DE’LONGHI
COOKING
USER & INSTALLATION INSTRUCTIONS
DSR 927 GX
GAS COOKERS
GB

2
CONTENTS Page Number
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important Safety Precautions & Recommendations . . . . . . . . . . . . . . . .
Advice for the Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Advice for the User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooking Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Use of the Hob Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to use the fan assisted gas oven . . . . . . . . . . . . . . . . . . . . . . . . .
60’ allarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Guarantee .& After Sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
4 - 8
9
10 - 13
14 - 24
25 - 26
27
28
29
30 - 35
36 - 43
44
45 - 54
55

3
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT
IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority di󰀨erentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible negati-
ve consequences for the environment and health deriving from inappro-
priate disposal and enables the constituent materials to be recovered
to obtain signicant savings in energy and resources. As a reminder of
the need to dispose of household appliances separately, the product is
marked with a crossed-out wheeled dustbin.
Dear Customer,
Thank you for purchasing the DeLonghi DSR 927-GX
gas cooker.
The safety precautions and recommendations listed
below are for your own safety and that of others. They
will also provide a means by which to make full use of the
features oered by your appliance.
Please retain this booklet for future reference.
This appliance must be used only for the task it
has explicitly been designed for, that is for cooking
foodstus. Any other form of usage is to be considered
as inappropriate and therefore potentially dangerous.
The manufacturer declines all responsibility in the
event of damage caused by improper, incorrect or
illogical use of the appliance.
GB
DECLARATION OF CE CONFORMITY
• This appliance has been designed to be used only for cooking. Any other use (such as
heating a room) is improper and dangerous.
• This appliance has been designed, constructed, and marketed in compliance with:
- Safety requirements of the “Gas” Regulation (EU) 2016/426;
- Safety requirements of the “Low voltage” Directive 2014/35/EU;
- Safety requirements of the “EMC” Directive 2014/30/EU;
- Requirements of EU Directive 93/68/EEC;
- Requirements of EU Directive 2011/65/EU.

4
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
• This appliance has been designed and manufactured in
compliance with the applicable standards for the household
cooking products, including those for surface temperatures.
Some people with sensitive skin may have a more pronounced
temperature perception with some components although these
parts are within the limits allowed by the norms.
The complete safety of the appliance also depends on the correct
use, we therefore recommend to always pay a extreme attention
while using the product, especially in the presence of children.
• After having unpacked the appliance, check to ensure that it is
not damaged and that the oven door closes correctly.
In case of doubt, do not use it and consult your supplier or a
professionally qualied technician.
• Packing elements (i.e. plastic bags, polystyrene foam, nails,
packing straps, etc.) should not be left around within easy reach
of children, as these may cause serious injuries.
• Some appliances are supplied with a protective lm on steel and
aluminium parts. This lm must be removed before using the
appliance.
• IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning this appliance.

5
• Do not attempt to modify the technical characteristics of
the appliance as this may become dangerous to use. The
manufacturer declines all responsibility for any inconvenience
resulting from the inobservance of this condition.
• CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
• Do not carry out cleaning or maintenance operations on the
appliance without having previously disconnected it from the
electric power supply.
• WARNING: Ensure that the appliance is switched o󰀨 before
replacing the oven lamp to avoid the possibility of electric shock.
• Do not use a steam cleaner because the moisture can get into
the appliance therefore making it unsafe.
• Do not touch the appliance with wet or damp hands (or feet).
• Do not use the appliance whilst in bare feet.
• If you should decide not to use this appliance any longer (or
decide to substitute another model), before disposing of it, it
is recommended that it be made inoperative in an appropriate
manner in accordance to health and environmental protection
regulations, ensuring in particular that all potentially hazardous
parts be made harmless, especially in relation to children who
could play with unused appliances.
• The various components of the appliance are recyclable. Dispose
of them in accordance with the regulations in force in your country.
If the appliance is to be scrapped, remove the power cord.
• After use, ensure that the knobs are in the o󰀨 position.
• Children less than 8 years of age shall be kept away unless
continuously supervised.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.

