Before You Begin
NOTE: Throughout the document, Dell PowerVault MD3600f series storage array
refers to both Dell PowerVault MD3600f and Dell PowerVault MD3620f.
Before setting up your PowerVault MD3600f series storage array, you must
consider certain best practices to ensure that your storage array operates at
maximum efficiency and offers full redundancy (if required).
• To enable redundancy, two Fibre Channel (FC) host bus adapters (HBA)
must be connected from the host system to the storage array. If
redundancy is not required, only one FC HBA is connected to the storage
array. See the
Support Matrix for a list of supported HBAs and Configuring
Fibre Channel With the Dell MD3600f Series Storage Array
for information
about installing HBA drivers. You can download both documents from
support.dell.com/manuals .
• Before connecting any cables between the host server and storage array,
physically label each port and connector.
• Always follow proper power-up and power-down procedures when cycling
power across the network. You must also ensure that critical network
components are on separate power circuits.
Working With SFP Modules and Fiber Optic Cables
Each storage controller can have up to four FC host ports. A small-form-
factor pluggable (SFP) module is used to connect a host port to a host or
switch. The SFP module is inserted into the port, and then a fiber optic cable
is inserted into the SFP module. The other end of the fiber optic cable is
connected to an optical interface connector either in a FC HBA on a host or a
switch. SFP modules are laser products.
WARNING: Data processing environments can contain equipment transmitting
on system links with laser modules that operate at greater than Class 1 power
levels. Never look into the end of an optical fiber cable or open receptacle.
Guidelines for Using Fiber Optic Cables
• Do not route the cable along a folding cable management arm.
• For devices on slide rails, leave enough slack in the cables so they do not
bend to a diameter of less than 76 mm (3"), or a radius less than
38 mm (1.5"), when extended or become pinched when retracted.

4 Getting Started With Your System
• Route the cable away from places where it can be damaged by other
devices in the rack cabinet.
• Do not use plastic cable ties in place of the provided cable straps.
• Do not over-tighten the cable straps or bend the cables to a diameter of
less than 76 mm (3") or a radius less than 38 mm (1.5").
• Do not place excess weight on the cable at the connection point. Ensure
that the cable is well supported.
Guidelines for Using SFP Modules
The storage array requires SFP modules. SFP modules convert electrical
signals to optical signals that are required for FC transmission to and from
RAID controller modules. After installing the SFP modules, fiber optic cables
are used to connect the storage array to other FC devices. Before installing
SFP modules and fiber optic cables, read the following information:
• Use only Dell supported SFPs with the PowerVault MD3600f series storage
arrays. Other generic SFPs are not supported and may not work with the
storage arrays.
• The SFP module housing has an integral guide key that is designed to
prevent you from inserting the SFP module incorrectly.
• Use minimal pressure when inserting an SFP module into a FC port.
Forcing the SFP module into a port may damage the SFP module or the
port.
• You can install or remove the SFP module while the port is powered on.
• You must install the SFP module into a port before you connect the fiber
optic cable.
• You must remove the fiber optic cable from the SFP module before you
remove the SFP module from the port.
CAUTION: When handling static-sensitive devices, take precautions to avoid
damaging the product from static electricity.

Getting Started With Your System 5
Other Documentation and Media You May Need
WARNING: See the safety and regulatory information that shipped with
your system. Warranty information may be included within this document or
as a separate document.
NOTE: All PowerVault MD3600f series documents are available at
support.dell.com/manuals.
• The rack documentation included with your rack solution describes how to
install your system into a rack.
• The
Owner’s Manual provides information about system features and
describes how to troubleshoot the system and install or replace system
components.
• The
Deployment Guide provides information about installing and
configuring the software and hardware.
• The
CLI Guide provides information about using the command line
interface (CLI) to configure and manage your storage array.
• The
SMI-S Programmer’s Guide provides information about using the
SMI-S provider and SMI-S programming.
• Any media that ships with your system that provides documentation and
tools for configuring and managing your system, including those
pertaining to the operating system, system management software,
system updates, and system components that you purchased
with your system.
NOTE: Always check for updates on support.dell.com/manuals and read the
updates first because they often supersede information in other documents.
Supported Operating Systems
• Microsoft Windows Server
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
•VMware
NOTE: For the latest information on all the supported operating system versions,
see the Support Matrix at support.dell.com/manuals.

