Delta-Opti RG-AP840-L User manual

Manufactured in China for:
DELTA-OPTI Monika Matysiak,
60-713 Poznan, 10 Graniczna St., Poland
www.shopdelta.eu
RG-AP840-L Wireless Access Point
Quick Installation Guide

Drill four holes on the wall, insert the anchors into the holes with the arrow on
the mounting bracket facing up, and attach the mounting bracket to the wall
using screws.
Method 1: Wall Mounting


Install the Ethernet cable first before you mount the AP onto the brackets.
Align the square feet on the rear of the AP over the mounting holes on the
bracket.

Keep the logo of Ruijie upward.
Slide the AP onto the bracket until it clicks into place.
Method 2: Ceiling Mounting
DC power supply or PoE power supply


Drill four holes on the ceiling, tap the wall anchors into the holes, and attach the
mounting bracket to the wall using the screws.

Install the Ethernet cable first before you mount the AP onto the brackets.
Align the square feet on the rear of the AP over the mounting holes on the
bracket.
DC power supply or PoE power supply


For ease of cable routing, you can adjust the direction of the AP accordingly.
Slide the AP onto the bracket in the reverse direction against the arrow on the
mounting bracket until it clicks into place.

Loosen the screw on the mounting bracket and enable the hidden lock.
(Optional) Enable Hidden Lock
loosen the screw


Install the Ethernet cable first before you mount the AP onto the brackets.
Align the square feet on the rear of the AP over the mounting holes on the
bracket.
If the hidden lock is enabled, attach the front part of the key to the edge of the
mounting bracket (keep the Ruijie logo of the key toward the top panel of the
AP).
Slide the key along with the four edges of the mounting bracket, and attempt
to insert the key to the keyhole (only one marked keyhole can be inserted).
Unlock the hidden lock. lf you hear a click sound after the key is inserted into the
keyhole and the key cannot be pulled out, the unlocking is successful.
Removing the Wall-Mount AP:
Removing the AP
Keyhole Mark

Hold the AP in your hands and push it upward in the LAN port direction.
Removing the Ceiling-Mount AP:
Hold up the two sides of the AP with hands, and attempt to push it in four
directions (the AP can be pushed out only in one direction).
Installing Optical Module


Insert the SFP

Installing Optical Module.
Thank you for choosing Ruijie Networks products. You can obtain the latest
quick installation guide at
https://www.ruijienetworks.com/resources/products/.
