Dell EMC PowerSwitch N3000E-ON Series Quick start guide

Dell EMC Networking N3048EP-ON, N3024ET-ON, N3024EF-ON,
N3024EP-ON and N3048ET-ON
Upgrading Dell EMC Networking
N3000E-ON Series Switches to
6.5.3.36 or 6.5.3.6 Firmware
Date: March 2019
Information in this document is subject to change without notice.
Copyright © 2019 Dell Inc. All rights reserved.
This product is protected by U.S. and international copyright and intellectual property laws. Dell and the Dell logo are
trademarks of Dell Inc. in the United States and/or other jurisdictions. All other marks and names mentioned herein may be
trademarks of their respective companies.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo and PowerConnect are trademarks of Dell Inc; Intel and Pentium are registered
trademarks and Celeron is a trademark of Intel Corporation; Microsoft and Windows are registered trademarks of Microsoft
Corporation.
Other trademarks and trade names may be used in this document to refer to either the entity claiming the marks and names or
their products. Dell Inc disclaims any proprietary interest in trademarks and trade names other than its own. All rights reserved.
This document may not, in whole or in part, be copied, photocopied, reproduced, translated, or reduced to any electronic
medium or machine-readable form without the prior written consent of Dell. Dell reserves the right to make changes without
further notice to any products or specifications referred to herein to improve reliability, functionality or design.

System Firmware Version 6.5.3.6
Reproduction, adaptation or translation without prior written permission is prohibited, except as allowed under the copyright
laws.

Subject to Change Without Notice
ii
Table of Contents
Introduction...............................................................................................................1
Global Support............................................................................................................1
Firmware Upgrade Overview...........................................................................................1
Firmware Downgrade Overview........................................................................................1
Upgrade Dell EMC Networking N3000E-ON Switches................................................................2
How to Access Serial Console Port on N3000E-ON switches.......................................................2
Upgrade Example for Dell EMC Networking N3000E-ON – Advanced Version ...................................3
Upgrade Stack of Dell EMC Networking N3000E-ON Switches – Advanced Version.............................5
How to setup mixed stack of N3000E-ON with N3000 Series switches(Advanced-Lite) .......................6
How to setup mixed stack of N3000E-ON with N3132PX-ON Switches – Advanced Version...................8
How to setup mixed stack of N3000E-ON, N3000, N3132PX-ON Switches (Advanced-Lite).................11
Upgrade mixed stack of N3132PX-ON, N3000E-ON and N3000 Series switches (Adv-Lite).................. 13
Upgrade mixed stack of N3000E-ON series and N3132PX-ON switches (Advanced)..........................14
Upgrade mixed stack of N3000 Series and N3132PX-ON switches (Advanced Lite)..........................14
Manual Install of OS6 image via ONIE...............................................................................15
Switch Recovery Procedure........................................................................................... 16
Switch Recovery Example.............................................................................................16
End of document....................................................................................................... 17

