Delta HCH1850 User manual

The power behind competitiveness
www.deltapowersolutions.com
Precision Cooling
Chilled Water Type (HCH1850/ HCH1870)
User Manual
Delta InfraSuite RowCool

II
InfraSuite RowCool Precision Cooling –
Chilled Water
Save This Manual
This manual contains important instructions and warnings that you should follow
during the installation, operation, storage and maintenance of this product. Failure
to heed these instructions and warnings will void the warranty.
Copyright © 2017 by Delta Electronics Inc. All Rights Reserved. All rights of this User Manual
(“Manual”), including but not limited to the contents, information, and figures are solely owned and
reserved by Delta Electronics Inc. (“Delta”). The Manual can only be applied to the operation or the
XVHRIWKLVSURGXFW$Q\GLVSRVLWLRQGXSOLFDWLRQGLVVHPLQDWLRQUHSURGXFWLRQPRGL¿FDWLRQWUDQVODWLRQ
extraction, or usage of this Manual in whole or in part is prohibited without the prior written permission
of Delta. Given that Delta will continuously improve and develop the product, changes may be made
to the information in this Manual at any time without obligation to notify any person of such revision
or changes. Delta will make all possible efforts to secure the accuracy and the integrity of this
Manual. Delta disclaims any kinds or forms of warranty, guarantee, or undertaking, either expressly
or implicitly, including but not limited to the completeness, faultlessness, accuracy, non-infringement,
PHUFKDQWDELOLW\RU¿WQHVVIRUDSDUWLFXODUSXUSRVHRIWKH0DQXDO

Table of Contents
III
Table of Contents
Chapter 1 : Guide for Safe Operation ------------------------------------------------ 1
1.1 Safety Instructions -------------------------------------------------------------------- 1
1.2 Installation Instructions -------------------------------------------------------------- 1
1.3 Instructions for Use ------------------------------------------------------------------- 1
1.4 Glossary of Symbols ----------------------------------------------------------------- 2
Chapter 2 : Introduction ------------------------------------------------------------------ 3
2.1 Product Introduction ------------------------------------------------------------------ 3
2.2 Functions and Features ------------------------------------------------------------- 3
2.3 Packing List----------------------------------------------------------------------------- 5
2.4 Optional Accessories ----------------------------------------------------------------- 6
2.5 Appearance----------------------------------------------------------------------------- 6
 &RPSRQHQWV,GHQWL¿FDWLRQ ---------------------------------------------------------- 7
2.7 Piping System-------------------------------------------------------------------------- 9
2.8 Control Panel------------------------------------------------------------------------- 10
Chapter 3 : Installation -------------------------------------------------------------------11
3.1 Installation Site------------------------------------------------------------------------11
3.2 Space Reservation------------------------------------------------------------------ 12
3.3 Handling ------------------------------------------------------------------------------- 12
3.4 Positioning ---------------------------------------------------------------------------- 13
3.5 Removal of Side Panels ----------------------------------------------------------- 15
3.6 Hole Drilling--------------------------------------------------------------------------- 16
3.7 External Piping----------------------------------------------------------------------- 17
3.8 Power Connection ------------------------------------------------------------------ 18
3.8.1 Power ------------------------------------------------------------------------ 18
3.8.2 Condensed water pipe -------------------------------------------------- 23
3.8.3 Control box ----------------------------------------------------------------- 24
Chapter 4 : Initial Startup----------------------------------------------------------------27
4.1 Pre Start-up Inspection ------------------------------------------------------------ 27
4.2 Power Supply ------------------------------------------------------------------------ 28
4.3 Operating Temperature and Humidity------------------------------------------ 28
4.4 Air Exhaust---------------------------------------------------------------------------- 30

