Dell PowerEdge Cluster FE100 User manual

www.dell.com
support.dell.com
Dell™ PowerEdge™ Cluster FE100/FL100 Datacenter Server
USER’S GUIDE

Notes, Notices, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in
bold type or in italic type. These blocks are notes, notices, cautions, and warnings,
and they are used as follows:
NOTE: A NOTE indicates important information that helps you make better use of
your computer system.
NOTICE: A NOTICE indicates either potential damage to hardware or loss
of data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
WARNING: A WARNING indicates a potentially hazardous situation which,
if not avoided, could result in death or serious bodily injury.
____________________
Information in this document is subject to change without notice.
© 2001 Dell Computer Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Computer Corpo-
ration is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, PowerEdge, PowerVault, and Dell OpenManage
are trademarks of Dell Computer Corporation; ClusterX is a registered trademark and VERITAS is
a trademark of VERITAS Corporation; Microsoft, Windows NT, and Windows are registered trade-
marks of Microsoft Corporation; Intel and Pentium are registered trademarks of Intel Corporation;
Computer Associates and ARCserve are registered trademarks of Computer Associates Interna-
tional, Inc.
Other trademarks and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. Dell Computer Corporation disclaims any propri-
etary interest in trademarks and trade names other than its own.
April 2001 P/N 9E926 Rev. A00

v
Preface
This guide provides information about the Dell PowerEdge Cluster FE100/FL100
Datacenter Server solution. This information includes procedures for installing, config-
uring, and troubleshooting the hardware and software components of PowerEdge
Cluster FE100/FL100 Datacenter Server configurations.
The chapters and appendixes in this guide are summarized as follows:
•Chapter 1, “Getting Started,” provides an overview of PowerEdge Cluster
FE100/FL100 Datacenter Server.
•Chapter 2, “Installation Overview,” provides an overview of the installation pro-
cess for PowerEdge Cluster FE100/FL100 Datacenter Server configurations.
Procedures are located throughout this guide.
•Chapter 3, “Preparing PowerEdge and PowerVault Systems for Clustering“pro-
vides information on adding peripherals and Fibre Channel host bus adapters.
•Chapter 4, “Cabling the Cluster Hardware,“provides instructions for properly
cabling the system hardware components.
•Chapter 5, “Configuring Storage Systems (Low-Level Configuration),“provides
information for configuring software and external shared storage.
•Chapter 6, “Configuring the System Software“provides the software configura-
tion options necessary for setting up the cluster.
•Chapter 7, “Installing Cluster Management and Systems Management Soft-
ware,“provides information on software tools for configuring and administering a
cluster including how to run Cluster Administrator locally on a cluster node and
how to install it on a remote console.
•Chapter 8, “Upgrading Your PowerEdge System to a Cluster Configuration,“pro-
vides procedures for upgrading your noncluster system to a PowerEdge Cluster
FE100/FL100 Datacenter Server configuration if the components of the cluster
hardware are already present.
•Chapter 9, “Maintaining the Cluster“provides information on maintaining
PowerEdge Cluster FE100/FL100 Datacenter Server configurations.
•Chapter 10, “SAN Components,” provides detailed information on storage area
network (SAN)-attached cluster configurations for the Dell PowerEdge Cluster
FE100/FL100 Datacenter Server configuration.

