either the entities claiming the
marks and names or their products, Dell Inc. disclaims any proprietary interest in trademarks and trade
names other than its own.
2011 — 06
Rev. A00

Contents
Notes, Cautions, and Warnings..................................................................2
1 Working on Your Computer......................................................................9
Before Working Inside Your Computer.............................................................................9
Recommended Tools.......................................................................................................10
Turning Off Your Computer..............................................................................................11
After Working Inside Your Computer..............................................................................11
2 Secure Digital (SD) Card.........................................................................13
Removing The Secure Digital (SD) Card.........................................................................13
Installing The Secure Digital (SD) Card...........................................................................13
3 ExpressCard..............................................................................................15
Removing the ExpressCard.............................................................................................15
Installing The ExpressCard..............................................................................................15
4 Battery........................................................................................................17
Removing The Battery.....................................................................................................17
Installing The Battery......................................................................................................17
5 Subscriber Identity Module (SIM) Card...............................................19
Removing The Subscriber Identity Module (SIM )Card..................................................19
Installing The Subscriber Identity Module (SIM )Card...................................................20
6 Bluetooth Card..........................................................................................21
Removing The Bluetooth Card.........................................................................................21
Installing The Bluetooth Card..........................................................................................22
7 Base Cover................................................................................................23
Removing The Base Cover..............................................................................................23

Installing The Base Cover...............................................................................................24
8 Keyboard Trim...........................................................................................25
Removing The Keyboard Trim.........................................................................................25
Installing The Keyboard Trim..........................................................................................26
9 Keyboard....................................................................................................27
Removing The Keyboard.................................................................................................27
Installing The Keyboard..................................................................................................29
10 Optical Drive............................................................................................31
Removing The Optical Drive............................................................................................31
Installing The Optical Drive.............................................................................................32
11 Primary Hard Drive.................................................................................33
Removing The Primary Hard Drive..................................................................................33
Installing The Primary Hard Drive...................................................................................35
12 Secondary Hard Drive...........................................................................37
Removing The Secondary Hard Drive.............................................................................37
Installing The Secondary Hard Drive..............................................................................38
13 Wireless Local Area Network (WLAN) Card.....................................39
Removing Wireless Local Area Network (WLAN) Card..................................................39
Installing The Wireless Local Area Network (WLAN) Card............................................40
14 Wireless Wide Area Network (WWAN) Card...................................41
Removing The Wireless Wide Area Network (WWAN) Card.........................................41
Installing The Wireless Wide Area Network (WWAN) Card..........................................42
15 Primary Memory.....................................................................................43
Removing The Primary Memory......................................................................................43
Installing The Primary Memory.......................................................................................44

16 Secondary Memory...............................................................................45
Removing The Secondary Memory.................................................................................45
Installing The Secondary Memory..................................................................................46
17 CPU Fan....................................................................................................47
Removing The CPU Fan...................................................................................................47
Installing The CPU Fan....................................................................................................48
18 Coin-Cell Battery....................................................................................49
Removing The Coin-Cell Battery.....................................................................................49
Installing The Coin-Cell Battery.......................................................................................50
19 Palm Rest.................................................................................................51
Removing The Palm Rest.................................................................................................51
Installing The Palm Rest..................................................................................................56
20 CPU and Heatsink...................................................................................57
Removing The CPU Heatsink...........................................................................................57
Installing The CPU Heatsink............................................................................................58
21 Processor................................................................................................59
Removing The Processor................................................................................................59
Installing The Processor.................................................................................................60
22 Graphics Card Heatsink........................................................................61
Removing The Graphics Card Heatsink...........................................................................61
Installing The Graphics Card Heatsink............................................................................64
23 Graphics Card.........................................................................................65
Removing The Graphics Card..........................................................................................65
Installing The Graphics Card...........................................................................................66
24 ExpressCard Module.............................................................................67
Removing The ExpressCard Module...............................................................................67

