Dell PowerVault DL2200 CommVault User manual

Dell™ PowerVault™
DL2200 Systems
Getting Started
With Your System
系统使用入门
Memulai Pengaktifan dengan Sistem Anda
粲筥筴窿
시스템 시작 안내서

Dell™ PowerVault™
DL2200 Systems
Getting Started
With Your System
Regulatory Model E13S Series

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
____________________
Information in this document is subject to change without notice.
© 2010-2012 Dell Inc. All rights reserved.
ReproductionofthesematerialsinanymannerwhatsoeverwithoutthewrittenpermissionofDellInc.
is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and PowerVault are trademarks of Dell Inc.;
Intel andXeonareregisteredtrademarksofIntelCorporationintheU.S.andothercountries;Microsoft,
and Windows Server are either trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Regulatory Model E13S Series
2012 - 9 P/N X51HX Rev. A01

Getting Started With Your System 3
Installation and Configuration
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
Unpacking the System
Unpack your system and identify each item.
Assemble the rails and install the system in the rack following the safety
instructions and the rack installation instructions provided with your system.

4Getting Started With Your System
Optional – Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which cable
to plug into each connector. Be sure to tighten the screws (if any) on the
monitor's cable connector.
Connecting the Power Cable(s)
Connect the system’s power cable(s) to the system and, if a monitor is used,
connect the monitor’s power cable to the monitor.

Getting Started With Your System 5
Securing the Power Cable(s)
Bend the system power cable into a loop as shown in the illustration and secure
the cable to the bracket using the provided strap. Plug the other end of the
power cable into a grounded electrical outlet or a separate power source such
as an uninterrupted power supply (UPS) or a power distribution unit (PDU).
Turning On the System
Press the power button on the system and the monitor. The power indicators
should light.

6Getting Started With Your System
Installing the Optional Bezel
Install the bezel (optional).
Operating System Information
The operating system is preinstalled and configured to support the
preinstalled applications. See the operating system documentation that
shipped with your system for additional information about customizing
the operating system, only if required for your environment.
Supported Operating System
Your system is preinstalled with Microsoft® Windows Server® 2008
Standard (x64) Edition with SP2.
NOTE: The operating system is installed on the internal hard drives in a
RAID 1 configuration.

Getting Started With Your System 7
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with
your system. Warranty information may be included within this document
or as a separate document.
• The rack documentation included with your rack solution describes
how to install your system into a rack.
• The
Hardware Owner’s Manual provides information about system
features and describes how to troubleshoot the system and install or
replace system components. This document is available online at
support.dell.com/manuals .
• Any media that ships with your system that provides documentation
and tools for configuring and managing your system, including those
pertaining to the operating system, system management software,
system updates, and system components that you purchased
with your system.
NOTE: Always check for updates on support.dell.com/manuals and read the
updates first because they often supersede information in other documents.
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does
not perform as expected, see your Hardware Owner’s Manual. Dell™ offers
comprehensive hardware training and certification. See www.dell.com/training
for more information. This service may not be offered in all locations.

8Getting Started With Your System
NOM Information (Mexico Only)
The following information is provided on the device described in this
document in compliance with the requirements of the official Mexican
standards (NOM):
Technical Specifications
Importer:
Model number: E13S Series
Supply voltage: 100–240 V CA
Frequency: 50/60 Hz
Current consumption: 7.5–4.0 A
Processor
Processor type
Up to two Intel
®
Xeon
®
processors 5600 series
Expansion Bus
Bus type PCI Express Generation 2
Riser Card Expansion Slots Slot 1: PCIe x4, half-length, full-height
Slot 2: PCIe x4, full-length, full-height
Slot 3: PCIe x8, half-length, full-height
Slot 4 : PCIe x4, internal slot for integrated card
NOTE: All four slots are x8 connectors.
Memory
Architecture 1066 or 1333 MHz DDR3 registered
or unbuffered Error Correcting Code
(ECC) DIMMs
Memory module sockets Eight 240-pin
Memory module capacities 1 GB, 2 GB, 4 GB, or 8 GB
Minimum RAM 1 GB with a single processor (1 DIMM
per processor)

Getting Started With Your System 9
Maximum RAM 64 GB (8 GB dual- and quad-rank DIMMs)
Drives
Hard drives Up to twelve 3.5" hot-swappable SAS, SATA,
or SSD drives and up to two cabled 2.5" SAS
or SSD drives
NOTE: The operating system is installed on the
internal hard drives in a RAID 1 configuration.
Optical drive Optional external USB DVD-ROM
Connectors
Back
NIC Two RJ-45 (for integrated 1-GB NICs)
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
Front
Video 15-pin VGA
USB One 4-pin, USB 2.0-compliant
Internal
USB Two 4-pin, USB 2.0-compliant
Video
Video type Matrox G200, integrated in the BMC
Video memory 8 MB
Memory (continued)

