2. PURPOSE
Universal transcutaneous electrostimulator DENAS-PCM is intended for application of
system-regulating impact on physiological systems of the body and for the treatment of
functional disorders under wide range of diseases. Dynamic electroneurostimulation is
executed through impulses of electric current on biologically active points and zones of
the human body. The device provides possibility of selection of individual treatment
program, as well as already prepared for use programs. The device has a inbuilt electrodes
and a socket for connection of external therapeutic electrodes *.
The device DENAS-PCM is intended for use in hospitals and in home conditions in
accordance with the instructions of a physician.
You can only connect to the device those external electrodes, which are produced by the company-manufacturer (see Appendix A).
9
Official webstores: www.denas-store.com & www.denashealthstore.com

19 4. COMPLETE SET
Item Quantity
Electrostimulator Denas-PCM 1
Operations manual Part 1 and 2 1
Consumer container 1
Battery LR6/AA 2
Official webstores: www.denas-store.com & www.denashealthstore.com

5. DEVICE ASSEMBLY Fig. 1. The device Denas-PCM
(top view)
1. Body.
2. Socket for connection of external
electrodes (closed with cover).
3. Display — liquid-crystal display.
4. Keyboard.
5. Button for selection of menu
item .
6. Button of return to previous
menu item .
7. Button of return to main menu
.
8. Buttons for navigation in device’s
menu .
9. Button for switching the device
on an off° .
1
7 86
4 52 3 9
20
Official webstores: www.denas-store.com & www.denashealthstore.com

Fig. 2. The device Denas-PCM
(bottom view)
1. Cover of battery cabinet.
2. Inbuilt electrode.
12
21
Official webstores: www.denas-store.com & www.denashealthstore.com

5.1. Appearance of display in different modes
5.1.1. Symbols and items of main menu of the device
Battery charge
Volume
Timer
Control of contact
Menu «Programs»
Menu «Frequencies»
Mode MED
Mode «Screening»
Menu «Settings»
5.1.2. Items ofmenu «Programs»
Scrolling up
Scrolling down
Program ”Allergy”
Program ”Pain”
Program ”Severe pain”
Program “Bloating”
Program “Neurocirculatory
dystonia”
23
Baby doctor
Function «Baby doctor»
Official webstores: www.denas-store.com & www.denashealthstore.com

7. USING THE MENU
7.1. Structure ofthe menu (in Russian)
27
Частоты
Программы
МЭД
Скрининг
Настройки
Вздутие
ВСД
Гинек. боль
Гинекология
Гипертония
Гипотония
Диарея
ЖКТ боль
Запор
Кашель
Мышцы
Насморк
Потенция
Почки
Спина
Суставы
Удушье
1,0–9,9 Гц 10 Гц 20 Гц 60 Гц 77 Гц 140 Гц 200 Гц «77 10» «77АМ»
Звук Яркость Экономия Запоминание Часы Будильник
Общий Контакт Клавиши Откл. Однократно
Аллергия
Боль
Боль сильная
Голова
Горло
Тошнота
Травма
Ежедневно
Детский д.
Official webstores: www.denas-store.com & www.denashealthstore.com

28
Structure ofthe menu (English translation)
Main
Menu
Frequenc.
Programs
MED
Screening
Settings
Allergy
Bloating
Gynaecology
Hypertension
Hypotonia
Diarrhea
Constipation
Cough
Muscles
Cold
Potency
Kidneys
Back
Joints
Asthma
1,0–9,9 Hz 10 Hz 20 Hz 60 Hz 77 Hz 140 Hz 200 Hz «77 10» «77АМ»
Sound
General Contact Buttons
Brightness Economy Storage of last
settings Time Alarm clock
OFF Repeat
Pain
Severe pain
Head
Throat
Nausea
Trauma
Daily
Neuro-circulatory
dystonia
Gynecologic
pain
Gastro-
intestinal pain
Baby doctor
Official webstores: www.denas-store.com & www.denashealthstore.com
