Dell PowerEdge C6145 Quick start guide

Dell PowerEdge
C6145 Rack Server
Technical Guide
Deliver velocity with two
4-socket AMD Opteron™
6200 and 6300 series
processors in 2U space
Shared infrastructure using
less floor space, power and
cooling
Mix, match, and maximize
connections; 5 PCIe
slots/server node, 10 total

ii Dell PowerEdge C6145 Rack Server Technical Guide
This document is for informational purposes only and may contain typographical errors and technical
inaccuracies. The content is provided as is, without express or implied warranties of any kind.
Dell, the DELL logo, PowerEdge, and OpenManage are trademarks of Dell, Inc. AMD, AMD Opteron,
AMD Virtualization, AMD-V, HyperTransport, and combinations thereof are trademarks of Advanced Micro
Devices, Inc. Intel is a registered trademarks of Intel Corporation in the U.S. and other countries. Microsoft,
Windows, Windows Server, and Hyper-V are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. SUSE is a registered trademark of Novell, Inc. in the
United States and other countries. Other trademarks and trade names may be used in this document to refer
to either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the
marks and names of others.
©Copyright 2013 Dell Inc. All rights reserved. Reproduction or translation of any part of this work beyond that
permitted by U.S. copyright laws without the written permission of Dell Inc. is unlawful and strictly forbidden.
September 2013 | Version 5.0

iii Dell PowerEdge C6145 Rack Server Technical Guide
Table of contents
1System overview..................................................................................................................................................................5
Key technologies ................................................................................................................................................................5
Product comparison ......................................................................................................................................................... 6
Specifications ......................................................................................................................................................................7
2Chassis views and features ............................................................................................................................................... 9
Front views.......................................................................................................................................................................... 9
Back view ............................................................................................................................................................................ 9
Internal view ..................................................................................................................................................................... 10
Chassis features ............................................................................................................................................................... 10
3Processor............................................................................................................................................................................12
Processor features............................................................................................................................................................12
Supported processors......................................................................................................................................................14
Processor configurations ................................................................................................................................................14
Processor installation.......................................................................................................................................................15
Chipset................................................................................................................................................................................15
4Memory...............................................................................................................................................................................16
Supported memory ..........................................................................................................................................................16
Memory configurations ...................................................................................................................................................16
Memory speed ..................................................................................................................................................................17
5Storage ................................................................................................................................................................................18
Internal storage .................................................................................................................................................................18
RAID configurations .........................................................................................................................................................19
Storage controllers...........................................................................................................................................................19
Optical drive ..................................................................................................................................................................... 20
Tape drive.......................................................................................................................................................................... 20
6Networking and I/O ..........................................................................................................................................................21
Embedded NICs/LAN on motherboard (LOM)............................................................................................................21
I/O slots ..............................................................................................................................................................................21
NIC cards........................................................................................................................................................................... 22
PCI card dimensions ....................................................................................................................................................... 23
7Power ................................................................................................................................................................................. 24
Power consumption and energy efficiency................................................................................................................ 24
Power supplies ................................................................................................................................................................. 25
System power supply throttling feature ...................................................................................................................... 25
8Rack information.............................................................................................................................................................. 26
Rails .................................................................................................................................................................................... 26
9Operating systems and virtualization ........................................................................................................................... 27
Supported operating systems........................................................................................................................................ 27
Supported virtualization ................................................................................................................................................. 27
10 Systems management ..................................................................................................................................................... 28
Embedded server management.................................................................................................................................... 28
Appendix A. Additional specifications and options ................................................................................................... 29
System dimensions.......................................................................................................................................................... 29
System weight .................................................................................................................................................................. 29
Environmental specifications ........................................................................................................................................ 29
Video specifications ........................................................................................................................................................ 30
Power supply specifications ...........................................................................................................................................31
USB peripherals.................................................................................................................................................................31
Appendix B. Standards compliance ............................................................................................................................. 32
Appendix C. Additional resources................................................................................................................................. 33

