DeLonghi MULTIFRY FH1396 User manual

FH1396
MULTICUISINE

2
For more recipes:
(free download)
De’Longhi Recipes multifry.delonghi.com

3
A
X
W
R
U V
I
L
S T
O N
K
M
C
B
E
PQ
D
HGF
J
Y
Z
DESCRIPTION OF APPLIANCE

4
123
456
789
10 11 12
20
min
max

5
SECURITY WARNINGS
Read all the Instructions Carefully Before Utilising the
Device. Keep these Instructions for Use.
• If the power cord is damaged, it must
be replaced by the manufacturer or the
manufacturer’s Customer Experience in
order to avoid all risks.
•Never immerse the appliance in water.
• When in operation, the door and accessi-
ble external surfaces could become very
hot. Always use the handgrip, handles
and buttons. Use oven gloves if neces-
sary.
• This electrical appliance operates at high
temperatures that could cause burns.
• This appliance can be used by children
aged from 8 years and above and per-
sons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
the use of the appliance in a safe way
and understand the hazards involved.
Children shall not play with the appli-
ance. Cleaning and user maintenance
shall not be carried out by children with-
out supervision.
• Do not preheat the appliance when
empty.
•Do not use the appliance without food.
You might damage it.
• This is a household appliance only. It is
not intended to be used in: sta kitchen
areas in shops, oces and other working
environments; farm houses; by clients in
hotels, motels and other residential type
environments; bed and breakfast type
environments.
• This appliance must not be operated by
an external timer or a separate remote
control system.
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
• Beforeusingtheappliance,checkthatthevoltageofthe
main power supply corresponds to the value indicated on
the appliance rating plate.
• Connect the appliance to an earthed power supply and
sockets with the correct current specications. The manu-
facturer declines all liability in the event that this impor-
tant accident-prevention rule is not respected.
Danger of burns!
Failure to observe the warnings could result in scalds or burns.
• Whileinoperation,the appliancebecomeshot.DO NOT
LEAVEWITHINREACHOFCHILDREN.
• Movetheappliancebythehandlesonly.Nevermovethe
appliance using the bowl handgrip.
• Never leave the power cord hanging from the edge of
the surface the appliance is resting on where it could be
grasped by a child or get in the way of the user.
• Hotsteammaycomeoutofthevents.Takegreatcare!
Important!
Failure to observe the warnings may result in life threatening
injury or damage to the appliance.
• Neverplacedtheappliancenearsourcesofheat.
• Thebowltsautomaticallyontothecentralpin.Toavoid
damage, never rotate it manually to nd the right position.
• Neverinsertanythingintotheventilationopenings.Make
sure they are unobstructed.
• DonotllthebowlwithliquidabovetheMAXlevel(E).
• Donotllthebowlwithquantitiesofoilinexcessofthe
maximum level marked on the oil measure (level 5).
Please note:
This symbol identies important advice or information for the
user.
• Before setting up the appliance, remove any paper and
other material inside the appliance such as protective
cardboard, booklets, plastic bags, etc.
• Beforeusingthe appliancefortherst time,thoroughly

