Dell PowerEdge M630 User manual

Dell PowerEdge M630
Owner's Manual
Regulatory Model: HHB
Regulatory Type: HHB005

Notes, cautions, and warnings
NOTE: A NOTEindicates important information that helps you make better use of your computer.
CAUTION: A CAUTION indicates either potentialdamage to hardware or lossof data andtellsyou how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury,or death.
Copyright © 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Other trademarks may be trademarks of their respective owners.
2018 - 03
Rev. A02

3
Contents
1 Dell PowerEdge M630 overview ......................................................................... 7
Supported configurations for the PowerEdge M630 system ...................................................................................... 7
Front panel ................................................................................................................................................................ 8
2.5-inch hard drive or SSD system ...................................................................................................................... 9
1.8-inch SSD system ........................................................................................................................................ 10
Diagnostic Indicators .............................................................................................................................................. 11
iDRAC Direct LED indicator codes .................................................................................................................... 11
Using USB diskette or USB DVD or CD drives .................................................................................................. 11
Hard drive or SSD indicator patterns ................................................................................................................. 12
Locating Service Tag of your system ...................................................................................................................... 13
2 Documentation resources ..............................................................................14
3 Technical specifications....................................................................................16
Chassis dimensions ............................................................................................................................................... 16
Chassis weight ....................................................................................................................................................... 16
Processor specifications ......................................................................................................................................... 16
System battery specifications ................................................................................................................................. 17
Memory specifications ............................................................................................................................................ 17
RAID controllers ..................................................................................................................................................... 17
PCIe mezzanine card slots ..................................................................................................................................... 17
Driver specification ................................................................................................................................................. 17
Hard drives ....................................................................................................................................................... 17
SSDs ................................................................................................................................................................ 17
Optical drive ..................................................................................................................................................... 17
Flash drive ........................................................................................................................................................ 18
Ports and connectors specifications ....................................................................................................................... 18
USB ports ......................................................................................................................................................... 18
Internal Dual SD Module ................................................................................................................................... 18
Video specifications ............................................................................................................................................... 18
Environmental specifications .................................................................................................................................. 18
Particulate and gaseous contamination specifications ...................................................................................... 19
Expanded operating temperature ..................................................................................................................... 20
Expanded operating temperature restrictions ................................................................................................... 21
4 Initial system setupand configuration............................................................... 22
Setting up your system ........................................................................................................................................... 22
iDRAC configuration ............................................................................................................................................... 22
Options to set up iDRAC IP address ................................................................................................................. 22
Options to install the operating system ................................................................................................................... 23
Methods to download firmware and drivers ....................................................................................................... 23

4
5 Pre-operating system management applications ............................................. 25
Options to manage the pre-operating system applications ..................................................................................... 25
System Setup ......................................................................................................................................................... 25
Viewing System Setup ...................................................................................................................................... 25
System Setup details ........................................................................................................................................ 26
System BIOS .................................................................................................................................................... 26
iDRAC Settings utility ........................................................................................................................................ 45
Device Settings ................................................................................................................................................. 45
Dell Lifecycle Controller .......................................................................................................................................... 46
Embedded system management ...................................................................................................................... 46
Boot Manager ......................................................................................................................................................... 46
Viewing Boot Manager ...................................................................................................................................... 46
Boot Manager main menu ................................................................................................................................ 46
PXE boot ................................................................................................................................................................ 47
6 Installing and removing blade components .....................................................48
Safety instructions .................................................................................................................................................. 48
Before working inside your system ................................................................................................................... 48
After working inside your system ...................................................................................................................... 48
Recommended tools .............................................................................................................................................. 48
Removing and installing a blade ............................................................................................................................. 49
Removing the blade .......................................................................................................................................... 49
Installing a blade ............................................................................................................................................... 51
System cover ......................................................................................................................................................... 51
Removing the system cover .............................................................................................................................. 51
Installing the system cover................................................................................................................................ 52
Inside the blade ...................................................................................................................................................... 54
Cooling shroud ....................................................................................................................................................... 55
Removing the cooling shroud ........................................................................................................................... 55
Installing the cooling shroud ............................................................................................................................. 55
Processor blank and DIMM blank ........................................................................................................................... 56
Removing a processor or DIMM blank .............................................................................................................. 56
Installing a processor or DIMM blank ................................................................................................................ 57
System memory ..................................................................................................................................................... 58
General memory module installation guidelines ................................................................................................ 60
Mode-specific guidelines .................................................................................................................................. 60
Sample memory configurations ........................................................................................................................ 61
Removing memory modules ............................................................................................................................. 63
Installing memory modules ............................................................................................................................... 64
I/O module mezzanine cards .................................................................................................................................. 65
Mezzanine card installation guidelines.............................................................................................................. 65
Removing the mezzanine card ......................................................................................................................... 66
Installing the mezzanine card ........................................................................................................................... 67
Internal dual SD module (optional) ......................................................................................................................... 68
Replacing an SD card ....................................................................................................................................... 68

