Dell SX2210WFP User manual

Dell™SX2210FlatPanelMonitorUser'sGuide
Notes, Notices, and Cautions
Information in this document is subject to change without notice.
©2009DellInc.Allrightsreserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: DELL and the DELLlogoaretrademarksofDellInc;Microsoft, Windows, and Windows Vista are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries; ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner,
Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Model SX2210b
January2009Rev.A00


About Your Monitor
Setting Up the Monitor
Operating the Monitor
Troubleshooting
Appendix
NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.


Back to Contents Page
About Your Monitor
Dell™SX2210 Flat Panel Monitor User's Guide
Package Contents
Your monitor comes with all the items shown below. Ensure that you have all the items. If something is missing, contact Dell.

Package Contents
Product Features
Identifying Parts and Controls
Monitor Specifications
Universal Serial Bus (USB) Interface
Plug and Play Capability
Camera -MIC Specifications
Maintenance Guidelines
NOTE: Some items may be optional and may not ship with your monitor. Some features or media may not be available in
certain countries.

lMonitor with stand
lPower cable
lPower adapter
lVGA cable


Product Features

The SX2210flat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD). The monitor features include:
■21.5 inches (546.8 mm) diagonal.
■1920X1080resolution,plusfull-screen support for lower resolutions.
■Tilt adjustment capabilities.
■Plug and play capability if supported by your system.
■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
■Software and documentation media which includes an information file (INF), Image Color Matching File (ICM), Webcam Software, Facial Recognition Software,
and product documentation.
■Energy Saver feature for Energy Star compliance.
■Security lock slot.
■2.0 Mega pixel internal webcam with integrated microphone.
Identifying Parts and Controls
Front View
lDVI cable
lUSB up stream cable (enables the USB ports on the
monitor)
lUSB down stream cable (optional)
lDocumentation (Safety Information, Quick Start Guide,
and CD)
Front View
Label
Description
Shortcut keys (for more information, see Operating the Monitor)


Back View

Side View

Bottom View
1-2
*The default settings are Preset Modes select and Brightness/Contrast select.
1
Preset Modes select
2
Brightness/Contrast select
3
OSD menu select
4
EXIT
5
Power button (with light indicator)
6
Webcam
7
Microphone
Back view
Back View with monitor stand
Label
Description
Use
1
Barcode serial number label
To contact Dell for technical support.
2
Security lock slot
To help secure your monitor.
3
Dell soundbar mounting brackets
To attach the optional Dell Soundbar.
4
USB downstream port
To connect the USB cable.
5
Regulatory rating label
Lists the regulatory approvals.
6
Cable management slot
To organize cables by placing them through the slot.
Leftview
Right view


Monitor Specifications
The following sections give you information about the various power management modes and pin assignments for various connectors of your monitor.
Power Management Modes
If you have VESA's compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. This
is referred to as Power Save Mode. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes functioning.
The following table shows the power consumption and signaling of this automatic power saving feature:
Activate the computer and 'wake up' the monitor to gain access to the OSD.
Bottom view
Label
Description
1
DC power cord connector
2
Audio Line-in
3
Audio Line-out
4
HDMI connector
5
DVI connector
6
VGA connector
7
USB upstream port
8
USB downstream ports (2)
VESA Modes
Horizontal Sync
Vertical Sync
Video
Power Indicator
Power Consumption
Normal operation and
USB active
Active
Active
Active
White
58 W (maximum)
Normal operation
Active
Active
Active
White
47 W (typical)
Active-off mode
Inactive
Inactive
Blanked
Amber
0.84 W
Switch off
-
-
-
Off
0.74 W
NOTE: The OSD functions in the 'Normal operation' mode. One of the following messages appears when the menu key is touched in Active-off mode.
or