6
wash the bowl, the paddle and the lid in hot water and
washingupliquid.Attheendofoperation,dryallcompo-
nents thoroughly and remove any water left in the bottom
of the bowl.
• It is normal for the appliance to give o a“new” smell
when used for the rst time.Ventilate the room.
• Theappliancemustbekeptatadistanceofatleast20cm
from the mains power socket to which it is connected.
• During some cooking programmes, steam may be
released from the lid. It should not therefore be po-
sitioned under kitchen cupboards or furniture (g.
12).
TECHNICAL DATA
size (DxLxH): 405x325x290 mm
weight: 6.3kg
For further information, see the rating plate on the appliance.
The appliance complies with the following EC directives:
• Europeanregulation1935/2004onmaterialsandarticles
intended to come into contact with food.
• EuropeanStandbyRegulation1275/2008.
DISPOSAL
The appliance must not be disposed of with house-
hold waste but taken to an authorised waste separa-
tion and recycling centre.
DESCRIPTION OF APPLIANCE
A Lid
B Hotairdischargegrille(ventilation)
C Viewing window release buttons
D Removable viewing window
E MaximumlevelMAX
F Power cord
G Condensate tray
H MainON/OFFbutton
I Paddle
J Ceramic coated bowl (with paddle pin)
K Handle slide
L Bowlhandgrip
M Oilmeasure(levelfrom1to5)
N Illuminated power level bar
O Powerlevelbutton
P Timer button + (increases time)
Q Display
R Timer button - (decreases time)
S Cookingprogrammeselectordial
T Illuminatedprogrammestart/stopbutton
U Appliance body
V Handle for lifting the appliance
W Lid open button
X Condensatechannel
Y Grill
Z Teon coated bowl
COOKING PROGRAMMES
Automatic programmes: when one of the following pro-
grammes is selected, the default cooking time and optimum
power levels are displayed.
These can, however, be changed according to the recipe or your
personalrequirements.
CASSEROLE/RISOTTO: this programme is ideal for cook-
ing all types of risotto and casseroles.
For this type of cooking, use the bowl with the paddle
pin (J).
The paddle (I) starts turning after about 3 minutes to
ensure the food is evenly cooked (it should therefore be
distributed evenly on the bottom of the bowl).
In this programme, the power level is set by default at
andcookingtimeat60minutes.YOUCAN,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
 Whenthelidisopened(A),cookingisNOTinterrupted
and the remaining cooking time is still shown on the
display (Q).
CAKE: this programme is ideal for cooking all types of
cakes, muns and biscuits.
For this type of cooking, use the bowl (Z) without the
paddle pin, intended for static cooking.
You should always grease and our the bowl (Z) before
inserting a cake. When cooking foods that can be turned
during cooking such as brioches or biscuits, use grease-
proof paper.
In this programme, the power level is set by default at
andcookingtimeat40minutes. You can,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
This cooking programme uses much less energy than a
traditionalovenasitdoesnotrequirepre-heating.
When the lid is opened (A), cooking and the time set on
the display (Q) are interrupted and will start again auto-
matically when the lid is closed.
PIZZA: this programme is ideal for making crunchy pizzas