5
Internal USB key ............................................................................................................................................... 70
Removing the optional IDSDM card .................................................................................................................. 71
Installing the optional IDSDM card .................................................................................................................... 72
rSPI card (optional) ................................................................................................................................................ 73
Removing the optional rSPI card ...................................................................................................................... 74
Installing the optional rSPI card ........................................................................................................................ 75
SD vFlash card ....................................................................................................................................................... 75
Replacing the SD vFlash card .......................................................................................................................... 76
Network Daughter Card .......................................................................................................................................... 77
Removing the Network Daughter Card ............................................................................................................. 77
Installing the Network Daughter Card ............................................................................................................... 79
Processors ............................................................................................................................................................. 80
Removing a heat sink ....................................................................................................................................... 80
Removing a processor ...................................................................................................................................... 81
Installing a processor ........................................................................................................................................ 84
Installing a heat sink ......................................................................................................................................... 85
Hard drives or SSDs ............................................................................................................................................... 87
Hard drive or SSD bay numbering .................................................................................................................... 87
Hard drive or SSD installation guidelines .......................................................................................................... 87
Removing a hard drive or SSD ......................................................................................................................... 88
Installing a hard drive or SSD ........................................................................................................................... 89
Removing a hard drive or SSD blank ................................................................................................................ 90
Installing a hard drive or SSD blank .................................................................................................................. 91
Shutdown procedure for servicing a hard drive or SSD ..................................................................................... 92
Configuring the boot drive ................................................................................................................................. 93
Removing a 2.5-inch hard drive or SSD from a 2.5-inch hard drive or SSD carrier ............................................. 93
Installing a 2.5-inch hard drive or SSD in a 2.5-inch hard drive or SSD carrier ................................................... 94
Removing a 1.8-inch SSD from a 1.8-inch SSD carrier ..................................................................................... 95
Installing a 1.8-inch SSD in a 1.8-inch SSD carrier ............................................................................................ 95
Removing the hard drive or SSD cage .............................................................................................................. 96
Installing the hard drive or SSD cage ................................................................................................................ 97
Hard drive or SSD backplane ................................................................................................................................. 98
Removing the hard drive or SSD backplane ..................................................................................................... 98
Installing the hard drive or SSD backplane ..................................................................................................... 100
System board ....................................................................................................................................................... 102
Removing the system board ........................................................................................................................... 102
Installing the system board ............................................................................................................................. 105
Trusted Platform Module ....................................................................................................................................... 108
Installing the Trusted Platform Module ............................................................................................................ 108
Initializing the TPM for BitLocker users ........................................................................................................... 109
Initializing the TPM for TXT users ................................................................................................................... 109
NVRAM backup battery ........................................................................................................................................ 110
Replacing the NVRAM backup battery ............................................................................................................ 110
Storage controller card or PCIe extender card ...................................................................................................... 112
Removing the PCIe extender or storage controller card .................................................................................. 112

