DellTM PowerConnectTM 5324 Systems
User’s Guide Addendum

2
www.dell.com | support.dell.com
Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
____________________
Information in this document is subject to change without notice.
© 2006 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, Dell OpenManage, the DELL logo, and PowerConnect are trademarks of Dell Inc. Microsoft and Windows
are registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
September 2006

3
New Features
This document in an addendum to the PowerConnect 5324 user guide and includes the following topics:
• Configuring LLDP
• Defining SNMP Parameters
• HTTP/HTTPS Upload/Download
• Defining STP Root Guard
• Configuring Multiple Spanning Tree
• Configuring QinQ
• Configuring Load Balancing

4
www.dell.com | support.dell.com
Configuring LLDP
The Link Layer Discovery Protocol (LLDP) allows network managers to troubleshoot and enhance network
management by discovering and maintaining network topologies over multi-vendor environments. LLDP
discovers network neighbors by standardizing methods for network devices to advertise themselves to other
system, and to store discovered information. Device discovery information includes:
• Device Identification
• Device Capabilities
• Device Configuration
The advertising device transmits multiple advertisement message sets in a single LAN packet. The multiple
advertisement sets are sent in the packet
Type Length Value (TLV) field. LLDP devices must support chassis and
port ID advertisement, as well as system name, system ID, system description, and system capability
advertisements.
The
LLDP Properties page contains fields for configuring LLDP.
To open the
LLDP Properties Page, click Security → LLDP → LLDP Properties in the tree view .
Figure 1-1. LLDP Properties
Enable LLDP — Indicates if LLDP is enabled on the device. The possible field values are:
Checked — Indicates that LLDP is enabled on the device.
Unchecked — Indicates that LLDP is disabled on the device. This is the default value.

5
Updates Interval (5-32768) — Indicates that rate at which LLDP advertisement updates are sent. The
possible field range is 5 - 32768 seconds. The default value is 30 seconds.
Hold Time (2-10) — Indicates the amount of time that LLDP packets are held before the packets are dis-
carded. The possible field range is 2 - 10 seconds. The field default is 4 seconds.
Reinitializing Delay (1-10) — Indicates the amount of time that passes between disabling LLDP and when
reinitializing begins. The possible field range is 1 - 10 seconds. The field default is 2 seconds.
Transmit Delay (1-8192) — Indicates the amount of time that passes between successive LLDP frame trans-
missions due to changes in the LLDP local systems MIB. The possible field value is
1 – 8192 seconds. The field default is 2 seconds.
Configuring LLDP Using CLI Commands
The following is an example of the CLI commands:
Table 1-1. LLDP Properties CLI Commands
CLI Command Description
lldp enable (global) Enables enable Link Layer Discovery
Protocol.
lldp hold-multiplier
number Specifies the time that the receiving
device should hold a Link Layer
Discovery Protocol (LLDP) packet
before discarding it.
lldp reinit-delay
Seconds Specifies the minimum time an LLDP
port will wait before reinitializing.
lldp tx-delay
Seconds Specifies the delay between successive
LLDP frame tr.ansmissions.
Console(config)# interface ethernet g5
Console(config-if)# lldp enable

6
www.dell.com | support.dell.com
Defining LLDP Port Settings
The LLDP Port Settings page allows network administrators to define LLDP port settings, including the port
number, the LLDP port number, and the type of port information advertised.
The
Port Settings page contains fields for configuring LLDP. To open the Port Settings page, click Security →
LLDP → Port Settings in the tree view .
Figure 1-2. Port Settings
Port — Contains a list of ports on which LLDP is enabled.
State — Indicates the port type on which LLDP is enabled. The possible field values are:
Tx Only — Enables transmitting LLDP packets only.
Rx Only — Enables receiving LLDP packets only.
Tx & Rx — Enables transmitting and receiving LLDP packets. This is the default value.
Disable — Indicates that LLDP is disabled on the port.
Use Default — Indicates that information included in the TLVs is per the device defaults. The possible field
values are:
Checked — Enables sending the device default LLDP advertisements.
Unchecked — Indicates that the device LLDP advertisement settings are disabled, and LLDP
advertisement settings are user defined. This is the default value.

7
Optional TLVs — Contains a list of optional TLVs advertised by the port. For the complete list, see the
Available TLVs field.
Available TLVs — Contains a list of available TLVs that can be advertised by the port. The possible field values
are:
Port Description — Advertises the port description.
System Name — Advertises the system name.
System Description — Advertises the system description.
System Capabilities — Advertises the system capabilities.
Management IP Address — Indicates the management IP address that is advertised from the interface.
The
LLDP Port Table page displays the LLDP Port Configuration. To open the LLDP Port Table , click Security
→ LLDP → Port Settings → S how All in the tree view .
Figure 1-3. LLDP Port Table
Table 1-2. LLDP Port settings CLI Commands
The following is an example of the CLI commands:
CLI Command Description
clear lldp rx
interface Restarts the LLDP RX state machine
and clearing the neighbors table
lldp optional-tlv
tlv1 [tlv2
… tlv5]
Specifies which optional TLVs from the
basic set should be transmitted
lldp enable [rx | tx | both] To enable Link Layer Discovery
Protocol (LLDP) on an interface.

