Dell PowerEdge T605 User manual

Dell™ PowerEdge™
T605 Systems
Getting Started With
Your System
Guide de mise en route
Primeiros passos com o sistema
Procedimientos iniciales con el sistema

Dell™ PowerEdge™
T605 Systems
Getting Started With
Your System

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use
of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data
and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury,
or death.
____________________
Information in this document is subject to change without notice.
© 2007 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly
forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; AMD and AMD Opteron
are registered trademarks of Advanced Micro Devices; Microsoft, Windows and Windows Server are
registered trademarks of Microsoft Corporation; Red Hat and Red Hat Enterprise Linux are registered
trademarks of Red Hat, Inc.; SUSE is a registered trademark of Novell Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks
and trade names other than its own.
Model SCM
November 2007 P/N GM693 Rev. A00

Getting Started With Your System 3
System Features
This section describes the major hardware and software features of your
system. It also provides information about other documents you may
need when setting up your system and how to obtain technical assistance.
• One or two dual-core or quad-core AMD™ Opteron™ processors.
NOTE: Use the System Setup program to view processor information.
See the Hardware Owner’s Manual.
• A minimum of 1 GB (single-processor systems) or 2 GB (two-processor
systems) of 533 or 667 MHz registered parity DDR-II memory modules.
Memory is upgradable to a maximum of 32 GB (two-processor systems)
by installing combinations of 512-MB, 1-GB, 2-GB, or 4-GB memory
modules in the eight memory module sockets on the system board.
• Support for up to four 3.5-inch, internal non-hot-pluggable or hot-
pluggable (when available) Serial Attached SCSI (SAS) or SATA hard
drives. A controller expansion card is required for SAS hard drives or
for more than two SATA hard drives.
• One 3.5-inch peripheral drive bay for the optional diskette drive, and
two 5.25-inch bays for the following supported drives: DVD-ROM,
combination CD-RW/DVD, DVD+RW, or tape backup device.
NOTE: DVD devices are data only.
• An intrusion switch that signals the appropriate systems management
software if the cover is opened.
• A 650-W non-redundant power supply, or an optional hot-pluggable
675-W power supply in a 1 + 1 redundant configuration.

4Getting Started With Your System
The system board includes the following integrated features:
• SATA controller that supports up to two cabled SATA hard drives,
and up to two of the following supported devices: DVD-ROM,
CD-RW/DVD combination drive, DVD+RW, or SATA tape
backup device.
NOTE: DVD devices are data only.
• One 133-MHz PCI-X expansion slot, three PCI Express (PCIe) x4
expansion slots, and one PCIe x8 expansion slot.
• An integrated ATI RN50 2D graphics controller with a minimum of 32 MB
of graphics memory. Maximum resolution is 1280 x 1024 with 65,536
colors; graphics are supported in the following resolutions: 640 x 480,
800 x 600, 1024 x 768, and 1280 x 1024.
• An integrated Gigabit NIC, capable of supporting 1000-Mbps, 100-Mbps,
or 10-Mbps data rates, with support for PXE, Wake-on-LAN, TCP/IP
Offload Engine (TOE), and iSCSI offload and boot.
• An integrated Trusted Platform Module (TPM) version 1.2 used for
security applications, capable of generating and storing keys and storing
passwords and digital certificates. (Not available in China.)
• Eight USB 2.0-compliant connectors (two on the front, one internal
for a bootable memory key, and five on the back) capable of supporting
a diskette drive, a DVD-ROM drive, a keyboard, a mouse, or a USB flash
drive.
• Optional Remote Access Controller (RAC) for remote systems
management.
• Standard Baseboard Management Controller (BMC) with serial
and LAN access.
• Back-panel connectors include serial, video, five USB connectors,
and one NIC connector.
• Front-panel connectors include two USB connectors.
• Front-panel LCD for system ID and error messaging.
For more information about specific features, see “Technical Specifications”
on page 10.