iv Dell PowerEdge C6145 Rack Server Technical Guide
Tables
Table 1. Comparison of PowerEdge C6145, R815 and C6105.................................................................................... 6
Table 2. Technical specifications.......................................................................................................................................7
Table 3. PowerEdge C6145 features.............................................................................................................................. 10
Table 4. AMD Opteron 6100, 6200 and 6300 series processor features.................................................................12
Table 5. Supported processors ........................................................................................................................................14
Table 6. DIMMs supported................................................................................................................................................16
Table 7. Memory speed capabilities ................................................................................................................................17
Table 8. Supported hard drives on the PowerEdge C6145 .........................................................................................18
Table 9. RAID support ........................................................................................................................................................19
Table 10. Detailed RAID support ....................................................................................................................................... 20
Table 11. Supported mezzanine and add-in cards........................................................................................................ 22
Table 12. Supported NIC add-in cards ............................................................................................................................ 22
Table 13. Power tools and technologies ......................................................................................................................... 24
Table 14. Power supply efficiency .................................................................................................................................... 25
Table 15. PowerEdge C6145 chassis dimensions .......................................................................................................... 29
Table 16. System weight..................................................................................................................................................... 29
Table 17. Environmental specifications ...........................................................................................................................30
Table 18. Supported video modes.................................................................................................................................... 30
Table 19. Power supply specifications..............................................................................................................................31
Table 20. Industry standard documents .......................................................................................................................... 32
Table 21. Additional resources .......................................................................................................................................... 33
Figures
Figure 1. PowerEdge C6145 front view with 2.5-inch hard drives .............................................................................. 9
Figure 2. PowerEdge C6145 front view with 3.5-inch hard drives .............................................................................. 9
Figure 3. PowerEdge C6145 back view............................................................................................................................. 9
Figure 4. PowerEdge C6145 internal view...................................................................................................................... 10
Figure 5. PowerEdge C6145 chassis dimensions .......................................................................................................... 29

5Dell PowerEdge C6145 Rack Server Technical Guide
1System overview
The Dell™PowerEdge™C6145 is an ultra-dense 2U, shared infrastructure server that can support
up to two 4-socket servers featuring the AMD Opteron™ 6100, 6200 and 6300 series processors.
Each independent server features dual or quad AMD Opteron 6000 series 8-core 12-core, or
16-core processors, SR56x0 chipset with SP5100 for I/O connectivity, DDR3 memory, DIMM thermal
sensors, PCI Express Generation 2 (PCIe 2.0), dual-port embedded gigabit Ethernet controllers, and
the integrated Intelligent Platform Management Interface (IPMI) 2.0 baseboard management
controller (BMC) with a dedicated RJ45 connection.
The PowerEdge C6145 is primarily used in high performance computing (HPC) environments, but
has many applications for other uses including:
HPC (large compute, graphics processing unit (GPU) compute)
—Oil and gas
—Life sciences
—Computational/fluid dynamics
Online gaming
Engineering design assessment (EDA—large memory)
Film/entertainment
Dense, HPC cluster environment
Core, memory, and I/O constrained applications
I/O constrained GPU farm
—PCIe 2.0 x16 delivers the maximum in the industry
Large memory footprint
—32 DIMMs per server in 2U
Key technologies
The PowerEdge C6145 is designed to provide the highest performance —it is a perfect match for
applications that take advantage of large core counts and large memory capacities and that have
high I/O needs. The PowerEdge C6145 is the first PowerEdge C driven platform based on direct
customer feedback. It is the premier dense server for high performance cluster computation,
massive I/O expansion, and very large memory capacity in a flexible shared infrastructure chassis.
Other features include:
Best in class density
—96 cores and 64 DIMMs in 2U
—128 cores and 64 DIMMs in 2U
2 x 4-socket servers in 2U
6 x 3.5-inch or 12 x 2.5-inch hard drives for 2-node configuration
12 x 3.5-inch or 24 x 2.5-inch hard drives for 1-node configuration
3 x PCIe x16 slots, 1 x PCIe x8 mezzanine slot, 1 dedicated host interface card (HIC) slots
Ideal platform for the C410x

