DellTM UltraSharpTM 17” / 19” Digital Flat Panel Displays
- 1707FP/1907FP
Displays
Dell
TM
UltraSharp
TM
17” (1707FP) and 19” (1907FP) flat panel displays
carry forward the value proposition of 1704FPV / 1704FPT / 1905FP -
incorporating many advanced features for great performance and ease of use.
These two performance flat panel displays have a new sleek black Dell
Industrial Design and their improved panel specifications compared to their
predecessors can enhance your viewing experiencing.
Outstanding Screen Performance
•UltraSharp
TM
17” / 19” Screen Size
- 1707FP: About 31% more viewing area than Dell 15” flat panel displays.
2
- 1907FP: About 25% more viewing area than Dell 17” flat panel displays.
3
•Fast response time with less smearing and ghosting than traditional flat
panel displays.
- 1707FP / 1907FP ~ 8ms typical (black-to-white)
•High contrast ratio resulting in excellent color accuracy and uniformity.
- 1707FP / 1907FP ~ 600:1 / 700:1 (typical)
•High Resolution can provide excellent entertainment and multimedia
experience.
-1707FP / 1907FP (1280 x 1024 resolution): About 66%
4
more content
compared to Dell 15” monitor.
Excellent Multimedia, Video and Graphics Experience
•DVI (Digital Video Interface) connector helps to ensure high quality image
(no jitter).
• Easy attachment of optional Dell 10W multimedia soundbar AS501.
Designed for Comfort and Convenience
•4 USB 2.0 high speed ports for easy access to connect peripheral devices
such as cameras, USB keys or mouse.
•Comprehensive flexibility of height adjustability (130mm up or down),
swivel (45
o
left and right) and tilt (4
o
forward and 21
o
backward).
•Dell-Designed Display Enhancements
- Slim black bezel designed to fit into most working environments and on
most desktops.
- Easy display detachment from stand can enable panel to be wall-mounted
(VESA standard 100mm, wall mount sold separately.)
- Stand lock down mechanism allows locking of monitor into place at the
lowest height which can allow easy transportation of display.
Quality
Dell-branded monitors are
designed to our exacting quality
standards and manufactured by the
world’s foremost suppliers, who
must pass Dell’s stringent quality
audit. All Dell monitors meet or
exceed relevant industry
standards.
Reliability
Dell-branded monitors undergo
exhaustive testing for performance,
reliability, durability and
compatibility with Dell systems.
Under our H.A.L.T (Highly
Accelerated Life Cycle Testing)
regimen, Dell engineers push our
monitors well past specified
tolerance limits for heat, cold,
vibration, shocks and drops, to
ensure that they can withstand
real-world conditions.
Price-Performance Value
Dell’s enormous buying power and
direct business model allows us to
offer high quality monitors at low
prices. Dealing with Dell, the
world’s largest Flat Panel
provider
1
, means a single point of
contact and accountability, and the
peace of mind of purchasing from
a stable and reliable technology
partner.
See Important Information on Page 3

DETAILED SPECIFICATIONS
60.0 kHz Horizontal, 75.0 Hz Vertical), 78.8 MHzVESA, 1024 x 768
67.5 kHz Horizontal, 75.0 Hz Vertical), 108 MHzVESA, 1152 x 864
64.0 kHz Horizontal, 60.0 Hz Vertical), 135 MHzVESA, 1280 x 1024
37.5 kHz Horizontal, 75.0 Hz Vertical), 31.5 MHzVESA, 640 x 480
37.9 kHz Horizontal, 60.3 Hz Vertical), 49.5 MHzVESA, 800 x 600
46.9 kHz Horizontal, 75.0 Hz Vertical), 49.5 MHzVESA, 800 x 600
48.4 kHz Horizontal, 60.0 Hz Vertical), 65.0 MHzVESA, 1024 x 768
80.0 kHz Horizontal, 75.0 Hz Vertical), 135 MHzVESA, 1280 x 1024
Less than 1W
Less than 2W
100 to 240 VAC / 50 Hz / 60 Hz + 3 Hz / 2.0A (Max.)