vi
•Appendix A, “Troubleshooting,” provides information to help you troubleshoot
problems with installing and configuring clusters.
•Appendix B, “Cluster Data Sheets,” provides worksheets on which to record
your specific configurations.
Warranty and Return Policy Information
Dell Computer Corporation (“Dell”) manufactures its hardware products from parts and
components that are new or equivalent to new in accordance with industry-standard
practices. See your Dell PowerEdge System Information document for complete war-
ranty information for your system.
Other Documents You May Need
You may need to refer to the following documentation when performing the proce-
dures in this guide:
•The Dell PowerVault SAN documentation for more information on storage area
networks.
•The User's Guide for your system, which describes system features and technical
specifications, small computer system interface (SCSI) device drivers, the
System Setup program, software support, and the system configuration utility.
•The Installation and Service Guide for your PowerVault storage system, which
provides installation and operation instructions for the PowerVault 65xF storage
system.
•The Dell OpenManage Data Agent Installation and Operation Guide, the Dell
OpenManage Data Supervisor Installation and Operation Guide, the Dell
OpenManage Data Administrator Installation and Operation Guide, and the Dell
OpenManage ATF Installation and Operation Guide, which provide installation
instructions for the Dell OpenManage Data Agent, Dell OpenManage Data Super-
visor, Dell OpenManage Data Administrator, and the Dell OpenManage ATF.
You may also have one or more of the following documents:
•The Rack Installation Guide for your PowerVault storage system and the rack
installation documentation for your Dell PowerEdge servers provide detailed
instructions for installing the cluster components in a rack.
•Dell OpenManage Cluster Assistant With ClusterX Getting Started Guide
provides installation and configuration instructions for the ClusterX software.
•The Hardware Installation Guide for the QLA2x00 and the Software Installation
Guide for the QLA2x00 provide installation instructions for the QLogic host bus
adapter.
•The Dell PowerVault Storage Area Network (SAN) Administrator’s Guide for
information on installing the QLogic software.

vii
•Dell PowerEdge Expandable RAID Controller Battery Backup Module User's
Guide.
•The Microsoft Cluster Server Administrator's Guide for the Windows 2000
Cluster Service documentation describes the clustering software used on
PowerEdge Cluster FE100/FL100 Datacenter.
•The Microsoft Windows 2000 Datacenter Server documentation describes how
to install (if necessary), configure, and use the Windows 2000 Datacenter Server
operating system.
Documentation is included with any options you purchase separately from the sys-
tem. This documentation includes information that you need to configure and install
these options in the Dell computer.
Technical information files-sometimes called “readme” files-may be installed on the
hard-disk drive to provide last-minute updates about technical changes to the system
or advanced technical reference material intended for experienced users or
technicians.
NOTE: Documentation updates are sometimes included with your system to describe
changes to your system or software. Always read these updates before consulting
any other documentation because the updates often contain the latest information.
Also consult Dell's Web site at http://www.support.com for updates.
Typographical Conventions
The following list defines (where appropriate) and illustrates typographical conven-
tions used as visual cues for specific elements of text throughout this document:
•Interface components are window titles, button and icon names, menu names
and selections, and other options that appear on the monitor screen or display.
They are presented in bold.
Example: Click OK.
•Keycaps are labels that appear on the keys on a keyboard. They are enclosed in
angle brackets.
Example: <Enter>
•Key combinations are series of keys to be pressed simultaneously (unless other-
wise indicated) to perform a single function.
Example: <Ctrl ><Alt><Enter>
•Commands presented in lowercase bold are for reference purposes only and are
not intended to be typed when referenced.
Example: “Use the format command to . . . .“
•In contrast, commands presented in the Courier New font are part of an instruc-
tion and intended to be typed.
Example: “Type format a: to format the diskette in drive A.”

viii
•Filenames and directory names are presented in lowercase bold.
Examples: autoexec.bat and c:\windows
•Syntax lines consist of a command and all its possible parameters. Commands
are presented in lowercase bold; variable parameters (those for which you substi-
tute a value) are presented in lowercase italics; constant parameters are
presented in lowercase bold. The brackets indicate items that are optional.
Example: del [drive:] [path] filename [/p]
•Command lines consist of a command and may include one or more of the com-
mand's possible parameters. Command lines are presented in the Courier New
font.
Example: del c:\myfile.doc
•Screen text is a message or text that you are instructed to type as part of a com-
mand (referred to as a command line). Screen text is presented in the Courier
New font.
Example: The following message appears on your screen:
•No boot device available
Example: “Type md c:\Programs and press <Enter>.”
•Variables are placeholders for which you substitute a value. They are presented in
italics.
Example: DIMM_x (where x represents the DIMM socket designation).