6Dell PowerEdge C6145 Rack Server Technical Guide
Product comparison
Table 1 compares the features of the PowerEdge C6145 to the PowerEdge R815 and C6105.
Table 1. Comparison of PowerEdge C6145, R815 and C6105
Specification
PowerEdge C6145
PowerEdge R815
PowerEdge C6105
Processors
AMD Opteron 6100, 6200,
and 6300 series
AMD Opteron 6100,
6200, and 6300 series
AMD Opteron 4100,
4200, and 4300 series
Front side bus
N/A
N/A
N/A
Sockets
4
4
2
Cores
8, 12, 16
8, 12, 16
4, 6, 8
L2/L3 cache
L1 128K/core
L2 1MB/core
L3 16MB (shared)
L1 128K/core
L2 1MB/core
L3 16MB (shared)
L1 128K/core
L2 1MB/core
L3 8MB (shared)
Chipset
AMD SR5690
AMD SR5690
AMD SR5670
DIMMs
32 x DDR3 RDIMM
4GB/8GB/16GB/32GB LV at
1333MT/s;
4GB/8GB/16GB at 1600MT/s;
4GB/8GB/16GB LV at
1600MT/s
32 x DDR3 RDIMM,
UDIMM
1GB/2GB/4GB/8GB at
1333/1600MT/s;
16GB QR at 1066MT/s
12 x DDR3 RDIMM
2GB/4GB/8GB/16GB LV
at 1333MT/s
Min/Max RAM
4GB/1TB
4GB/1TB
2GB/192GB
Hard drive bays
24 x 2.5-inch or
12 x 3.5-inch
24 x 2.5-inch or
12 x 3.5-inch
24 x 2.5-inch or
12 x 3.5-inch
Hard drive types
SAS, SATA, SAS SSD
SAS, SATA, SAS SSD
SAS, NLSAS, SATA,
SATA SSD
External drive
bay
None
1
None
Embedded hard
drive controller
AMD SP5100
Dell H700
AMD SP5100
Optional storage
controller
N/A
Dell H800
N/A
Systems
management
BMC, IPMI 2,0 compliant
iDRAC6 Express,
Enterprise (Optional)
BMC, IPMI 2,0 compliant
I/O slots
5
6
2
RAID
LSI®2008 or LSI9265-8i
Dell H700
LSI 2008 or LSI9260-8i

7Dell PowerEdge C6145 Rack Server Technical Guide
Specification
PowerEdge C6145
PowerEdge R815
PowerEdge C6105
NIC/LOM
2 x 1Gb LOMs
4 x 1Gb LOMs
2 x 1Gb LOMs
Power supplies
Hot-plug redundant 1100W
(80+ Gold)
Auto Ranging
(100V-240V)
Redundant, 1400W
(80+ Platinum) (240V)
Hot-plug redundant
1100W (80+ Gold)
Auto Ranging
(90V-264V)
Hot-plug redundant
1100W (80+ Gold)
Auto Ranging
(100V-240V)
Redundant, 1400W (80+
Platinum) (240V)
USB
3
3
2
Form factor
1 or 2 nodes in
30-inch 2U
24-inch 2U
2 or 4 nodes in
30-inch 2U
Dimension
W: 44.8 cm (17.6 in)
D: 79 cm (31.1 in)
W: 48.2 cm (18.97in)
D: 74.4 cm (29.29in)
W: 44.8 cm (17.6 in)
D: 79 cm (31.1 in)
Weight
Min: 16.5 kg (36.38 lb)
Max: 42 kg (92.61 lb)
Max: 24.1kg (53.13lb)
Max: 33.67kg (74.2lb)
Min: 15.11kg (33.32lb)
Specifications
Table 2 summarizes the product features for the PowerEdge C6145 rack server. For the latest
information on supported features, visit Dell.com/PowerEdgeC.
Table 2. Technical specifications
Feature
PowerEdge C6145 technical specifications
Chassis
2U rack mount
Processor
AMD Opteron 6100, 6200, and 6300 series processors
Processor sockets
Up to two 4-socket servers
Front side bus
Intel®QuickPath Interconnect (QPI)
Number of cores
8, 12 or 16
L2/L3 cache
24MB, 28MB, or 32MB
Chipset
AMD SR5670 and SR5690
Memory
Up to 1TB (32 DIMM slots): 4GB/8GB/16GB/32GB DDR3 (1333MT/s 1.35V),
4GB/8GB/16GB (1600MT/s 1.5V and 1.35V)
Video
Integrated AST2050 with 64MB RAM
Maximum internal
storage
48TB SATA or 48TB Nearline SAS

