Dell SE2417HG User manual

Model No.: SE2417HG/SE2417HGR
Regulatory model: SE2417HGc
User’s Guide
Dell SE2417HG/SE2417HGR

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better
use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury or death.
_________________________
Information in this document is subject to change without notice.
© 2015-16 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission
of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; Microsoft
and Windows are either trademarks or registered trademarks of Microsoft. Corporation in
the United States and/or other countries, Intel is a registered trademark of Intel Corporation
in the U.S. and other countries; and ATI is a trademark of Advanced Micro Devices, Inc.
ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an
ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR
guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the
entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary
interest in trademarks and trade names other than its own.
2016 - 05 Rev. A02

Contents | 3
Contents
About your monitor ................................................................ 5
Package contents.......................................................................................5
Product features.........................................................................................6
Identifying parts and controls.................................................................. 7
Plug and play capability ..........................................................................10
LCD monitor quality and pixel policy...................................................10
Maintenance guidelines..........................................................................10
Setting up the monitor ......................................................... 11
Connecting the stand.............................................................................. 11
Connecting your monitor ...................................................................... 12
Organizing cables ....................................................................................13
Disconnecting the monitor stand.........................................................14
Operating your monitor....................................................... 15
Power on the monitor............................................................................. 15
Using the front panel controls ..............................................................15
Using the on-screen display (OSD) menu .......................................... 17
Setting up your monitor..........................................................................29
Using tilt .................................................................................................... 30

4| Contents
Troubleshooting.................................................................... 31
Self-test ......................................................................................................31
Built-in diagnostics ..................................................................................32
Common problems .................................................................................33
Product-specific problems ....................................................................35
Appendix ....................................................................................................36
FCC notices (U.S. Only) and other regulatory information.............36
Contacting Dell.........................................................................................36
Monitor specifications.......................................................... 37
Flat panel specifications..........................................................................37
Resolution specifications........................................................................37
Supported video modes..........................................................................38
Preset display modes...............................................................................38
Electrical specifications...........................................................................38
Physical characteristics...........................................................................39
Environmental characteristics .............................................................. 40
Power management modes ................................................................. 40
Pin assignments........................................................................................42

About your monitor | 5
About your monitor
Package contents
Your monitor ships with the components shown below. Ensure that you have
received all the components and Contacting Dell if something is missing.
NOTE: Some items may be optional and may not ship with your monitor. Some
features or media may not be available in certain countries.
Monitor
Stand riser
Stand base
Power cable (varies by
country)
VGA cable

6| About your monitor
Dell
TM
SE2417HG/SE2417HGR Monitor
∞ Drivers and
Documentation media
∞ Quick Setup Guide
∞ Safety and Regulatory
Information
Product features
The Dell SE2417HG/SE2417HGR flat panel display has an active matrix, Thin-Film
Transistor (TFT), Liquid Crystal Display (LCD), and LED backlight. The monitor features
include:
∞ 59.9 cm (23.6 inch) viewable area display (measured diagonally). 1920 x 1080
resolution, plus full-screen support for lower resolutions.
∞ Plug and play capability if supported by your system.
∞ VGA and dual HDMI connectivity.
∞ Fast 2ms panel response time.
∞ On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
∞ Software and documentation media includes an Information File (INF), Image
Color Matching File (ICM), and product documentation.
∞ Dell Display Manager Software (in the CD shipped with the monitor).
∞ Energy Saver feature for Energy Star compliance.
∞ Security-cable slot.
∞ Capability to switch from wide aspect to standard aspect ratio while maintaining
image quality.
∞ EPEAT Silver rating.
∞ TCO-certified display.
∞ BFR/PVC- Reduced.
∞ High dynamic-contrast ratio (8,000,000:1).
∞ 0.3 W power consumption when in the sleep mode.
∞ Energy Gauge shows the energy level being consumed by the monitor in real
time.

About your monitor | 7
Identifying parts and controls
Front View
Front panel controls
12
Label Description
1Function buttons (For more information, see Operating your monitor)
2Power on/off button (with LED indicator)
NOTE: For displays with glossy bezels the user should consider the placement of
the display as the bezel may cause disturbing reflections from surrounding light
and bright surfaces.

8| About your monitor
Back View
2
3
1
4
Back View with monitor stand
Label Description Use
1Stand release button Releases stand from monitor.
2Security-cable slot Secures monitor with security lock
(security lock not included).
3Barcode serial number label Refer to this label if you need to
contact Dell for technical support.
4Cable management slot Uses to organize cables by placing
them through the slot.
Back View without monitor stand

About your monitor | 9
Bottom View
CAN ICES-3 (B)/NMB-3(B)
Удельнаямощность рабочего режима - X.XXX Вт/см²
Потребляемаямощность изделием в режиме ожидания - X.XX Вт
Потребляемаямощность изделием в выключенном режиме - X.XX Вт
Theequipment must be connected to an earthed mains socket-outlet.
L'appareildoit être branché sur une prise de courant munie d'une mise à la terre.
XXXXXXX-XXXXX
MSIP-REM-TPV-SE2416Hc
㐔㷡㢬ڕTOP VICTORY ELECTRONICS (FUJIAN) CO., LTD.
㥐㦤㣄ڕTPV Electronics (Fujian) Co., Ltd.
080-200-3800
Consumo de energía: XX.X Wh
Consumo de energía en modo de espera: X.XX Wh

XXXXXX-XX
䊂
XXXXXX
56
423
1
Bottom view without monitor stand
Label Description Use
1Power port Connect the power cable.
2Line-out port* Connect external speakers (sold separately).
3Regulatory label Lists the regulatory approvals.
4HDMI1 port Connect your computer with HDMI cable.
5HDMI2 port
6VGA port Connect your computer with VGA cable.
* Headphone usage is not supported for the audio line out port.

10 | About your monitor
Plug and play capability
You can install the monitor in any Plug and Play-compatible system. The monitor
automatically provides the computer system with its Extended Display Identification
Data (EDID) using Display Data Channel (DDC) protocols so the system can configure
itself and optimize the monitor settings. Most monitor installations are automatic,
you can select different settings if desired. For more information about changing the
monitor settings, see Operating your monitor.
LCD monitor quality and pixel policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more
pixels to become fixed in an unchanging state which are hard to see and do not affect
the display quality or usability. For more information on Dell Monitor Quality and Pixel
Policy, see Dell Support site at: www.dell.com/support/monitors.
Maintenance guidelines
Cleaning your monitor
WARNING: Before cleaning the monitor, unplug the monitor power cable from
the electrical outlet.
CAUTION: Read and follow the Safety instructions before cleaning the monitor.
For best practices, follow the instructions in the list below while unpacking, cleaning
or handling your monitor:
∞ To clean your anti-static screen, lightly dampen a soft, clean cloth with water.
If possible, use a special screen-cleaning tissue or solution suitable for the anti-
static coating. Do not use benzene, thinner, ammonia, abrasive cleaners or
compressed air.
∞ Use a lightly-dampened, warm cloth to clean the monitor. Avoid using
detergent of any kind as some detergents leave a milky film on the monitor.
∞ If you notice white powder when you unpack your monitor, wipe it off with a
cloth.
∞ Handle your monitor with care as a darker-colored monitor may get scratched
and show white scuff marks more than a lighter-colored monitor.
∞ To help maintain the best image quality on your monitor, use a dynamically
changing screen saver and turn off your monitor when not in use.
