Delta Electronics Delphi Q48DB User manual

Delta Electronics, Inc.
DATABRIEF
DB_Q48DB_04262006
1
APPLICATIONS
 Telecom/DataCom
 Wireless networks
 Optical network equipment
 Server and data storage
 Industrial/Test Equipment
OPTIONS
 Positive On/Off logic
 Short pin lengths available
FEATURES
 High efficiency: 90%@ ±12V/2.7A
 Size: 57.9mm x 36.8mm x 8.5mm
(2.28”×1.45”×0.33”)
 Industry standard pin out
 Fixed frequency operation
 Input UVLO, Output OCP, OVP, OTP
 Basic insulation
 No minimum load required
 Adjustable output voltage
 ISO 9001, TL 9000, ISO 14001, QS 9000,
OHSAS 18001 certified manufacturing
facility
 UL/cUL 60950 (US & Canada)
Recognized, and TUV (EN60950) Certified
 CE mark meets 73/23/EEC and
93/68/EEC directives
Delphi Series Q48DB, 65W Quarter Brick Dual Output
DC/DC Power Modules: 48V in, ±12V Output
The Delphi Series Q48DB Quarter Brick, 48V input, positive and negative
bipolar dual output, and isolated DC/DC converters are the latest offering
from a world leader in power system and technology and manufacturing ―
Delta Electronics, Inc. This product family provides positive and negative
bipolar output (output voltage is 12V) and up to 65 watts of power in an
industry standard quarter brick package size. Both output channels can be
used independently. With creative design technology and optimization o
f
component placement, these converters possess outstanding electrical
and thermal performance, as well as extremely high reliability under highl
y
stressful operating conditions.
A
ll models are fully protected from
abnormal input/output voltage, current, and temperature conditions. The
Delphi Series converters meet all safety requirements with basic
insulation.

2
SPECIFICATIONS
GENERAL SPECIFICATIONS OUTPUT SPECIFICATIONS
Input Voltage 36~75V Voltage Accuracy Typical ±1.5%
Switching Frequency Typical 300KHz Line Regulation Typical (balance load) ±0.5%
Isolation Voltage In/Out 1500V Load & Cross Regulation Typical (balance load) ±1%
Isolation Capacitance Typical 2000 pF Ripple & Noise Typical 50 mV
Isolation Resistance Minimum 10M Ohms Current Limits Typical 135%
MTBF Bellcore 1.17M hours
Over Voltage Typical 130%
OTP Typical 130°C Voltage Trim +10%, -10%
Size (2.28”×1.45”×0.33”) 57.9x36.8x8.5mm
PART NUMBERING SYSTEM
Q 48 D B 120 03 N R F A
Type of
Product Input Voltage Number of Outputs Product Series Output Voltage Output Current ON/OFF Logic Pin Length Option Code
Q - Quarter
Brick
48V D – Dual
Output
B – Bipolar
output
120 - 12V
03-2.7A N- Negative
P- Positive
R- 0.150”
N- 0.145”
K- 0.110”
F- RoHS 6/6
(Lead Free)
A- Standard
Functions
MODEL LIST
MODEL NAME INPUT OUTPUT Efficiency @ Full Load
Q48DB12003NRFA 36V~75V 2.4A ±12V 2.7A 90%
MECHANICAL DRAWING
CONTACT: www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: [phone]
West Coast: [phone]
Fax: [phone]
Email: [email protected]
Europe:
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Asia & the rest of world:
Telephone: [phone] ext 6220
Fax: [phone]
Email: [email protected]
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon request from
Delta.