8Dell PowerEdge C6145 Rack Server Technical Guide
Feature
PowerEdge C6145 technical specifications
I/O slots
1 PCIe x8 mezzanine slot
3 x PCIe x16 riser slot
1 dedicated HIC card
Mellanox®ConnectX®-2 40Gb/sec dual-port QDR InfiniBand®adapter (optional)
Intel 82559 dual-port 10GbE adapter (optional)
Drive controller
LSI 2008 6Gb SAS mezzanine (optional)
RAID controller
LSI 9265-8i add-in RAID controller
Drive bays and
hard drives
Up to 24 x 2.5-inch SAS, SATA, or SSD drives or 12 x 3.5-inch SAS or SATA drives
2.5” SAS (15K): 146GB, 300GB
2.5” SAS (10K): 300GB, 600GB, 900GB, 1.2TB
2.5” SATA (7.2K): 500GB, 1TB
2.5” NL SAS (7.2K): 500GB, 1TB
2.5” SATA SSD (MLC): 300GB, 600GB
2.5” SATA (eMLC): 100GB, 200GB, 400GB
3.5” SATA (7.2K): 500GB, 1TB, 2TB, 3TB, 4TB
3.5” SAS (15K): 300GB, 600GB
3.5” NL SAS (7.2K): 1TB, 2TB, 3TB, 4TB
Connectivity
Embedded Intel Kawela™82576 gigabit Ethernet controller
1Gb Ethernet network interface card (NIC)
Power supply
Dual hot-plug redundant high-efficiency 1100W/1400W power supplies
Fans
Shared redundant cooling with 4 x 80mm speed fans detectable with PWM
USB
2 external ports
Operating systems
Microsoft®Windows®HPC Server 2008 R2 (64-bit)
Microsoft Windows Server®2008 Core R2 (64-bit)
Microsoft Windows Server 2008 R2 Enterprise (64-bit)
Novell®SUSE®Linux®Enterprise Server
Red Hat®Enterprise Linux
Optional embedded hypervisors:
Citrix®XenServer®
VMware®vSphere®ESXi™
Microsoft Hyper-V ® Server 2008 R2
Services
(Availability varies by
region. Please contact
your sales
representative for
details.)
Infrastructure consulting services
Rack integration (U.S. only, not available in China)
Onsite deployment
Basic support
ProSupport for IT
Keep your hard drive
Enterprise wide contract
Specialized onsite services

9Dell PowerEdge C6145 Rack Server Technical Guide
2Chassis views and features
Front views
The PowerEdge C6145 is a 2U rack-mount server that can support up to two four-socket server
nodes. The PowerEdge C6145 chassis supports up to twenty-four 2.5-inch SAS, SATA, or SSD drives,
or twelve 3.5-inch SAS or SATA drives.
Figure 1. PowerEdge C6145 front view with 2.5-inch hard drives
Figure 2. PowerEdge C6145 front view with 3.5-inch hard drives
Back view
Figure 3. PowerEdge C6145 back view

10 Dell PowerEdge C6145 Rack Server Technical Guide
Internal view
Figure 4. PowerEdge C6145 internal view
Chassis features
Table 3 lists the features on the PowerEdge C6145 rack server. For additional feature information,
see the Dell PowerEdge C6145 Systems Hardware Owner’s Manual on Dell.com/Support/Manuals.
Table 3. PowerEdge C6145 features
Feature
Description
Power indicator
Indicates the system power is on
System identification
indicator
Used to locate a particular system within a chassis
Hard drives
Up to 12 hot-plug 3.5-inch hard drives
Up to 24 hot-plug 2.5-inch hard drives
Drive cover
Covers the system’s front-loading hard drives
Power supplies
1100W or 1400W
Thermal sensor
Monitors the inlet ambient temperature
NIC connectors
Embedded 10/100/1000 NIC connectors
NIC link/activity indicator
Indicates network activity and status