IV
InfraSuite RowCool Precision Cooling –
Chilled Water
4.5 Water Leakage Detector----------------------------------------------------------- 31
4.6 Water Balance ----------------------------------------------------------------------- 31
4.7 PID Setting---------------------------------------------------------------------------- 33
Chapter 5 : Operation---------------------------------------------------------------------35
5.1 LCD Display Hierarchy------------------------------------------------------------- 35
5.2 Control Panel Operation----------------------------------------------------------- 36
5.3 Status Screen and Main Menu--------------------------------------------------- 36
5.4 Account Authority and Login------------------------------------------------------ 37
5.5 Operation Modes -------------------------------------------------------------------- 38
5.6 Shutdown------------------------------------------------------------------------------ 39
5.7 Setting of Cooling Unit ------------------------------------------------------------- 40
5.7.1 Local setting---------------------------------------------------------------- 40
5.7.2 Set point--------------------------------------------------------------------- 42
5.7.3 Controller setting---------------------------------------------------------- 42
5.7.4 Setting of automatic control mode------------------------------------ 43
5.7.5 Alarm setting --------------------------------------------------------------- 44
5.7.6 Inquiry of system status ------------------------------------------------- 46
5.7.7 Inquiry/ elimination of event log --------------------------------------- 46
5.7.8 Inquiry / reset of running hours---------------------------------------- 47
5.7.9 Change of system type-------------------------------------------------- 48
5.7.10 Restoration of defaults-------------------------------------------------- 48
Chapter 6 : Maintenance and Cleaning ---------------------------------------------49
6.1 Firmware Upgrade ------------------------------------------------------------------ 49
6.2 Storage -------------------------------------------------------------------------------- 49
Chapter 7 : Troubleshooting -----------------------------------------------------------50
$SSHQGL[7HFKQLFDO6SHFL¿FDWLRQV----------------------------------------------55
Appendix 2 : Periodic Inspection/ Maintenance List ---------------------------56
Appendix 3 : Glycol Correction Table -----------------------------------------------58
Appendix 4 : Warranty--------------------------------------------------------------------59

1
Chapter 1 Guide for Safe Operation
Chapter 1 : Guide for Safe Operation
1.1 Safety Instructions
y
Please carefully read all chapters of the Manual before any installation, operation, and
maintenance. To avoid personal injury and equipment damage, please be sure to operate
the product in accordance with the instructions in this Manual and the markings on the
cabinet.
yThe unit should only be moved by at least two people so as to guarantee safety.
yIn handling or removal of the equipment, please pay attention to its height and center of
gravity. When using a transportation tool for handling, it must be raised from the bottom to
avoid toppling.
yThe unit contains moving components. Be careful to keep it away from your arms, legs,
hair, clothes or jewelry so as to avoid any danger.
1.2 Installation Instructions
y
The unit can be connected with a single or dual power source. Make sure the input power
LVGLVFRQQHFWHGEHIRUHPDNLQJDFRQQHFWLRQ,IQHFHVVDU\XVHDPXOWLPHWHUWRFRQ¿UP
this.
y'RQRWLQVWDOOWKHHTXLSPHQWRQDÀDPPDEOHRUXQVWDEOHÀRRU
yThis unit is only intended for indoor use. The indoor environment must be separated from
the outside air so as to avoid temperature and humidity interference. Consult the national
or local regulations for separating the installation environment.
yThe diameters and lengths of all electronic connection wires must follow the requirements
of the International IEC or relevant national regulations, whichever is stricter. Meanwhile,
the grounding wires of the unit must be effectively connected with the grounding system.
1.3 Instructions for Use
y
The inner high voltage of the unit may be fatal! The inner components may have hidden
dangers and only qualified service personnel can operate the unit. Improper operation
may lead to serious injury or death or equipment damage. Be sure to follow all the instruc-
tions and warnings contained in the Manual.
yWhen replacing the side panels or front or back doors, make sure there is no foreign mat-
ter in the cabinet.

2
InfraSuite RowCool Precision Cooling –
Chilled Water
1.4 Glossary of Symbols
No. Symbol Meaning
1Indicates supplementary information.
2Indicates important information that must be heeded.