8
www.dell.com | support.dell.com
Console(config)# interface ethernet g5
Console(config-if)# lldp enable

9
Viewing Advertised Information
The LLDP Advertised Information page displays the information advertised by specific ports when advertising
LLDP information. To open the
Advertised Information page, click Security → LLDP → Advertised
Information
in the tree view.
Figure 1-4. Advertised Information
Port — Displays the port number from which the advertised information is sent.
Device ID — Displays the advertised device ID.
Capabilities — Displays the advertised device capabilities.
System Name — Displays the advertised system name.
System Description — Displays the advertised system description.
Port Description — Displays the advertised port description.
Management Address — Displays the advertised management address.

10
www.dell.com | support.dell.com
Displaying the Advertised Information Table
To open the Advertised Information Table , click Security → LLDP → Advertised Information → Show All in
the tree view
.
Figure 1-5. Advertised Information Table
Table 1-3. LLDP Advertised Information CLI Commands
CLI Command Description
show lldp local
ethernet
interface
Displays LLDP information
advertised from a specific port.

11
The following is an example of the CLI commands:
Switch# show lldp local ethernet 1
Device ID: 0060.704C.73FF
Port ID: 1
Capabilities: Bridge
System Name: ts-7800-1
System description:
Port description:
Management address: 172.16.1.8
802.3 MAC/PHY Configuration/Status
Auto-negotiation support: Supported
Auto-negotiation status: Enabled
Auto-negotiation Advertised Capabilities: 100BASE-TX full duplex,
1000BASE-T full duplex
Operational MAU type: 1000BaseTFD
LLDP-MED capabilities: Network Policy, Location Identification
LLDP-MED Device type: Network Connectivity
LLDP-MED Network policy
Application type: Voice
Flags: Tagged VLAN
VLAN ID: 2
Layer 2 priority: 0
DSCP: 0
LLDP-MED Power over Ethernet
Device Type: Power Sourcing Entity
Power source: Primary Power Source
Power priority: High
Power value: 9.6 Watts
LLDP-MED Location
Coordinates: 54:53:c1:f7:51:57:50:ba:5b:97:27:80:00:00:67:01

12
www.dell.com | support.dell.com
Viewing the LLDP Neighbor Information
The Neighbors Information page contains information received from neighboring device LLDP advertisements.
To open the
Neighbor Information page, click Security → LLDP → Neighbors Information in the tree view .
Figure 1-6. Neighbors Information
Port — Displays the neighboring port number.
Device ID — Displays the neighboring device ID.
Port ID — Displays the neighboring port ID
Capabilities — Displays the neighboring device capabilities.
System Name — Displays the neighboring system time.
1 Select a port.
2 Click Apply Changes . The port advertisement information is displayed.
Displaying the Neighbor Information Table
1 Click Security → LLDP → Neighbors Information in the tree view .
2 Click Show All . The Neighbor Table opens:

13
Figure 1-7. Neighbors Table
Table 1-4. LLDP Neighbor Information CLI Commands
The following is an example of the CLI commands:
Switch# show lldp neighbors
CLI Command Description
show lldp neighbors
interface
Displays information about
neighboring devices discovered using
Link Layer Discovery Protocol (LLDP)
Port Device ID Port
ID
Hold
Time Capabilities
System
Name
1 0060.704C.73FE 1 117 B ts-7800-2
1 0060.704C.73FD 1 93 B ts-7800-2
2 0060.704C.73F C 9 1 B, R ts-7900-1
3 0060.704C.73FB 1 92 W ts-7900-2

14
www.dell.com | support.dell.com
Defining SNMP Parameters
Simple Network Management Protocol (SNMP) provides a method for managing network devices. Devices
supporting SNMP run a local software (agent).
The SNMP agents maintain a list of variables, which are used to manage the device. The variables are defined in
the Management Information Base (MIB). The MIB contains the variables controlled by the agent. The SNMP
protocol defines the MIB specification format, as well as the format used to access the information over the
network.
Access rights to the SNMP agents are controlled by access strings. To communicate with the device, the
Embedded Web Server submits a valid community string for authentication. To open the SNMP page, click
System → SNMP in the tree view.
This section contains information for managing the SNMP configuration.
Defining SNMP Global Parameters
The SNMP Global Parameters page permits enabling both SNMP and Authentication notifications. To open
the
SNMP Global Parameters page, click System → SNMP → Global Parameters in the tree view.
Figure 1-8. Global Parameters