Installing The ExpressCard Module................................................................................68
25 Input/Output Board................................................................................69
Removing The Input/Output Board..................................................................................69
Installing The Input/Output Board...................................................................................71
26 DC-in Jack...............................................................................................73
Removing The DC-in Jack...............................................................................................73
Installing The DC-in Jack................................................................................................75
27 Display Assembly...................................................................................77
Removing The Display Assembly....................................................................................77
Installing The Display Assembly.....................................................................................81
28 System Board..........................................................................................83
Removing The System Board..........................................................................................83
Installing The System Board...........................................................................................86
29 Touchscreen Display Bezel..................................................................87
Removing The Touchscreen Display Bezel.....................................................................87
Installing The Touchscreen Display Bezel......................................................................89
30 Touchscreen Display Panel..................................................................91
Removing The Touchscreen Display Panel.....................................................................91
Installing The Touchscreen Display Panel......................................................................94
31 Display Bezel...........................................................................................95
Removing The Display Bezel...........................................................................................95
Installing The Display Bezel............................................................................................96
32 Display Panel..........................................................................................97
Removing The Display Panel...........................................................................................97
Installing The Display Panel............................................................................................99

33 Camera...................................................................................................101
Removing The Camera..................................................................................................101
Installing The Camera...................................................................................................102
34 Display Hinge Cap Tower....................................................................103
Removing The Display Hinge Cap Tower......................................................................103
Installing The Display Hinge Cap Tower.......................................................................105
35 Low-Voltage Differential Signaling (LVDS) Camera Cable............107
Removing The Low-Voltage Differential Signaling (LVDS) Camera Cable....................107
Installing The Low-Voltage Differential Signaling (LVDS) Camera Cable.....................109
36 Specifications.......................................................................................111
Technical Specifications...............................................................................................111
37 System Setup........................................................................................117
System Setup Overview................................................................................................117
Entering System Setup..................................................................................................117
System Setup Menu Options.........................................................................................117
38 Diagnostics............................................................................................131
Device Status Lights......................................................................................................131
Battery Status Lights.....................................................................................................131
Diagnostics....................................................................................................................131
39 Contacting Dell.....................................................................................135
Contacting Dell .............................................................................................................135

8

Working on Your Computer 1
Before Working Inside Your Computer
Use the following safety guidelines to help protect your computer from potential
damage and to help to ensure your personal safety. Unless otherwise noted,
each procedure included in this document assumes that the following
conditions exist:
• You have performed the steps in Working on Your Computer.
• You have read the safety information that shipped with your computer.
• A component can be replaced or--if purchased separately--installed by
performing the removal procedure in reverse order.
WARNING: Before working inside your computer, read the safety information that
shipped with your computer. For additional safety best practices information, see
the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface, such as a
connector on the back of the computer.
CAUTION: Handle components and cards with care. Do not touch the components
or contacts on a card. Hold a card by its edges or by its metal mounting bracket.
Hold a component such as a processor by its edges, not by its pins.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab, not
on the cable itself. Some cables have connectors with locking tabs; if you are
disconnecting this type of cable, press in on the locking tabs before you disconnect
the cable. As you pull connectors apart, keep them evenly aligned to avoid bending
any connector pins. Also, before you connect a cable, ensure that both connectors
are correctly oriented and aligned.
9