11 Dell PowerEdge C6145 Rack Server Technical Guide
Feature
Description
Serial port
Connects a serial device to the system
VGA port
Connects a VGA display to the system
BMC management port
Dedicated management port
USB ports
Connects USB devices to the system; ports are USB 2.0-compliant
iPASS connector
Connects to external PCIe devices or a PCIe bus extender port

12 Dell PowerEdge C6145 Rack Server Technical Guide
3Processor
Dell PowerEdge servers featuring AMD Opteron 6100, 6200 and 6300 series processors are
designed to handle the increasing complexity and demands of today’s real-world workloads. The
AMD Opteron 6100, 6200 and 6300 series processors deliver the world’s first x86 16-core processor,
delivering a rich mix of performance, scalability and efficiency for today’s highly threaded computing
environments.
Processor features
Table 4 highlights the features of the AMD Opteron 6100, 6200 and 6300 series processors.
Table 4. AMD Opteron 6100, 6200 and 6300 series processor features
Feature
Function
Benefits
AMD-P 2.0
Advanced
Platform
Management
Link (APML)
Provides an interface for
processor and systems
management monitoring
and controlling of system
resources (in APML-
enabled platforms);
comprised of the Remote
Power Management
Interface (RPMI) and the
precision thermal
monitor.
RPMI in APML enabled platforms:
Ability to monitor and control
platform power consumption
through p-state limits
Access to processor identification
and health
Precision thermal monitor:
Provides accurate information
about processor thermals to
closely monitor power/cooling
and proactively alert the BMC
Early notification helps save time
and money by providing
intelligence that can be used to
more effectively monitor power
and thermals to optimize cooling
solutions in an IT data center
Link Width
PowerCap
Power efficiency
capability (manually
enabled thru BIOS) that
changes all 16-bit links to
8-bit links
Helps improve performance-per-watt
AMD CoolSpeed
Technology
Reduces p-states when a
temperature limit is
reached
Server can continue to operate if
processor’s thermal environment
exceeds safe operational limits
Offers platform providers the
ability to safely reduce system fan
speeds, which helps deliver
greater platform efficiency

13 Dell PowerEdge C6145 Rack Server Technical Guide
Feature
Function
Benefits
C1E
An active sleep state
invoked when all
processor cores are idle
Delivers additional power savings (up to
10W for 2-processor servers) depending
on system configuration, such as when
the Northbridge and HyperTransport
technology links are powered down and
cores are at idle
LV-DDR3
support
Lower memory voltage of
1.35V versus standard
voltage memory of 1.5V
Helps reduce overall memory power
consumption
Ultra-low power
platform
Specialized ultra-low
power platforms are
great for cloud/dense
environments
Cooperative designs for specialized and
ultra-low power platform provide power
efficiency beyond just the processor
Direct Connect
Architecture
2.0
Up to DDR3-
1333 (1.333GHz)
memory support
Provides higher peak
throughput than earlier
memory technologies
Enables improved overall system
performance and investment protection
compared to earlier technologies
HyperTransport™
technology HT
Assist
Helps increase coherent
memory bandwidth and
reduce latency in
multi-node systems by
reducing cache probe
traffic between cores
Reduces the amount of cache probe bus
traffic, enhancing a server’s efficiency
and scalability
HyperTransport
3.0 technology
(HT3)
Provides superior system
bandwidth between
processors and I/O,
increasing interconnect
rate from 2GT/s with HT1
in previous generations
up to a maximum
6.4GT/s with HT3
Helps improves overall system balance
and scalability
Cache and core
count
Choice of 4- or 6-core
processors, with each
core having its own L1
and L2 caches, and a
shared 6MB L3 cache
Infrastructure designed to accommodate
either single- or dual-socket servers
providing server scalability from 4 cores
to 12 cores per server platform
AMD
Virtualization™
(AMD-V™)
technology
Features
I/O Virtualization
Supports I/O level
virtualization, which
provides direct control of
devices by a VM (enabled
by the
SR5690/SR5670/SR5650
chipsets)
Improved I/O performance within
a virtual machine
Enables an I/O device to be
directly assigned to a virtual
machine (VM)
Improved security through VM
address isolation
AMD Extended
Migration
AMD Extended Migration
allows you to safely
migrate a VM between
various AMD64 processor
revisions
Provides unprecedented flexibility in
deploying, maintaining, and upgrading
servers in live migration environments
based on AMD64 processors