ZeropowerconsumptioninOFFmodecanonlybeachievedbydisconnectingthemaincablefromthepoweradapter.
Pin Assignments
VGA Connector
DVIConnector
NOTE: This monitor is ENERGY STAR®-compliant.
Pin
Number
15-pin Side of the Connected Signal Cable
1
Video-Red
2
Video-Green
3
Video-Blue
4
GND
5
Self-test
6
GND-R
7
GND-G
8
GND-B
9
Computer 5V
10
GND-sync
11
GND
12
DDC data
13
H-sync
14
V-sync
15
DDC clock
Pin
Number
24-pin Side of the Connected Signal
Cable
1
TMDS RX2-
2
TMDS RX2+
3
TMDS Ground
4
Floating
5
Floating
6
DDC Clock
7
DDC Data
8
Floating
9
TMDS RX1-
10
TMDS RX1+
11
TMDS Ground
12
Floating

HDMIConnector

Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the left side of your monitor.
USB Upstream Connector
13
Floating
14
+5V power
15
Selftest
16
Hot Plug Detect
17
TMDS RX0-
18
TMDS RX0+
19
TMDS Ground
20
Floating
21
Floating
22
TMDS Ground
23
TMDS Clock+
24
TMDS Clock-
Pin
Number
19-pin Side of the Connected Signal
Cable
1
T.M.D.S. Data 2-
2
T.M.D.S. Data 2 Shield
3
T.M.D.S. Data 2+
4
T.M.D.S. Data 1+
5
T.M.D.S. Data 1 Shield
6
T.M.D.S. Data 1-
7
T.M.D.S. Data 0+
8
T.M.D.S. Data 0 Shield
9
T.M.D.S. Data 0-
10
T.M.D.S. Clock +
11
T.M.D.S. Clock Shield
12
T.M.D.S. Clock -
13
CEC
14
Reserved (N.C. on device)
15
SCL
16
SDA
17
DDC/CEC Ground
18
+5V Power
19
Hot Plug Detect
NOTE: This monitor supports High-Speed Certified USB 2.0 interface
Transfer speed
Data Rate
Power Consumption
High speed
480 Mbps
2.5W(Max.,eachport)
Full speed
12 Mbps
2.5W(Max.,eachport)
Low speed
1.5 Mbps
2.5W(Max.,eachport)

USB Downstream Connector
USB Ports
l1 upstream -back
l2 downstream at back & 2 downstream at bottom
Camera -MIC Specifications
Overview
The integrated USB camera and analog microphones allow you to take pictures, videos, and communicate with other computer users. The camera is located at
the top of the monitor and is fixed. However, the camera’s software--Dell Webcam Software suite, provides limited panning abilities. When the camera is on,
the white light next to the camera turns on.
System Requirements
The following are the minimum system requirements for the Dell Webcam Software Suite:
lIntel®Pentium®4 or AMD®equivalent processor running at 2.4 GHz or higher
(Recommended: Intel Pentium Core 2 Duo E4300 or AMD equivalent processor running at 2.8 GHz with Hyper-Threading enabled)
lMicrosoft®Windows®XP Service Pack 2 or Windows Vista®
l256 MB RAM (2 GB RAM or higher recommended)
l580 MB free hard disk space
Pin Number
4-pin Side of the connector
1
DMU
2
VCC
3
DPU
4
GND
Pin Number
4-Pin Side of the Signal Cable
1
VCC
2
DMD
3
DPD
4
GND
NOTE:USB2.0functionalityrequiresaUSB2.0-
capablecomputer
NOTE:
The monitor's USB interface works only when the monitor is on or in power save mode. If you turn off the monitor and then turn it on, the attached peripherals may take a few seconds
to resume normal functionality.
Lens
Field of view
66.2 degree +/-5 %
Focus mode
Fixed Focus
Focus area
37 cm~Infinity
Focusingdistance(normalmode)
1.100 mm
Image Sensor
Active array size
2.0 mega-pixel
Video specification

Video frame rate
1600 x 1200 (UXGA) -up to 10 frames per second
640 x 480 (VGA) and below -up to 30 frames per second
Image flip
Horizontally
Digital zoom
2x
Audio Specification
Microphone type
Dual Microphone
Interface