6
Installing the PCIe extender or storage controller card .................................................................................... 113
7 Using system diagnostics .............................................................................116
Dell Embedded System Diagnostics ..................................................................................................................... 116
Running the Embedded System Diagnostics .................................................................................................. 116
Running embedded system diagnostics from an external media ..................................................................... 116
System diagnostics controls ........................................................................................................................... 117
8 Jumpers and connectors ...............................................................................118
System board jumper settings .............................................................................................................................. 118
System board connectors ..................................................................................................................................... 119
Disabling a forgotten password ............................................................................................................................ 120
9 Troubleshooting your system........................................................................121
Safety first — for you andyour system ................................................................................................................. 121
Troubleshooting system memory ......................................................................................................................... 121
Troubleshooting hard drives ................................................................................................................................. 122
Troubleshooting USB devices .............................................................................................................................. 122
Troubleshooting Solid State Drives ...................................................................................................................... 123
Troubleshooting an Internal SD Card ................................................................................................................... 123
Troubleshooting Processors ................................................................................................................................. 124
Troubleshooting the system board ....................................................................................................................... 124
Troubleshooting the NVRAM backup battery ........................................................................................................ 125
10 Getting help................................................................................................126
Contacting Dell ..................................................................................................................................................... 126
Accessing system information by using QRL ........................................................................................................ 126
Quick Resource Locator for M630 .................................................................................................................. 127

7
1
Dell PowerEdge M630overview
The Dell PowerEdge M630 is a half-height blade supported on the PowerEdge M1000e and PowerEdge VRTX enclosure and
support upto:
• One or two Intel Xeon E5-2600 v3 or E5-2600 v4 processors
• 24 DIMMs
• Single processor: Up totwo 2.5-inch hard drives
• Single processor: Up to four 1.8-inch SSDs
• Dual processor: Up to two 2.5-inch hard drives
• Dual processor: Up to four 1.8-inch SSDs
Supported configurations for the PowerEdge M630 system
The Dell PowerEdge M630 system supports the following configurations:

8
Figure 1. M630 configuration overview
Front panel
The features on the front panel include USB management port, iDRAC Direct LED indicator, sled handle and status indicator.

9
2.5-inch hard drive or SSD system
Figure 2. Front panel features — 2.5-inch hard drive or SSD system
1. Hard drives or SSDs 2. USB2 port
3. USB1 or iDRAC managed USB port 4. Management indicator
5.
Status indicator 6. blade power-on indicator,power button
7.
blade handle
Table 1. Front panel features — 2.5-inch hard drive or SSDs system
Item Indicator, Button, or
Connector
Icon Description
1 Hard drives or SSDs
2.5-inchharddrive Two 2.5-inch hot-swap SAS
system or SATAor PCIeSSDs or
SAS or SATA hard drives.
2
USB2 port A USB device to be connected to the system.
3
USB1 or iDRAC managed
USB port
The USB management port can function asaregular
USB port or provide access to the iDRAC features.
For more information, see the DellIntegratedDell
Remote Access Controller User's Guide at Dell.com/
idracmanuals.
4
Management indicator The management indicator turns on when iDRAC
controls the USB1 port for management functions.
5
Status indicator Provides information about the status of the system.
6
blade power-on indicator,
power button
The power indicator turns on when the blade power
is on. The power button controls the power supply
output to the system.
7
blade handle Used to slide the blade out of the enclosure.

