Delta Electronics Pulse Generator Card PG-04 User manual

1
PG-04 Pulse Generator Card for VFD-V Series
Instruction Sheet
1-1 PG-04 Appearance
1-2 Explanations of the terminals of PG-04 Card
Terminals Explanation
VP Output voltage of encoder: +12V±5% 200mA
DCM Common point of the power supply and the signal
A1,
B1,
Z1,
A1
B1
Z1
The input signal of encoder (select output type of the encoder from FJP1)
The power supply can be single-phase and 2-phase and the Max. is
500KP/Sec.
A2,
B2,
A2
B2
The input signal of encoder (select output type of the encoder from FJP4)
The power supply can be single-phase and 2-phase and the Max. is
500KP/Sec.
A/O, B/O,
Z/O
The output signal of encoder can set the dividing frequency by using
parameter 10-20.
The Max. output of Open Collector is DC24V 100mA.
Grounding
Outputterminal
VP
A1A1 B1 B1 Z1 Z1
A
2
A
2B2
B2
VP
Input terminal
CH1
Pulse input terminal
CH2
Power

2
1-3 Wiring Notes
1. Using the shielded wire to prevent interference, and do not line up in parallel with
circuits of AC200V or above.
2. Recommended wire size: 0.21~0.81mm2 (AWG24~AWG18).
3. Wire length
The Output Types of the Encoder Max. Wire Length Wire Gauge
Voltage 50m
Open Collector 50m
1.25mm2(AWG18) or above
Line Driver 300m
Complementary 70m
1.25mm2(AWG18) or above

3
1-4 Wiring Examples
Wiring Diagram 1
MPG
FWD
REV
Mi1
Mi2
Mi3
Mi4
Mi6
Mi5
DCM
24V
FWD/STOP
REV/STOP
Multi-step2
Multi-step3
Multi-step4
Digital common
R/L1
S/L2
T/L3
Non-Fuse breaker
NFB
R
S
T
+1 +2/B1 B2
U/T1
V/T2
W/T3
M
3~
Braking Resistor(Option)
Motor
Multi-function input terminals
Factory Default
Jumper
Reset
E.F.
-
U
W
V
VP
DCM
A1
A1
B1
B1
Z1
Z1
PG
VP
DCM
A2
A2
B2
B2
VP
DCM
A/O
B/O
Z/O
Multi-step1
Line driver encoder
Line driver
Line driver
Main circuit (power) terminals Control circuit terminals Shielded leads & Cable
10-08
10-12

4
Wiring Diagram 2
FWD
REV
Mi1
Mi2
Mi3
Mi4
Mi6
Mi5
DCM
24V
FWD/STOP
REV/STOP
Multi-step2
Multi-step3
Multi-step4
Digital common
R/L1
S/L2
T/L3
Non-Fuse breaker
NFB
R
S
T
+1 +2/B1 B2
U/T1
V/T2
W/T3
M
3~
Braking Resistor(Option)
Motor
Multi-function input terminals
Factory Default
Jumper
Reset
E.F.
-
U
W
V
VP
DCM
A1
A1
B1
B1
Z1
Z1
PG
DCM
A2
A2
B2
B2
VP
DCM
A/O
B/O
Z/O
Multi-step1
Line driver encoder
Line driver
Main circuit (power) terminals Control circuit terminals Shielded leads & Cable
EH-PLC
Y0
Y0
Y1
Y1
Y0
Y0
Y1
Y1
Phase difference 90
o
COM
Recommended Wiring for Resistors
VP
DCM
A/O
B/O
Z/O
330 330 330
Pull High Resistor

5
1-5 Installation
For 1-5HP For 7.5 HP and above
Step 1: Insert 3 PCB supports into control board.
Step 2: Press the PG card on the control board to be fixed to tighten the 3 screws with a
torque of 4-6kgf-cm. If the PG card is not fixed on the control board, it may cause
screw idle running and cannot turn the screw into supports.

6
1-6 The corresponding output types of encoder
Output Types of the Encoder FJP1 FJP4
Voltage
O/P
0V
VCC
oc
TP
oc
TP
Open collector
O/P
0V
VCC
oc
TP
oc
TP
Line driver
Q
Q
oc
TP
oc
TP
Complementary
O/P
0V
VCC
oc
TP
oc
TP
2007-07-16
5011614303-G4E3