6
• The manufacturer declines all liability for injury to persons or
damage to property caused by incorrect or improper use of the
appliance.
• WARNING: During use the appliance and its accessible parts
become hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements (on
the hob and inside the oven).
– The door is hot, use the handle.
– To avoid burns and scalds, young children should be kept
away.
• Make sure that electrical cables connecting other appliances in
the proximity of the cooker cannot come into contact with the hob
or become entrapped in the oven door.
• WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re
with water, but switch o󰀨 the appliance and then cover ame e.g.
with a lid or a re blanket.
• WARNING: Danger of re: do not store items on the cooking
surfaces.
• WARNING: When correctly installed, your product meets all
safety requirements laid down for this type of product category.
However special care should be taken around the rear or the
underneath of the appliance as these areas are not designed or
intended to be touched and may contain sharp or rough edges,
that may cause injury.
• FIRST USE OF THE OVEN - it is advised to follow these
instructions:
– Furnish the interior of the oven as described in the chapter
“CLEANING AND MAINTENANCE”.
– Switch on the empty oven on max to eliminate grease from the
heating elements.
– Disconnect the appliance from the electrical power supply, let
the oven cool down and clean the interior of the oven with a
cloth soaked in water and neutral detergent; then dry carefully.

7
• CAUTION: Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
• Do not line the oven walls or base with aluminium foil. Do not place
baking trays or the drip tray on the base of the oven chamber.
• FIRE RISK! Do not store ammable material in the oven or in the
storage compartment.
• Always use oven gloves when removing the shelves and food
trays from the oven whilst hot.
• Do not hang towels, dishcloths or other items on the appliance or
its handle – as this could be a re hazard.
• Clean the oven regularly and do not allow fat or oils to build up in
the oven base or tray. Remove spillages as soon as they occur.
• Do not stand on the cooker or on the open oven door.
• Always stand back from the appliance when opening the oven
door to allow steam and hot air to escape before removing the
food.
• SAFE FOOD HANDLING: Leave food in the oven for as short
a time as possible before and after cooking. This is to avoid
contamination by organisms which may cause food poisoning.
Take particular care during warmer weather.
• WARNING: Take care NOT to lift the cooker by the door handle.
• CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
• The appliance must not be installed behind a decorative door in
order to avoid overheating.
• The oven accessories (e.g. oven wire rack) must be tted
correctly as indicated at page 49.
• If the power supply cable is damaged, it must be replaced only
by an authorized service agent in order to avoid a hazard.

8
ENERGY LABELLING/ECODESIGN
• Commission delegated regulation (EU) No 65/2014 (supplementing Directive 2010/30/EU
of the European Parliament and of the Council).
• Commission regulation (EU) No 66/2014 (implementing Directive 2009/125/EC of the Eu-
ropean Parliament and of the Council).
Reference to the measurement and calculation methods used to establish compliance with
the above requirements:
• Standard EN 15181 (gas ovens).
• Standard EN30-2-1 (hobs: gas red burners).
USE OF THE APPLIANCE, ENERGY SAVING TIPS
OVEN
• Check the oven door always closes properly and the door gasket is clean and in order.
During use, open the oven door only when strictly necessary to avoid heat losses (for
some functions it may be necessary to use the oven with the door half-closed, check
the oven operating instructions).
• Turn o󰀨 the oven 5-10 minutes before the end of the theoretical cooking time to recu-
perate the stored heat.
• We recommend using oven proof dishes and adjusting the oven temperature during
cooking if necessary.
HOB
GAS FIRED BURNERS
• It is important that the diameter of the pot be suitable to the size of the burner so as
not to compromise the high output of the burners and therefore energy waste. A small
pot on a large burner does not give you a boiling point in a shorter amount of time
since the capacity of heat absorption of a liquid mass depends on the volume and the
surface of the pot.
• Avoid keeping a burner on without something on it (without pot).

9
IMPORTANT
• Cooker installation must only be carried out by QUALIFIED TECHNICIANS and in
compliance with local safety standards. Failure to install the appliance correctly could
invalidate any manufacturer’s warranty.
• The appliance must be installed in compliance with regulations in force in your country
and in observation of the manufacturer’s instructions.
• Always disconnect the appliance from the electrical supply before carrying out any
maintenance operations or repairs.
• Some appliances are supplied with a protective lm on steel and aluminium parts.
This lm must be removed before using the cooker.
Advice for the installer