Firmware Upgrade Procedure Dell™ Networking N3000E-ON Series Switch
Page 1
Introduction
This document provides specific procedures for upgrading the firmware to the Dell EMC Networking
N3024ET-ON/N3024EP-ON/N3024EF-ON/N3048ET-ON/N3048EP-ON switches to firmware version 6.5.3.36 or
later.
IMPORTANT: Dell EMC Networking N3048EP-ON switches support firmware
version 6.5.1.1/6.5.1.31 and later.
IMPORTANT: Dell EMC Networking N3024ET-ON/N3024EP-ON/N3024EF-ON/
N3048ET-ON switches support firmware version 6.5.2.5/6.5.2.35 and later.
It is recommended that this document be thoroughly reviewed prior to installing or upgrading of this product.
Global Support
For information regarding the latest available firmware, release note revisions, or additional assistance, please visit
support.dell.com.
Firmware Upgrade Overview
Administrators must have access to the CLI via telnet, SSH or the serial port to perform the upgrade procedure.
IMPORTANT: Dell EMC Networking N3000E-ON switches support two versions of
latest firmware – Advanced Version and Advanced-Lite Version. The image file for
Advanced Version is N3000Advv6.5.3.36.stk and Advanced-Lite Version is
N3000AdvLitev6.5.3.6.stk. The firmware image version 6.5.3.36 supports full stack
capability of up to 12 units with maximum active VLAN support of 4093. The
firmware image version 6.5.3.6 supports reduced stack size of up to 8 units with
maximum active VLAN support of 1024. It’s required to use the Advanced-Lite
(N3000AdvLitev6.5.3.6.stk) version of firmware image to form the mixed stack of
N3000E-ON and N3000 Series switches. It’s required to use the Advanced Version
(N3000Advv6.5.3.36.stk) version of firmware image to form the mixed stack of
N3000E-ON and N3132PX-ON switches to support full stack capability of up to 12
units with maximum active VLAN support of 4093
Firmware Downgrade Overview
Downgrading from firmware 6.5.3.36 or 6.5.3.6 to an earlier 6.5.1.x release is not supported on Dell EMC
Networking N3000E-ON Series switches. Migration of switch configuration information form a later release to an
earlier release is NOT supported. It is strongly recommended that the current configuration be saved locally (i.e., not
on the switch) prior to downgrading the firmware. The existing configuration may or may not work with the earlier
version of firmware, therefore, it is always best to be physically present at the switch site and to be prepared to
access the switch over the serial port if necessary when downgrading firmware.

Upgrade Dell EMC Networking N3000E-ON Switches
Page 2
Upgrade Dell EMC Networking N3000E-ON Switches
The procedure given below to download firmware to an individual switch or a stack of switches.
Please do not interrupt switch operation during the downloading process as this may result in corruption of
flash memory. Do not power off a switch undergoing the upgrade process unless specifically directed to do so
by the instructions.
An annotated download example is shown following this section.
1. Back up your configuration.
2. Upgrade using telnet or SSH require default enable authentication method or enable password in current
configuration. If not configured follow steps below to configure an enable password:
console#configure
console(config)#enable password <password>
console(config)#exit
console#copy running-config startup-config
3. Download the 6.5.3.36 firmware image (N3000Advv6.5.3.36.stk) or 6.5.3.6 firmware image
(N3000AdvLitev6.5.3.6.stk) to the standalone-switch or stack master.
NOTE: Activate the image to use as the boot (active) image after the switch
resets. Images on the N3000E-ON switches are named active and backup.
4. Activate 6.5.3.36 (Advanced) or 6.5.3.6 (Advanced-Lite) firmware.
5. Reload the switch.
How to Access Serial Console Port on N3000E-ON switches
NOTE: How to access serial console of the N3000E-ON switch?
 Use a supplied “RJ45 Yost to DB9 serial cable” to access the serial console.
 Connect the RJ45 end of the cable to the RJ45 serial console port and the DB9 connector to your PC.
 Download and Install the terminal emulation software on your PC (for example, PuTTY) to access the
serial console with the correct settings (default setting 115200 baud, 8 data bits, no parity bit, 1 stop
bit, and no flow control).
Figure.1N3048EP‐ONwith4810/100/1000BASE‐TPorts(FrontPanel)

Out-of-Band Management Port
RJ-45 serial console port
NOTE: A TFTP server must be on the network and the switch software
must be accessible to the TFTP server before attempting to download
the switch software by TFTP.