ix
Contents
Chapter 1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Overview of Microsoft Windows 2000 Datacenter Server . . . . . . . . . . . . . . . . . . . 1-1
Overview of a Dell PowerEdge Cluster FE100/FL100
Datacenter Server Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
SAN-Attached Cluster Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
PowerEdge Cluster FE100/FL100 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Activen/Active and Activen/Passive Configurations . . . . . . . . . . . . . . . . . . . . . 1-5
Failover and Failback Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
PowerEdge Cluster FE100/FL100
Datacenter Server Failover Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
N+1 Failover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Multiway Failover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Cascading Failover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
N-Way Migration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
PowerEdge Cluster FE100/FL100
Datacenter Server Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . 1-11
Cluster Nodes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Cluster Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Cluster Interconnect Connections
(Private Network) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Cluster Client Network Connections
(Public Network). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Operating System and System Management Software . . . . . . . . . . . . . . . . 1-12
PowerEdge Cluster FE100/FL100
Datacenter Server Support Configuration Requirements . . . . . . . . . . . . . . . . . . . 1-13
Required Configuration Requirements for the PowerEdge Cluster
FE100/FL100 Datacenter Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Shared Storage Requirements for the PowerEdge Cluster
FE100/FL100 Datacenter Server Configuration . . . . . . . . . . . . . . . . . . . . . . . 1-14
SAN-Attached Cluster Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15

x
Chapter 2 Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Chapter 3 Preparing PowerEdge and
PowerVault Systems for Clustering . . . . . . . . . . . . . . . 3-1
Adding Peripherals to Your Cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Configuring Fibre Channel HBAs on Separate PCI Buses . . . . . . . . . . . . . . . . 3-2
Configuring PowerVault DPE and DAE Enclosure Addresses . . . . . . . . . . . . . 3-2
Chapter 4 Cabling the Cluster Hardware . . . . . . . . . . . . . . . . . . 4-1
Cluster Cabling Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Fibre Channel Copper Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Cabling Your Public Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Using NICs in Your Public Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Cabling Your Private Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Using Broadcom NetExtreme Gigabit Ethernet Controllers in
Your Private Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Using Giganet cLAN for the Private Network . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Protecting Your Cluster From Power Failure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Connecting Standby Power Supplies in the PowerVault System . . . . . . . . . . 4-5
Cabling Your Mouse, Keyboard, and
Monitor in a Dell Rack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Chapter 5 Configuring Storage Systems
(Low-Level Configuration). . . . . . . . . . . . . . . . . . . . . . 5-1
Configuring PowerVault Shared Storage Hard-Disk Drives. . . . . . . . . . . . . . . . . . . 5-1
Configuring the LUNs and RAID Level for the Shared Storage Subsystem . . 5-2
Configuring Internal SCSI Hard-Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
RAID Level for the Internal SCSI Hard-Disk Drives . . . . . . . . . . . . . . . . . . . . . 5-2
Chapter 6 Configuring the System Software . . . . . . . . . . . . . . . . 6-1
Preparing for Microsoft Windows 2000 Datacenter Server Installation . . . . . . . . . 6-1
Configuring the Cluster Nodes in a
Windows 2000 Domain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Configuring the Windows 2000 Cluster Service . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Configuring the Public and Private Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Static IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Configuring the IP Addresses for the Private Network . . . . . . . . . . . . . . . . . . 6-5

xi
Installing and Configuring Your Windows 2000 Datacenter Server Network . . . . . 6-6
Overview of a Windows 2000 Datacenter Server Network Installation. . . . . . 6-6
Updating the Host Bus Adapter Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Installing the Dell OpenManage Storage Management Software
for the PowerVault Storage System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Configuring Shared Drives Using the Windows 2000
Disk Management Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Assigning Drive Letters and Formatting Drives
on the Shared Storage System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Using the Windows 2000 Dynamic Disks and Volumes . . . . . . . . . . . . . 6-12
Verifying Cluster Readiness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
Installing and Configuring the Windows 2000 Cluster Service . . . . . . . . . . . 6-13
Cluster Quorum Resource . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
Cluster Resource Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
Adding Additional Applications and Data to the Quorum Disk . . . . . . . . 6-14
Verifying Cluster Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Verifying Cluster Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Verifying Cluster Resource Availability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
Configuring the Dell OpenManage
Manage Node (Data Agent) for a Cluster Environment . . . . . . . . . . . . . . . . . . . . . 6-16
Configuring the Data Agent for Cluster Failover . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
Configuring Failover and Failback Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
Failover Support Through Four-Node Clustering . . . . . . . . . . . . . . . . . . . . . . 6-18
Modifying the Failover Sequence of the Disk Groups. . . . . . . . . . . . . . . 6-19
Chapter 7 Installing Cluster Management
and Systems Management Software . . . . . . . . . . . . . 7-1
Microsoft Cluster Administrator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Running Cluster Administrator on a Cluster Node . . . . . . . . . . . . . . . . . . . . . . 7-1
Installing Cluster Administrator on a Remote Console Running
Windows 2000 Professional. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Installing the Cluster Administrator on a Remote Console Running
Windows 2000 Advanced Server or Server Editions . . . . . . . . . . . . . . . . . . . . 7-2
Installing Cluster Administrator for Windows 2000 on a Remote Console
Running Windows NT 4.0 Server, Enterprise Edition. . . . . . . . . . . . . . . . . . . . 7-2
Installing Dell OpenManage Cluster Assistant With ClusterX (Optional). . . . . . . . . 7-3
Chapter 8 Upgrading Your PowerEdge
System to a Cluster Configuration . . . . . . . . . . . . . . . 8-1
Upgrading Your PowerEdge System to a PowerEdge Cluster FE100/FL100
Datacenter Server Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Installing the Appropriate Version of
Windows 2000 on Your PowerEdge System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

