Dell PowerEdge C6145 User manual

Dell PowerEdge
C6145
Getting Started
With Your System
Guide de mise en route du système
Primeiros passos com o sistema
Procedimientos iniciales con el sistema

Dell PowerEdge
C6145
Getting Started
With Your System

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
______________
Information in this publication is subject to change without notice.
© 2011 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission
of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, and PowerEdge™ are trademarks of
Dell Inc. AMD®is a registered trademark and AMD Opteron™ is a trademark of
Advanced Micro Devices, Inc. Red Hat Enterprise Linux®and Enterprise Linux®are
registered trademarks of Red Hat, Inc. in the United States and/or other countries.
Novell®is a registered trademark and SUSE™ is a trademark of Novell Inc. in the United
States and other countries. Citrix®and XenServer®are either registered trademarks or
trademarks of Citrix Systems, Inc. in the United States and/or other countries. VMware®
is a registered trademarks or trademarks of VMWare, Inc. in the United States or other
countries.
Other trademarks and trade names may be used in this publication to refer to either the
entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Regulatory Model B05S
January 2011 P/N 6HNH8 Rev. A00

Getting Started With Your System | 5
CAUTION: Restricted Access Location
This server is intended for installation only in restricted access locations as
defined in Cl. 1.2.7.3 of IEC 60950-1: 2001 where both these conditions apply:
 Access can only be gained by service persons or by users who have been
instructed about the reasons for the restrictions applied to the location and
about any precautions that shall be taken.
 Access is through the use of a tool or lock and key, or other means of
security, and is controlled by the authority responsible for the location.
Installation and Configuration
WARNING: Before performing the following procedure, review and follow the
safety instructions that came with the system.
Unpacking the System
Unpack your system and identify each item.
Installing the Tool-Less Rail Solution
WARNING: Whenever you need to lift the system, get others to assist you.
To avoid injury, do not attempt to lift the system by yourself.
WARNING: The system is not fixed to the rack or mounted on the rails. To
avoid personal injury or damage to the system, you must adequately
support the system during installation and removal.
WARNING: To avoid a potential electrical shock hazard, a third wire safety
grounding conductor is necessary for the rack installation. The rack
equipment must provide sufficient airflow to the system to maintain proper
cooling.
CAUTION: When installing rails in a square-hole rack it is important to
ensure that the square peg slides through the square holes.

Getting Started With Your System | 6
1 Pull on the latch release buttons on the end piece midpoints to open
the rail latches.
2 Align the end pieces of the rails on the vertical rack flanges to seat
the pegs in the bottom hole of the first U and the top hole of the
second U. Engage the back end of the rails until the latches lock in
place.
NOTE: The rails can be used in both square-hole (item 1 in the following figure)
and round-hole racks (item 2 in the following figure).
3 Repeat Step 1 and Step 2 to position and seat the front end pieces on
the vertical flanges.
NOTE: To remove the rails, pull on the latch release button on the end piece
midpoint and unseat each rail.
4 On each vertical rack flange on the rear, put two screw bases into the
two square holes right above the rail.
5 Install the chassis stabilizer shipping brackets (optional) on the rear
rack flanges and simultaneously fasten the screws.
NOTE: To transport systems already installed in the rack, ensure that the two
chassis stabilizer shipping brackets (optional) are in place.

Getting Started With Your System | 7
6 Slide the system into the rack.
7 Tighten the thumbscrews to secure the ears of the system to the front
of the rack flanges.

Getting Started With Your System | 8
Optional-Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which cable to
plug into each connector. Be sure to tighten the screws (if any) on the monitor’s
cable connector.

Getting Started With Your System | 9
Connecting the Power Cable(s)
Connect the system’s power cable(s) to the system and, if a monitor is used,
connect the monitor’s power cable to the monitor. Plug the other end of the
power cables into a grounded electrical outlet or a separate power source such as
an uninterrupted power supply or a power distribution unit.

Getting Started With Your System | 10
Turning on the System
Press the power button(s) either on the front or back of the system and on the
monitor. The power indicators should light.

Getting Started With Your System | 11
Complete the Operating System Setup
To install an operating system for the first time, see the installation and
configuration documentation for your operating system. Be sure the operating
system is installed before installing hardware or software not purchased with the
system.
Supported Operating Systems
 Microsoft Windows HPC Server 2008 R2 (64-bit)
 Microsoft Windows Server 2008 Core R2 (64-bit)
 Microsoft Windows Server 2008 R2 Hyper-V
 Microsoft Windows Server 2008 R2 Enterprise (64-bit)
 Red Hat Enterprise Linux 5.5 (64-bit)
 Red Hat Enterprise Linux 6.0 (Certification only)
 SUSE Linux Enterprise Server 11 SP1 (64-bit)
 VMware ESX Server 4.1 U1 and ESXi Embedded
 Citrix XenServer 5.6 Feature Pack 1
NOTE: For the latest information on supported operating systems, see
support.dell.com .