3
Chapter 2 Introduction
Chapter 2 : Introduction
2.1 Product Introduction
The Delta InfraSuite RowCool Precision Cooling Unit (Chilled Water Type) adopts a parallel
FDELQHWGHVLJQDQGFDQEHVHWLQDQDUHDDGMDFHQWWRDKHDWORDG,WVKLJKFRROLQJHI¿FLHQF\
can create an effect of dropping temperature. The modularized design facilitates expansion or
PRYHPHQWDQGFDQEHÀH[LEO\LQWHJUDWHGLQWR\RXUGDWDFHQWHUHQYLURQPHQW:LWKHQODUJHPHQW
RI\RXUGDWDFHQWHUVLQFUHDVHGFRROLQJQHHGVFDQEHPHWE\HDV\UHFRQ¿JXUDWLRQRUDGGLWLRQ
of the equipment.
When installed in a data center, the untreated air will be sucked in from the rear of the cooling
unit and the air, after treatment, will be released from the front of the unit to achieve the aim of
cooling.
<RXFDQPDQDJH\RXUFRROLQJXQLWYLDDXVHUIULHQGO\LQWHUIDFH7KHFRROLQJHI¿FLHQF\FDQEH
actively controlled by its built-in MCU and it will remind you of any abnormality via the alarm
system so as to guarantee normal operation.
2.2 Functions and Features
yIntelligent temperature control
Built-in MCU accurately detects and manages the data center’s temperature,
automatically adjusts the unit’s output, and supports two kinds of automatic control
modes, intelligent control mode (default) & PID control mode.
yUser-friendly control interface
Easy setting and monitoring and access to system status.
yAutomatic spring-resetting of three-way ball valve
,QDEQRUPDOSRZHULQWHUUXSWLRQWKHLQQHUÀRZUDWHDFWXDWRUZLOODXWRPDWLFDOO\FORVHWKH
WKUHHZD\EDOOYDOYHZLWKLQVHFRQGVWRVWRSFKLOOHGZDWHUIURPFRQWLQXRXVO\ÀRZLQJLQWR
the coil and generating condensed water, which may lead to water leakage.
yElastic Piping
6XSSRUWVXSSHURUORZHUSLSLQJWRHQDEOHDÀH[LEOHSLSLQJFRQ¿JXUDWLRQ
yAlarm system
Detection of abnormality and reminding the user via a buzzer or an external dry contract
device.

4
InfraSuite RowCool Precision Cooling –
Chilled Water
yDetection of heat load temperature
Accurate monitor of the heat load temperature by remote temperature sensors.
yLeakage detection
Optional maximum 50m water leakage detector (4m is provided as default), which will
immediately inform the user of any water leakage so as to protect the safety of the
equipment.
yOutput and input dry contacts
7ZRRXWSXWDQGWZRLQSXWGU\FRQWDFWVIRU¿UHDODUPVPRNHDODUPV\VWHPDODUPHWF
yHeat insulation side panels
Isolate the interference of outside temperature.
yHot-swappable & multi-speed fans
7KHXQLWHTXLSVZLWKKLJKHI¿FLHQF\HQHUJ\VDYLQJIDQVZKRVHURWDWLRQVSHHGFRXOGEH
adjustable between 30~100%, and works normally when you change or replace the fans.
yLockable front and rear doors and side panels
Prevent any unauthorized operation.
yCondensed water pump (optional)
The condensed water pump and the water level sensor at the bottom of the cabinet
automatically drain the condensed water and detect the water level of the condensed
water pan respectively to avoid leakage.
yCasters
For convenient movement or relocation.
yCompatible SNMP card (optional)
Monitoring management through SNMP protocol.

5
Chapter 2 Introduction
2.3 Packing List
䳢䵘㨈⻶
╆⊼⽬㩆
x 2
x 3
x 2
x 1
x 1
x 1
x 1
x 2
x 2
x 2
x 1
x 1
1
2
3
4
5
6
7
8
9
10
11
12
No. Description Quantity
1Delta InfraSuite RowCool Precision Cooling Unit 1
2User manual 1
3Key (shared by front & rear doors and side panels) 2
4Cable Tie 3
5Remote temperature sensor (2.9m) 2
64-pin terminal block 2
73-pin terminal block 1
82.8 mm Hex wrench 1
9Cable gland 2
10
Cover plate for communication wiring duct 2
11
Cover plate for power supply 1
12
1RQZRYHQ¿OWHU 1
8VHRQO\IRUGXVWSURRIDWWULDORSHUDWLRQE\HQJLQHHULQJSHUVRQQHO'RQRWFRQWLQXHWRXVHLQQRUPDORSHUDWLRQ

