Delta ATLO-RM-822 User manual

Large Capacity Access Control
Proximity Card Reader

1. Introduction
This series of product is a new generation of multifunctional standalone access control. It adopts new ARM core
32- it microprocessor design, which is powerful, sta le and relia le. It includes reader mode and standalone
access control mode etc.. It’s widely applied to different occasions, such as offices,residential communities,
villa, ank and prison etc..
2. Features
Read 125KHz EM Card
Operate y infrared remote control
Contains reader mode, the transmission format could e adjusted y users.
Support admin add card, admin delete card and setting card
10,000 card users
The unlocking signal adopts NO,NC,COM output of relay
3. Technical Specifications
Operating Voltage: DC 12-24V
Stand y Current: ≤35mA
Operation Current: ≤100mA
Operating Temperature: -20℃~60℃
Operating Humidity: 0%~95%
Maximum Rated Current：≤1A
Door Relay Time:0～99s（adjusta le）
Dimension: 120*56*20mm
4. Installation
Remove the ack cover from the keypad using the supplied special screw driver
Drill 2 holes on the wall for the self tapping screws and dig a hole for the ca le
Put the supplied ru er ungs into the two holes
Fix the ack cover firmly on the wall with 2 self tapping screws
Thread the ca le through the ca le hole
Attach the keypad to the ack cover. (See the figure elow)

.Wiring
No. Color Marks Description
1 Green D0 Wiegand input ( Wiegand output as reader mode)
2 White D1 Wiegand input ( Wiegand output as reader mode)
3 Yellow OPEN Exit utton input end
4 Red +12V Positive power supply
5 Black GND Negative power supply
6 Blue NO Relay NO end
7 Purple COM Relay COM end
8 Orange NC Relay NC end
6. Diagram
6.1 Common Power Supply

6.2 Special Power Supply
6.3 Reader Mode
7. Sound and Light Indication
Operation Status Light indicator Buzzer
Stand y Red
Operation successful Green Beep-
Operation failed Beep-Beep-Beep
Admin card enter programming Beep-Beep-
Admin card exit programming Beep-
Press * key Beep-
Data ackup Green indicator flash slowly

8. Admin Menu
Admin Card Operation
1Add and Delete Users
Add card user Read admin add card Read user card ...
Read admin add card
Read card continuously to add card user
Delete card user Read admin delete card
Read user card ...Read admin delete card
Read card continuously to delete card user
Delete ALL users Read admin delete card Read admin add card
Read admin add card
Delete ALL users
2Door opening time setting
Door opening time :
1s
Read admin add card Read setting card once
Read admin add card
Door opening time :
5s
Read admin add card Read setting card twice
Read admin add card
Default
Door opening time :
10s
Read admin add card Read setting card thrice
Read admin add card
4Data backup (See figure 10)
Data backup output Read setting card Read admin add card twice
Read setting card
Green indicator light flash slowly
Data backup input Read setting card Read admin delete card twice
Read setting card
Green indicator light flash slowly
Operation by Remote controller
1Add Users Remarks
Change admin code * Admin code # 0 New code # Repeat new code # Default admin code: 999999
Add card user * Admin code # 1 Read card # Read card continuously to add card user
Add card num er user * Admin code # 1
8 digits/ 10 digits card num er #
2Delete Users
Delete card user * Admin code # 2 Read card or
8 digits/ 10 digits card num er #
Read card continuously to delete card user
Delete ALL users * Admin code # 2 0000 # Delete ALL users
3Door opening time setting
Door opening time setting * Admin code # 4 0～99 # Door opening time range: 0-99 s
Default : 5s
4Mode setting
Standalone access control
mode
* Admin code # 50 # After unlocked the door, the door will e locked
automatically
Relay toggle mode * Admin code # 51 # After unlocked the door, users should read the card
again or press exit utton to lock the door.
Reader mode * Admin code # 52 26/34 # WG26/34 input and output
5Data backup (See figure 10)
Data backup output * Admin code # 7 0 # Send the data to external device.
Data backup input * Admin code # 7 1 # The device will receive the data.

9 Admin Card Operation
9.1 Add Card
Read admin add card , Read the 1st user card Read the 2nd user card …,Read admin add card
Note: The admin add card is used to add card users continuously and quickly. When you read the admin add card
at the first time, you will hear short "BEEP-BEEP" and the indicator light turns orange, it means you have entered
into add user programming. When you read the admin add card at the second time, you will hear long "BEEP--"
sound once and the indicator light turns red, it means you have exited the add user programming.
9.2 Delete Card
Read admin delete card , Read the 1st user card Read the 2nd user card … , Read admin delete card
Note: The admin delete card is used to delete card users continuously and quickly. When you read the admin
delete card at the first time, you will hear short "BEEP-BEEP" sound twice and the indicator light turns orange, it
means you have entered into delete user programming. When you read the admin delete card at the second time,
you will hear long "BEEP--" sound once, the indicator light turns red, it means you have exited the delete user
programming.
10 Data Backup Operation
Example: Backup the data of machine A to machine B ( Machine A uses admin card of A, machine B uses admin
card of B)
The green wire and white wire o machine A connects with the green wire and white wire o machine B
correspondingly, set B or receiving mode at irst, then set A or sending mode, the indicator light turns
green lash during the data backup, data backup is success ul when indicator light turns red.
11 Reset to Factory Default/Register admin card
Users can reset to the factory default when the admin code is forgotten, or the default settings has een modified,
operation as elow:
Power off, press and hold the exit utton continuously, power on, release the exit utton immediately when
hearing eep sound twice, the admin code has een reset to 999999, factory default settings are successful.
Power off, press and hold the exit utton continuously, power on, release the exit utton immediately when
hearing eep sound twice, swipe the first card as for admin add card, swipe the second card as for admin delete
card.
Note: Registered user data won’t e deleted when reset to factory default.
