DeLonghi EC9155.YE User manual

EC9155
COFFEE MAKER
Instructions for use

2
B4B3
B2
B1
B5 B6 B7 B8 B9
De’LonghiAppliancess.r.l.
ViaL.Seitz, 47 31100 Treviso - ITALY
Tel.[phone]
5413218631/04.15
Decalcicantepermacchine da caè
Descalerfor coee machines
Détartrantpour machines à café
Entkalkerfür Kaeemaschinen
C4
C3
C5
C1
C2
C6
SoftBalls
C7* C10
C8 C9
C12*C11
EN
page 4

3
A1
A2
A3 A4
A7
A5
2 1
3
4
5
67
8
FIN
E
ESRA
OC
A6
A8
A14
A16
A17
A19
A15
A9
A18
A10
A11
A12
A13

4
Before using the appliance, always read the safety warnings.
This appliance shall not be used by children.
Keep the appliance and its cord out of reach
of children.
1. DESCRIPTION
1.1 Description of appliance - A
A1. Main switch
A2. Grinding level selector (ne to coarse)
A3. Beans container
A4. Beans container lid
A5. Accessory holder lid
A6. Water tank lid
A7. Water tank
A8. Power cord
A9. Steam wand
A10. Coee outlet
A11. Hot water spout
A12. Portalter holder
A13. Coee grinder outlet
A14. Small cup grille support
A15. Small cup grille
A16. Mug or cup tray
A17. Mug or cup tray support
A18. Water level indicator
A19. Drip tray
1.2 Description of control panel - B
B1. Pressure gauge
B2. No water light
B3. Descale light
B4. Coee dose dial
B5. 1 or 2-cups selection button
B6. OK button: to deliver the beverage/conrm
B7. Coee Temperature button
B8. Mode selector dial:
• Espresso
• Long Black
• Hot water
• Descaling
B9. Steam button: to deliver steam
1.3 Description of accessories - C
C1. Portalter
C2. Dosing&Tamping Guide
C3. 1-cup coee lter
C4. 2-cups coee lter
C5. “Water hardness test“ indicator paper
C6. Descaler
C7. Softballs (* some models only)
C8. Milk pitcher
C9. Cleaning brush
C10. Cleaning needle for steam nozzle
C11. Tamper
C12. Tamping Mat (* some models only)
1.4 Recommended optional cleaning accessories
Visit Delonghi.com for more information.
Cleaner
EAN: 8004399333307
2. EXPLANATION OF LIGHTS
LIGHTS EXPLANATION OF LIGHTS OPERATION
All the lights ash briey Turning the machine on Self-diagnosis
On
The appliance is being turned on for the rst
time and the water circuit must be lled
Proceed as described in the Quick start guide.
+
On
(The indicators and show
the respective selections)
The machine is ready to use Prepare the machine, select the desired beverage
and press OK to start delivery
…→

5
LIGHTS EXPLANATION OF LIGHTS OPERATION
Flashing
The machine is warming up Wait until the ideal delivery temperature has
been reached
On
Insucient water in tank (A7) or water
tank not inserted correctly
Fill the tank or extract the tank and put it back
correctly
Flashing
You are trying to deliver a beverage but
water tank (A7) is empty
Fill the tank
Because the beans are too nely
ground, the coee is delivered too
slowly or not at all
Remove the portalter (C1) and repeat the
operations to make the coee, bearing in mind
the instruction given in the quick start guide
relative to the grinding section
The lter (C3) or (C4) is blocked Clean as described in section “5. Cleaning and
maintenance”.
The tank (A7) has been inserted incorrectly
and the valves on the bottom are not open
Press the tank down lightly to open the valves
on the bottom
Scale in the water circuit Descale as described in section “9. Descaling”
On
1-dose beverage is selected All the process (from grinding to delivery) is
setted for preparing 1 cup
On 2-doses beverages are selected All the process (from grinding to delivery) is
setted for preparing 2 cups
MIN MED MAX
On
Choose 1 of the 3 temperatures
available
See Quick Guide for tips.
Flashing
General alarm Turn the machine o and wait 10 minutes
before turning on again. If the problem con-
tinues, contact customer services.
Flashing
Steam function is selected and running In a few seconds the appliance starts steam
delivery
On - red
Descaling must be performed Descale the appliance as described in section
“9. Descaling”
Flashing - On
Descaling is selected Press OK (B6) to run descaling cycle or turn the
selection knot to the beverage desired
…→
Red
Orange

6
+
Press both buttons (B5)
and (B7) for 3 seconds to
enter setting menu
Keep pressed steam but-
ton (B9) for 3 seconds
Enter the setting
menu
Reset to default
values
➡ 9 minutes
➡ 1,5 hours
➡ 3 hours
Auto o
➡soft
➡ medium
➡ hard
Water hardness
➡No
➡ 1 sec
➡ 2 sec
Pre-infusion
delay
➡1st range
➡2nd range
Extra grinding
adjustment
Press the temperature button: the light corresponding to the corrent setting ashes.
Press the temperature button again to change the setting:
Turn the knob (B8)
to select the position
corresponding to the
function to set
Select the setting
x3 sec
LIGHTS EXPLANATION OF LIGHTS OPERATION
Flashing
Descaling proceeds.The machine deliv-
ers descaling solution
Proceed by completing the descaling cycle
(see“9. Descaling”)
Flashing - On
The rst phase of the descaling cycle
is complete. You now need to proceed
with rinsing.
Press OK to start rinsing.
Flashing
The machine proceeds with the rinsing
phase to complete the descaling cycle.
Proceed by completing the descaling cycle
(see“12. Descaling”)
3. MENÙ SETTINGS
Red
Orange
Red
White
Red
White
…→

