DeLonghi EO14902.S User manual

ELECTRIC OVEN

14
DESCRIPTION OF APPLIANCE
A Top heating element
B Inside light (certain models only)
C Wire rack – (*) Certain models only
D Bake pan (certain models only)
E Thermostat dial
F Timer dial
G Function selector dial
H Thermostat light
I Bottom heating element
L Glass door
M Crumb tray
N Pizza plate (certain models only)
TECHNICAL DATA
Voltage: 220-240 V ~ 50/60Hz
Absorbed power: 1400W
Size LxHxD: 490 x 235 x 370 mm
Weight: 8.3 kg
FUNCTIONS
GRILL FUNCTION ideal for grilling food
TRADITIONAL OVEN FUNCTION ideal for all types of
traditional cooking
DEFROSTING FUNCTION ideal for defrosting all prod-
ucts (certain models only)
CONVECTION ideal for quicker more even cooking
(certain models only)
KEEPING FOOD WARM
Please note: For more information regarding the
various functions and cooking tables, refer to the images on
page 4-13.
THERMOSTAT LIGHT
The thermostat light (H) lights when the oven is on and turns
o when the oven reaches the set temperature.
IMPORTANT SAFEGUARDS
Read all the instructions carefully before using the
appliance. Keep these instructions.
Please note:
This symbol identies important advice or information for
the user.
• Before using the oven for the rst time, remove any
paper and other material inside the oven such as pro-
tective cardboard, booklets, plastic bags, etc.
• Theappliancemustbekeptatadistanceofatleast20
cm from the mains power socket to which it is connect-
ed.
• Beforeusingforthersttime,operatetheovenemp-
ty with the thermostat at maximum for at least 20
minutes to eliminate the “new” smell and any smoke
caused by the presence of protective substances applied
to the heating elements before transport. Ventilate the
room.
• Washallaccessoriesbeforeuse.
• Neverusecorrosiveoracidoraggressivedetergentto
clean the oven cavity or the accessories.
• Tosettimeslessthan20minutes,rstturnthetimer
dial all the way to the end and then position it on the
desired time.
Important!
Failure to observe the warning could result in injury or dam-
age to the appliance.
• This oven is designed to cook food. It must never be
used for other purposes, modied or tampered with in
any way.
• Afterunpacking the appliance,makesurethe door is
undamaged and working correctly.
The door is made from glass and is therefore fragile. If
it is visibly chipped, scored or scratched, it should be re-
placed. While using, cleaning or moving the appliance,
avoid slamming or knocking the door violently. Do not
pour cold liquid onto the glass while the appliance is
hot.
• Placetheapplianceonahorizontalsurfaceataheight
of at least 85 cm and out of reach of children.
• This appliance can be used by children
aged from 8 years and above and per-
sons with reduced physical, sensory
or mental capabilities or lack of ex-
perience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children should be super-
vised to ensure that they do not play

