Deni 9360 Owner's manual

Model 3200
IMPORTANT
Please keep these instructions
and your original box
packaging.
INSTRUCTIONS
FOR PROPER USE AND CARE
BONUS
Includes
Recipes
3Qt Deep Fryer
with glass sides
Model #9360
®

1
3Qt Deep Fryer
IMPORTANT SAFEGUARDS
WARNING: A risk of fire and electrical shock exists in all electrical
appliances and may cause personal injury or death. Please follow
all safety instructions.
gREAD ALL INSTRUCTIONS BEFORE USING APPLIANCE.
gHot oil can cause very serious burns. The appliance is hot during
operation and retains heat for some time after being switched off. Do
not touch hot surface such as oil tank and metal surface. Never move
the appliance during use.
gDo not operate this appliance if it has a damaged cord or plug, is not
working properly, has been dropped, damaged, or is dropped into
water. Return the appliance to our service center or an electrician for
proper repair.
gThis appliance is not for use by children.
gClose supervision is necessarywhen the appliance is used by or near
children and disabled persons.
gDo not operate unattended, and never leave the appliance unattended
when connected to power outlet.
gUnplug the appliance from power outlet after use, before filling and
emptying oil, and before cleaning.
gIf the power cord of this appliance is damaged, it must only be
replaced by an authorized service center.
gThe use of accessory attachments not recommended by the
manufacturer may cause injuries and may damage the appliance.
gDo not use outdoors.
gDo not let the cord hang over edge of table or touch hot surfaces.
gDo not place on or near a hot gas or electric burner, or in a heated
oven.
gPlace the appliance on a surface that is resistant to heat.
gAlways attach plug to the appliance first, then plug cord into the wall
outlet. To disconnect, switch OFF, then remove plug from power outlet.
gDo not use the appliance for other than intended use.
gBe sure handle is properly assembled to basket and locked in place.
gTo protect against electric shock, do not immerse the oil tank, the cord
or the plug in water or other liquid.
gDamp food should be dried first. Remove any loose ice from frozen
food. Lower the basket with food gently into the oil. Close the lid
during cooking of the food. Beware of oil spattering when food is put
into the oil.
gNever obstruct the air outlet vent on top of the lid with any objects.
Beware of hot steam escaping from the air outlet vent.
gThe oil in the oil tank must always be above the minimum oil level.
Never operate the appliance without oil or with insufficient oil in the
oil tank.
gEnsure that there are no inflammable objects put over or close to the
appliance. If the oil catches fire, unplug the appliance and close the
lid. Never use water to extinguish the fire.
gDo not operate this appliance if the lid and the oil tank are not free
from water completely.
gCAUTION: A short power cord is provided to reduce the risk of
personal injury from entanglement in or tripping over a longer cord.
An extension cord or longer detachable cord is not recommended for
use with deep-fat fryers and cooker/fryers.
gThis appliance has a polarized plug (one blade is wider than the
other), as a safety feature to reduce the risk of electric shock. This plug
is intended to fit into a polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it still does not fit, contact
aqualified electrician. Do not attempt to defeat this safety feature.
SAVE THESE INSTRUCTIONS

®
2
Features
FryBasket with
detachable handle
Cool Touch
Handles
Temperature Control Dial
Power Light
Filter to trap odor
Glass
Housing
Working Light
Assembling the Fry Basket
1. Squeeze the handle prongs together
and slide the feet into the slots on the
side of the basket.
2. Continue to squeeze the prongs as
you pull the handle back toward you,
to lock into place.
Note: Always check that the handles
arelocked into position before
cooking with oil.
Removable
Inner Tank