7
Press the OK (B6) button
to conrm.
Save new
settings: Please note:
The appliance automatically
exits the menù setting after 30
seconds of inactivity
4. CUSTOMISING THE QUANTITY OF BEVERAGES
1. Prepare the appliance to
deliver the beverage you
want to make. Prepare the
coee dose and attach the
portalter (C1) to the coee
outlet (A10).
2. Turn the dial (B8) to
select the drink to be
programmed.
3. Keep pressed the OK
button (B6) until the de-
sired quantity in cup is
reached.
4. Once released the but-
ton, the quantity is
programmed.
Please note:
• You can programme beverages quantities, but not steam.
• Programming changes the quantity of the beverages, but
not the amount of coee ground.
• “X2” beverages can be programmed separately.
1 2 3 4
Coee
Recipe
Default
quantity
Programmable quantity
35 ml from 25 to 90 ml
X2
70 ml from 50 to 180 ml
100 ml • water: from 25 to 120 ml
• espresso: from 25 to 60 ml
X2
200 ml • water: from 50 to 240 ml
• espresso: from 50 to 120 ml
250 ml from 65 to 300ml

8
5. CLEANING AND MAINTENANCE
Important!
• Do not use solvents, abrasive detergents or alcohol to clean the coee machine.
• Do not use metal objects to remove encrustations or coee deposits as they could scratch metal or plastic surfaces.
• If the appliance is not used for more than a week, before using it again, we recommend you perform a rinse cycle.
Danger!
• While cleaning, never immerse the coee maker in water. It is an electrical appliance.
• Before cleaning the outside of the appliance, turn it o, unplug from the mains socket and allow to cool.
✕✓✕ ✕ ✕
✓✕ ✕ ✕ ✕
✓✕ ✕ ✓✕
✕✓ ✓ ✕✓
✕✓ ✓ ✕✓
6. CLEANING THE GRINDER
1. Clean the attachment area with a brush;
2. Use the brush (C9) to clean the coee funnel.
1 2

9
7. WATER HARDNESS
7.1 Water hardness
The descale light (B3) comes on after a period of time established according to water hardness. The machine can also be pro-
grammed according to the actual hardness of the water supply in the various regions, in which case descaling may be required less
frequently.
1. Remove the“TOTAL HARD-
NESS TEST” indicator paper
(C5) from its pack.
2. Immerse the paper
completely in a glass of
water for one second.
3. Remove the paper from
the water and shake
lightly.
4. Set the appliance as indi-
cated in section“3. Menù
settings”.
After about a minute, 1, 2, 3, or 4 red squares form, depending
on the hardness of the water. Each square corresponds to one
level.
Total Hardness Test result Button Level
1
soft water
2
medium
water
3
hard or
very hard
water
8. CLEANING THE STEAM NOZZLE
1. After every use, remove
with a soft damp cloth
any milk residues from
the steam wand (A9) and
the nozzle.
2. Use the steam for a deeper
cleaning.
3. To maintain the better
usability of the nozzle,
when clogged, use the
Cleaning Tool (C10) for
opening the hole.
1 2 3
123

10
A
B
A
B
9. DESCALING
1. IF PRESENT, REMOVE
THE WATER SOFTENER
DEVICE. Pour the des-
caler into the tank (A7)
up to the level A
marked inside the tank
(equal to one 100ml
packet).
2. A dd water (1 liter) up
to t he level B.
Then put the water tank
back in the appliance.
3. Turn the mode selector
dial (B8) to : the OK
light (B6) turns to orange
and the descaling light
(B3) ashes.
4. Make sure the portalter is
not attached and position a
recipient under the coee
outlet (A10), hot water
spout (A11) and steam
wand (A9).
5. Keep pressed for at least
3 seconds the OK button:
the OK light begins to
ash; descaling starts.
12.
Please note
• Before use, read the instructions and the labelling on the descaler pack.
• It is important to use De’Longhi descaler only. Using unsuitable descaler and/or performing descaling incorrectly may result
in faults not covered by the manufacturer’s guarantee.
• Descaler could damage delicate surfaces. If the product is accidentally spilt, dry immediately.
4
1
5
2 3
RED
40
Minutes
De’LonghiAppliances s.r.l.
ViaL. Seitz, 47 31100 Treviso - ITALY
Tel.[phone]
5413218631/04.15
Decalcificanteper macchine da caffè
Descalerfor coffee machines
Détartrantpour machines à café
Entkalkerfür Kaffeemaschinen 2 L
Please note
• In case you start the descaling cycle by mistake, you can press the OK button
for 10 seconds; the rinsing cycle can not be stopped (from step 9).
6. The descale programme starts and the descaler liquid
comes out of the steam wand and coee outlet.The des-
cale programme removes limescale deposits from inside
the appliance by automatically performing a series of
rinses and pauses until the tank is empty.
Delivery stops and the OK light turns to white. This indi-
cates that it is necessary to proceed with rinsing: see next
page.
When the light (B3) comes
on, it is time to proceed descal-
ing the machine. The descaling
cycle can be run in any moment.