6 Getting Started With Your System
Common Configurations
Cabling Your Direct-Attached Hosts
Server 1 Server 2
PowerVault MD3600f
series storage array
Corporate, public, or
private network
Server 3 Server 4

Getting Started With Your System 7
Cabling Your SAN-Attached Hosts
The illustration below represents a redundant system. For example, a system
used in a remote replication environment.
PowerVault MD3600f
series storage array
Switch 2
Switch 1
Up to 64 hosts
Corporate, public, or
private network

8 Getting Started With Your System
Installation and Configuration
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
Unpacking the System
Unpack your system and identify each item with the packing list that shipped
with your system.
Installing the Rails and System in a Rack
Assemble the rails and install the system in the rack following the safety
instructions and the rack installation instructions provided with your system.
NOTE: To balance the weight load, it is recommended that you install the
PowerVault MD3600f series storage array at the bottom of the rack and the
PowerVault MD12xx expansion enclosures above it.

Getting Started With Your System 9
Connecting the Power Cable(s)
Ensure that the power switch is in the OFF position before connecting the
power cables. Connect the system’s power cable(s) to the system.
Securing the Power Cable(s)
Secure the cable(s) firmly to the bracket using the provided strap.
Plug the other end of the power cables into a grounded electrical outlet or
a separate power source such as an uninterrupted power supply (UPS) or
a power distribution unit (PDU). Each power supply must be connected
to a separate power circuit.

10 Getting Started With Your System
Installing and Removing SFP Modules
To install SFP modules:
1
If all the FC IN ports have an SFP module installed, go to step 5.
2 Remove the SFP module from the static protective package.
3 Remove the protective cap from the SFP module and SFP port. Store the
protective caps for future use.
4 Insert the SFP module into the host port until it clicks into place.
5 Connect an FC cable. See "Installing and Removing Fibre Channel
Cables" on page 10.
To remove SFP modules:
1
Remove the FC cable from the SFP module. See "Installing and Removing
Fibre Channel Cables" on page 10.
NOTE: To avoid damaging the cable or the SFP module, disconnect
the FC cable before removing the SFP module.
2 Unlock the SFP module latch. For SFP modules that contain wire tabs,
unlock the SFP module latch by pulling the wire latch outward 90°.
3 With the SFP module latch in the unlocked position, remove the
SFP module. For SFP modules that contain wire tabs, grasp the wire latch
and pull the SFP module out of the port.
4 Replace the protective cap on the SFP module and the host port.
5 Place the SFP module into a static-protective package.
Installing and Removing Fibre Channel Cables
WARNING: Data processing environments can contain equipment transmitting
on system links with laser modules that operate at greater than Class 1 power
levels. Never look into the end of an optical fiber cable or open receptacle.
Before installing an FC cable, see "Guidelines for Using Fiber Optic Cables"
on page 3.
To install an FC cable:
1
If applicable, remove the protective cap from the SFP module and store
the protective cap for future use.
2 Remove the two protective caps from one end of the cable and store them
for future use.

Getting Started With Your System 11
3 Insert the cable into an SFP module that is installed in the storage array.
The cable connector is keyed for correct installation. Holding the
connector, push in the cable until it clicks into place.
4 Remove the two protective caps from the other end of the cable and store
them future use.
5 Connect this end of the cable to one of the following devices:
– An SFP module that is installed in an FC switch port
– A FC HBA port
To remove an FC cable:
1
Press and hold the lever to release the latches before removing the cable
from the SFP module. Ensure that the levers are in the released position
when removing the cable. Do not grasp the SFP module plastic tab when
removing the cable.
2 On the end of the cable that connects into the SFP module or HBA,
press down and hold the lever to release the latches.
3 While pressing down the cable lever, pull the connector to remove the
cable from the SFP module.
4 Replace the protective caps on the cable ends.
5 Replace the protective cap on the SFP module.

12 Getting Started With Your System
Cabling Your Expansion Enclosure
Turning On the Storage Array
Turn on the components in the following order:
1
FC switches (if used)
2 MD12 xx expansion enclosures (if used)
NOTE: Before turning on the storage array, ensure that the expansion
enclosure status LED is blue.
PowerVault MD3600f
series storage array
PowerVault MD12xx
expansion enclosure 1
(optional)
PowerVault MD12xx
expansion enclosure 2
(optional)

Getting Started With Your System 13
3 MD3600f series storage array
NOTE: Before turning on the host server(s), ensure that the storage array
status LED is blue.
4 Host server(s)
Installing the Bezel
Install the bezel (optional).
Installing HBAs and Drivers
NOTE: Ensure that you read the Configuring Fibre Channel With the Dell MD3600f
Series Storage Array document before continuing with this procedure. For detailed
instructions about installing the MD storage software, setting up the enclosure, and
the post-installation tasks, see the Deployment Guide.
1 Physically install the HBAs.
2 Connect the cables.
3 Install the HBA drivers and the operating system HBA patches/hotfixes.
4 Ensure that the recommended HBA settings are applied.

