DELTA DORE TYWATT 1000 User manual

User Guide
Energy consumption meter
TYWATT 1000

- 2 - - 3 -
• DHW override possible.
• Access to consumption data ( ),
• Changeover to standby after a 30 seconds time-out period
TYWATT
1
Ti1Ti2 Ti3
3 5 7 9
T
C
BUS A
246810
11
4VA
230V~50Hz
N
16
C
17
T
3A - 230V
~
12
L
Ref. : 4100794
BUS
T
C
1- AUTO mode
1- AUTO mode................................................................................ 3
2- Technical unit indicator lights...................................................... 3
3- Home automation functions........................................................ 4
4- Date and time settings................................................................ 5
5- Consumption data display .......................................................... 7
6- ‘i’ information button .................................................................. 8
7- DHW override............................................................................. 9
8- Help.......................................................................................... 10
Contents
2- Technical unit indicator lights
Bus indicator light
Blinks in sync with the data
Steady blinking = Bus fault
Off = Power supply failure
Electronic meter indicator light
On = Normal operation
Blinking = remote-info fault
DHW load control indicator light
On = Load control in progress
DHW (Domestic Hot Water) indicator
light
On = ON
Off = OFF
Consumption
data display
Hot water tank
override
Information
button
Temperature
measured
Standby mode
Press a button
Auto Mode
Time

- 4 - - 5 -
4- Date and time settings3- Home automation functions
EXIT
JJ/MM/AA HH/MM
3
2
1
5
5
4
>3s
The home automation functions control the following functions either locally
or remotely via a tablet or a smartphone:
- display of the consumption data over the current month and the history of
previous months (electricity, gas, etc.).
To get this service, you have to associate the room unit with the TYDOM
home automation gateway.
ADSL BOX
Wi (local)
or
Internet (remote)
Smartphone
Tablet
OR
TYDOM 2000
Wireless
Ethernet cable
TYDOM 1000
1
Volets
Alarme
Autres
Eclairages
Garage
Scénarios
Chauffage
Portail
Pièces
TYDOM 2000
1
Volets Alarme
Autres
Eclairages Garage
Scénarios
Chauffage Portail
Pièces
Example with the TYDOM 2000 home automation gateway
Hold the 'i' button
down for 3 seconds
Enter the date, then the time.
Confirm with OK.
Confirm with
OK.
Turn the selector
knob
to exit the mode

- 6 - - 7 -
From the AUTO mode.
: Total gas consumption
: Total electric consumption
: Cooling consumption
: Heating consumption
: Domestic Hot Water consumption (DHW)
: Consumption of devices connected to the mains
- To change over to a different consumption, turn the selector knob.
- Depending on the system's configuration, some symbols will not be avail-
able.
- To exit the "Consumption data display" mode, press .
Example: To view the total electric consumption of your system
turn the selector knob to select the symbol.
Gas
Cooling
DHW
Others
Heating
Plugs
Elec.
Displays the con-
sumption for the
current month
History: Press '+' to display the overall consump-
tion history from the beginning of the current year,
then for the previous year
History:
Press '-' to display the
consumption history for the12 previous months
Press
.
• If you own a "hybrid" boiler, the heating and DHW consumption data will
be displayed for each type of energy used (gas and electricity).
• The consumption indices and the history can be reset (menu 2-24,
installation instructions).
5- Consumption data display
Gas
Cooling
DHW
Others
Heating
Plugs
Elec.

- 8 - - 9 -
6- 'i' information button
The AUTO mode displays the system status ('i' button) and any faults (refer
to the "Help" section).
Press 'i'. Display of the
measured
temperature.
Press 'i'.
The 'Heat/Cool' option will only be
available if the presence of a cooling
system has been declared (installer
menu, 0-06).
Press '+' or '-'. Confirm with OK.
The symbol blinks.
The DHW is restarted
for 6 hours.
Restart may be suspended when
changing to Off-Peak times or by
pressing again.
From the AUTO mode.
Press .
7- DHW override

- 10 - - 11 -
8- Help
Nothing is displayed on the room unit screen.
There is no power supply.
Check the circuit breaker.
The symbol does not appear.
The DHW is not managed by the device.
Refer to menu 1-04.
Replacing a consumption emitting product (e.g. Tywatt 5100, etc.):
You must initialise the indices (menu 2-24).
The symbol blinks.
A fault is detected on the installation.
Press 'i' to display the type of "Fault".
dEF 6: There is a communication fault between TYWATT and the technical
unit (Bus A). Check the system.
dEF 7: There is a communication fault with the electronic meter.
Check the connection with the electronic meter.
No consumption index is displayed or "- - -" is displayed.
The indices were reset less than one hour ago. Wait.