Getting Started With Your System 5
Supported Operating Systems
Your system supports the following operating systems:
• Microsoft
®
Windows Server
®
2008 Standard and Enterprise (32-bit x86)
Editions
• Microsoft Windows Server 2008 Standard and Enterprise (x64) Editions
• Microsoft Windows
®
Small Business Server 2008 Standard and Premium
Editions
• Microsoft Windows Server 2003 Standard and Enterprise (32-bit x86)
Editions with SP2
• Microsoft Windows Server 2003 Standard and Enterprise (x64) Editions
with SP2
• Microsoft Windows Server 2003 R2 Standard and Enterprise (32-bit x86)
Editions with SP2
• Microsoft Windows Server 2003 R2 Standard and Enterprise (x64)
Editions with SP2
• Microsoft Windows Small Business Server 2003 R2 Standard
and Premium Editions with SP2
•RedHat
®
Enterprise Linux
®
ES and AS (version 4.5) (x86_32)
• Red Hat Enterprise Linux ES and AS (version 4.5) (x86_64)
• Red Hat Enterprise Linux Server 5 (x86_32)
• Red Hat Enterprise Linux Server 5 (x86_64)
•SUSE
®
Linux Enterprise Server 9 (SP4) (x86_64)
• SUSE Linux Enterprise Server 10 (x86_64)
NOTE: For the latest information on supported operating systems,
see www.dell.com.

6Getting Started With Your System
Other Information You May Need
CAUTION: The Product Information Guide provides important safety and
regulatory information. Warranty information may be included within this
document or as a separate document.
•The Hardware Owner’s Manual provides information about system
features and describes how to troubleshoot the system and install
or replace system components.
• CDs included with your system provide documentation and tools
for configuring and managing your system.
• Updates are sometimes included with the system to describe changes
to the system, software, and/or documentation.
NOTE: Always check for updates on support.dell.com and read the updates
first because they often supersede information in other documents.
• Release notes or readme files may be included to provide last-minute
updates to the system or documentation or advanced technical reference
material intended for experienced users or technicians.
• Operating system documentation describes how to install (if necessary),
configure, and use the operating system software.
• Documentation for any components you purchased separately provides
information to configure and install these options.
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system
does not perform as expected, see your Hardware Owner’s Manual.
Dell Enterprise Training and Certification is available; see
www.dell.com/training for more information. This service may not be
offered in all locations.

Getting Started With Your System 7
Installation and Configuration
CAUTION: Before performing the following procedure, read and follow the safety
instructions and important regulatory information in your Product Information
Guide.
NOTICE: Make sure there are no physical obstructions within 30 cm (12 inches)
of the front of the system and 61 cm (24 inches) of the rear of the system.
This may cause a decrease in airflow, which could cause your system to overheat.
This section describes the steps to set up your system for the first time.
Unpack the System
Upack your system and identify each item. Keep all shipping materials in case
you need them later.

8Getting Started With Your System
Connect the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which
cable to plug into each connector. Be sure to tighten the screws (if any)
on the monitor's cable connector.
Connect the System to Power
Connect the monitor’s power cable to the monitor (optional), and connect
the system’s power cable(s) to the system.

Getting Started With Your System 9
Installing the Power Cord Retention Bracket
Attach the power cord retention bracket on the right bend of the power
supply handle. Bend the system power cable into a loop as shown in the
illustration and attach to the bracket’s cable clasp. Repeat the procedure
for the second power supply.
Plug the other end of the power cable(s) into a grounded electrical outlet
or a separate power source such as an uninterrupted power supply (UPS)
or a power distribution unit (PDU).
Turn on the System and Monitor
Press the power button on the system and the monitor (optional). The power
indicators should light. Adjust the monitor's controls until the displayed
image is satisfactory.

10 Getting Started With Your System
Complete the 0perating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system
for the first time, see the Quick Installation Guide. Be sure the operating system
is installed before installing hardware or software not purchased with the
system.
Technical Specifications
Processor
Processor type One or two dual- or quad-core
AMD
™ Opteron ™ processors
Expansion Bus
Bus type PCIe and PCI-X
Expansion slots
PCIe One x8 full-height, full-length 3.3-V
(slot 4)
Three x4 full-height, full-length 3.3-V
(slots 1 through 3)
PCI-X One full-height, full-length 3.3-V (slot 5)
One internal USB key socket
Memory
Architecture
128-bit DDR II SDRAM DIMMs, rated
for
533-MHz or 667-MHz operation
Memory module sockets Eight 240-pin
Memory module capacities
512 MB, 1 GB, 2 GB, or 4 GB
Minimum RAM 1 GB (one processor) or 2 GB
(two processors)
Maximum RAM 16 GB (one processor) or 32 GB
(two processors)