10
1.8-inch SSD system
Figure 3. Front panel features — 1.8-inch SSD system
1. Hard drives or SSDs 2. USB2 port
3. USB1 or iDRAC managed USB port 4. Management indicator
5.
Status indicator 6. blade power-on indicator,power button
7.
blade handle
Table 2. Front panel features — 1.8-inch SSD system
Item Indicator, Button, or
Connector
Icon Description
1 Hard drives or SSDs 1.8-inchSSD
Four 1.8-inch hot-swap
system SATA SSDs.
2
USB2 port A USB device to be connected to the system.
3
USB1 or iDRAC managed
USB port
The USB management port can function asaregular
USB port or provide access to the iDRAC features.
For more information, see the DellIntegratedDell
Remote Access Controller User's Guide at Dell.com/
idracmanuals.
4
Management indicator The management indicator turns on when iDRAC
controls the USB1 port for management functions.
5
Status indicator Provides information about the status of the system.
6
blade power-on indicator,
power button
The power indicator turns on when the blade power
is on. The power button controls the power supply
output to the system.
7
blade handle Used to slide the blade out of the enclosure.

1
Diagnostic Indicators
The diagnostic indicators on the system front panel display error status during system startup.
iDRAC Direct LED indicator codes
NOTE: The iDRAC Direct LED indicator does not turn on for the USB mode.
Figure 4. iDRAC Direct LED indicator
1. iDRAC Direct statusindicator
Table 3.iDRACDirect LEDindicators
Convention iDRAC Direct LED
indicator pattern
Condition
A Green Turns green for a minimum of two seconds at the starting and end of a file transfer.
B
Flashing green Indicates file transfer or any operation tasks.
C Green and turns off Indicates that the file transfer is complete.
D Not lit Indicates that the USB is ready to be removed or that a task is complete.
The following table describes iDRAC Direct activity when configuring iDRAC Direct by using your laptop and cable (Laptop Connect).
Table 4. iDRAC Direct LED indicator patterns
iDRAC Direct LED
indicator pattern
Solid green for two
seconds
Flashing green (on for two
seconds and off for two
seconds)
Condition
Indicates that the laptop is connected.
Indicates that the laptop connected is recognized.
Turns off Indicates that the laptop is unplugged.
Using USB diskette or USB DVD or CD drives
The blade has USB ports on the front which allows you to connect a USB diskette drive, USB flash drive, USB DVD or CD drive,
keyboard, or mouse. The USBdrives can be used to configure the blade.
To designate the USB diskette drive as the boot drive:

12
1. connect the USB drive
2. restart the system
3. enter the System Setup
4. set the drive as first in the boot sequence
The USB device is displayed in the boot order setup screen only if it is attached to the system before you run the System Setup. You
can also select the boot device bypressing F11 during system start-up and selecting aboot device for the current boot sequence.
Hard drive or SSD indicator patterns
The hard drive or SSD (Solid-State Drives) indicators display different patterns as drive events occur in the system.
NOTE: The blade must have a hard drive or SSD or a hard drive blank installed in each drive bay.
Figure 5. Hard drive or SSD indicators
1. drive activityindicator (green) 2. drive status indicator (green and amber)
NOTE: If the drive is in Advanced Host Controller Interface (AHCI) mode, the status LED (on the right side) does not
functionandremains off.
Drive-Status
Indicator Pattern
Flashes green twice
per second
Condition
Identifying drive or preparing for removal
Off
Drive ready for insertion or removal
NOTE: The drivestatus indicatorremains off until all drives areinitialized after system power is
applied. Drives are not ready for insertion or removal during this time.
Flashes green,
amber, and then
turns off
Flashesamberfour
times per second
Drive predicted failure
Drive failed

1
Drive-Status
Indicator Pattern
Condition
Flashes green slowly
Drive rebuilding
Steadygreen Driveonline
Flashes green for
three seconds,
amber for three
seconds, and turns
off after six seconds
Rebuild stopped
Locating Service Tag of your system
Your system is identified by a unique Express Service Code and Service Tag number. The Express Service Code and Service Tag are
found on the front of the system by pulling out the information tag. Alternatively, the information may be on a sticker on the c hass is
of the system. This information isused by Dell to route support calls to the appropriate personnel.