9.20 Kg (20.28 Ib)
4.85 Kg (10.69 Ib)
488.56(extended) x 358.33 (compressed) x 410.1 x
181.9
19.23(extended) x 10.18 (compressed) x 13.27 x 7.16
YES (100mm)
Tilt, Swivel, Height Adjustable
4 Universal Serial Bus (USB) 2.0 Ports, Kensington
security port
Analog, DVI-D (Digital)
1280 x 1024 at 60 Hz
56 Hz to 76 Hz (automatic)
30 kHz to 81 kHz (automatic)
700:1
300cd/m
2
Typical
130
o
(vertical), 140
o
(horizontal)
300mm (11.81 inches)
380mm (14.96 inches)
8ms
0.294mm
19 inches (19-inch)
1907FP
Flat Panel Display
Tilt, Swivel, Height AdjustableStand
4 Universal Serial Bus (USB) 2.0 Ports, Kensington
security port
Other Connectors / Features
100 to 240 VAC / 50 Hz / 60 Hz + 3 Hz / 2.0A (Max.)AC input voltage
Operating (Typical Maximum)
Less than 2W- Active Off
31.5 kHz Horizontal, 70.0 Hz Vertical), 28.3 MHzVESA, 720 x 400
31.5 kHz Horizontal, 60.0 Hz Vertical), 25.2 MHzVESA, 640 x 480
337mm (13.3 inches)Horizontal
270mm (10.6 inches)Vertical
YES (100mm)VESA Mounting Support
Analog, DVI-D (Digital)Connector Type
Less than 1W- Switched Off
Preset Display Area:
0.264mmPixel Pitch
130
o
(vertical), 140
o
(horizontal)Viewing Angle (Typical)
8.06 Kg (17.77 Ib)Weight (with packaging)
4.14 Kg (9.13 Ib)Weight (monitor only)
457.66(extended) x 328.16 (compressed) x 371.81 x
181.9
Dimensions (H x H x W x D) mm
18.02(extended) x 12.92 (compressed) x 14.64 x
7.16
Dimensions (H x H x W x D) Inch
Preset Display Modes:
1280 x 1024 at 60 HzOptimal Resolution
56 Hz to 76 Hz (automatic)Vertical Scan Frequency Hz
30 kHz to 81 kHz (automatic)Horizontal Scan Frequency kHz
600:1Contrast Ratio (Typical)
300cd/m
2
TypicalLuminance (Brightness)
8msResponse Type (Typical)
17 inches (17-inch)Monitor Size (Viewable Image Screen)
1707FPModel Name and Number
Flat Panel DisplayProduct Category
Recycling: Dell recommends that customers dispose of their used computer hardware, including monitors, in
an environmentally sound manner. Potential methods include reuse of parts or whole products and recycling of
product, components and/or materials. For more information, please visit http://dell.com/recycling_programs
and www.dell.com/environment.

Important Information
Dell cannot be held responsible for typography and photography.
1. DisplaySearch Q3 Quarterly Desktop Monitor Report, “ Top 10 WW LCD PFD Vendors”,
December 2005.
2. Dell UltraSharp 1505FP and Dell E156FP, 15” Flat Panel Display’s preset display area in
comparison to Dell UltraSharp 1707FP’s ~ 304.1mm (Width, W) x 228.1mm (Height, H)
versus 337mm (W) x 270mm (H) respectively.
3. Dell UltraSharp1707FP, 17” Flat Panel Display’s preset display area in comparison to Dell
UltraSharp1907FP’s ~ 337mm (Width, W) x 270mm (Height, H) versus 380mm (W) x
300mm (H) respectively.
4. Content area determined by total pixel count per given area. Dell UltraSharp 1505FP and Dell
E153FP, 15” Flat Panel Display’s resolution in comparison to Dell UltraSharp 1707FP /
1907FP, 17”/19” Flat Panel Display’s ~ 1024 x 768 pixels versus 1280 x 1024 pixels
respectively.