xii
Chapter 9 Maintaining the Cluster. . . . . . . . . . . . . . . . . . . . . . . . 9-1
Connecting to Your PowerVault
Storage Systems Using Dell OpenManage Storage Management Software . . . . . 9-1
Connecting to the PowerVault Shared Storage Systems
Using Data Agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Connecting to Data Agent Using Data Administrator . . . . . . . . . . . . . . . . . . . 9-2
Identifying the Cluster Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Connecting to Data Agent Using Data Supervisor . . . . . . . . . . . . . . . . . . . . . . 9-3
Identifying the Device Name of the Storage Processor . . . . . . . . . . . . . . 9-3
Restoring Communications to a Failed Storage Device Using
Dell OpenManage ATF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Using the QLogic Fibre Channel Configuration Software for PowerVault
65xF Storage Processor Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
Determining the RAID Levels of the Shared Disk Volumes . . . . . . . . . . . . . . . . . . 9-4
Configuring Your Cluster Nodes Using
Windows 2000 Datacenter Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
Adding a Third NIC to a Cluster Node . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
Changing the IP Address of a Cluster Node . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Uninstalling Cluster Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
Running chkdsk /f on a Quorum Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
Replacing a Cluster Node. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
Chapter 10 SAN Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
Overview of a PowerVault SAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
PowerVault SAN Components for PowerEdge Cluster
FE100/FL100 Datacenter Server Configurations . . . . . . . . . . . . . . . . . . . . . . 10-1
SAN-Attached Clusters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
Fibre Channel Fabrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Attaching a SAN-Attached Cluster Configuration to a Network . . . . . . . 10-4
Using Dell PowerVault Fibre Channel Switches . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
Attaching a PowerVault Storage System to a SAN-Attached Cluster . . . . . . . . . . 10-6
Connecting the PowerEdge Cluster to a Single PowerVault
Storage System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
Connecting a PowerVault 130T DLT Library and PowerVault 35F
Fibre Channel Bridge to a Cluster-Attached PowerVault SAN . . . . . . . . . . . . 10-7
Configuring Hard-Disk Drive Letters Using Multiple
Shared Storage Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-7
Additional PowerEdge Cluster Maintenance Procedures . . . . . . . . . . . . . . . . . . . 10-8
Using the QLogic Fibre Channel Configuration Utility
for Storage Processor Failure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-8
Appendix A Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Troubleshooting Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