10 Getting Started With Your System
Power
AC power supply (per power supply)
Wattag e 750 W (redundant power supply)
Voltage 100–240 VAC, autoranging, 50–60 Hz
Heat dissipation 2450 BTU/hr maximum
Maximum inrush current Under typical line conditions and over the
entire system ambient operating range,
the inrush current may reach 55 A per
power supply for 10 ms or less
Batteries
System battery CR 2032 3.0-V lithium coin cell
Physical
Height 8.67 cm (3.42")
Width 44.52 cm (17.53")
Depth 66.46 cm (26.17")
Weight (maximum configuration) 29.0 kg (63.8 lbs)
Weight (empty) 15.85 kg (34.87 lbs)
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F) with a maximum
temperature gradation of 10°C per hour
NOTE: For altitudes above 2950 feet,
the maximum operating temperature is
derated 1ºF/550 ft.
Storage –40° to 65°C (–40° to 149°F) with a
maximum temperature gradation
of 20°C per hour

Getting Started With Your System 11
Relative humidity
Operating 20% to 80% (noncondensing) with
a maximum humidity gradation
of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 G at 5–350 Hz for 15 min
Storage 1.54 G at 10–250 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis
(one pulse on each side of the system) of
31 G for 2.6 ms in the operational orientation
Storage Six consecutively executed shock pulses in
the positive and negative x, y, and z axes
(one pulse on each side of the system)
of 71 G for up to 2 ms
Altitude
Operating –16 to 3048 m (–50 to 10,000 ft)
NOTE: For altitudes above 2950 feet,
the maximum operating temperature
is derated 1ºF/550 ft.
Storage –16 to 10,600 m (–50 to 35,000 ft)
Airborne Contaminant Level
Class G2 or lower as defined by ISA-S71.04-1985
Environmental (continued)

12 Getting Started With Your System

Dell™ PowerVault™
DL2200 系统
系统使用入门
管制型号 E13S 系列

注、小心和警告
注：“注”表示可以帮助您更好地使用计算机的重要信息。
小心：“小心”表示如果不遵循说明，就有可能损坏硬件或导致数据丢失。
警告：“警 ”表示可能会造成财产损失、人身伤害甚至死亡。
____________________
本说明文件中的信息如有更改，恕不另行通知。
© 2010-2012 Dell Inc. 版权所有，翻印必究。
未经 Dell Inc. 书面许可，严禁以任何形式复制这些材料。
本文中使用的商标：Dell 、DELL 标、和PowerVault 是Dell Inc. 的商标； Intel 和 Xeon 是
Intel Corporation 在美国和 /或其它国家和地区的商标； Microsoft 和Windows Server 是
Microsoft Corporation 在美国和 /或其它国家和地区的商标或注册商标。
本说明文件中述及的其它商标和产品名称是指拥有相应商标和产品名称的公司或其制造的
产品。 Dell Inc. 对其它公司的商标和产品名称不拥有任何所有权。
管制型号 E13S 系列
2012 年9 月 P/N X51HX Rev. A01

系统使用入门 15
安装和配置
警告：执行下列步骤之前，请查看系统随附的安全说明。
打开系统包装
打开系统包装并确认各个组件。
遵循系统随附的安全说明和机架安装说明，在机架中组装滑轨并安装
系统。

16 系统使用入门
可选 – 连接键盘、鼠标和显示器
连接键盘、鼠标和显示器 （可选）。
系统背面的连接器附有图标，指示要插入每个连接器的电缆。请确保拧紧
显示器电缆连接器上的螺钉 （如果有）。
连接电源电缆
将系统电源电缆连接至系统，如果使用显示器，则将显示器电源电缆连接
至显示器。

系统使用入门 17
固定电源电缆
如图所示，将系统电源电缆弯曲成一个环状，并使用所提供的腕带将其固
定到支架。将电源电缆的另一端插入接地的电源插座或单独的电源，如不
间断电源设备 (UPS) 或配电装置 (PDU)。
开启系统
按下系统和显示器的电源按钮。电源指示灯将会亮起。

18 系统使用入门
安装可选挡板
安装挡板 （可选）。
操作系统信息
操作系统已预安装并被配置为支持已预安装的应用程序。请参阅附随系统
的操作系统说明文件以获得有关自定义操作系统的更多信息，仅当您的环
境有此要求。
支持的操作系统
您的系统已预安装了 Microsoft® Windows Server® 2008 Standard (x64)
Edition with SP2。
注：操作系统安 在按 RAID 1 配置的内部硬盘驱动器上。