10
INSTALLATION
The installation conditions, concerning protection against overheating of the surfaces
adjacent to the cooker, must conform to gs. 1.1a or 1.1b.
The appliance must be kept no less than 200 mm away from any side wall which exceeds
the height of the hob surface (gs. 1.1a or 1.1b).
The veneered syntetical material and the glue used must be resistant to a temperature of
90°C in order to avoid ungluing or deformations.
Curtains must not be tted
immediatly behind appliance or
within 500 mm of the sides.
If the cooker is located on a pedestal
it is necessary to provide safety
measures to prevent falling out.
The appliance must be housed in
heat resistant units.
The walls of the units must not
be higher than work top and
must be capable of resisting
temperatures of 75 °C above
room temperature.
Do not instal the appliance
near inammable materials (eg.
curtains).
■Class 1
(g. 1.1a)
Gas connection made using rubber
hose which must be visible and
easily inspected or using rigid or
exible metal pipe.
A space of at least 2 cm must be
left between the cooker and any
adjacent furniture, which must not
exceed the height of the cooktop.
■Class 2
■Subclass 1
(g. 1.1b)
Gas connection made using rigid
or exible metal pipe.
INSTALLATION
1
Important: Always maintain conditions that ensure the presence of an adequate
air ow at the bottom of the appliance. Do not close o󰀨 the space between the two
levelling feet. If the space must be closed, leave an area of at least 1/4 of the space
open.
200 mm
650 mm
500 mm
450 mm
Fig. 1.1b
200 mm
650 mm
500 mm
450 mm
20 mm
20 mm
Fig. 1.1a

11
CB
A
FITTING THE ADJUSTABLE FEET
The adjustable feet must be tted to the
base of the cooker before use (g. 1.2).
Rest the rear of the cooker on a piece of
the polystyrene packaging exposing the
base for the tting of the feet.
Fit the 4 legs by screwing them tight into
the support base as shown in gure 1.3.
LEVELLING THE COOKER
The cooker may be levelled by screwing
the lower ends of the feet IN or OUT (g.
1.4).
BACKGUARD (SUPPLIED WITH
SOME MODELS ONLY)
Before installing the cooker, assemble the
backguard “C” (g. 1.5).
• The backguard “C” can be found
packed at the rear of the cooker.
• Before assembling remove any
protective lm/adhesive tape.
• Remove the two spacers “A” and the
screw “B” from the rear of the cooktop.
• Assemble the backguard as shown
in gure 1.5 and x it by screwing the
central screw “B” and the spacers “A”.
Fig. 1.4 Fig. 1.3
Fig. 1.5
Fig. 1.2
SOME MODELS ONLY

12
MOVING THE COOKER
WARNING: When raising cooker to upright position always ensure two people carry
out this manoeuvre to prevent damage to the adjustable feet (g. 1.6).
WARNING
Be carefull: do not lift the cooker by the
door handle when raising to the upright
position (g. 1.7).
WARNING
When moving cooker to its nal position
DO NOT DRAG (g. 1.8).
Lift feet clear of oor (g. 1.6).
Fig. 1.8
Fig. 1.7
Fig. 1.6

13
PROVISION FOR VENTILATION
• The appliance should be installed into a room or space with an air supply in accordan-
ce with the current version of BS 5440-2: 2000.
• For rooms with a volume of less than 5m3- permanent ventilation of 100 cm2free area
must be provided.
• For rooms with a volume of between 5 m
3
and 10 m
3
a permanent ventilation of 50 cm
2
free area will be required unless the room has a door which opens directly to the outside
air in which case no permanent ventilation is required.
• For rooms with a volume greater than 10 m3- no permanent ventilation is required.
Note: Regardless of room size, all rooms containing the appliance must have direct
access to the outside air via an openable window or equivalent.
• Where there are other fuel burning appliances in the same room, the current version
of BS 5440-2: 2000 should be consulted to determine the correct amount of free area
ventilation requirements.
• The above requirements allow also for use of a gas oven and grill but if there are other
gas burning appliances in the same room, consult a qualied engineer.

