Table Of Contents
Description Page Description Page
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
6.Mechanical Instruction………………..……..…..….......29
7.Schematic Diagram………..................................….....34
7.1Main Board......………......................................34
7.2 Power Board……..…….……....................................38
7.3 Key Board………………………...…………………….40
8.PCB Layout..……...………….......................................41
8.1.Main Board……………..…........................................41
8.2.Power Board……………........................................43
8.3.Key Board………………….....................................44
9.Maintainability………….......................................45
9.1.Equipments and Tools Requirement..…….…...........45
9.2.Trouble Shooting………………….............................45
10.White-Balance, Luminance adjustment...……….....51
11.ISP Instruction…………….…….................................53
12.Monitor Exploded View…………….…………............57
13.BOM List………….....................................................59
14.Different Parts List………………...……………………71
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVIC
ING
Table Of Contents.......…….................……...........…........1
Revision List.….........................………................……......2
ECN History.….......................………..................……......3
Important Safety Notice.….……….…..................……......4
1.Monitor Specifications.....…........................………........5
2.LCD Monitor Description…………………………….......6
3.Operation Instructions……………...............……...........7
3.1.Control Buttons……………...............……..............7
3.2 Adjusting the Picture...........…………….........…….9
4.Input/Output Specification.............……………........…17
4.1.Input Signal Connector............………….................17
4.2.Factory Preset Display Modes...…..…......................18
4.3.Power Supply Requirements..........……...................18
4.4.Panel Specification…….....……………..................19
4.5 Incoming inspection standard...................................21
5. Block Diagram………………………………………..….25
5.1.Software Flow Chart………..……………....….......25
5.2.Electrical Block Diagram…………….…..…..….......27

19" LCD Color Monitor Dell E1909Wc
2
Revision List
Revision Release Date Revise history TPV model
T9RAMAHKX5DFHN
T9RMMAHKX5DFHN
A00 Jun.-16-2008 Initial Release
T9RSMAHKX5DFHN
T9RSMAHKX5DFHC
T9RMMAHKX5DFHC
A01 Aug.-12-2008 Add TPV Model in item 14
T9RAMAHKX5DFHC

19" LCD Color Monitor Dell E1909Wc
3
ECN History
ECN No. Change Description Service Deposition Cut-in date MSR

19" LCD Color Monitor Dell E1909Wc
4
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performing
service operations. Some of these service operations require the use of tools specially designed for the purpose.
The special tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read
in order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics may create
shock, fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from AOC.
AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open. AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION
OF THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth
may damage the panel.)

19" LCD Color Monitor Dell E1909Wc
5
1. Monitor Specifications
Screen type Active matrix - TFT LCD
Panel Type M190PW01 V00A SZ AUO
Size 19 inches (19-inch viewable image size)
Pixel pitch 0.283mm (H) x 0.283mm(V)
Viewable angle 160° (vertical) typ, 160° (horizontal) typ
LCD Panel
Response time 8ms typical
Video R, G, B Analog Interface, DVI digital Interface
Separate Sync H/V TTL
H-Frequency 30kHz – 83kHz
Input
V-Frequency 56 - 75Hz
Dynamic contrast ratio 1000:1 (typical)
Luminance output 300 CD/m ²(typical)
Max. Resolution 1440 x 900 at 75 Hz
Plug & Play VESA DDC
ON Mode <75W
EPA ENERGY
STAR®OFF Mode <1W
Input Connector 15-pin D-subminiature, blue connector;
DVI-D, white connector
Dimensions (with stand)
Height : 14.32 inches (363.74 mm)
Width: 17.45 inches (442.85 mm)
Depth：5.78 inches (146.86 mm)
Power Source 100 to 240 VAC / 50 or 60 Hz + 3 Hz / 1.5A
Video display capabilities (DVI playback) 480i/480p/576i/576p/720p/1080i/1080p (Support HDCP)
Environmental
Considerations
Operating Temp: 5° to 35°C
Operating Humidity: 10% to 80%
Storage Temp.: -20° to 60°C
Weight
Weight with packaging: 13.54 lbs (6.14 kg)
Weight with stand assembly and cables: 10.27 lbs (4.66 kg)
Weight without stand assembly: 7.80 lbs (3.54 kg)
Weight of stand assembly: 2.23 lbs (1.01 kg)