USB 2.0 high Speed
Power Supply

3.3 volts +/- 5%

lAvailable USB 2.0 port or a USB 2.0 hub with external power supply
Dell Webcam Software Suite
The Dell Webcam Software Suite includes the following applications:
DellWebcamCentre
Dell Webcam Central enables convenient access to all exciting applications to enhance your Dell Webcam experience.
CreativeLive!CamAvatarCreator
Creative Live! Cam Avatar Creator lets you personalize an animated avatar from any digital photo you want. Using advanced speech technology,
yourpersonalizedavatarevenlipsyncswithyou.SharecreationwithfriendsusingLive!CamAvatar,viaemailorevenYouTube™.
Facial Recognition Software (FastAccess)
Face recognition technology greatly reduces the need to manually log in with passwords, while providing superior security and functionality
compared to passwords and other biometrics (for Windows Vista®only).
Plug and Play Capability
You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display
Identification Data (EDID) using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. Most monitor
installations are automatic; you can select different settings if desired. For more information about changing the monitor settings, see Operating the Monitor.
Flat Panel Specifications
*SX2210 color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test standards.
Resolution Specifications

Video Supported Modes

Screen type
Active matrix -TFT LCD
Panel Type
TN
Screen dimensions
21.5 inches (21.5-inch viewable image size)
Preset display area:
Horizontal:
Vertical:

476.64 mm (18.76 inches)
268.11 mm (10.56 inches)
Pixel pitch
0.248 mm
Viewing angle
160°(vertical)typical,170°(horizontal)typical
Luminance output
300 CD/m²(typical)
Contrast ratio
1000:1 (typical)
Dynamic contrast ratio
50,000:1 (max)
Faceplate coating
Glare with hard-coating (3H)
Backlight
CCFL edgelight system
Response Time
2 ms typical (Grey to Grey)
Color Depth
16.7 mil colors
Color Gamut
85%*
Horizontal scan range
30 kHz to 83 kHz (automatic)
Vertical scan range
50Hzto76Hz(automatic)
Optimal preset resolution
1920 x 1080 at 60 Hz
Highest preset resolution
1920 x 1080 at 60 Hz
Video display capabilities (DVI
playback)
480i/480p/576i/576p/720p/1080i/1080p
(Supports HDCP)


Preset Display Modes

Electrical Specifications

Physical Characteristics
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/Vertical)
640 x 350
31.47
70.09
25.18
+/-
640 x 400
31.47
70.09
25.18
-/+
640 x 480
31.47
59.94
25.17
-/-
640 x 480
31.50
75.00
31.5
-/-
720 x 400
31.47
70.08
28.32
-/+
800 x 600
37.88
60.32
40.00
+/+
800 x 600
46.880
75.00
49.50
+/+
1024 x 768
48.36
60.00
65.00
-/-
1024 x 768
60.02
75.03
78.75
+/+
1152 x 864
67.50
75.00
108.00
+/+
1280 x 1024
63.98
60.02
108.00
+/+
1280 x 1024
79.98
75.02
135.00
+/+
1920 x 1080-R
66.587
59.934
138.50
+/-
1920 x 1080
55.62
49.92
141.50
-/+
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at
75 ohm input impedance
Digital DVI-D TMDS, HDMI, 600mV for each
differential line, positive polarity at 50 ohm input
impedance
Audio Input and Output signals
Input signal level: 1Vrms without chipping
Synchronization input signals
Separate horizontal and vertical synchronizations,
polarity-free TTL level, SOG (Composite SYNC on
green)
AC/DC Adaptor input voltage/frequency/current
100 to 240 VAC/50 or 60 Hz +3 Hz/1.6A (Max.)
For use only with power supply DELL,
DA65NS4-00.
Inrush current
120 V: 30 A (Max.)
240 V: 60 A (Max.)
Connector type
15-pin D-sub miniature, blue connector; DVI-D,
white connector; HDMI, Black connector
Signal cable type
Digital: Detachable, DVI-D, Solid pins, shipped
detached from the monitor
Analog: Detachable, D-Sub, 15pins, shipped
attached to the monitor
HDMI: Detachable, HDMI-A, Solid pins, shipped
without cable
Dimensions (with stand)
Height
382.59 mm (15.63 inches)
Width
529.93 mm (20.86 inches)