6
InfraSuite RowCool Precision Cooling –
Chilled Water
2.4 Optional Accessories
For purchase of the following optional accessories, please contact service personnel.
ySNMP card: Use the Delta SNMP card to achieve the best compatibility.
yFilters: HCH1850 HCH1870
MERV MERV1 MERV8
Material Aluminum Washable Paper Disposable
2.5 Appearance
(Figure 2-1 : Appearance and dimensions)
2000
mm
╆⊼⽬㩆
䳢䵘㨈⻶
1090
mm
300
mm

7
Chapter 2 Introduction
 &RPSRQHQWV,GHQWL¿FDWLRQ
External
╆⊼⽬㩆
䳢䵘㨈⻶
1
2
3
4
5
6
7
8
11
12
13
14
15
16
(Figure 2-2 : Front view) (Figure 2-3 : Bottom view)
9
10
Rear/ hot aisle
Front/cold aisle
No. Description No. Description
1Wiring access 9Lower inlet hole
2Upper outlet hole
10
Lower outlet hole
3Upper inlet hole
11
Casters
4Input power terminal block
12
Levelers
5Removable rear door
13
Gradienter
6Removable heat-insulating side panel
14
Front door lock
7Side panel lock
15
Front door
8Side panel latch
16
Control panel

8
InfraSuite RowCool Precision Cooling –
Chilled Water
Internal
(Figure 2-4 : Internal components)
No. Description No. Description
1Upper outlet connector 9Lower outlet connector
2Upper inlet connector
10
Lower inlet connector
3Upper inlet shut-off valve
11
Condensed water pan
4Manual exhaust valve of outlet
water pipe
12
Coils
5Filters
13
Flow meter
6Three-way ball valve and actuator
14
Fans
7Bypass valve
15
Power supply unit (each of front side
and rear side has one)
8Lower inlet shut-off valve Level switch
(DFKRIWKH 1 2 9
10
connectors is a 1” PT female connector.
12
11
15
pon q
r
u
s
v
t
13
14
w
16
16

9
Chapter 2 Introduction
2.7 Piping System
(Figure 2-5 : Pipe circuit diagram)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
No. Description No. Description
1Upper inlet connector 9Lower inlet shut-off valve
2Upper outlet connector
10
Lower outlet connector
3Three-way ball valve and actuator
11
Lower inlet connector
4Flow meter
12
Condensed water drain pipe
5Bypass valve
13
Condensed water pump(Optional)
6Upper inlet shut-off valve
14
Condensed water pan
7Inlet water temperature sensor
15
Coils
8Outlet water temperature sensor

10
InfraSuite RowCool Precision Cooling –
Chilled Water
2.8 Control Panel
1
2
3
4
5
6
7
8
(Figure 2-6 : Control panel)
No. Item Description
1E.P.O. Emergency power off button.
2MAIN ON 7KHJUHHQOLJKWLQGLFDWHVSRZHURQ7KHÀDVKLQJLQGLFDWRU
indicates the unit is in installation mode.
3STANDBY The yellow light indicates the unit runs in standby mode. The
ÀDVKLQJLQGLFDWRULQGLFDWHVWKHXQLWUXQVLQIRUFHPRGH
4WARNING The yellow light indicates alarm information.
5FAULT The red light indicates fault information.
6Ÿź Goes back to previous screen or goes to next screen/ Moves up
or down/ Increases or decrease number.
7ESC Goes back to previous screen or cancels current operation.
8(QWHUV\RXUVHOHFWHGLWHPRUFRQ¿UPV\RXUVHOHFWLRQRUVHWWLQJ
NOTE: The emergency power off button (E.P.O.) is OFF by default. If such a
function is needed, please contact service personnel.