15
Local Engine ID (10 - 64 Hex Characters) — Indicates the local device engine ID. The field value is a
hexadecimal string. Each byte in hexadecimal character strings is two hexadecimal digits. Each byte can be
separated by a period or a colon. The Engine ID must be defined before SNMPv3 is enabled.
For stand-alone devices select a default Engine ID that is comprised of Enterprise number and the default MAC
address.
Use Default — Uses the device generated Engine ID. The default Engine ID is based on the device MAC
address and is defined per standard as:
First 4 octets — first bit = 1, the rest is IANA Enterprise number.
Fifth octet — Set to 3 to indicate the MAC address that follows.
Last 6 octets — MAC address of the device.
SNMP
Notifications — Enables or disables the router sending SNMP notifications.
Authentication Notifications — Enables or disables the router sending SNMP traps when authentication fails.
Enabling SNMP Notifications
1 Open the SNMP Global Parameters page.
2 Select Enable in the SNMP Notifications field.
3 Click Apply Changes .
SNMP notifications are enabled, and the device is updated.
Enabling Authentication Notifications
1 Open the SNMP Global Parameters page.
2 Select Enable in the Authentication Notifications field.
3 Click Apply Changes .
Enabling SNMP Notifications Using CLI Commands
The following table summarizes the equivalent CLI commands for viewing fields displayed in the SNMP Global
Parameters
page.
Table 1-5. SNMP Notification Commands
CLI Command Description
snmp-server enable
traps
Enables the router to send Simple Network
Management Protocol traps.
snmp-server trap
authentication
Enables the router to send Simple Network
Management Protocol traps when authentication
fails.
show snmp Checks the status of SNMP communications.

16
www.dell.com | support.dell.com
snmp-server engine
ID local {
engineid-
string
| default}
Indicates the local device engine ID. The field
values is a hexadecimal string. Each byte in
hexadecimal character strings is two hexadecimal
digits. Each byte can be separated by a period or
colon. The Engine ID must be defined before
SNMPv3 is enabled.
Table 1-5. SNMP Notification Commands
CLI Command Description

17
The following is an example of the CLI commands:
Defining SNMP View Settings
SNMP Views provides access or blocks access to device features or feature aspects. For example, a view can be
defined which states that SNMP group A has read only (R/O) access to Multicast groups, while SNMP group B
has read-write (R/W) access to Multicast groups. Feature access is granted via the MIB name, or MIB Object ID.
The Up and Down arrows allow navigating through the MIB tree, and MIB branches.
Console (config)# snmp-server enable traps
Console (config)# snmp-server trap authentication
Console# show snmp
Community-String Community-Access View name IP address
---------------- ----------------- --------- ----------
public read only view-1 All
Community-String Group name IP address Type
----
---------------- ---------- ----------
Traps are enabled.
Authentication-failure trap is enabled.
Version 1,2 notifications
Target
Address
Type Community Version Udp
Port
Filter
name
To
Sec
Retries
------- ---- --------- ------- ---- ------ --- -------
Version 3 notifications
Target
Address
Type Username Security
Level
Udp
Port
Filter
name
To
Sec
Retries
-------- ---- --------- -------- ----
-
------
-
--- -------
System Contact: Robert
System Location: Marketing

18
www.dell.com | support.dell.com
To open the SNMPv3 View Settings page, click System → SNMP → View Settings in the tree view.
Figure 1-9. SNMPv3 View Settings
View Name — Contains a list of user-defined views. The view name can contain a maximum of 30 alphanumeric
characters. The possible field values are:
Default — Displays the default user-defined view.
DefaultSuper — Displays the default super user-defined view.
New Object ID Subtree — Indicates the device feature OID included or excluded in the selected SNMP view.
Selected from List — Select the device feature OID by using the Up and Down buttons to scroll through a list of
all device OIDs.
Insert — Specify the device feature OID.
View Type — Indicates if the defined OID branch will be included or excluded in the selected SNMP view.
Adding a View
1 Open the SNMPv3 View Settings page.
2 Click Add .
The
Add a View page opens.

19
Figure 1-10. Add a View
3
Define the field.
4 Click Apply Changes .
The
SNMP View is added, and the device is updated.
Displaying the View Table
1 Open the SNMPv3 View Settings page.
2 Click Show All .
The
View Table page opens.
Figure 1-11. View Table
Defining SNMP Views Using CLI Commands
The following table summarizes the equivalent CLI commands for defining fields displayed in the SNMPv3
View Settings
page.
Figure 1-12. SNMP View CLI Commands
CLI Command Description
snmp-server view
view-name oid-tree
{included | excluded}
Creates or updates a view entry.

20
www.dell.com | support.dell.com
The following is an example of CLI commands:
show snmp views
[
viewname ]
Displays the configuration of views.
Console (config)# snmp-server view user1 1 included
Console (config)# end
Console # show snmp views
Name OID Tree Type
------------- ----------------- --------
user1 iso included
Default iso included
Default snmpVacmMIB excluded
Default usmUser excluded
Default rndCommunityTable excluded
DefaultSuper iso included
Figure 1-12. SNMP View CLI Commands
CLI Command Description