14 Getting Started With Your System
Installing the MD Storage Software
The MD Storage Manager application configures, manages, and monitors the
storage array.
1
Insert the resource media.
2 Select Install MD36 xx f Storage Software .
3 Install the MD Storage Manager software. Select one of the following
installation options:
• Full (recommended)—This package installs core software and
providers. It includes the necessary host-based storage agent,
multipath driver, MD Storage Manager, and providers.
• Host Only—This package includes the host-based storage agent and
multipath drivers.
• Management Station—This package includes the MD Storage
Manager and providers.
• Custom—This option allows you to select specific components.
4 Reboot each host server.
5 Start the MD Storage Manager and discover the array(s).
NOTE: If Dynamic Host Configuration Protocol is not used on the network
where the MD storage array’s management ports are connected, it is
recommended that you enable IPv6 on the management station to discover
the storage array(s).
6 Configure single initiator and multiple target zoning on your switches.
For information about zoning, see the
Deployment Guide .
7 Perform the remaining post-installation tasks.
NOTE: The MD Storage Manager software installer automatically installs
operating system patches/hotfixes.

Getting Started With Your System 15
Enabling Premium Features (Optional)
If you ordered premium features, follow the instructions on the
Premium Features Card to install the additional features.
Locating Your Service Tag
Your system is identified by a unique Express Service Code and Service Tag
number. The Express Service Code and Service Tag are found on the front
of the system and at the back of the system next to the RAID controller
modules. This information is used by Dell to route support calls to the
appropriate personnel.

16 Getting Started With Your System
NOM Information (Mexico Only)
The following information is provided on the device described
in this document in compliance with the requirements of the
official Mexican standards (NOM):
Technical Specifications
Importer:
Model number: E03J and E04J
Supply voltage: 100–240 V CA
Frequency: 50/60 Hz
Current consumption: 8.6 A
Drives
PowerVault MD3600f Up to twelve 3.5" SAS hot-swappable hard
drives (3.0 Gbps and 6.0 Gbps)
PowerVault MD3620f Up to twenty four 2.5" SAS hot-swappable
hard drives (3.0 Gbps and 6.0 Gbps)
RAID Controller Modules
RAID controller modules
• One or two hot-swappable modules with
temperature sensors
• 2 GB of cache per controller
Back-Panel Connectors (Per RAID Controller Module)
FC connectors Four FC IN ports to connect hosts
One SAS OUT port for expansion to an
additional PowerVault MD12xx enclosure
NOTE: The SAS connector is SFF-8088
compliant.
SAS connector

Getting Started With Your System 17
Serial connector One 6-pin mini-DIN connector
NOTE: For technical support use only.
Management Ethernet connector One 100/1000 Base-T port Ethernet for
out-of-band management of the enclosure
Expansion
PowerVault MD12xx series Supports a maximum of 96 hard drives with
any combination of PowerVault MD1200 or
PowerVault MD1220 expansion enclosures.
NOTE: You cannot use more than seven
expansion enclosures.
Redundant path connectivity provides
redundant data paths to each hard drive.
Backplane Board
Connectors
• 12 or 24 SAS hard-drive connectors
• Two power supply/cooling fan
module connectors
• Two sets of RAID controller module
connectors
• One control panel connector for front LEDs
and system identification button
Sensors Two temperature sensors
LED Indicators
Front panel
• One two-color LED indicator for
system status
• Two single-color LED indicators for power
and enclosure mode
NOTE: The enclosure mode LED is not
applicable to the PowerVault MD3600f series
storage array.
Back-Panel Connectors (Per RAID Controller Module) (continued)

18 Getting Started With Your System
Hard-drive carrier • One single-color activity LED
• One two-color LED status indicator per
drive
Power supply/cooling fan Three LED status indicators for power supply
status, power supply/fan fault, and AC status
RAID controller module 14 single-color LEDs:
• One battery fault
• One cache active
• One controller fault
• One controller power
• One system identification
• One management Ethernet activity
• Eight FC link or fault
2 two-color LEDs:
• One SAS OUT link or fault
• One management Ethernet link speed
Switch
System identification button Located on the front control panel.
This button is used to locate a system
within a rack.
Enclosure mode switch Located on the front of the system.
This switch is not applicable to the
PowerVault MD3600f series storage array.
Password reset switch Located on the back-panel of the RAID
controller module. This switch is used to
reset the storage array password.
LED Indicators (continued)