Getting Started With Your System | 12
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with your
system. Warranty information may be included within this document or as a
separate document.
The
Hardware Owner’s Manual provides information about system features and
describes how to troubleshoot the system and install or replace system
components. This document is available at
support.dell.com/manuals .
Dell systems management application documentation provides information
about installing and using the systems management software. This document is
available online at
support.dell.com/manuals .
NOTE: Always check for updates on support.dell.com/manuals and read the
updates first because they often supersede information in other documents.

Getting Started With Your System | 13
Technical Specifications
Processor (Per System Board)
Processor type Four AMD Opteron 6100 Series
processors
Expansion Bus (Per System Board)
Bus type PCI Express Generation 2
Expansion slots
PCIe One x16, low profile
Two x16, half-length/half-height
Daughter card PCIe One x16, Mezzanine slot
Memory (Per System Board)
Architecture 32 x DDR3 1066/1333 MHz RDIMM
or UDIMM
Memory module sockets 32 x DDR3 DIMM sockets
Memory module capacities 2 GB, 4 GB, 8 GB, or 16 GB
Minimum RAM 64 GB
Maximum RAM 512 GB
Drives
Hard drives Up to twelve 3.5-inch, hot-swappable
SAS/SATA drives or up to twenty four
2.5-inch, hot-swappable
SAS/SATA/SSD drives
NOTE: SAS hard drives are supported by add-on
card.
Connectors (Per System Board)
Back
NIC Two RJ-45 (10/100/1000 Mbps
Ethernet)
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant

Getting Started With Your System | 14
Video 15-pin D-Sub VGA
Management port Dedicated Ethernet port for remote
management access
V
ideo (Per System Board)
Video type On-board AST2050 video controller
Video memory 8 MB
Power
AC power supply (per power supply)
Wattage 1023 W low line/1100 W high line
Voltage 100-240 V CA, 50-60 Hz, maximum
input current: 12.0 Amps
Heat dissipation 4217.063 BTU/hr maximum
Wattage
1400 W
Voltage 200-240 V CA, 50-60 Hz, maximum
input current: 8.6 Amps
Heat dissipation 5724 BTU/hr maximum
Maximum inrush current Initial In-rush Current cannot exceed 55
Amps (peak). Secondary In-rush
Current cannot exceed 35 Amps (peak).
Battery (per system board)
System battery
CR 2032 3.0-V lithium ion coin cell
RAID battery (optional) 3.7-V lithium ion battery pack
Physical
Height 8.76 cm (3.45 in)
Width 44.8 cm (17.6 in)
Depth 79.0 cm (31.1 in)
Weight (maximum
configuration)
42 kg (92.61 lb)
Weight (empty) 16.5 kg (36.38 lb)

Getting Started With Your System | 15
Environmental
NOTE: For additional information about environmental measurements for specific system
configurations, see
www.dell.com/environmental_datasheets .
Temperature
Operating 10° to 35°C (50° to 95°F) with a
maximum temperature gradation of
10°C per hour
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1°F/550 ft.
Storage –40° to 65°C (–40° to 149°F) with a
maximum temperature gradation of
20°C per hour
Relative humidity
Operating 20% to 80% (noncondensing) with a
maximum humidity gradation of 10%
per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 Grms at 5–350 Hz
Storage 1.88 Grms at 10–500 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis
(one pulse on each side of the system)
of 31 G for 2.6 ms in the operational
orientation
Storage Six consecutively executed shock
pulses in the positive and negative x, y,
and z axes (one pulse on each side of
the system) of 71 G for up to 2 ms;
Six consecutively executed shock
pulses in the positive and negative x, y,
and z axes (one pulse on each side of
the system) of 22 G faired square wave
pulse with velocity change at 200
inches/second (508 centimeters/second)

Getting Started With Your System | 16
Environmental
Altitude
Operating –16 to 3,048 m (–50 to 10,000 ft)
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1°F/550 ft.
Storage –16 to 10,600 m (–50 to 35,000 ft)
Airborne contaminant level
Class G2 or lower as defined by
ISA-S71.04-1985