Upgrade Dell EMC Networking N3000E-ON Switches
Page 3
Upgrade Example for Dell EMC Networking N3000E-ON – Advanced Version
This example shows an annotated upgrade example for a N3000E-ON switch to Advanced Version. This example
presumes the administrator is logged in to the switch via Serial console. You can also follow this upgrade procedure
via telnet or SSH after setting enable password if it is not set so.
1. Back up your configuration. The following commands copy the running-config to a TFTP server:
console#copy running-config tftp://10.10.10.200/myconfig.txt
Mode........................................... TFTP
Set TFTP Server IP............................. 10.10.10.200
TFTP Path...................................... ./
TFTP Filename.................................. myconfig.txt
Data Type...................................... Config Script
Source Filename................................ running-config
Management access will be blocked for the duration of the transfer
Are you sure you want to start? (y/n) y
11062 bytes transferred
File transfer operation completed successfully.
console#
2. Set an enable password and save the configuration (not required if an alternative enable authentication
method is already configured).
console#configure
console(config)# enable password <password>
console(config)# exit
console# copy running-config startup-config
3. Download the 6.5.3.36 firmware image from a TFTP server.
console#copy tftp://10.10.10.200/N3000Advv6.5.3.36.stk backup
Transfer Mode.................................. TFTP
Server IP Address.............................. 10.10.10.200
Source File Path............................... ./
Source Filename................................ N3000Advv6.5.3.36.stk
Data Type...................................... Code
Destination Filename........................... backup
Management access will be blocked for the duration of the transfer
Are you sure you want to start? (y/n) y
TFTP Code transfer starting...
30073854 bytes transferred...
File contents are valid. Copying file to flash...
Attempting to send the STK file to other units in the stack...
File transfer operation completed successfully.
console#show version
Machine Description............... Dell EMC Networking Switch
System Model ID................... N3048EP-ON
Machine Type...................... Dell EMC Networking N3048EP-ON
Serial Number.....................
Manufacturer...................... 0xbc00
Burned In MAC Address............. 0090.BC06.A571
System Object ID.................. 1.3.6.1.4.1.674.10895.3060
SOC Version....................... BCM56340_A0
HW Version........................ 5
CPLD Version...................... 20
Image File........................ N3000Advv6.5.3.36
Software Capability............... Stack Limit = 12, VLAN Limit = 4093
unit active backup current-active next-active
---- ----------- ----------- -------------- --------------
1 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
NOTE: Set the image to use as the boot (active) image after the switch
resets. Images on the N3000E-ON series switches are named active and
backup.

Upgrade Dell EMC Networking N3000E-ON Switches
Page 4
4. Activate the 6.5.3.36 firmware
console#boot system backup
Activating image backup ..
5. Reload the switch.
console#reload
Management switch has unsaved changes.
Are you sure you want to continue? (y/n) y
Configuration Not Saved!
Are you sure you want to reload the stack? (y/n) y
6. After the switch has finished rebooting, log in and verify that the firmware has been updated to the 6.5.3.36
version using the show version command. A single switch will typically reboot in around two minutes. A
stack may take significantly longer to complete the upgrade process.
console#show version
Machine Description............... Dell EMC Networking Switch
System Model ID................... N3048EP-ON
Machine Type...................... Dell EMC Networking N3048EP-ON
Serial Number.....................
Manufacturer...................... 0xbc00
Burned In MAC Address............. 0090.BC06.A571
System Object ID.................. 1.3.6.1.4.1.674.10895.3060
SOC Version....................... BCM56340_A0
HW Version........................ 5
CPLD Version...................... 20
Image File........................ N3000Advv6.5.3.36
Software Capability............... Stack Limit = 12, VLAN Limit = 4093
unit active backup current-active next-active
---- ----------- ----------- -------------- --------------
1 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
7. The switch or stack is now ready for normal operation. Verify the configuration and make any changes
needed prior to connecting the switch to the operational network.
8. Reload the switch.
console#reload
Management switch has unsaved changes.
Are you sure you want to continue? (y/n) y
Configuration Not Saved!
Are you sure you want to reload the stack? (y/n) y