14
2
Documentation resources
This section provides information about the documentation resources for your system.
Table 5. Documentation resources for system
Task Document Location
Setting up your system For information about installing the system into a
rack, see the Rack documentation included with
your rack solution.
Dell.com/poweredgemanuals
For information about turning onthe system and
the technical specifications of your system, see
the Getting Started With Your System that
shipped with your system.
For information about Getting Started With Your
System that shipped with your system or the
Technical specifications section in this
document.
Configuring your system For information about iDRAC features,
configuring and logging in to iDRAC, and
managing your system remotely, see the
Integrated Dell Remote Access Controller User's
Guide.
For information about installing the operating
system, see the operating system
documentation.
For information about understanding Remote
Access Controller Admin (RACADM)
subcommands and supported RACADM
interfaces, see the RACADM Command Line
Reference Guide for iDRAC.
For information about updating drivers and
firmware, see the Download firmware and
driverssectioninthisdocument.
Managing your system For information about the features of the Dell
OpenManage Systems Management, see the
Dell OpenManage Systems Management
Overview Guide.
For information about setting up, using, and
troubleshooting OpenManage, see the Dell
OpenManage Server Administrator User’s Guide.
For information about installing, using, and
troubleshooting Dell OpenManage Essentials,
see the Dell OpenManage Essentials User’s
Guide.
Dell.com/poweredgemanuals
Dell.com/poweredgemanuals
Dell.com/idracmanuals
Dell.com/operatingsystemmanuals
Dell.com/idracmanuals
Dell.com/support/drivers
Dell.com/openmanagemanuals
Dell.com/openmanagemanuals
Dell.com/openmanagemanuals

1
Task Document Location
Working with Dell PowerEdge
RAID controllers
Understanding event and
error messages
For information about installing and using Dell
System E-Support Tool (DSET), see the Dell
System E-Support Tool (DSET) User's Guide.
For information about installing and using Active
System Manager (ASM), see the Active System
Manager User’s Guide.
For understanding the features of Dell Lifecycle
Controller (LCC), see the Dell Lifecycle
Controller User’s Guide.
For information about partner programs
enterprise systems management, see the
OpenManage Connections Enterprise Systems
Management documents.
For information about connections and client
systems management, see the OpenManage
Connections Client Systems Management
documentation.
For information about viewing inventory,
performing configuration and monitoring tasks,
remotelyturning on or off servers, and enabling
alerts for events on servers and components
using the Dell Chassis Management Controller
(CMC), see the CMC User’s Guide.
For information about understanding the
features of the Dell PowerEdge RAID controllers
(PERC) and deploying the PERC cards, see the
Storage controller documentation.
For information about checking the event and
error messages generated by the system
firmware and agents that monitor system
components, see the Dell Event and Error
Messages Reference Guide.
Dell.com/DSET
Dell.com/asmdocs
Dell.com/idracmanuals
Dell.com/
omconnectionsenterprisesystemsmanagement
Dell.com/dellclientcommandsuitemanuals
Dell.com/esmmanuals
Dell.com/storagecontrollermanuals
Dell.com/openmanagemanuals > OpenManage
software

16
3
Technical specifications
The technical and environmental specifications of your system are outlined in this section.
Chassisdimensions
Figure 6. Chassis dimensions
Table 6. Chassis dimensions of the Dell PowerEdge M630 system
System X Y Z
PowerEdge M630 192.3 mm 50.3 mm 544.3 mm
Chassis weight
Table 7. Chassis weight
System Maximum weight
PowerEd
g
e M630 6.8 kg (14.99 lb)
Processor specifications
The PowerEdge M630 system supports up one or two Intel Xeon E5-2600 v3 or E5-2600 v4 product family processors.
CAUTION: For processorsof 105 W,120 W,or 135 W,use heat sinks of 68 mm width.
CAUTION: For processors of 135 W (four cores, six cores, or eight cores) or 145 W,use heat sinks of 86 mm width.
NOTE: Mixing processors of different wattages is not supported.