7
in the best Italian tradition.
For this type of cooking, use the bowl (Z).
When cooking home-made pizzas, you should always oil
the bottom of the bowl (Z), while to cook frozen pizzas,
it is sucient to use greaseproof paper.
In this programme, the power level is set by default at
andcookingtimeat30minutes.YOUCAN,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
When the lid is opened (A), cooking and the time set on
the display (Q) are interrupted and will start again auto-
matically when the lid is closed.
 POTATOES: this programme is particularly suitable for
cooking any type of fresh or frozen potatoes, chips or
croquettes.
For this type of cooking, use the bowl (J) with the paddle
pin (J).
There is a delay of a few minutes before the paddle (I)
starts turning to avoid breaking the potatoes while still
frozen.
In this programme, the power level is set by default at
and cooking time at 32 minutes. YOUCAN,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
When the lid is opened (A), cooking and the time set on
the display (Q) are interrupted and will start again auto-
matically when the lid is closed.
GRILL: this programme is ideal for making all types of
grilled food.
For this type of cooking, always use the grill (Y) inserted
on the bottom of the bowl (Z).
In this programme, the power level is set by default at
andcookingtimeat50minutes.YOUCAN,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
When the lid is opened (A), cooking and the time set on
the display (Q) are interrupted and will start again auto-
matically when the lid is closed.
Semiautomatic programmes: when one of the following
programmes is selected, the default cooking times and basic
power levels are displayed. These can then be modied accord-
ingtotherecipeandyourpersonalrequirements.
 OVEN: this programme is ideal for cooking excellent
crunchyfriedfoodssuchasscampi,cutlets,croquettes,
etc. coated in breadcrumbs before cooking.
It can also be used for roast meats, baked sh, bread
and roast vegetables, with or without the paddle (I).
Consequently,forthistypeofcookingbothbowlscanbe
utilised.
This cooking programme saves considerable energy as it
doesnotrequirepre-heating.
In this programme, the power level is set by default at
andcookingtimeat60minutes.YOUCAN,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
When the lid is opened (A), cooking and the time set on
the display (Q) are interrupted and will start again auto-
matically when the lid is closed.
AIRGRILL: this programme is recommended for cooking
grilled meat, sh and vegetables. It is also excellent to
complete cooking for foods that must be baked then
browned.
For this type of cooking, it is recommended to utilise the
bowl (Z).
In this programme, the power level is set by default at
andcookingtimeat40minutes.YOUCAN,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
When the lid is opened (A), cooking and the time set on
the display (Q) are interrupted and will start again auto-
matically when the lid is closed.
PAN: This programme cooks in much the same way
as a saucepan, with the advantage of the paddle that
automatically mixes the food. It is excellent for soups,
jams, braised foods, sauces, fruit drinks, boiled foods and
lightly frying the ingredients for making meat and sh
balls.
For this type of cooking, use the bowl with the paddle
pin.(J).
In this programme, the power level is set by default at
andcookingtimeat40minutes.YOUCAN,
however, modify the degree of cooking by using the
powerlevelbutton(O)andthecookingtimebypressing
the timer buttons + (P) and - (R) depending on your rec-
ipe.
 Whenthelidisopened(A),cookingisNOTinterrupted
and the remaining cooking time is still shown on the

8
display (Q).
USE
Please note: Before using the appliance for the rst
time, thoroughly wash the bowl (J) and (Z), paddle (I), grill (Y)
and removable viewing window (D) in hot water and neutral
washingupliquid.
Proceed as follows:
• Openthelid(A)bypressingthebutton(W)(g.1).
• Release the removable viewing window (D) by pressing
the two buttons (C) (g. 2).
• Liftthebowlhandgrip(L)untilyouheara“click”(g.3).
• Extractthebowl(J)bypullingupwards(g.4).
• Extractthepaddle(I)fromitshousing(g.4).
• Washthebowl(J)and(Z),paddle(I),grill(Y)andremov-
able viewing window (D) (g. 6).
• Attheendoftheoperation,dryallcomponentsthoroughly
and remove any water left in the bottom of the bowl (J)
and (Z).
• Putthebowl(J)or(Z)(basedonthedesirablerecipe)back
in the appliance (U), making sure it is correctly positioned.
• Lowerthebowlhandgrip(L)usingtheslide(K)(g.7).
• Ifrequiredbytherecipe,insertthepaddle(I),makingsure
it is correctly positioned on the pin at the bottom of the
bowl (J) (g. 4).
Cooking with the programme GRILL, always utilise the grill
(Y) positioned on the bottom of the bowl (Z) (g. 5).
• Placetheingredientstobecookedinthebowl(J)or(Z),re-
spectingthequantitiesgiveninthecookingtables/recipes.
• Ifrequiredbythecookingprocedure,addoil,referringto
thequantitiesindicatedinthecookingtables/recipesand
usingthemeasure(M).
• Closethelid(A).
• Plugtheapplianceintothemainssocket.
• TurntheapplianceonbypressingthemainON/OFFbutton
(H).
• Turn the cooking programme selector dial (S) to the re-
quiredposition(g.8)(seecookingtables/recipes).
• Adjusttherequireddegreeofcookingbypressingthepow-
erlevelbutton(O)(g.9)(seecookingtables/recipes).
• Adjust the required cooking time by pressing the timer
buttons+(P)and-(R)(g.10).Theminutessetappearon
the display (Q).
• Press the programme start/stop button (T). The light
comes on (g. 11).
• Cookingbegins.
• Attheendofthecookingtime,theapplianceemitstwo
series of beeps. To turn the beeps o, press and hold the
programmestart/stopbutton(T).
• TurntheapplianceobypressingtheON/OFFbutton(H).
• Openthelid(A)andremovethebowl(J)or(Z)containing
the cooked food.
• Leavethe lid(A)opento coolthe appliance downmore
rapidly.
Please note: In some programmes, to guarantee best
results, the paddle (I) begins to turn a few minutes after cooking
begins.
Please note: During cooking, you can lift up the lid (A)
to add ingredients or check cooking progress.The display ashes
and ventilation stops briey, then starts again when you close
the lid. In functions without ventilation, cooking is not inter-
rupted.
Please note: If the programme start/stop button (T)
has been pressed, extracting the bowl turns the appliance o. It
starts functioning again when the bowl is reinserted.
Please note: During cooking, pressing the program
start/stopbutton(T)putstheapplianceinpause.Holdingthe
button down for at least 2 seconds interrupts cooking and the
function returns to the default parameters.
CLEANING AND MAINTENANCE
Danger!Beforecleaningtheappliance,alwaysunplug
from the mains socket and allow to cool. Never immerse the
appliance in water and never place under running tap water. If
water gets into the appliance, it could cause electric shock.
• Beforeusingtheappliance fortherst time,thoroughly
wash the bowl (J) and (Z), paddle (I), grill (Y) and remova-
ble viewing window (D) in hot water and neutral washing
upliquid.Thebowlisdishwashersafe.Frequentwashing
could reduce the properties of the ceramic coating.
• Cleanthehotairdischargegrille(B)withoutremovingit.
• Checkandemptythecondensatetray(G)regularly,par-
ticularly if there is abundant steam.
Please note: Never use abrasive objects or detergents to
clean the bowl (J) and (Z). Clean with a soft cloth and neutral
detergent only.