xiii
Appendix B Cluster Data Sheets. . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
PowerEdge Cluster FE100/FL100
Datacenter Server Configuration Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Cluster Data Sheets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
Index
Figures Figure 1-1. SAN-Attached Cluster Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Figure 1-2. N+1 Failover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Figure 1-3. Example of a 4-Node Multiway Failover . . . . . . . . . . . . . . . . . . . . . . 1-8
Figure 1-4. Example of a 4-Node Cascading Failover. . . . . . . . . . . . . . . . . . . . . . 1-9
Figure 1-5. Example of a 4-Node N-Way Migration Solution . . . . . . . . . . . . . . . 1-10
Figure 4-1. DB-9 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Figure 4-2. HSSDC Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Figure 4-3. Configuration Using a Broadcom NetExtreme Gigabit NICs
for the Private Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Figure 4-4. Configuration Using a GigaNet cLAN NIC
for the Private Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Figure 4-5. Cable Configuration of PowerVault 65xF Power Supplies . . . . . . . . . 4-6
Figure 10-1. SAN-Attached Cluster Configuration . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Figure 10-2. SAN-attached Clusters Using a Public, Private,
and SAN Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5
Tables Table 2-1. System-Setup Navigation Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Table 2-2. Device-List Screen Navigation Keys . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Table 2-3. Power Time-Out Periods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Table 3-1. ICU Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Table 5-1. System-Board Jumper Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Table 5-2. System Board and Riser Board Connectors and Sockets . . . . . . . . . 5-8
Table 6-1. Sample DIMM Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Table A-1. Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Table B-1. Configuration Utility Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Table B-2. Configuration Manager Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . B-5

xiv

support.dell.com Getting Started 1-1
CHAPTER 1
Getting Started
This chapter provides an overview of the following information for the
Dell™PowerEdge™Cluster FE100/FL100 Datacenter Server configuration:
•Microsoft®Windows®2000 Datacenter Server operating system
•Configuration and operation
•Cluster identification
•Failover options
•Minimum system requirements
•Support configuration requirements
Overview of Microsoft Windows 2000
Datacenter Server
Windows 2000 Datacenter Server is geared specifically for organizations implement-
ing and managing enterprise applications that require high availability and high
performance. Typical application usages include large data warehouses, server con-
solidation, online transaction processing (OLTP), and modeling/simulation.
Windows 2000 Datacenter Server provides all of the features included with Microsoft
Windows 2000 Advanced Server, along with the following additional features:
•Two-to-four-node clustering—provides high availability of applications through
failover to another node in the cluster
•Support for up to 32-way symmetrical multiprocessing (SMP)—the operating sys-
tem distributes the processing workload with up to 32 central processing units
(CPUs)
•Support for up to 32 gigabyte (GB) random access memory (RAM) on the physi-
cal address extension (PAE)-capable PowerEdge 8450 system—improves
multiple application performance
•Winsock Direct—optimizes Internet protocol (IP) performance
•Process Control management tool—improves server resource management

1-2 User’s Guide
NOTE: Since Datacenter Server is one of four operating systems in the
Windows 2000 platform, some of the core services incorporated within Datacenter
Server are common to all Windows 2000 platforms. In the following sections, “Win-
dows 2000” is used to identify the services common to all Windows 2000 platforms
and “Windows 2000 Datacenter Server” is used to identify services and components
specific to the Datacenter Server platform.
Overview of a Dell PowerEdge Cluster
FE100/FL100 Datacenter Server
Configuration
The PowerEdge Cluster FE100/FL100 Datacenter Server is a cluster solution that
implements 2-node to 4-node clustering technology based on the Microsoft
Windows 2000 Cluster Service (MSCS) software incorporated within the Windows
2000 Datacenter Server operating system.
NOTE: In this guide and in other cluster documentation, MSCS is also referred to as
Cluster Service.
PowerEdge Cluster FE100/FL100 Datacenter Server solutions provide the following
benefits in meeting the needs of mission-critical network application programs:
•High availability of system services and resources to network clients
•Redundant storage for application program data
•Failure recovery for cluster application programs
•Flexible maintenance capabilities, allowing you to repair, maintain, or upgrade a
cluster node without taking the entire cluster offline
•Load balancing between the cluster nodes
A PowerEdge cluster consists of two or more PowerEdge 8450 server systems
(referred to as cluster nodes) that are interconnected with hardware and software
components, providing a single point of continuous access to network services
(including file systems, databases, enterprise resource planning [ERP], and other
application programs, and services) for network clients. Each cluster node is config-
ured with software, storage, and network resources that enable it to monitor and
interact with the other nodes to provide mutually redundant operation. Because the
cluster nodes interact in this way, they appear as a single system to the network
clients.
In a standard client/server environment, a user accesses a network resource by con-
necting to a physical server with a unique Internet Protocol (IP) address and network
name. If the server fails for any reason, the user will no longer be able to access the
resource. In a cluster environment, a user does not access a physical server, but a vir-
tual server—a network resource managed by the Cluster Service that is not
associated with a physical server, and can failover to another cluster node. Virtual
servers are designed to dynamically reconfigure user resources during a connection
or hardware failure, providing a higher availability of network resources as compared
to a nonclustered PowerEdge system.