1
System battery specifications
The PowerEdge M630 system supports CR 2032 3.0-V lithium coin cell system battery.
Memory specifications
The PowerEdge M630 system supports DDR4 registered DIMMs (RDIMMs) and load-reduced DIMMs (LRDIMMs).
Table 8. Memory specifications
Memory module
sockets
Memory capacity Minimum RAM Maximum RAM Speed
PowerEdge M630
64 GB quad rank
(LRDIMMs)
4 GB with single
processor
• Up to 768 GB with a
single processor
• Up to 1536 GB with
a dual processor
2 400 MT / s , 2133 MT / s ,
or 1866 MT / s , DDR 4
DIMMs
32 GB quad rank
(LRDIMMs)
2133 MT / s , or 1866
MT / s ,, DDR 4 DIMMs
4 GB, 8 GB, 16 GB or 32
GB single rank
(RDIMMs)
2 400 MT / s , 2133 MT / s ,
or 1866 MT / s , DDR 4
DIMMs
8 GB, 16 GB and 32 GB
dual rank (RDIMMs)
2 400 MT / s , 2133 MT / s ,
or 1866 MT / s , DDR 4
DIMMs
RAID controllers
The PowerEdge M630 system supports PERC H330, PERC H730P, and PERC H730.
PCIemezzaninecardslots
The PowerEdge M630 system supports TwoPCIe x8 Gen 3 slots mezzanine card supporting dual port 10 Gb Ethernet, quad port 1
Gb, FC8 Fibre Channel, FC16 Fibre Channel, or Infiniband mezzanine cards
Driver specification
Hard drives
ThePowerEdge M630 system supports:
• Up totwo 2.5-inch, hot-swappable SAS, SATAhard drives or SAS or SATAor PCIe SSDs
SSDs
The PowerEdge M630 system supports:
• Up to four 1.8-inch, hot-swappable SATA SSDs
Optical drive
The P o w erEdge M 630 s yst em support s e xt ernal op tional USB D VD and one op tional S A T A D VD-ROM driv e or D VD+ / -RW driv e .

18
Flash drive
The PowerEdge M630 system supports internal optional USB, internal optional SD card and optional vFlash card (with integrated
iDRAC8 Enterprise).
Ports and connectors specifications
USB ports
The PowerEdge M630 system supports:
• USB 2.0-compliant ports on the front panel
• internal USB 3.0-compliant port
The following table provides more information about the USB specifications:
Table 9. USB specifications
System Frontpanel Internal
PowerEdge M630 One 4-pin, USB 2.0-compliant and one 4-
pin, USB 3.0-compliant
• Twointernal SD cards dedicated for
the hypervisor
• One SD card dedicated for future
vFlash support
Internal Dual SD Module
The PowerEdge M630 system supports two SD card slots anda USB interface dedicated for theembedded hypervisor. This card
offers the following features:
• Dual card operation — maintains a mirrored configuration by using SD cards in both slots and provides redundancy.
• Single card operation — single card operation is supported, but without redundancy.
Video specifications
The PowerEdge M630 system supports Matrox G200 VGA controller integrated withiDRAC and 2 GB shared withiDRAC
application memory.
Environmental specifications
NOTE:For additionalinformation aboutenvironmental measurements for specific system configurations, seeDell.com/
environmental_datasheets.
Table 10. Temperature specifications
Temperature Specifications
Storage –40°C to 65°C (–40°F to 149°F)
Continuous operation (for altitude less than 950 m or 3117 ft) 10°C to 35°C (50°F to 95°F) with no direct sunlight on the
equipment.
Fresh air For information about fresh air, see Expanded Operating
Temperature section.
Maximum temperature gradient (operating and storage) 20°C/h (36°F/h)