Dell PowerEdge
C6145
Guide de mise en route
du système

Remarques, précautions
et avertissements
REMARQUE : Une REMARQUE indique des informations importantes qui
peuvent vous aider à mieux utiliser votre ordinateur.
PRÉCAUTION : Une PRÉCAUTION indique un risque d'endommagement
du matériel ou de perte de données en cas de non respect des instructions.
AVERTISSEMENT : Un AVERTISSEMENT indique un risque
d'endommagement du matériel, de blessure corporelle ou de mort.
______________
Les informations contenues dans cette publication sont sujettes à modification sans
préavis.
© 2011 Dell Inc. tous droits réservés.
La reproduction de ce document de quelque manière que ce soit sans l'autorisation écrite
de Dell Inc. est strictement interdite.
Marques utilisées dans le présent document : Dell™, le logo DELL et PowerEdge™ sont
des marques de Dell Inc. AMD®est une marque déposée et AMD Opteron™ est une
marque d'Advanced Micro Devices, Inc. Red Hat Enterprise Linux®et Enterprise Linux®
sont des marques déposées de Red Hat, Inc. aux États-Unis et/ou dans d'autres pays.
Novell®est une marque déposée et SUSE™ est une marque de Novell Inc. aux États-Unis
et dans d'autres pays. Citrix®et XenServer®sont des marques déposées ou des marques de
Citrix Systems, Inc. aux États-Unis et/ou dans d'autres pays. VMware®est une marque
déposée ou une marque de VMware, Inc. aux États-Unis ou dans d'autres pays.
D'autres marques et noms de marque peuvent être utilisés dans ce document pour faire
référence aux entités se réclamant de ces marques et de ces noms ou de leurs produits.
Dell Inc. rejette tout intérêt propriétaire dans les marques et les noms de marques autres
que les siens.
Modèle réglementaire B05S
Janvier 2011 N/P 6HNH8 Rév. A00

Guide de mise en route du système | 19
PRÉCAUTION : Lieux à accès restreint
Ce serveur est conçu pour être installé uniquement dans des zones à accès
restreint telles que définies par la consigne Cl. 1.2.7.3 de la norme
IEC 60950-1: 2001 où les deux conditions suivantes s'appliquent:
 Seuls peuvent avoir accès le personnel d'entretien et les utilisateurs qui
ont été informés des motifs des restrictions appliquées au lieu et des
précautions à prendre.
 L'accès, qui se fait par l'intermédiaire d'un outil ou d'un verrou et d'une clé,
ou par d'autres moyens de sécurité, est contrôlé par le responsable en
charge du lieu.
Installation et configuration
AVERTISSEMENT : Avant de commencer la procédure suivante, lisez et
respectez les consignes de sécurité fournies avec le système.
Déballage du système
Sortez le système de son emballage et identifiez chaque élément.
Installation des rails sans outil
AVERTISSEMENT : Demandez toujours de l'aide avant de soulever le
système. N'essayez pas de le soulever seul, car vous risqueriez de vous
blesser.
AVERTISSEMENT : Le système n'est fixé ni au rack ni aux rails. Vous
devez le soutenir correctement au cours de l'installation et du retrait pour
éviter de l'endommager ou de vous blesser.
AVERTISSEMENT : Afin d'éviter un éventuel choc électrique, assurez-
vous que vous disposez d'un troisième conducteur de mise à la terre pour
l'installation du rack. L'équipement du rack doit assurer une ventilation
suffisante pour bien refroidir le système.
PRÉCAUTION : Lorsque vous installez des rails dans un rack à trous
carrés, vérifiez que les taquets de fixation à tête carrée glissent bien dans
les trous carrés.

Guide de mise en route du système | 20
1 Appuyez sur les boutons de dégagement des loquets situés au milieu
des embouts afin d'ouvrir les loquets des rails.
2 Alignez les extrémités des rails avec les montants verticaux du rack
de manière à insérer les chevilles, l'une en bas et l'autre en haut.
Faites glisser l'extrémité arrière des rails coulissants jusqu'à ce que
les loquets de verrouillage s'enclenchent.
REMARQUE : Les rails peuvent aussi bien être utilisés dans un rack à
trous carrés (élément 1 dans la figure ci-dessous) que dans un rack à
trous ronds (élément 2 dans la figure ci-dessous).
3 Répétez l'étape 1 et l'étape 2 afin de positionner et fixer les embouts
avant des rails sur les montants verticaux.
REMARQUE : Pour retirer les rails, appuyez sur le bouton de
dégagement du loquet situé au milieu de l'embout et dégagez les rails un
par un.
4 À l'arrière de chaque montant vertical du rack, insérez deux vis dans
les deux trous carrés situés juste au-dessus du rail.
5 Installez les supports d'expédition du stabilisateur de châssis (en
option) sur les montants arrière du rack et serrez simultanément les
vis.
REMARQUE : Avant de transporter des systèmes déjà installés dans le
rack, assurez-vous que les deux supports d'expédition du stabilisateur de
châssis (en option) sont en place.
Vue avan t
Vue arrière