14
GAS SECTION
2
GAS INSTALLATION REQUIREMENTS
Important !
• The walls adjacent to the cooker must be of heat-resistant material.
• Before installation, make sure that the local distribution conditions (gas type and
pressure) and the adjustment of this appliance are compatible. The appliance
adjustment conditions are given on the plate or the label.
• This appliance must be installed and serviced only by a suitably qualied,
registered installer. The installer shall refer to the local standards in force.
• Failure to install the appliance correctly could invalidate any manufacturer’s
warranty.
This appliance is supplied for use on Natural gas or LPG (check the gas regulation label
attached on the appliance).
• Appliances supplied for use on Natural gas: they are adjusted for this gas only and
cannot be used on any other gas (LPG) without modication. The appliances are
manufactured for conversion to LPG.
• Appliances supplied for use on LPG: they are adjusted for this gas only and cannot
be used on any other gas (Natural gas) without modication. The appliances are
manufactured for conversion to Natural gas.
If the Natural gas/LPG conversion kit is not supplied with the appliance this kit can be
purchased by contacting the After-Sales Service.
INSTALLATION & SERVICE REGULATIONS (UNITED KINGDOM)
It is a legal requirement that all gas appliances are Installed & Serviced by a competent
person in accordance with the current editions of the following Standards & Regulations or
those regulations appropriate to the geographical region in which they are to be installed:
• Gas Safety (Installation & Use) Regulations
• Building Regulations
• British/European Standards
• Regulations for Electrical Installation
Installation and service of any gas product must be made by a suitably qualied and
registered person competent on the type of product being installed or serviced and holding
a valid certicate of competence for the work being carried out. Currently the proof of
competence is the Accredited Certication Scheme (ACS) or S/NVQ that has been aligned
to the ACS.
It is also a requirement that all businesses or self employed installers are members of a
class of person approved by the Health and Safety Executive.
Failure to install the appliance correctly could invalidate any manufacturers warranty and
lead to prosecution under the above quoted regulation.

15
GAS CONNECTION
GB Cat: II 2H 3+
It is a requirement that a restraining chain (not supplied with the appliance) is also used to
prevent stress being applied to the gas hose or pipework. The chain should be attached
securely to the product and on the wall (g. 2.1).
Cook e r
RESTRAINING CHAIN
Chain
security
holes
Back of
the cooker
Rear wall
Fig. 2.1
Installation to Natural Gas
Installation to Natural Gas must conform to the Code of Practice, etc.
The supply pressure for Natural Gas is 20 mbar.
The installation must conform to the relevant British/European Standards.
Installation to LP Gas
When operating on Butane gas a supply pressure of 28-30 mbar is required.
When using Propane gas a supply pressure of 37 mbar is required.
The installation must conform to the relevant British/European Standards.
Warning: Only a suitably qualied and registered installer, also with technical knowledge
of electricity should install the appliance.
He should observe the Regulations and Codes of Practice governing such installation of
gas appliances.
Note: It is recommended that the gas connection to the appliance is installed with a exible
hose connecting tube made to BS669 or EN 14800.
Chain
security
holes

16
Notes:
• Flexible hoses can be used where the sited ambient temperature of the hose
does not exceed 70°C. These hoses must be manufactured in accordance with
BS669 part 1 or EN 14800 and be of the correct construction for the type of gas
being used.
• Gas hoses designed for natural gas MUST NOT be used for supplying LPG gas
(LPG gas hoses can be identied by a either a red band or stripe on the rubber
outer coating of the hose).
The hose should not be crushed or trapped or be in contact with sharp or
abrasive edges.
IMPORTANT! It is the responsibility of the gas installer to ensure that the product is
fully tested and commisioned in accordance with current regulations to ensure there
are no gas escapes.
Gas connection (gs. 2.2, 2.3, 2.4)
• The gas supply must use the gas inlet pipe which is located at the left hand side at the
rear of the appliance.
• IMPORTANT NOTE: Before connecting the appliance to the gas mains t the female
connector (supplied with the appliance in a separate kit) to the left inlet pipe using the
bre washer supplied.
IMPORTANT: Check the correct positioning of the connector as per pictures and
always operate using two suitable spanners.
• The hose should not be crushed or trapped or be in contact with sharp or abrasive
edges. It should also not be subjected to corrosion by acidic cleansing agents.
 The hose should also be connected in such away that it does not touch the oor and
must hang in a natural loop between the appliance and the bayonet tting.
• To avoid damage to the appliance gas rail inlet pipe the ttings should be tightened
using two suitable spanners.
Fig. 2.2
Gas inlet pipe
Connector