9
TROUBLESHOOTING
Fault Cause/solution
The appliance does not heat up The thermal cutout may have tripped. Contact Customer
Experience, see enclosed guarantee or visit the Delonghi
website
The bowl is not positioned correctly and the appliance does not work Position the bowl correctly
The lid is not properly closed and the appliance does not work Close the lid properly
The paddle does not turn Wait for a few minutes after cooking begins
EI is displayed and the appliance emits a series of 3“beeps” Turn the appliance o and allow to cool down, then check
whether the appliance has been operated without food. If
the fault persists, contact Customer Experience
E3 is displayed and the appliance emits a series of 5“beeps” Turn the appliance o and allow to cool down, then check
whether the appliance has been operated without food. If
the fault persists, contact Customer Experience, see enclo-
sed guarantee or visit the Delonghi website
E5 is displayed and the applianceemitsaseriesof7“beeps” Contact Customer Experience, see enclosed guarantee or
visit the Delonghi website
E6 is displayed and the applianceemitsaseriesof7“beeps” Contact Customer Experience, see enclosed guarantee or
visit the Delonghi website
COOKING TABLES
Potatoes
Recipe Type Quantity Oil Cooking time
(min) Paddle Cooking programmes
Power
level
Potatoes
standard10x10
Fresh
1750gr(*) level 5 40-43 YES
1500gr(*) level 4 37-40 YES
1250gr(*) level 3 35-37 YES
1000gr(*) level 2 28-31 YES
750gr(*) level 1 23-26 YES
Frozen
1500gr without 32-34 YES
1250gr without 30-32 YES
1000gr without 28-30 YES
750gr without 26-28 YES
500gr without 24-26 YES
Roast potatoes Fresh 1700gr level 3 40-43 YES
Potato wedges Frozen 1000gr without 30-32 YES
New potatoes Frozen 1200gr without 35-40 YES
Bakedcroquettes Frozen 750gr without 20-25 YES
(*)un-peeledpotatoweight