14 Dell PowerEdge C6145 Rack Server Technical Guide
Supported processors
The PowerEdge C6145 rack server supports up to two four-socket servers featuring the AMD
Opteron 6100, 6200, or 6300 series processors. The PowerEdge C6145 supports the processors
listed in Table 5. For the latest information on supported processors, visit Dell.com/PowerEdgeC.
Table 5. Supported processors
Model
Speed
Power
Cache
Core
6180SE
2.5GHz
140W
6M L2, 12MB L3
12
6176
2.3GHz
115W
6M L2, 12MB L3
12
6172
2.1GHz
115W
6M L2, 12MB L3
12
6164HE
1.7GHz
85W
6M L2, 12MB L3
12
6128HE
2.0GHz
85W
6M L2, 12MB L3
8
6136
2.4GHz
115W
6M L2, 12MB L3
8
6132HE
2.2GHz
85W
6M L2, 12MB L3
8
6280
2.6GHz
140W
8M L2, 16MB L3
16
6276
2.3GHz
115W
8M L2, 16MB L3
16
6274
2.2GHz
115W
8M L2, 16MB L3
16
6234
2.4GHz
115W
8M L2, 16MB L3
12
6212
2.6GHz
85W
8M L2, 16MB L3
8
6262HE
1.6GHz
85W
8M L2, 16MB L3
16
6386SE
2.8GHz
140W
8x2M L2, 16MB L3
16
6380
2.5GHz
115W
8x2M L2, 16MB L3
16
6378
2.4GHz
115W
8x2M L2, 16MB L3
16
6376
2.3GHz
115W
8x2M L2, 16MB L3
16
6348
2.8GHz
115W
6x2M L2, 16MB L3
12
6344
2.6GHz
115W
6x2M L2, 16MB L3
12
6328
3.2GHz
115W
4x2M L2, 16MB L3
8
6320
2.8GHz
115W
4x2M L2, 16MB L3
8
6366HE
1.8GHz
85W
8x2M L2, 16MB L3
16
Processor configurations
The PowerEdge C6145 supports dual and quad-processor configurations. All processors must
match in all configurations.

15 Dell PowerEdge C6145 Rack Server Technical Guide
The PowerEdge C6145 uses only 3.5-inch hard drives with limited configurations and 140W AMD
Opteron processors.
Processor installation
For information on processor installation, see the Dell PowerEdge C6145 Systems Hardware
Owner’s Manual on Dell.com/Support/Manuals.
Chipset
The PowerEdge C6145 uses the AMD SR5690 and SR5670 chipsets. For more information, visit
AMD.com.

16 Dell PowerEdge C6145 Rack Server Technical Guide
4Memory
The PowerEdge C6145 uses DDR3 memory to provide a high-performance, high-speed memory
interface capable of low latency response and high throughput. The PowerEdge C6145 supports
registered ECC DDR3 DIMMs (RDIMMs); standard-voltage and low-voltage RDIMMs are available.
The PowerEdge C6145 has 32 memory sockets split into 4 sets of 8 sockets with one set of memory
sockets per processor. Each 8-socket set is organized into 4 channels, with 2 memory sockets per
channel.
Supported memory
The DDR3 memory interface consists of 4 channels, with up to 2 RDIMMs per channel for dual rank
(DR). The PowerEdge C6145 supports 4GB, 8GB, 16GB and 32GB low-voltage RDIMMs at
1066/1333/1600MT/s DDR3 frequencies.
The PowerEdge C6145 supports the DIMMs listed in Table 6. For the latest information on supported
memory, visit Dell.com/PowerEdgeC.
Table 6. DIMMs supported
Capacity
(GB)
Speed
(MT/s)
Type
Ranks per
DIMM
Data
width
SDDC support
Voltage
4
1333
RDIMM
2
x8
Advanced ECC
1.35
4
1333
RDIMM
1
x4
All modes
1.35
4
1600
RDIMM
2
x8
Advanced ECC
1.5
8
1333
RDIMM
2
x4
All modes
1.35
8
1600
RDIMM
2
x4
All modes
1.5
16
1066
RDIMM
4
x4
All modes
1.35
16
1333
RDIMM
2
x4
All modes
1.35
16
1600
RDIMM
2
x4
All modes
1.35
32
1333
LRDIMM
4
x4
All modes
1.35
Memory configurations
The PowerEdge C6145 server supports flexible memory configurations ranging from capacities of
4GB to 512GB (or 1TB per chassis). The PowerEdge C6145 supports a flexible memory configuration
according to these basic rules:
Speed: If DIMMs of different speeds are mixed, all channels across all processors operate at the
slowest DIMM’s common frequency.
DIMM type: Only one type of DIMM is allowed per system. RDIMM and UDIMM cannot be mixed.
For more information on memory configuration, see the Dell PowerEdge C6145 Systems Hardware
Owner’s Manual on Dell.com/Support/Manuals.