Upgrade Dell EMC Networking N3000E-ON Switches
Page 5
Upgrade Stack of Dell EMC Networking N3000E-ON Switches – Advanced Version
Note on “copy” command from steps 2,3 and 4 in switch upgrade above:
 “copy” command will take longer to complete with a stack of switches. This is due to the master switch
copying the software to the member switches. The master switch will display the line “Distributing the
code to the members of the stack!” for several minutes until the copy is done.
 “copy” command will copy the software to all the switches as “backup” image
console#show version
Machine Description............... Dell EMC Networking Switch
System Model ID................... N3048EP-ON
Machine Type...................... Dell EMC Networking N3048EP-ON
Serial Number.....................
Manufacturer...................... 0xbc00
Burned In MAC Address............. 0090.BC06.A571
System Object ID.................. 1.3.6.1.4.1.674.10895.3060
SOC Version....................... BCM56340_A0
HW Version........................ 5
CPLD Version...................... 20
Image File........................ N3000Advv6.5.3.36
Software Capability............... Stack Limit = 12, VLAN Limit = 4093
unit active backup current-active next-active
---- ----------- ----------- -------------- --------------
1 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
2 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
3 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
console# boot system backup
Activating image backup ..
console#show version
Machine Description............... Dell EMC Networking Switch
System Model ID................... N3048EP-ON
Machine Type...................... Dell EMC Networking N3048EP-ON
Serial Number.....................
Manufacturer...................... 0xbc00
Burned In MAC Address............. 0090.BC06.A571
System Object ID.................. 1.3.6.1.4.1.674.10895.3060
SOC Version....................... BCM56340_A0
HW Version........................ 5
CPLD Version...................... 20
Image File........................ N3000Advv6.5.3.36
Software Capability............... Stack Limit = 12, VLAN Limit = 4093
unit active backup current-active next-active
---- ----------- ----------- -------------- --------------
1 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
2 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
3 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
console#reload
Management switch has unsaved changes.
Are you sure you want to continue? (y/n) y
Configuration Not Saved!
Are you sure you want to reload the stack? (y/n) y
After the stack of switches has finished rebooting, log in and verify that the firmware has been updated to the
6.5.3.36 version using the show version command. A single switch will typically reboot in around two minutes. A
stack may take significantly longer to complete the upgrade process.

Upgrade Dell EMC Networking N3000E-ON Switches
Page 6
console#show version
Machine Description............... Dell EMC Networking Switch
System Model ID................... N3048EP-ON
Machine Type...................... Dell EMC Networking N3048EP-ON
Serial Number.....................
Manufacturer...................... 0xbc00
Burned In MAC Address............. 0090.BC06.A571
System Object ID.................. 1.3.6.1.4.1.674.10895.3060
SOC Version....................... BCM56340_A0
HW Version........................ 5
CPLD Version...................... 20
Image File........................ N3000Advv6.5.3.36
Software Capability............... Stack Limit = 12, VLAN Limit = 4093
unit active backup current-active next-active
---- ----------- ----------- -------------- --------------
1 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
2 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
3 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
4 6.5.3.36 6.5.3.36 6.5.3.36 6.5.3.36
How to setup mixed stack of N3000E-ON with N3000 Series switches(Advanced-Lite)
Dell EMC Networking N3000E-ON switches can be mixed stack with N3000 Series switches of up to 8 units.
Mixed stack of N3000E-ON and N3000 Series supports only 1024 active VLANs configurable in the range 1-4093
and does not support MMRP/MVRP. Dell EMC Networking N3000E-ON switches has an expansion slot to install
optional stacking module with two mini-SAS stack ports. Dell EMC Networking N3000 Series switches are
available with two fixed mini-SAS stack ports.
Administrators setting up mixed stack of N3000E-ON and N3000 Standalone switches should follow the below
steps below:
1. Back up your configuration of N3000E-ON and N3000 Switches.
2. Upgrade using telnet or SSH require default enable authentication method or enable password in current
configuration. If not configured follow steps below to configure an enable password:
console#configure
console(config)#enable password <password>
console(config)#exit
console#copy running-config startup-config
3. Download the Advanced-Lite version of 6.5.3.6 firmware image (N3000AdvLitev6.5.3.6.stk) to N3000E-
ON and N3000 Series switches.
NOTE: Activate the image to use as the boot (active) image after the switch
resets. Images on the N3048EP-ONswitch is named as active and backup.
4. Activate 6.5.3.6 (Advanced-Lite) firmware on N3000E-ON and N3000 switches
5. Reload the switches.
6. After switch reloaded, download and activate the mixed-stack firmware image
(N3000N3100AdvLitev6.5.3.6.itb) on N3000E-ON and N3000 switches.
7. Reload the switches again.
8. Power OFF both N3000E-ON and N3000 Series switches. Plug-in mini-SAS stack cables and form the
stack between N3000E-ON and N3000 Series switches.
