PRELIMINARY DATABRIEF
DB_DNT12_06252007
Delphi series DNT12 Non-Isolated Point of Load
DC/DC Power Modules: 8.3~14Vin, 0.75~5.5Vo, 3A/5A
The Delphi series DNT12, 8.3V~14V input, single output, non-isolated point of
load DC/DC converters are the latest offering from a world leader in power
systems technology and manufacturing －Delta Electronics, Inc. The DNT12
series provides a programmable output voltage from 0.75V to 5.5V using an
external resistor. This product family is available in a surface mount or SIP
package and provides up to 3A or 5A of current in an industry standard
footprint. With creative design technology and optimization of component
placement, these converters possess outstanding electrical and thermal
performance and extremely high reliability under highly stressful operating
conditions.
APPLICATIONS
 Telecom/DataCom
 Distributed power architectures
 Servers and workstations
 LAN/WAN applications
 Data processing applications
OPTIONS
 Positve On/Off logic
 Surface mount and SIP packages
FEATURES
 High Efficiency: 92.5% @ 12Vin, 5V/3A out
 Small size and low profile:
0.80” x 0.45” x 0.27” (SMD)
0.90” x 0.40” x 0.25” (SIP)
 Standard footprint and pinout
 Resistor-based trim
 Output voltage programmable from
0.75Vdc to 5.5Vdc via external resistors
 Pre-bias startup
 No minimum load required
 Fixed frequency operation
 Input UVLO, Output OTP, OCP
 Remote ON/OFF
 ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing facility
 UL/cUL 60950 (US & Canada) Recognized,
and TUV (EN60950) - pending
 CE mark meets 73/23/EEC and 93/68/EEC -
pending

2
SPECIFICATIONS
GENERAL SPECIFICATIONS OUTPUT SPECIFICATIONS
Input Voltage Typical 8.3V~12V Voltage Adjustment Typical 0.75V ~ 5.5V
Switching Frequency Typical 300KHz /480kHZ for 3A/ 5A Line Regulation Typical 0.3%
Turn-on time Typical 7 mS /15mS for 3A/ 5A Load Regulation Typical 0.4%
Ripple & Noise Typical 50 mVp-p
Size Typical 0.80” x 0.45” x 0.27”(SMD)
0.90” x 0.40” x 0.25” (SIP) Current Limits Typical 200%
PART NUMBERING SYSTEM
DNT 12 S 0A0 S 03 N F A
Product
Family Input Voltage Number of Outputs Output Voltage Package Type Output Current On/Off Logic Option Code
DNT - 3A
04 - 2.4V ~ 5.5V 12 - 8.3V ~ 14V S - Single 0A0 -
Programmable R - SIP
S - SMD 03 - 3A 05 - 5A
N - Negative
P - Positive F- RoHS 6/6
(Lead Free)
A - Standard Function
MODEL LIST
Model Name Package Input Voltage Output Voltage Output Current Efficiency
12Vin, 5Vout full load
DNT12S0A0S03NFA SMD 8.3V ~ 14Vdc 0.75V ~ 5.5Vdc 3A 93.0%
DNT12S0A0R03NFA SIP 8.3V ~ 14Vdc 0.75V ~ 5.5Vdc 3A 92.5%
DNT12S0A0S05NFA SMD 8.3V ~ 14Vdc 0.75V ~ 5.5Vdc 5A 92.0%
DNT12S0A0R05NFA SIP 8.3V ~ 14Vdc 0.75V ~ 5.5Vdc 5A 91.0%
MECHANICAL DRAWING
SMD PACKAGE SIP PACKAGE
CONTACT: www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: [phone]
West Coast: [phone]
Fax: [phone]
Email: [email protected]
Europe:
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Asia & the rest of world:
Telephone: [phone] x6220
Fax: [phone]
Email: [email protected]
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor for any
infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any
patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