support.dell.com Getting Started 1-3
NOTE: For more information on failover, failback, and groups, see “Configuring
Failover and Failback Support” in Chapter 6, “Configuring the System Software.”
SAN-Attached Cluster Configuration
A PowerEdge Cluster FE100/FL100 Datacenter Server configuration is a SAN-attached
cluster configuration where all four cluster nodes are attached to a single
PowerVault™ storage system or to multiple PowerVault storage systems through a
Dell PowerVault SAN using a redundant Fibre Channel switch fabric.
NOTE: A PowerEdge Cluster FE100/FL100 Datacenter Server configuration cannot
coexist on the Fibre Channel switch fabric with other clusters or stand-alone servers.
A Fibre Channel switch fabric is an active, intelligent, and private connection of one or
more fibre channel switches that provide high-speed, point-to-point connections
between servers and storage devices. Using instructions that are programmed into
the switch, the switches in a Fibre Channel fabric provide point-to-point connection
through inbound and outbound points from one device (sender) to another device or
switch (receiver) on the network. If the data is sent to another switch, the process
repeats itself until a connection is established between the sender and the receiver.
One or more PowerVault Fibre Channel switches make up a Fibre Channel fabric.
Figure 1-1 shows an advanced SAN-attached cluster configuration.

1-4 User’s Guide
Figure 1-1. SAN-Attached Cluster Configuration
PowerEdge Cluster FE100/FL100
Identification
The Dell PowerEdge Fibre Channel clusters are configured and identified by the
private network connection (cluster interconnect) that connects the cluster nodes
together— FE (Fibre Channel Ethernet) and FL (Fibre Channel Low Latency)—and the
type of storage devices in the cluster configuration.
PowerEdge
server
PowerVault
storage
system
Fibre Channel
Switch
LAN/WAN
PowerVault
storage
system
PowerVault
storage
system
Fibre Channel
Switch
PowerEdge
server
PowerEdge
server
PowerEdge
server
private net-
work switch

support.dell.com Getting Started 1-5
Table 1-1 provides an overview of the differences between PowerEdge Cluster FE100
and FL100 Datacenter Server configurations.
Activen/Active and Activen/Passive Configurations
MSCS and PowerEdge Clusters support multiple variations of Activen/Active and
Activen/Passive configurations (where n = the number of active cluster nodes).
Table 1-2 provides a description of the configuration types and their definitions.
An activen/active configuration refers to a cluster with virtual servers running on each
node. When an application is running on node 1, the remaining cluster nodes do not
have to wait for node 1 to fail. The remaining cluster nodes can run their own cluster-
aware applications (or another instance of the same application) while providing
failover capabilities for the resources on node 1. However, an activen/active cluster
node must be configured appropriately to handle the workload of other cluster nodes
in case one cluster node fails.
Activen/passive refers to failover cluster configurations in which one cluster node is
actively processing requests for a clustered application while another cluster node
simply waits for the active node to fail. An activen/passive configuration is more costly
in terms of price and performance because one cluster node sits idle all of the time.
Table 1-1. PowerEdge Cluster FE100/FL100 Configurations
Cluster Solution Cluster Interconnect
Type
Cluster Interconnect
Network Interface
Controller (NIC)
PowerEdge
Cluster FE100
Fast Ethernet Broadcom NetExtreme
Gigabit Ethernet NIC
PowerEdge
Cluster FL100
Giganet Giganet cLAN 1000
Table 1-2. Activen/Active and Activen/Passive Configuration Types
Configuration Type Number
of Active
Cluster
Nodes
Definition
Active/Active
Active/Active/Active
Active/Active/Active/Active
2
3
4
The active node(s) process requests
and provide failover for each other,
depending on cluster node resources
and your configuration.
Active/Passive
Active/Active/Passive
Active/Active/Active/Passive
1
2
3
The active node(s) processes
requests while the passive node
waits for the active node to fail.