Getting Started With Your System 11
Drives
Hard drives
Up to four 3.5-inch internal non-hot-plug
or hot-plug (when available) SAS or SATA
Diskette drive One optional internal 3.5-inch, 1.44-MB
Optical drives Up to two optional internal DVD-ROM
(SATA or PATA), DVD+RW (SATA or
PATA), or CD-RW/DVD combination
(SATA) drives
NOTE: DVD devices are data only.
External optional USB DVD
Tape drive One optional internal half-height,
5.25-inch SAS, SATA, or SCSI
External optional USB tape backup
device
Flash drive External optional USB
Internal optional USB
Connectors
Back
NIC One RJ-45 (for Broadcom Gigabit LOM)
Serial 9-pin, DTE, 16550-compatible
USB Five 4-pin, USB 2.0-compliant
Video 15-pin VGA
Front
USB Two 4-pin, USB 2.0-compliant
Internal
USB One 4-pin, USB 2.0-compliant

12 Getting Started With Your System
Video
Video type Integrated
Video memory 32 MB (minimum)
Power
AC power supply
Wattage 650 W (non-redundant power supply)
675 W (redundant power supply)
Voltage 100-240VAC, 6.0-3.0A, 50/60 Hz
Heat dissipation
624 BTU/Hour (non-redundant
power supply)
574 BTU/Hour (redundant power supply)
CMOS backup battery CR 2032 3.0-V lithium ion coin cell
Physical
Height 456 mm (17.95 inches)
Width 210 mm (8.27 inches)
Depth 635 mm (25 inches)
Weight (maximum configuration) 27 kg (59.52 lb)

Getting Started With Your System 13
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 20% to 80% (noncondensing)
with a maximum humidity gradient
of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 Grms, 5 to 350 Hz at 0.0002 G2/Hz
Storage 1.54 Grms, 10 to 250 Hz
at 0.003 to 0.01 G2/Hz
Maximum shock
Operating 27 G +/– 10% with pulse duration
of 2.6 msec +/– 10%
Storage 71 G +/– 10% with pulse duration
of 2 msec +/– 10%, 32G +/– 5% with
velocity change of 235 ips +/– 5%
Altitude
Operating –15.2 to 3,048 m (–50 to 10,000 ft)
Storage –15.2 to 10,600 m (–50 to 35,000 ft)
Airborne contaminant level
Class G2 or lower as defined
by ISA-S71.04-1985

14 Getting Started With Your System

Systèmes Dell™
PowerEdge™ T605
Guide de mise en route

Remarques, avis et précautions
REMARQUE : Une REMARQUE indique des informations importantes
qui peuvent vous aider à mieux utiliser votre ordinateur.
AVIS : Un AVIS vous avertit d'un risque de dommage matériel ou de perte
de données et vous indique comment éviter le problème.
PRÉCAUTION : Une PRÉCAUTION indique un risque potentiel d'endommagement
du matériel, de blessure corporelle ou de mort.
____________________
Les informations contenues dans ce document peuvent être modifiées sans préavis.
© 2007 Dell Inc. Tous droits réservés.
La reproduction de ce document de quelque manière que ce soit sans l'autorisation écrite de Dell Inc.
est strictement interdite.
Marques utilisées dans ce document : Dell et le logo DELL sont des marques de Dell Inc. ;
AMD et AMD Opteron sont des marques déposées d'Advanced Micro Devices ; Microsoft, Windows
et Windows Server sont des marques déposées de Microsoft Corporation ; Red Hat et Red Hat Enterprise
Linux sont des marques déposées de Red Hat, Inc. ; SUSE est une marque déposée de Novell Inc.
D'autres marques et noms de marques peuvent être utilisés dans ce document pour faire référence
aux entités se réclamant de ces marques et de ces noms ou à leurs produits. Dell Inc. dénie tout intérêt
propriétaire vis-à-vis des marques et des noms de marque autres que les siens.
Modèle SCM
Novembre 2007 N/P GM693 Rév. A00