11
Chapter 3 Installation
Chapter 3 : Installation
WARNING:
1. Only service personnel can perform the following installation procedures. No installation,
piping or handling should be performed without authorization so as to avoid equipment
damage and personal injury.
2. The high voltage in the equipment is potentially fatal! The inner components have
SRWHQWLDOGDQJHUVDQGRQO\TXDOL¿HGVHUYLFHSHUVRQQHOFDQSHUIRUPZLULQJ
3.1 Installation Site
When planning the installation site for the cooling unit, you must take the following into
FRQVLGHUDWLRQVRDVWRJXDUDQWHHWKHEHVWHI¿FLHQF\
yEnvironmental requirements: The installation site must allow the equipment to move in
DQGRXWWKHÀRRULQJPXVWEHDUWKHZHLJKWRIWKHHTXLSPHQWDQGWKHUHLVDVXI¿FLHQWVSDFH
for maintenance, operation, and pipe repair. The cooling unit can only be located indoors
and the indoor environment must be isolated from the outside air to avoid temperature
and humidity interference. The outside humidity entry must be minimized in accordance
with the local or national regulations so as to avoid the increase of operation costs due to
loss of cooling capacity.
yHumidity and heat source: Implement water-proof and heat insulation engineering for the
indoor environment so as to isolate the outside humid hot air.
NOTE:
The unit cannot humidify or automatically de-humidify. If the humidity of the
installation environment exceeds the operation scope (refer to 4.3 Operating
Temperature and Humidity), the condensation of the water of the coil may lead to a
rise in the water level of the condensed water pan, triggering an alarm.
yNoise impact: At a high load, the operation of this cooling unit may produce loud noise.
7KHUHIRUHLWLVQRWVXLWDEOHWRLQVWDOOWKHXQLWFORVHWRRI¿FHV
yInput power: In connecting the power supply, make sure that the power conforms to the
UDWHGYDOXHDQGWKHSRZHUGLVWULEXWLRQGHYLFHLVVXI¿FLHQWWRVDWLVI\WKHORDGUHTXLUHPHQW
Inspect the rated values of each unit and make sure they have been properly grounded.
One branch circuit or power distribution device can only be connected with one cooling
unit.

12
InfraSuite RowCool Precision Cooling –
Chilled Water
 0DNHVXUH WKHSDVVDJHÀRRUHOHYDWRURUVORSHRQWKHKDQGOLQJURXWHFDQEHDUWKH
ZHLJKWRIWKHHTXLSPHQWDQGKDQGOLQJGHYLFHDQGWKHUHLVDVXI¿FLHQWQHWVSDFHWR
avoid collisions.
2. In the case of a slope on the handling route, its inclination must not be greater than 15
degrees so as to avoid toppling the cabinet.
3. The bottom casters are only suitable
for short distance movement. For long
distance movement, use a handling
device (such as Figure 3-2) so as to
avoid damage to the casters.
4. The casters are only suitable for moving
RQÀDWVXUIDFHV$YRLGKHDY\IDOOLQJRI
and moving of the unit on uneven ground,
which may damage the casters or even
result in toppling.
5. When moving the unit, pay attention to its height and center of gravity. At least two
people working together should handle the unit so as to guarantee safety.
3.2 Space Reservation
In order to facilitate maintenance, operation,
and air circulation, please reserve a net
space around the equipment.
It is suggested to preserve 1200mm for the
front passage, 600mm for the rear passage
and at least 300mm above the cabinet for
pipe installation. If the pipeline adopts a lower
connection mode, the height of the raised
ÀRRUVKRXOGQRWEHORZHUWKDQPP,IWKH
pipeline adopts an upper connection mode,
WKHHTXLSPHQWFDQEHVHWRQDFRPPRQÀRRU
3.3 Handling
yHandling Instructions
Before moving the equipment to the
installa-tion site, plan the route according
to the following instructions:
(Figure 3-2 : Forklift handling)
(Figure 3-1 : Space reservation)
╆⊼⽬㩆
䳢䵘㨈⻶
Raised Floor
Common Floor
600
mm
1200
mm
300
mm
300
mm