NOTE: The color of your computer and certain components may appear differently
than shown in this document.
To avoid damaging your computer, perform the following steps before you begin
working inside the computer.
1. Ensure that your work surface is flat and clean to prevent the computer
cover from being scratched.
2. Turn off your computer (see Turning Off Your Computer ).
3. If the computer is connected to a docking device (docked) such as the
optional Media Base or Battery Slice, undock it.
CAUTION: To disconnect a network cable, first unplug the cable from your
computer and then unplug the cable from the network device.
4. Disconnect all network cables from the computer.
5. Disconnect your computer and all attached devices from their electrical
outlets.
6. Close the display and turn the computer upside-down on a flat work
surface.
NOTE: To avoid damaging the system board, you must remove the main battery
before you service the computer.
7. Remove the main battery (see Battery ).
8. Turn the computer top-side up.
9. Open the display.
10. Press the power button to ground the system board.
CAUTION: To guard against electrical shock, always unplug your computer from the
electrical outlet before opening the display.
CAUTION: Before touching anything inside your computer, ground yourself by
touching an unpainted metal surface, such as the metal at the back of the
computer. While you work, periodically touch an unpainted metal surface to
dissipate static electricity, which could harm internal components.
11. Remove any installed ExpressCards or Smart Cards from the appropriate
slots.
Recommended Tools
The procedures in this document may require the following tools:
• Small flat-blade screwdriver
10

• #0 Phillips screwdriver
• #1 Phillips screwdriver
• Small plastic scribe
• Flash BIOS update program CD
Turning Off Your Computer
CAUTION: To avoid losing data, save and close all open files and exit all open
programs before you turn off your computer.
1. Shut down the operating system:
• In Windows Vista :
Click Start , then click the arrow in the lower-right corner of the
Start menu as shown below, and then click Shut Down.
• In Windows XP:
Click Start → Turn Off Computer → Turn Off . The computer turns off
after the operating system shutdown process is complete.
2. Ensure that the computer and all attached devices are turned off. If your
computer and attached devices did not automatically turn off when you
shut down your operating system, press and hold the power button for
about 4 seconds to turn them off.
After Working Inside Your Computer
After you complete any replacement procedure, ensure you connect any
external devices, cards, and cables before turning on your computer.
CAUTION: To avoid damage to the computer, use only the battery designed for this
particular Dell computer. Do not use batteries designed for other Dell computers.
1. Connect any external devices, such as a port replicator, battery slice, or
media base, and replace any cards, such as an ExpressCard.
2. Connect any telephone or network cables to your computer.
11

CAUTION: To connect a network cable, first plug the cable into the network device
and then plug it into the computer.
3. Replace the battery.
4. Connect your computer and all attached devices to their electrical outlets.
5. Turn on your computer.
12

Secure Digital (SD) Card 2
Removing The Secure Digital (SD) Card
1. Follow the procedures in Before Working On Your Computer
2. Press in the Secure Digital (SD) memory card to release it.
3. Slide the SD memory card out of the computer.
Installing The Secure Digital (SD) Card
1. Locate the Secure Digital (SD) memory card compartment on the left side of
the chassis.
2. Push the SD memory card into the compartment until it is fully engaged
with a click sound.
13

14

ExpressCard 3
Removing the ExpressCard
1. Follow the procedures in Before Working On Your Computer .
2. Press in on the ExpressCard gently to release it from the computer.
3. Grasp the ExpressCard and pull out to release from the computer.
Installing The ExpressCard
1. Slide the ExpressCard into its slot until it clicks into place.
2. Follow the procedures in
After working inside your computer .
15

16

Battery 4
Removing The Battery
1. Follow the procedures in Before Working On Your Computer .
2. Slide the battery release latch into the unlock position.
3. Remove the battery from the computer.
Installing The Battery
1. Slide the battery back into the computer.
2. The battery release latch automatically clicks back to the locked position.
3. Follow the procedures in
After Working Inside Your Computer .
17

18

Subscriber Identity Module (SIM)
Card 5
Removing The Subscriber Identity Module (SIM )Card
1. Follow the procedures in
Before Working On Your Computer .
2. Remove the battery .
3. Slide the Subscriber Identity Module (SIM) outward away from the slot.
4. Pull out the SIM from the slot.
19

Installing The Subscriber Identity Module (SIM )Card
1. Locate the Subscriber Identity Module (SIM) card slot in the battery
compartment.
2. Push the SIM card into the slot until it is fully engaged.
3. Replace the
battery .
4. Follow the procedures in After Working Inside Your Computer .
20