10
First courses
Recipe Type Quantity Oil Cooking time
(min) Paddle Cooking programmes Power level
Risotto Fresh 480gr level 5 15-18 YES
Meatsauce Fresh 1000gr level 5 60-65 YES
Paella Frozen 600gr without 13-15 YES
Cannelloni Fresh 1500gr without 40-45 NO
Meat - poultry
Recipe Type Quantity Oil
Cooking time
(min)
Paddle
Cooking
programmes
Power level Tips
Chicken nuggets Frozen 750gr without 15-18 YES -
Roast chicken
drumsticks Fresh 1000gr without 45-50 NO turn 2-3 times
Casseroled chicken
drumsticks Fresh 1000gr without 70-80 NO turn 2-3 times
Veal stew Fresh 600gr level 2 30-35 YES -
Veal cutlets Fresh 3pz without 20-25 NO turn after 15
min
Roast Fresh 1000gr without 80-90 NO turn 2-3 times
Meatskewers Fresh 800gr without 20-25 NO turn 2-3 times
Hamburger Fresh 4pz without 15-20 NO turn after 15
min
Meatballs Fresh 450gr without 25-28 YES -
Lamb chops Fresh 600gr without 12-15 NO
utilise the grill
and turn after
10minutes
Chicken nuggets Fresh 500gr without 20-25 NO
utilise the grill
and turn after
13-15 minutes

11
Fish - Shellsh
Recipe Type Quantity Oil Cooking time
(min)
Paddle
Cooking
programmes
Power
level Tips
Fish ngers Frozen 18pz without 20-23 NO -
Sliceof
salmon Fresh 400gr without 20-25 NO -
Fillet of
salmon Fresh 350gr without 20-25 NO -
Scallops Fresh 4 pz without 15-17 NO -
Cuttlesh Fresh 8 pz level 1 15-20 NO -
Tiger prawns Fresh 600gr level 1 13-18 YES -
Prawns Fresh 800gr level 1 15-20 YES -
Gilthead sea
bream Fresh 2pz without 20-25 NO
utilise the grill
and turn after
13-15 minutes
Fish skewer Fresh 300gr without 12-15 NO
utilise the grill
andturnafter10
minutes
Vegetables
Recipe Type Quantity Oil Cooking time
(min)
Paddle Cooking
programme Power level
Courgettes Fresh 800gr level 5 25-30 YES
Aubergines Fresh 1000gr level 3 25-30 YES
Mushrooms Fresh 1000gr level 5 20-25 YES
Artichokes Frozen 800gr level 3 35-40 YES

12
Snacks
Recipe Type Quantity Oil
Cooking time
(min)
Paddle
Cooking
programme
Power level
Tips
Pizza
Fresh 300gr level 1 30 NO oil the pan and turn
180°after20min
Frozen 450gr without 20-25 NO turn180°after15min
Savourypies
andquiches
Fresh 600gr without 20-23 NO
use greaseproof paper
andturn180°after
15 min
Frozen 700gr without 45-50 NO
use greaseproof paper
andturn180°after
30min
Mini-pizzas Frozen 14 pz without 20-25 NO use greaseproof paper
Mini-savouries Frozen 14 pz without 20-25 NO use greaseproof paper
Onionrings Frozen 12/15pz without 10-15 NO spread evenly on the
bottom of the bowl
Desserts, cakes and pastries
Recipe Type Quantity Oil
Cooking time
(min)
Paddle
Cooking
programme
Power level
Tips
Tart Fresh 700gr without 45-50 NO -
Brioches Frozen 4 pz without 25-30 NO
use greaseproof paper
andturn180°after
12-13 min
Biscuits Fresh 8 pz without 12-15 NO
use greaseproof paper
andturn180°after
15 min
Strudel Fresh 400gr without 20-25 NO -