1
Table 11. Relative humidity specifications
Relative humidity Specifications
Storage 5% to 95% RH with 33°C (91°F) maximum dew point.
Atmosphere must be noncondensing always.
Operating 10% to 80% Relative Humidity with 29°C (84.2°F) maximum
dew point.
Table 12. Maximum vibration specifications
Maximum vibration Specifications
Operating 0.26 Grms at 5 Hz to 350 Hz (all operation orientations).
Storage 1.88 Grms at 10 Hz to 500 Hz for 15 min (all six sides tested).
Table 13. Maximum shock specifications
Maximum shock Specifications
Operating Six consecutively run shock pulses in the positive and negative
x, y, and z axes of 40 G for up to 2.3 ms.
Storage Six consecutively run shock pulses in the positive and negative
x, y, and z axes (one pulse on each side of the system) of 71 G
for up to 2 ms.
Table 14. Maximum altitude specifications
Maximum altitude Specifications
Operating 3048 m (10,000 ft).
Storage 12,000 m (39,370 ft).
Table 15. Operating temperature derating specifications
Temperature Specifications
Up to 35 °C (95 °F) Maximum temperature is reduced by 1°C/300 m (1°F/547 ft)
above 950 m(3,117 ft).
35 °C to 40 °C (95 °F to 104 °F) Ma ximum t emper a tur e is r educed by 1°C /175 m ( 1°F / 3 19 ft )
above 950 m (3,117 ft).
40 °C to 45 °C (104 °F to 113 °F) Maximum temperature is reduced by 1°C/125 m (1°F/228 ft)
above 950 m(3,117 ft).
Particulate and gaseous contamination specifications
The following table defines the limitations that help avoid any equipment damage or failure from particulates and gaseous
contamination. If the levels of particulates or gaseous pollution exceed the specified limitations and result in equipment damage or
failure, you may need to rectifythe environmental conditions. Remediation of environmental conditions is the responsibility of t h e
customer.
Table 16. Particulate contamination specifications
Particulatecontamination Specifications
Air filtration Datacenterairfiltrationasdefinedby ISOClass 8 per ISO
14644-1with a 95% upper confidence limit.

20
Particulatecontamination Specifications
NOTE: This condition applies only to data center
environments.Air filtration requirementsdonotapplyto
ITequipmentdesignedtobeusedoutsideadata center,
in environments such as an
office or factory floor.
NOTE: Air entering the data center must have MERV11
or MERV13filtration.
Conductive dust Air must be free of conductive dust, zinc whiskers, or other
conductive particles.
NOTE:Thisconditionapplies todatacenterand nondata
center environments.
Corrosive dust • Air must be free of corrosive dust.
• Residualdustpresentintheair musthaveadeliquescent
point less than 60% relativehumidity.
NOTE:Thisconditionapplies todatacenterand nondata
center environments.
Table 17. Gaseous contamination specifications
Gaseous contamination Specifications
Copper coupon corrosion rate <300 Å/month per Class G1 as defined by ANSI/ ISA71.04-1985.
Silver coupon corrosion rate <200 Å/month as defined by AHSRAE TC9.9.
NOTE: Maximum corrosive contaminant levels measured at ≤50% relativehumidity.
Expanded operating temperature
Table 18. Expanded operating temperature specifications
Expanded operating temperature Specifications
Continuous operation 5°C to 40°C at 5% to 85% RH with 29°C dew point.
NOTE:Outsidethestandardoperatingtemperature
(10°C to 35°C), the system can operate continuously in
temperatures as low as 5°C and as high as 45°C.
For temperatures between 35°C and 40°C, derate maximum
allowable temperature by 1°C per 175 m above 950 m (1°F per
319 ft).
< 1% of annual operating hours –5°C to 45°C at 5% to 90% RH with 29°C dew point.
NOTE:Outsidethestandardoperating temperature
(10°C to 35°C), the system can operate down to –5°C
orupto45°Cforamaximumof1%ofitsannual
operating hours.
For temperatures between 40°C and 45°C, de-rate maximum
allowable temperature by 1°C per 125 m above 950 m (1°F per
228 ft).