Guide de mise en route 17
Caractéristiques du système
Cette section décrit les principales caractéristiques matérielles et logicielles
du système. Elle contient également des informations sur d'autres documents
pouvant être utiles à la configuration du système et indique comment obtenir
une assistance technique.
• Un ou deux processeurs AMD™ Opteron™ double coeur ou quadruple
coeur.
REMARQUE : Utilisez le programme de configuration du système pour
visualiser les informations concernant les processeurs. Reportez-vous
au document Hardware Owner's Manual (Manuel du propriétaire).
• Barrettes de mémoire DDR-II à registres et avec parité, représentant
un minimum de 1 Go (systèmes monoprocesseur) ou de 2 Go (systèmes
bi-processeur) et cadencées à 533 ou 667 MHz. La mémoire est extensible
à un maximum de 32 Go (systèmes bi-processeur) via l'installation de
combinaisons de barrettes de 512 Mo, 1 Go, 2 Go ou 4 Go dans les huit
emplacements mémoire de la carte système.
• Prise en charge d'un maximum de quatre disques durs internes SAS
(Serial Attached SCSI) ou SATA de 3,5 pouces, enfichables à chaud ou
non (selon disponibilité). Une carte contrôleur d'extension est requise
pour les disques durs SAS, ou si vous utilisez plus de deux disques durs
SATA.
• Une baie de périphérique de 3,5 pouces pouvant accueillir le lecteur de
disquette en option, et deux baies de 5,25 pouces prenant en charge les
lecteurs suivants : lecteur de DVD-ROM, lecteur combo CD-RW/DVD,
lecteur de DVD+RW ou unité de sauvegarde sur bande.
REMARQUE : Les périphériques DVD sont uniquement des périphériques
de données.
• Un détecteur d'intrusion qui transmet une alerte aux logiciels de gestion
de systèmes appropriés en cas d'ouverture du capot de l'ordinateur.
• Un bloc d'alimentation de 650 W non redondant, ou un bloc
d'alimentation de 675 W enfichable à chaud dans une configuration
redondante 1 + 1 (en option).

18 Guide de mise en route
La carte système offre les caractéristiques suivantes :
• Contrôleur SATA prenant en charge jusqu'à deux disques durs SATA
connectés par câble, et jusqu'à deux périphériques parmi les suivants :
lecteur de DVD-ROM, lecteur combo CD-RW/DVD, lecteur de
DVD+RW ou périphérique SATA de sauvegarde sur bande.
REMARQUE : Les périphériques DVD sont uniquement des périphériques
de données.
• Un logement d'extension PCI-X à 133-MHz, trois logements d'extension
PCI Express (PCIe) x4 et un logement d'extension PCIe x8.
• Un contrôleur vidéo 2D intégré ATI RN50 avec au moins 32 Mo
de mémoire vidéo. La résolution maximale prise en charge est de
1280 x 1024 avec 65536 couleurs. Les graphiques sont pris en charge
dans les résolutions suivantes : 640 x 480, 800 x 600, 1024 x 768
et 1280 x 1024.
• Un NIC Gigabit intégré prenant en charge des débits de données
de 1000, 100 ou 10 Mbps, ainsi que les fonctions suivantes :
PXE, Wake-on-LAN, moteur de décentralisation TCP/IP (TOE),
déchargement et amorçage iSCSI.
• Puce TPM (Trusted Platform Module) intégrée version 1.2, utilisée
pour la sécurité des applications et pouvant générer et mémoriser des
clés, des mots de passe et des certificats numériques (non disponible
en Chine).
• Huit connecteurs USB 2.0 (deux à l'avant, cinq à l'arrière et
un connecteur interne pour une clé de mémoire amorçable).
Ces connecteurs permettent de brancher un lecteur de disquette
ou de DVD-ROM, un clavier, une souris ou un lecteur flash USB.
• Un contrôleur RAC (Remote Access Controller) en option, pour la
gestion de systèmes à distance.
• Un contrôleur BMC (Baseboard Management Controller) standard
avec accès série et réseau local.
• Panneau arrière comprenant des connecteurs série et vidéo, des ports
USB (5) et un connecteur de NIC.