1-6 User’s Guide
However, this configuration is appropriate for business-critical systems since the
application can use the full power of another cluster node in case one cluster node
fails.
NOTE: For clarity, future references of activen/active and activen/passive configura-
tions will use “n” to equal the number of active cluster nodes. For example, an
active/active/active/active configuration consisting of four active cluster nodes will be
referred to as an active4configuration.
Failover and Failback Support
One of the key features of Cluster Service is failover and failback support. Failover is
the process of automatically moving resources from a failed cluster node to other
healthy node(s) in the cluster. Failback is the process of returning the resources back
to the original cluster node. Both failover and failback can be an automatic or manual
process, depending on how you configure the Cluster Service.
NOTE: For more information on failover, failback, and cluster groups, see “Configuring
Failover and Failback Support” in Chapter 6, “Configuring the System Software.”
PowerEdge Cluster FE100/FL100
Datacenter Server Failover Options
The PowerEdge FE100/FL100 Datacenter Server configuration provides the following
failover options:
•N + 1
•Multiway
•Cascading
•N-Way migration solution
The following subsections describe each of these failover options.
N+1 Failover
N+1 failover is an activen/passive failover solution where one cluster node provides
backup for multiple cluster nodes. This solution provides the following features:
Advantage:
•One cluster node is a dedicated backup node for all cluster nodes, providing the
best solution for critical applications.
Disadvantages
•High expense, as one node is not used to provide network resources.
•Backup cluster node may lack the resources to support multiple cluster node
failures.
Figure 1-2 shows an example of N + 1 failover configuration.

support.dell.com Getting Started 1-7
Figure 1-2. N+1 Failover
Table 1-3 provides a N+1 failover configuration for the cluster shown in Figure 1-2. For
each cluster resource group, the failover order in the Preferred Owners list provides
the order that you want that resource group to failover. If that resource group or its
cluster node fails, the cluster will try to fail that resource group to the first available
node in the list. In this example, node 1 owns cluster resource group A, node 2 owns
cluster resource group B, and node 3 owns cluster resource group C. Cluster
resource groups A, B, or C would failover to cluster node 4, if cluster node 1, 2, or 3
fails, respectively.
NOTE: When implementing this type of failover solution, failback should be config-
ured if the cluster node lacks the resources (such as memory or processing power) to
support one or more cluster node failures.
Multiway Failover
Multiway failover is an activen/active failover solution where running applications from
a failed node migrate to multiple nodes in the cluster. This activen/active type of
failover provides the following features:
Advantage:
•Automatic failover and load-balancing between the cluster nodes.
Table 1-3. N+1 Failover Configuration for a 4-Node Cluster
Cluster Resource Group Failover Order in the Preferred
Owners List
A1,4
B2,4
C3,4
cluster
node 1
cluster
node 2
cluster
node 3
cluster
node 4
(backup)

1-8 User’s Guide
Disadvantage:
•Must ensure that the failover cluster nodes have ample resources available to
handle the additional workload.
Figure 1-3 shows an example of multiway failover configuration.
Figure 1-3. Example of a 4-Node Multiway Failover
Table 1-4 provides an example of a multiway failover configuration for the cluster
shown in Figure 1-3. For each cluster resource group, the failover order in the
Preferred Owners list outlines the order that you want that resource group to failover.
In this example, node 1 owns cluster resource groups A, B, and C. If node 1 fails, the
cluster resource groups A, B, and C will failover to cluster nodes 2, 4, and 3, respec-
tively. The cluster resource groups on cluster nodes 2, 3, and 4 need to be configured
similarly.
NOTE: When implementing this type of failover solution, failback should be config-
ured to avoid performance degradation.
Cascading Failover
With Cascading failover, all running applications migrate from the failed node to the
next preassigned cluster node. If you do not make a failover selection, cascading
failover will be the default failover type. This type of failover provides the following
features:
Table 1-4. Example of a 4-Node Multiway Failover Configuration
Cluster Resource Group Failover Order in the
Preferred Owners List
A 1, 2, 3, 4
B 1, 4, 2, 3
C 1, 3, 4, 2
cluster
node 1
cluster
node 2
cluster node 3 cluster node 4
Application A
Application B
Application C