Environmental Characteristics

Maintenance Guidelines
Cleaning Your Monitor
For best practices, follow the instructions in the list below while unpacking, cleaning, or handling your monitor:
lTo clean your antistatic screen, lightly dampen a soft, clean cloth with water. If possible, use a special screen-cleaning tissue or solution suitable for the
antistatic coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed air.
lUse a lightly-dampened,warmclothtocleanthemonitor.Avoidusingdetergentofanykindassomedetergentsleaveamilkyfilmonthemonitor.
lIf you notice white powder when you unpack your monitor, wipe it off with a cloth.
lHandleyourmonitorwithcareasadark-colored monitor may scratch and show white scuff marks more than a light-coloredmonitor.
lTo help maintain the best image quality on your monitor, use a dynamically changing screen saver and turn off your monitor when not in use.
Back to Contents Page
Depth
179.62 mm (7.07 inches)
Dimensions (without stand)
Height
321.55 mm (12.66 inches)
Width
529.93 mm (20.86 inches)
Depth
83.29 mm (3.28 inches)
Stand dimensions
Height
250.61 mm (9.67 inches)
Width
215.28 mm (8.48 inches)
Depth
179.62 mm (7.07 inches)
Weight
Weight with packaging
7.5 kg (16.53 Lbs)
Weight with stand assembly and cables
4.5 kg (9.92 Lbs)
Temperature

Operating
0°to40°C(32°to104°F)
Non-operating
Storage: -20°to60°C(-4°to140°F)
Shipping: -20°to60°C(-4°to140°F)
Humidity

Operating
10% to 80% (non-condensing)
Non-operating
Storage: 20% to 80% (non-condensing)
Shipping: 20% to 80% (non-condensing)
Altitude

Operating
3,657.60 m (12,000 ft) max
Non-operating
12,192 m (40,000 ft) max
Thermal dissipation
222.3 BTU/hour (maximum)
188.1 BTU/hour (typical)
CAUTION: Read and follow the safety instructionsbeforecleaningthemonitor.
CAUTION:Beforecleaningthemonitor,unplugthemonitorpowercablefromtheelectricaloutlet.

Back to Contents Page

Appendix
Dell™SX2210 Flat Panel Monitor User's Guide
Safety Instructions
FCC Notice (U.S. Only) and Other Regulatory Information
Contacting Dell

CAUTION: Safety Instructions
For information on safety instructions, see the safety information that shipped with your monitor.
FCC Notices (U.S. Only) and Other Regulatory Information
For FCC notices and other regulatory information, see the regulatory compliance website located at www.dell.com\regulatory_compliance.
Contacting Dell
For customers in the United States, call 800-WWW-DELL (800-999-3355).
Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be
available in your area. To contact Dell for sales, technical support, or customer service issues:

Back to Contents Page
CAUTION: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock,
electrical hazards, and/or mechanical hazards.
NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or
Dell product catalog.
1.
Visit support.dell.com.
2.
Verify your country or region in the Choose A Country/Region drop-downmenuatthebottomofthepage.
3.
Click Contact Us on the left side of the page.
4.
Select the appropriate service or support link based on your need.
5.
Choose the method of contacting Dell that is convenient for you.

Back to Contents Page
Setting Up Your Monitor
Dell™SX2210FlatPanelMonitor
IfyouhaveaDell™desktoporaDell™portablecomputerwithinternetaccess
1. Go to http://support.dell.com,enteryourservicetag,anddownloadthelatestdriverforyourgraphicscard.
2. After installing the drivers for your graphics Adapter, attempt to set the resolution to 1920 X 1080 again.
Back to Contents Page
NOTE:
Ifyouareunabletosettheresolutionto1920x1080,pleasecontactDell™toinquireaboutagraphicsAdapterthatsupportstheseresolutions.