19" LCD Color Monitor Dell E1909Wc
6
2. LCD Monitor Description
The LCD monitor will contain a main board, power board, and a key board which house the flat panel control logic,
brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Video signal, DDC
Power board
Flat Panel and
CCFL backlight
Main Board
Key board
RS232 Connector
For white balance
adjustment in factory
mode
CCFL Drive.
AC-IN
100-240V
Monitor Block Diagram
Host Computer

19" LCD Color Monitor Dell E1909Wc
7
3. Operation instructions
3.1 Control Buttons
Use the buttons on the front of the monitor to adjust the image settings.
Front panel Button Description
A
Menu
Use the MENU button to launch the on-screen display (OSD) and select the OSD
Menu.
B
Brightness&Con
trast /Adjust UP
Use this button to directly access the "Brightness/Contrast" menu or to increase the
values of the selected menu option.
C
Automatic
Adjust /Adjust
Down
Use Auto Adjust to activate automatic setup/adjustment or to decrease the values of
the selected menu option. The following dialog appears on a black screen as the
monitor self-adjusts to the current input:
Auto Adjustment allows the monitor to self-adjust to the incoming video signal. After
using Auto Adjustment, you can further tune your monitor by using the Pixel Clock
(Coarse) and Phase (Fine) controls under Image Settings.
D
Input Source
Select/Select
Use this button to select the input source or select an OSD menu option. Use the
Input source button to select one of the two different video signals that may be
connected to your monitor:
•VGA input

19" LCD Color Monitor Dell E1909Wc
8
•DVI-D input
< to image the for seconds 2 or 1 take may It source. input selected currently indicate
messages following see will you inputs through cycle>
or
or
If either VGA or DVI-D input is selected and both VGA and DVI-D cables are not
connected, a floating dialog box as shown below appears.
or
E
Power
(with power light
indicator)
Use the Power button to turn the monitor on and off.
The Blue LED indicates the monitor is on and fully functional. An amber LED
indicates DPMS power save mode.

19" LCD Color Monitor Dell E1909Wc
9
3.2 Adjusting the Picture
1.Push the MENU button to launch the OSD menu and display the main menu.
Main Menu for Analog (VGA) Input
Or
Main Menu for Digital (DVI-D) Input
2.Push the and buttons to move between the setting options. As you move from one icon to another, the
option name is highlighted. See the following table for a complete list of all the options available for the monitor.
3.Push the button once to activate the highlighted option.
4.Push the and buttons to select the desired parameter.
5.Push to enter the slide bar and then use the or button, according to the indicators on the menu, to
make your changes
6.Press the Menu button once to return to the main menu to select another option or press the Menu button two or
three times to exit from the OSD menu.
The table below provides a list of all the OSD menu options and their functions.

19" LCD Color Monitor Dell E1909Wc
10
Icon Menu and
Submenus
Description
Brightness
& Contrast
Use this menu to activate Brightness/Contrast adjustment.
Brightness Brightness adjusts the luminance of the backlight.
Push the button to increase brightness and push the button
to decrease brightness (min 0 ~ max 100).
Contrast Adjust Brightness first, and then adjust Contrast only if further adjustment is
necessary.
Push the button to increase contrast and push the button to
decrease contrast (min 0 ~ max 100).
The Contrast function adjusts the degree of difference between darkness
and lightness on the monitor screen.
Auto Adjust Even though your computer recognizes your monitor on startup, the Auto
Adjustment function optimizes the display settings for use with your particular
setup.
Input Source Use the INPUT SOURCE menu to select between different video signals that
may be connected to your monitor.