13
Chapter 3 Installation
yLevelers
After moving the unit into place, use a
wrench to rotate clockwise the four levelers
be-side the casters to put them down and
stable on the floor. Make sure the unit
cannot slide or topple.
WARNING:
The levelers are only used for
leveling the unit and cannot be
used to compensate for the height
difference of the floor so as to
avoid toppling.
3.4 Positioning
After moving the unit into place and it is parallel with the adjacent cabinet, you must position
it so as to ensure its stability. The following two methods can be used, depending on the
installation environment:
yCabinet fasteners
If the adjacent cabinets are Delta cabinets (MSR1110 and MSR2110), you may use
FRQQHFWLQJIDVWHQHUVWR¿[WKHHTXLSPHQW(DFKFRROLQJXQLWLVSURYLGHGZLWKIRXUFRQ
necting fasteners (two at the front and two at the rear). You must remove the front and
back doors before making the fastener connection. Refer to the following procedures:
1
If the front door is locked, use the attached key to open it.
2
 5HPRYHWKHFRQWUROSDQHO¶VÀDWFDEOH
and ground wire 1, raise the front
door 2, and take it out.
(Figure 3-3: Leveling feet)
(Figure 3-4 : Open the front door)

14
InfraSuite RowCool Precision Cooling –
Chilled Water
3
Use a screw driver to remove the two screws and ground wirefrom the rear door 1,
lean the rear door and lift it up 2to take it out.
(Figure 3-5: Remove the rear door)
1
1
2
NOTE: Put the front and rear doors that have been removed in a safe place so
as to avoid any equipment damage or personal injury due to collisions.
4
Use a screwdriver to loosen the screw below the fastener and lock it on the adja-
cent cabinet.
(Figure 3-6: Join the cooling unit and the adjacent cabinet together)
(Cooling unit) (Adjacent cabinet)
5
Fix the front and rear (8 in all) fasteners with the adjacent cabinet.
6
 $IWHU¿[LQJWKHIDVWHQHUVSOHDVHUHLQVWDOOWKHIURQWDQGUHDUGRRUV
yL-type balance support
7KH/W\SHEDODQFHVXSSRUWLVRULJLQDOO\XVHGWR¿[WKHFRROLQJXQLWRQWKHSDOOHWGXULQJ
WUDQVSRUWDWLRQDQGFDQEHXVHGIRUJURXQG¿[LQJDIWHUSRVLWLRQLQJWRSURYLGHH[WUDORFNLQJ
force.

15
Chapter 3 Installation
1
 8VHWZR0VFUHZVWR¿[WKH/W\SHEDODQFHVXSSRUWEHORZWKHIURQWGRRUZLWKWKH
extruding part forward) as shown in Figure 3-7 1.
2
 8VHH[SDQVLRQVFUHZVWR¿[WKHH[WUXGLQJHQGRQWKHÀRRU3OHDVHVHHFigure 3-7 2.
(Figure 3-7 : Installation of L-type balance support)
1
12
2
Expansion
screws
Floor
L-type
balance
support
3.5 Removal of Side Panels
If each side panel is locked, use the attached key to open it. There are two door holders on
each of the two sides of the side panel. Press them downward at the same time and take out
the side panel.
(Figure 3-8 : Removal of side panel)
1
2
2
3
To re-install the side panel, align the two lower holes and press down the two door holders at
the same time to reset the side panel.

16
InfraSuite RowCool Precision Cooling –
Chilled Water
3.6 Hole Drilling
'ULOOKROHVLQWKHUDLVHGÀRRURUFHLOLQJDFFRUGLQJWRWKHSLSLQJPRGHXSSHURUORZHUDVVKRZQ
LQWKHIROORZLQJ¿JXUHVIRUSLSHSDVVLQJ
The pipeline is wrapped with an external heat insulation layer to reduce the interference of
outside temperature and avoid condensed water. The hole diameter should be about 13mm.
(Figure 3-9: Upper and lower piping positions and dimensions)
%
$
'
&
(Figure 3-10 : Hole diameters and positions for upper and lower piping)
FG
Ø65
Ø65
E
509
Ø65
614
Ø65
62
(unit: mm)
(Top view)
(Bottom view)
(unit: mm)
ABCDEFG
HCH1850 235 192 283 192 120 215 315
HCH1870 223 181 329 293 95 215 315