Back to Contents Page
Setting Up Your Monitor
Dell™SX2210 Flat Panel Monitor
IfyouhaveanonDell™desktop,portablecomputer,orgraphicscard
1. Right-click on the desktop and click Properties.
2. Select the Settings tab.
3. Select Advanced.
4. Identify your graphics controller supplier from the description at the top of the window (e.g. NVIDIA, ATI, Intel etc.).
5. Refer to the graphic card provider website for updated driver (for example, http://www.ATI.com OR http://www.NVIDIA.com ).
6. After installing the drivers for your graphics adapter, attempt to set the resolution to 1920 X 1080 again.

Back to Contents Page
NOTE: If you are unable to set the resolution to 1920 x 1080, please contact the manufacturer of your computer or consider purchasing a graphics
adapterthatwillsupportthevideoresolutionof1920x1080.

Back to Contents Page
Operating the Monitor
Dell™SX2210 Flat Panel Monitor User's Guide
Turn On the Monitor
Using the Front Panel Controls
Using the On-Screen Display (OSD) Menu
Setting the Maximum Resolution
Using the Dell Soundbar (Optional)
Using the Tilt
Using the Camera
Installing and Using the Facial Recognition Software (FastAccess)

Turn On the Monitor
Press the buttontoturnonthemonitor


Using the Front Panel Controls
Usethebuttonsonthefrontofthemonitortoadjusttheimagesettings.

Front panel button
Description
A
Preset modes

Use the Preset modes button to choose from a list of preset color modes. See Using the OSD Menu.
B
Brightness / Contrast
Use the Brightness / Contrast button to direct access to the "Brightness" and "Contrast" control menu.
C
Menu

Use the Menu button to open the on-screen display OSD).
D


Front panel button
Use the buttonsonthesideofthemonitortoadjusttheimagesettings.
 

Using the On-Screen Display (OSD) Menu

Accessing the Menu System
Exit
Use the Exit button to exit on-screen display (OSD) from menu and sub-menus.
Front panel Button
Description
A
Up
Use the Up button to adjust (increase ranges) items in the OSD menu.
B
Down
Use the Down button to adjust (decrease ranges) items in the OSD menu.
C
OK

Use the OK button to confirm your selection.
D
Back

Use the back button to back main menu.
NOTE: IfyouchangethesettingsandtheneitherproceedtoanothermenuorexittheOSDmenu,themonitorautomaticallysavesthechanges.The
changes are also saved if you change the settings and then wait for the OSD menu to disappear.

1.
Press any key to launch the OSD menu and press to display the main menu.
Main Menu

The table below provides a list of all the OSD menu options and their functions.

2.
Press the and buttons to toggle between options in the Menu. As you move from one icon to another, the option name is highlighted.
3.
To select the highlighted item on the menu press the again.
4.
Press the and buttons to select the desired parameter.
5.
Press the buttonstoentertheslidebarandthenusethe or button, according to the indicators on the menu, to make your changes.
6.
Select the to return to previous menu without accepting current settings or to accept and return to previous menu.
Icon
Menu and Submenus
Description
BRIGHTNESS/CONTRAST
Use the Brightness and Contrast menu to adjust the Brightness/Contrast.




Back
Press the button to go back to the main menu.

Brightness
Allows you to adjust the brightness or luminance of the backlight.
Press the buttontoincreasebrightnessandpressthe button to decrease brightness (min 0 ~ max 100).

Contrast
Allows you to adjust the contrast or the degree of difference between darkness and lightness on the monitor screen. Adjust
brightness first, and adjust contrast only if you need further adjustment.
Press the button to increase contrast and press the button to decrease contrast (min 0 ~ max 100).
Auto Adjust
Use this button to activate automatic setup and adjust menu. The following dialog appears on a black screen as the monitor self
adjusts to the current input:





Auto Adjustment allows the monitor to self-
adjust to the incoming video signal. After using Auto Adjustment, you can further tune
your monitor by using the Pixel Clock (Coarse) and Phase (Fine) controls under Image Settings.


NOTE: Auto Adjust does not occur if you press the button while there are no active video input signals or attached cables.
Input Source
Use the Input Source menu to select different video signals that may be connected to your monitor.




Press the button to go back to the main menu


Select VGA input when you are using the analog (VGA) connector. Press the
button to select the VGA input source.