19" LCD Color Monitor Dell E1909Wc
11
VGA Select VGA input when you are using the analog (VGA) connector. Push
to select the VGA input source.
DVI-D Select DVI-D input when you are using the Digital (DVI) connector. Push
to select the DVI input source.
Color
Settings
Use the Color Settings to adjust the color setting mode and color
temperature.
There are different color setting sub-menus for VGA/DVI-D and Video input.
Input Color
Format
Choose the RGB option if monitor is connected to a PC or a DVD using a
VGA or DVI cable. Choose the YPbPr option if monitor is connected to a
DVD by a YPbPr to VGA or YPbPr to DVI cable or if the DVD color output
setting is not RGB.
Mode
Selection
You can choose Graphics or Video according to the input signal. Select
Graphics if connecting a PC to your monitor; for connecting DVD, STB or
VCR to your monitor, Video is recommended.

19" LCD Color Monitor Dell E1909Wc
12
Preset Modes When you select Graphics, you can choose Standard, Multimedia, Game,
Warm, Cool, or Custom (R,G,B);
•If you view media application like photo, clip etc via PC, choose
"Multimedia" preset;
•If you play a game in PC, choose "Gaming" preset;
•If you prefer a lower color temperature (5700K), choose "Warm"
preset;
•If you prefer a higher color temperature, choose "Cool" preset;
•Custom (R, G, B) Preset offers a range of 6500K colors;
•Choose "Standard" to utilize the panel native color format;
•Select Warm preset for a reddish tint. This color setting is used for
color-intensive applications (photograph image editing, multimedia,
movies, etc.)
•Select Cool preset for a bluish tint. This color setting is used for text
based applications (spreadsheets, programming, text editors, etc.)
•Select Custom preset to increase or decrease each of the three
colors (R, G, B) independently, in single digit increments, from 0 to
100.
When you select Video, you can choose Movie, Game, Sports, or Nature
preset:
•For playing a movie, choose "Movie" preset;
•For playing a sport program, choose "Sports" preset;
•For playing a game, choose "Game" preset;
•For general picture or web or watch TV, choose Nature preset. You
can adjust the Hue(Tint)/Saturation based on your preference. If you
want to restore default color settings, choose Color Reset;
•Select Color Reset preset to restore default (factory) Color settings.
This setting is also the “sRGB” standard default color space.

19" LCD Color Monitor Dell E1909Wc
13
Hue This feature can shift color of video image to green or purple. This is used to
adjust the desired flesh tone color. Use or to adjust the hue
from '0' to '100' .
Push to increase the green shade of the video image
Push to decrease the purple shade of the video image
Saturation This feature can adjust the color saturation of the video image. Use
or to adjust the saturation from '0' to '100'.
Push to increase the monochrome appearance of the video image
Push to decrease the colorful appearance of the video image
Reset Color
Settings
Reset your monitor color settings to the factory settings.
Display
Settings
Use the Display Settings to adjust image.

19" LCD Color Monitor Dell E1909Wc
14
Horizontal
Position Use the or buttons to adjust image left and right. Minimum is
'0' (-). Maximum is '100' (+).
Vertical
Position Use the or buttons to adjust image up and down. Minimum is
'0' (-). Maximum is '100' (+).
Sharpness This feature can make the image look sharper or softer. Use
or to adjust the sharpness from '0' to '100'.
Pixel Clock The Phase and Pixel Clock adjustments allow you to adjust your monitor to
your preference. These settings are accessed through the main OSD menu,
by selecting 'Image Settings'.
Use the or buttons to adjust for best image quality.
Phase If satisfactory results are not obtained using the Phase adjustment, use the
Pixel Clock (coarse) adjustment and then use Phase (fine), again.
Reset Display
Settings
Select this option to restore default display settings.
Other
Settings
Select this option to adjust the settings of the OSD, such as, the languages
of the OSD, the amount of time the menu remains on screen, and so on.