3
3Qt Deep Fryer
Before First Use
gThis appliance is designed for household and indoor use
only. It is not intended for commercial use.
gIf the fryer is used for the first time, follow the cleaning
instructions and clean the deep fryer first.
How to Operate
1. Pour a good quality corn or vegetable oil into the unit until it
reaches between the ‘MIN’ and ‘MAX’ oil level mark
indicated on the inside wall, approx. 3 quart. Never
operate the fryer without oil or with insufficient oil.
2. Attach the magnetic end of the power cord to the deep fryer
and plug the other end into a wall outlet.
3. Set the temperature dial to the desired temperature setting.
The red indicator light will come on.
4. When the deep fryer has reached the set temperature (after
about 5-7 minutes), the red indicator light will go out. Open
the lid. NOTE: The indicator light will go on and offas the
temperature fluctuates.
5. Attach the handle to the basket. (as shown on page 2)
6. Put food in the basket and slowly lower it into the oil. Close
the lid.
7. The frying time and temperature chart on this page is for
reference only and should be adjusted for different quantities
of food and your own taste.
8. When the cooking process is finished, turn the temperature
dial counter-clockwise to the OFF position. Open the lid.
9. Lift the basket up and allow the excessive oil to drain into the
unit. The food is then ready for serving. NOTE: To avoid early
degradation of the oil, do not add salt or spices above the oil
or during frying.
Cleaning the Unit
1. Always unplug the appliance and let the appliance and oil cool
down to room temperature before cleaning.
2. Drain and strain the oil through a cheesecloth or strainer and
put oil into a suitable container.
3. Wash the basket in warm soapy water. Dry thoroughly after
cleaning.
4. Never immerse the oil tank. Clean the inside of the unit and the
lid with a soft soapy cloth. Rinse and dry thoroughly. Wipe the
outer surface of the deep fryer with a soft damp cloth. Never
use abrasive pads or alcohol.
5. Be sure all parts are dry after washing and before use.
Fresh Cut Potatoes 350°F 10-13 Minutes
Frozen French Fries 350°F 8-12 Minutes
Chicken Pieces 325°F 15-20 Minutes
Fish Fillets 325°F 5-9 Minutes
Onion Rings 300°F 5-7 Minutes
Mushrooms 300°F 9-13 Minutes

®
4
Trouble Shooting
FRYER IS ON, BUT IS NOT HEATING UP.
gCheck to see that it is properly plugged in.
gCheck to see that the thermostat is set at the proper
temperature.
gThere is not sufficient oil in the oil tank. Make sure to fill to
the fill line.
FOOD IS NOT GOLDEN.
gUse good frying oil not, butter, margarine, olive oil or
animal fats.
gThe food is too thick.
gThe thermostat is at the wrong temperature.
gToo much food. Trysmaller batches.
Hints and Tips
gAlways use oil and fats that can withstand high
temperatures.
gDo not mix different types of oil or fat.
gWhen frying, oil may take on the flavor of other foods that
are being fried. Therefore, fry strong flavor foods such as
fish after such foods as french fries to avoid crossing flavors.
gFry foods of similar size at once to avoid under or over
cooking foods.
gFood for frying should be completely dry to avoid
overflowing and to help make the oil last longer.
gWhen preparing potato based food (chips, fries, etc.) cut
them up and wash them in cold water to remove the starch.
This will prevent them from sticking. Dry carefully.
gDo not over fill basket, oil temperature will drop making the
food greasy and not crispy.
gDo not keep oil at high temperatures for long periods of time,
it will lose its properties.
gSet the temperature dial to the lowest setting between batches.
gDo not leave cooked food in the basket to drain for too long.
The vapors could cause the food to lose its crispness and go
soft.
gFrozen food can be cooked in the basket without being
defrosted.
gOnly metal utensils can be used, do not use plastic as they
will melt.
gUse caution when frying items such as flour tortillas for tortilla
chips and deep fried enchiladas. Oil can become trapped in
bubbles and if not properly drained will burst and burn. Allow
oil to drain for a minute after frying.
gSeasoning right after frying is recommended for seasoning to
adhereto the food and to conserve oil quality.
gBeware of steam. It is normal for steam to come out from the
vents and when opening. Keep distance from hands and face.
gFryer needs to cool completely with cover on before removing
oil and cleaning.
gReusing oil can be done, provided that it is properly strained
through a cheesecloth or strainer and it is tightly sealed and
unexposed to light and air. Refrigerating the oil is an option.
gChange the oil regularly, after approximately 20 batches.