15
with the appliance.
Cleaning and user maintenance shall
not be made by children, unless they
are more than eight years old and un-
der constant supervision.
• Keep the appliance and power cable
away from children under eight years
of age.
• Donotmovetheappliancewhileinuse.
• Donotusetheapplianceif:
- The power cable is faulty
- The appliance has been dropped, is visibly damaged or
malfunctioning.
In these cases, to avoid all risk take the appliance to
your nearest authorised customer services.
• Neverpositiontheappliancenearheatsources.
• Donotusetheapplianceasaheatsource.
• Neverplacepaper,cardboardorplasticinsidetheoven
and never rest anything on top of the appliance (uten-
sils, wire racks, other objects).
• Never insert anything into the ventilation openings.
Make sure they are unobstructed.
• Thisovenisnotdesignedforbuilt-ininstallation.
• Donotrestheavyobjects,boilingpansorcontainerson
the open door.
Do not pull the handle downwards.
• Professional or inappropriate use, or
failure to observe the instruction for
use absolves the manufacturer from
all responsibility and invalidates the
guarantee.
• This is a household appliance only.
It is not intended to be used in: sta
kitchen areas in shops, oces and oth-
er working environments, farm hous-
es, hotels, motels and other residential
type environments, bed and breakfast
type environments.
• Whennotin use and beforecleaning,alwaysunplug
the appliance.
• This appliance must not be operated
by a timer or a separate remote control
system.
• Theappliance must be placedandoperatedwith the
back next to the wall.
• Beforecleaning,alwaysturntheapplianceobyset-
ting the timer to “0” and unplugging it from the mains
socket.
Danger of burns!
Failure to observe the warning could re-
sult in scalds or burns.
• When in operation, the door and ac-
cessible external surfaces could be-
come very hot. Always use the knobs,
handles and buttons. Never touch
metal parts or the glass. Use oven
gloves if necessary.
•This electrical appliance operates at
high temperatures which could cause
burns.
• Do not leave inammable products near the oven or
under the work surface where it is located.
• Neveroperatetheapplianceunderawallcupboardor
shelfor near inammable materialssuch as curtains,
blinds, etc.
• If food or other parts of the oven catch re, never
try and put out the ames with water.
Close the door, unplug from the mains and
smother the ames with a damp cloth.
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
• Before plugging into the mains, make sure that:
- The mains voltage corresponds to the voltage
indicated on the rating plate.
- the mains socket is earthed and has a minimum
rating of 16A.
The manufacturer declines all liability in the
event that this important accident-prevention
rule is not respected.
• Donotletthepowercabledangleandavoidtouching
hot parts of the oven.
Never unplug the appliance by pulling on the power
cable.

16
• Ifyouintendtouseanextension,makesureitisingood
condition, that the plug is earthed and that the cross
section of the wires is at least equal to that of the power
cable provided with the appliance.
• To avoid all risk of electric shock, never immerse the
power cable, plug or appliance itself in water.
• If the power cable is damaged, it must
be replaced by the manufacturer, the
manufacturer’s customer services or a
qualied electrician in order to elimi-
nate all risk.
• For your personal safety, never take the appliance to
pieces on your own. Always contact customer services.
The appliance complies with the following EU di-
rectives:
• Low Voltage Directive 2006/95/EC and subsequent
amendments;
• EMC Directive 2004/108/EC and subsequent amend-
ments;
• Materialsandaccessoriescomingintocontactwithfood
conform to European regulation (EC) no. 1935/2004.
DISPOSAL
In compliance with European directive 2002/96/EC, the
appliance must not be disposed of with household waste,
but taken to an authorised waste separation and recycling
centre.
ELECTRICAL CONNECTION (UK ONLY)
A) If your appliance comes tted with a plug, it will in-
corporate a 13 Amp fuse. If it does not t your socket,
the plug should be cut o from the mains lead, and an
appropriate plug tted, as below.
WARNING: Very carefully dispose of the cut o plug af-
ter removing the fuse: do not insert in a 13 Amp socket
elsewhere in the house as this could cause a shock ha-
zard.
With alternative plugs not incorporating a fuse, the
circuit must be protected by a 15 Amp fuse. If the plug
is a moulded-on type, the fuse cover must be re-tted
when changing the fuse using a 13 Amp Asta approved
fuse to BS 1362. In the event of losing the fuse cover, the
plug must NOT be used until a replacement fuse cover
can be obtained from your nearest electrical dealer. The
colour of the correct replacement fuse cover is that as
marked on the base of the plug.
B) If your appliance is not tted with a plug, please follow
the instructions provided below:
WARNING - THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with
the following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead may not corre-
spond with the coloured markings identifying the terminals
in your plug, proceed as follows:
The green and yellow wire must be connected to the termi-
nal in the plug marked with the letter E or the earth symbol
or coloured green or green and yellow.
The blue wire must be connected to the terminal marked
with the letter N or coloured black.
The brown wire must be connected to the terminal marked
with the letter L or coloured red.

5711811541/06.15