17 Dell PowerEdge C6145 Rack Server Technical Guide
Memory speed
The PowerEdge C6145 supports up to 1600MT/s memory performance with all channels and DIMMs
fully populated as long as the memory speed is 1600MT/s.
The memory frequency is determined by a variety of inputs, including the speed of the DIMMs. The
configuration of the DIMMs affects the speed of the processor.
Table 7 lists memory configuration and performance details for the PowerEdge C6145 based on the
population of the number and type of DIMMs per memory channel.
Table 7. Memory speed capabilities
DIMM type
DIMM 1
DIMM 2
Maximum
GB/channel
Maximum speed (MT/s)
1.5V
DIMMs
1.35V
DIMMs
1.25V
DIMMs
UDIMM
SR or DR
Empty
8GB
1600
1333
1333
SR
SR
8GB
1600
1333
1333
SR or DR
SR or DR
16GB
1333
1333
1066*
RDIMM
SR or DR
Empty
16GB
1600
1333
1333
SR
SR
16GB
1600
1333
1333
SR or DR
DR
32GB
1600
1333
1066*
QR
Empty
32GB
1333
1066*
1066*
QR
SR, DR, or QR
64GB
1066*
800*
800*
*Although the PowerEdge C6145 supports DIMM speeds of 800MT/s and 1066MT/s, you can only
purchase these systems with DIMM speeds of 1333MT/s and 1600MT/s on Dell.com/PowerEdgeC.

18 Dell PowerEdge C6145 Rack Server Technical Guide
5Storage
Each server node can have up to a maximum of 12 hard drives, depending on the number of
independent server nodes and drive type (3.5-inch or 2.5-inch) that are installed in each PowerEdge
C6145 chassis. To accommodate the supported drive options, the PowerEdge C6145 has one
backplane type for 12 x 3.5-inch drives, and one for 24 x 2.5-inch drives. These drive slots are
divided equally across two independent midplanes with dedicated power and controller
connections for each of the two nodes. All drive slots can be hot-swapped, and each Serial Attached
SCSI (SAS) or Serial ATA (SATA) slot has an LED indicator to indicate drive status and health.
Note: Mixing SAS and SATA drives is not supported.
Internal storage
The PowerEdge C6145 system supports up to 12 hard disk drives per server node, depending on the
number of installed nodes (1-2) and drive type (2.5-inch or 3.5-inch). The number of drives that can
be installed depends on the processor TDP wattage. Hard drives must use the PowerEdge C6145
specific drive carrier.
The PowerEdge 6145 supports the following hard drive types:
7.2K, 10K and 15K RPM 2.5-inch and 3.5-inch SAS drives
7.2K RPM Enterprise 2.5-inch and 3.5-inch SATA
The following hard disk drive configurations are for a two-node solution:
—Up to 6 x 3.5-inch SATA (6 HD-85W, 4 HD–115W, 4HD-140W)
—Up to 6 x 3.5-inch SAS (6 HD-85W, 4 HD–115W, 4HD-140W)
—Up to 12 x 2.5-inch SATA (12 HD-85W, 9 HD-115W, no 140W processor support)
—Up to 12 x 2.5-inch SAS (12 HD-85W, 9 HD-115W, no 140W processor support)
—Up to 12 x 2.5-inch SSD
The following hard disk drive configurations are for a single-node solution:
—Up to 12 x 3.5-inch SATA (12 HD-85W, 8 HD–115W, 8HD-140W)
—Up to 12 x 3.5-inch SAS (12 HD-85W, 8 HD–115W, 8HD-140W)
—Up to 24 x 2.5-inch SATA (12 HD-85W, 9 HD-115W, no 140W processor support)
—Up to 24 x 2.5-inch SAS (12 HD-85W, 9 HD-115W, no 140W processor support)
—Up to 24 x 2.5-inch SSD
Supported hard drives
Table 8 lists the hard drive options for the PowerEdge C6145 rack server. For additional information,
see Dell.com/PowerEdgeC.
Table 8. Supported hard drives on the PowerEdge C6145
Form
factor
Type
Speed
(rpm)
Capacities
3.5”
SATA
7.2K
500GB, 1TB, 2TB, 3TB, 4TB
Nearline SAS (6Gb)
7.2K
1TB, 2TB, 3TB, 4TB
SAS (6Gb)
15K
300GB, 600GB