Select DVI-D input when you are using the digital (DVI) connector. Press the button to select the DVI input source.
Select HDMI input when you are using the digital (HDMI) connector. Press the button
to select the HDMI input source.
Select Auto select to let the monitor search for available input signals.
COLOR SETTINGS
Use the Color Settingmenutoadjustthemonitor'scolorsettings.


Color setting mode
submenu



Back
Press the button to go back to the main menu.

Input Color Format
Allows you to set the video input mode to:
lRGB
: Select this option if your monitor is connected to a computer or DVD player using the HDMI cable or the HDMI to DVI
adapter.
lYPbPr: Select this option if your DVD player supports only YPbPr output.

Mode Selection
Allows you to set the display mode to:
lGraphics: Select this mode if your monitor is connected to your computer.
lVideo: Select this mode if your monitor is connected to a DVD player.
NOTE: Depending upon the Display Mode you select the Preset Modes available for your monitor change.

Preset Mode
Allows you to choose from a list of preset color modes.
In the Graphics mode, you can set the color to the following preset values:
lStandard: Loads the monitor's default color settings. This is the default preset mode.
lMultimedia: Loads color settings ideal for multimedia applications.
lGame: Loads color settings ideal for most gaming applications.
lWarm: Increase the color temperature. The screen appears warmer with a red/yellow tint.
lCool: Decreases the color temperature. The screen appears cooler with a blue tint.
lCustom (RGB): Allows you to manually adjust the color settings. Press the and buttons
to adjust the Red, Green,
and Blue values and create your own preset color mode.
In the Video mode, you can set the color to the following preset values:
lMovie:Loads color settings ideal for movies. This is the default preset mode.
lGame: Loads color settings ideal for most gaming applications.
lSports: Loads color settings ideal for sports.
lNature: Loads color settings ideal for nature.

Hue
Allows you to adjust the skin tone of the image. Use or button to adjust the hue from '0' to '100'.
NOTE: Hue adjustment is available only in the Video mode.

Saturation
Allows you to adjust the color saturation of the image. Use or
button to adjust the saturation from '0' to '100'.
NOTE: Saturation adjustment is available only in the Video mode.

Demo Mode
Vertically splits the screen into two segments. The left half of the screen in the normal mode and the right half of the screen is
displayed in the color enhanced mode.
NOTE: Demo Mode is only available for video input.

Reset Color Settings
Resets your monitor's color settings to the factory defaults.
DISPLAY SETTINGS




Display setting mode
submenu


Back
Press the button to go back to the main menu.

Horizontal position
Usethe and buttons to adjust image left and right (min 0 ~ max 100).
NOTE: When using DVI or HDMI source, the Horizontal Position setting is not available.

Vertical Position
Usethe and buttons to adjust image up and down (min 0 ~ max 100).
NOTE: When using DVI or HDMI source, the Vertical Position setting is not available.

Pixel Clock
T
he Phase and Pixel Clock adjustments allow you to adjust your monitor to your preference. These settings are accessed through the
main OSD menu, by selecting 'Display Settings'.
Use the and buttons to adjust for best image quality.

Phase
If satisfactory results are not obtained using the phase adjustment, use the Pixel Clock (coarse) adjustment and then use Phase
(fine).
NOTE: Pixel Clock and Phase Adjustments are only available for "VGA" input.

Sharpness
Allows you to increase or decrease the sharpness of the image.
Use and buttons to adjust the sharpness from '0' to '100'.

Dynamic Contrast
The dynamic contrast helps get a higher contrast if you choose Game preset, Movie preset, Sports preset and Nature preset.
Use the button to enable the Dynamic Contrast adjustment.
Use the button to disable the Dynamic Contrast adjustment.

NOTE: Brightness control is disabled in Dynamic Contrast mode.

Response Time
Response time is the time required for an LCD pixel to change from fully active (black) to fully inactive (white), then back to fully active
again.
You can set the response time to:
lNormal
lOverdrive (default).

Reset Display Settings
Resets the monitor's display settings to the factory defaults.
AUDIO SETTINGS
Use the Audio Settings menu to adjust the audio settings.