19" LCD Color Monitor Dell E1909Wc
15
Language Language option to set the OSD display to one of seven languages (English,
Espanol, Francais, Deutsch, Portugues,Simplified chinese or Japanese).
Menu Transp
arency
Select this option to change the menu transparency by pressing
or (Minimum: 0 ~ Maximum: 100).
Menu Timer OSD Hold Time: Sets the length of time the OSD will remain active after the
last time you pressed a button.
Use the or buttons to adjust the slider in 5 second
increments, from 5 to 60 seconds.
Menu Lock Controls user access to adjustments. When 'Lock' is selected, no user
adjustments are allowed. All buttons are locked except the menu button.
DDC/CI DDC/CI (Display Data Channel/Command Interface) allows your monitor
parameters (brightness, color balance etc) to be adjustable via software on
your PC. You can disable this feature by selecting "Disable".
Enable this feature for best user experience and optimum performance of
your monitor.

19" LCD Color Monitor Dell E1909Wc
16
LCD
Conditioning
Helps reduce minor cases of image retention. Depending on the degree of
image retention, the program may take some time to run. You can enable
this feature by selecting "Enable".
Factory Reset Reset all OSD settings to the factory preset values.

19" LCD Color Monitor Dell E1909Wc
17
4. Input/Output Specification
4.1 Input Signal Connector
VGA Connector:
Pin No. Description Pin No. Description
1. Red Video 9.
Computer 5V/3.3V
2. Green Video 10. GND-sync
3. Blue Video 11. GND
4. GND 12. DDC data
5. Self-test 13. H-Sync
6. R-Ground 14. V-Sync
7. G-Ground 15. DDC clock
8. B-Ground
VGA Connector layout
DVI Connector:
Note: Pin 1 is at the top right.
Pin Signal Assignment Pin Signal Assignment Pin Signal Assignment
1 T.M.D.S. Data 2- 9 TMDS RX1- 17 TMDS RX0-
2 T.M.D.S. Data 2+ 10 TMDS RX1+ 18 TMDS RX0+
3 TMDS Ground 11 TMDS Ground 19 TMDS Ground
4 Floating 12 Floating 20 Floating
5 Floating 13 Floating 21 Floating
6 DDC Clock 14 +5V/+3.3V power 22 TMDS Ground
7 DDC Data 15 Self test 23 TMDS Clock+
8 Floating 16 Hot Plug Detect 24 TMDS Clock-

19" LCD Color Monitor Dell E1909Wc
18
4.2 Factory Preset Display Modes
Display Mode Horizontal
Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/Vertical)
VESA, 720 x 400 31.5 70.0 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40 +/+
VESA, 800 x 600 46.9 75.0 40 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 800 61.6 60.0 83.5 +/-
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1440 x 900 56.0 60.0 106.0 -/+
4.3 Power Supply Requirements
A/C Line voltage range : 100 V ~ 240 V
A/C Line frequency range : 50 ±3Hz, 60 ±3Hz
Current : 1.5A max at 100V; 0.8A max at 240 V
Peak surge current : < 60A peak at 240 VAC and cold starting
Leakage current : < 3.5mA
Power line surge : No advance effects (no loss of information or defect)
with a maximum of 1 half-wave missing per second
DC output Voltage : 5VDC ± 5％; 12VDC± 5％

19" LCD Color Monitor Dell E1909Wc
19
4.4 Panel Specification
This specification applies to the 19 inch-wide Color TFT-LCD Module M100PW01.
The display supports the WXGA+(1440(H)X900(V))screen format and 16.7M clors.All input signal are 2 signal
LVDS interface compatible。
This module does not contain an inverter card for backlight.
4.4.1 Display Characteristics

19" LCD Color Monitor Dell E1909Wc
20
4.4.2 Optical Characteristics
Ta= 25°C, VLCD=5.0V, fV=60Hz fCLK=54MHz, IBL=7.5mA