17
IMPORTANT PRESCRIPTIONS FOR GAS CONNECTION
Cooker
manifold (gas
inlet pipe)
Manifold
male
pipe tting
Fibre
washer (*)
Connector
(*)
1/2” G cylindrical
(ISO 228-1) male
20 mm
20 mm
10 mm
10 mm
1/2” G cylindrical
(ISO 228-1) female
1/2” BSP
female
(*)Supplied with the
appliance in a
separate kit
700 mm
Rear wall
Suggested area for
gas mains connection
Fig. 2.3
Fig. 2.4

18
GAS MAINTENANCE
LUBRICATION OF THE GAS TAPS
• In case of di󰀩culty in the gas taps operation, call Service.
IMPORTANT
All intervention regarding installation maintenance of the appliance must be fullled
with original factory parts.
The manufacturer declines any liability resulting from the non-compliance of this
obligation.
TABLE FOR THE CHOICE OF THE INJECTORS - Cat. II 2H 3+
BURNERS
Nominal
power
[kW]
Reduced
power
[kW]
LPG
G30 28-30 mbar
G31 37 mbar
Natural Gas
G20 20 mbar
Ø injector
[1/100 mm]
Ring
opening
[mm]
Ø injector
[1/100 mm]
Ring
opening
[mm]
Semi-rapid (SR) 1,75 0.45 66 - 101 -
Triple-ring (TR) 4,00 1,50 98 - 141
Dual (D)
inner
crown 0,80 (*) 0,35 (*) 46 (no.1 central)
-70
(no.1 central)
-
outer
crowns 4,00(**) 1,90 (**) 65 (no.2 outer)
-99
(no.2 outer)
-
Oven 4,70 1,00 105 Fully open (#) 155 2 (#)
Grill 4,20 - 102 Fully open (#) 150 4 (#)
(*) Power calculated with inner crown operating.
(**) Power calculated with inner and outer crowns operating.
(#) Reference value
AIR VENT NECESSARY FOR GAS COMBUSTION = (2 m3/h x kW)
BURNERS Air necessary for combustion [m3/h]
Semi-rapid (SR) 3,50
Triple-ring (TR) 8,00
Dual (D) inner crown 1,60
outer crown 9,00
Oven 9,40
Grill 8,40
GB

19
REPLACEMENT OF THE
INJECTORS OF THE BURNERS
Select the injectors to be replaced
according to the “Table for the choice of the
injectors”.
The nozzle diameters, expressed in
hundredths of a millimetre, are marked on
the body of each injector.
If the injectors are not supplied they can
be obtained from the “Service Centre”.
REPLACEMENTOFTHE INJECTORS
OF THE COOKTOP BURNERS
To replace the injectors proceed as follows:
• Remove pan supports and burners
from the cooktop.
• Using a wrench, substitute the nozzle
injectors “J” (gs. 2.5, 2.6, 2.7) with
those most suitable for the kind of gas
for which it is to be used.
The burners are conceived in such a
way so as not to require the regulation
of the primary air.
J
Fig. 2.5
Semi-rapid burners
J
Injectors for
outer crown
J
Injector for
inner crown
Dual burner
Fig. 2.7
Triple ring burners
Fig. 2.6
J

20
SETTING THE MINIMUM OF THE
COOKTOP BURNERS
When switching from one type of gas to
another, the minimum ow rate must also
be correct: the ame should not go out
even when passing suddenly from maxi-
mum to minimum ame.
To regulate the ame follow the instructions
below:
Auxiliary, semi-rapid and rapid burners:
• Light the burner.
• Set the gas valve to the “minimum
rate” position.
• Remove the knob.
• Using a screwdriver turn the screw
“F1” until adjustment is correct (g.
2.8).
Inside crown of DUAL burner:
• Light the DUAL burner.
• Set the gas valve to the “minimum
rate” position of the inner crown only.
• Remove the knob.
• Using a screwdriver turn the screw
“F2” until the correct setting is obtai-
ned (g. 2.9b).
Outside crowns of DUAL burner:
• Light the DUAL burner.
• Set the gas valve to the “minimum rate”
position of the inner + outer crowns.
• Remove the knob.
• Using a screwdriver turn the screw
“F3” until the correct setting is obtai-
ned (g. 2.9).
For LPG gas, tighten the adjustment
screws completely.
F
Fig. 2.8
F2 F3
Fig. 2.9
F1