19 Dell PowerEdge C6145 Rack Server Technical Guide
Form
factor
Type
Speed
(rpm)
Capacities
2.5”
SATA
7.2K
500GB, 1TB
Nearline SAS (6Gb)
7.2K
500GB, 1TB
SAS (6Gb)
10K
300GB, 600GB, 900GB, 1.2TB
SAS (6Gb)
15K
146GB, 300GB
SATA SSD (MLC)
NA
300GB, 600GB
SATA SSD (eMLC)
NA
100GB, 200GB, 400GB
RAID configurations
The PowerEdge C6145 supports RAID configurations, but only as a user-configurable option. See
the available RAID options in Table 9.
Table 9. RAID support
Controller
Supported RAID levels
Embedded SP5100 SATA Controller
RAID 0, 1, 10
LSI 2008 mezzanine
RAID 0,1, 10
LSI MegaRAID SAS 9265-8i SGL PCIe card
RAID 0, 1, 5, 6, 10, 50, 60
Storage controllers
LSI 9265-8i PCIe card
The PowerEdge C6145 supports a SAS daughtercard option if you need high performance SAS drives
but do not require higher-end resiliency features such as battery backup for NVRAM. Other features
include:
Storage controller: LSI MegaRAID SAS 9265-8i
Maximum quantity of storage devices: 6 hard drives
RAID level: RAID 0, 1, 5, and 6
RAID spans: 10, 50, and 60
Device type: PCIe add-in controller
PCI interface: PCIe 2.0 x8 lanes
SAS interface type: Two MiniSAS SFF-8087 x4 connectors
SAS interfaces transfer rate: Up to 6 Gb/second per port
Max ambient when this card is installed is 30°C

20 Dell PowerEdge C6145 Rack Server Technical Guide
Table 10 lists the features for the RAID support.
Table 10. Detailed RAID support
Product
Usage
Slot
PCI
connector
PCI
bracket
I/O
connector
RAID
Battery
backup
unit
SAS HBA
SAS/SATA
LSI 9265-8i
SGL
Internal
backplane
storage
RAID
(HDD,
SDD)
PCIe slot
x8
Yes
2 mini-SAS
x4
RAID 0, 1,
5, 6, 10,
50, 60
Yes
LSI 2008
mezzanine
card
Internal
backplane
storage
(HDD,
SDD)
Mezzanine
connector
x8
N/A
1 mini-SAS
x4 + 2 SAS
RAID 0, 1,
10
N/A
SP5100
On planar
through
chipset
Internal
SATA
HDDs only
N/A
N/A
N/A
6x internal
N/A
N/A
Optical drive
The PowerEdge C6145 chassis does not support optical drives. If needed, any external USB 2.0
compliant drive can be used, although no specific vendors have been qualified.
Tape drive
The PowerEdge C6145 chassis does not support an internal tape drive. External storage peripherals
are not directly validated with PowerEdge C6145, but customers can use any supported
network-based storage options validated with our network and fabric card matrix.
