DVD-1940CI
DVD-Audio/Video & Super Audio CD Player
New model information
DVD Audio/Video & Super Audio CD Player features 1080p DMI scaling
The DVD-1940CI is endowed with technology to unleash the full impact of DVD-Video picture quality. The DVD-1940CI also
uses 12-bit, 216-M z video D/A converter to faithfully preserve the delicate low-level signals often lost during D/A conversion.
With these advanced video image technologies, the DVD-1940CI will reproduce with the highest resolution, DVD images on
Progressive-compliant monitors and projectors. In addition to these features, the DVD-1940CI’s DMI port supports multi-
channel DVD-Video and DVD-Audio output when connected to DMI compliant equipment. For sound, it is high quality
audio D/A conversion and Digital Bass Management that will bring out the best of not only Super Audio CD and DVD-Audio
discs, but your entire CD collection as well.
• DMI Interface with Multi Channel Audio (*1) (480p/720p/1080i/1080p Scaling)
DMI is the only interface in consumer electronics that can carry both uncom-
pressed high-definition ( D) video and uncompressed multi-channel audio in
all D formats including 720p, 1080i and even 1080p. An all-digital, uncom-
pressed signal translates into the highest quality video and audio, seen and
heard, direct from the source. DVD-1940CI scaling circuit supports up to
1080p.
• Progressive Scan featuring DCDi by Faroudja
Progressive Scan technology represents a vast improvement over the
interlaced scanning method used in TV broadcasts and other conventional
applications, as it can process around twice as much video data to pro-
duce a sharper, noise-free picture with finer details. igh-definition video
images are faithfully displayed with optimum naturalness and beauty. Now,
this DCDi technology that was available only in the higher-end DVD players
has been included in Denon's affordable DVD-1940CI.
The DVD-1940CI has a feature of manual IP detection mode selection.
Even if a DVD-Video disc was mastered with wrong progressive flag or
without a flag, the user can select a mode (Auto1, Auto2, Video1, 2 or 3)
to enjoy higher performance of picture quality.
• 12 bit, 216 M z igh Resolution Video D/A Converters
• DMI/Component (Interlace) Parallel video outputs
• 2 MB Buffer Memory
This unit is equipped with a 2 MB buffer memory to ensure that both picture
and sound are played without interruption when the DVD disc shifts from layer
1 to layer 2, or in the rare event of a pickup dropout.
• Picture Adjustment function
Brightness/Contrast/Colour/ Gamma Correction/Sharpness
• Picture Zooming (x2 or x4)
• DivX Ultra
*Official DivX ® Ultra Certified product
*Plays all versions of DivX ® video ((including DivX ® 6)) with enhanced playback of DivX ® media files and
the DivX ® Media Format
• DVD-Audio/Video, Super Audio CD Universal Player
• DVD-R/RW Playback (*2)
With the increasing presence of DVD recorders, consumers are increasingly
recording audio and video material onto DVD discs.
These discs can be played back on the DVD-1940CI.
• CD-R/RW and DVD-R/RW (MP3 / Windows Media Audio 9 / JPEG /
Kodak Picture CD/DivX) Playback (*2)
The DVD-1940CI supports the CD-R/RW and DVD-R/RW formats. It plays
finalised CD-R/RW and DVD-R/RW discs (single-session or multi-session)
containing MP3/WMA9 audio files. It also reads still photos in the Kodak
Picture CD or JPEG format taken by a digital camera. WMA (Windows
Media Audio) is an audio compression format developed with Microsoft
technology. It claims to offer the highest quality sound available in the
industry. If WMA is used to compress a music CD on a PC, for instance,
using the new Encoder 9, the quality of sound at 48 kbps is said to be
equivalent to that of the original CD.
• 24-bit, 192-k z igh Resolution Audio D/A Converters
• Bass Management for DMI Output
• A Wealth of Playback Functions
The DVD-1940CI includes a wide variety of playback functions, such as
Resume Play, for returning to the Pause position on the disc after the playback
was restarted; Slow Play; Repeat Play (A-B, Chapter, Track, Disc); Random Play
and Program Play.
• Aluminum Front Panel
The DVD-1940CI features the front panel is made of strong, high-grade alu-
minum.
• RS-232C control capability
• Remote in/out IR control capability
• AC Inlet
Bullet points

56090807 B
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
(*1) Version 1.3 compliant. DMI audio output capacity is dependent on the monitor being used. DMI outputs is
DCP compliant. Video cannot be viewed if connected to a monitor that does not support DCP; video can be viewed
only on DCP-compliant monitors.
(*2) Discs that have been poorly finalised following recording may be only partially playable or not playable at all.
• Design and specifications are subject to change without notice.
• Dolby and the double-D symbol are registered trademarks of Dolby Laboratories.
• DTS and DTS Digital Out are registered trademarks of DTS Technology.
• DMI, the DMI logo and igh-Definition Multimedia Interface are trademarks or registered trademarks of DMI Licensing
LLC.
• "WMA"(Windows Media Audio) is a audio codec developed by Microsoft® in the United States of America.
Denon Electronics (USA), LLC
100 Corporate Drive
Mahwah, NJ 07430, U.S.A.
www.usa.denon.com
Specifications
Video Section
Signal system NTSC/PAL
Disc played
DVD Audio, DVD Video, Music CD, Video CD
CD-R/RW (Audio/MP3/WMA/JPEG/Kodak picture CD/DivX)
DVD-R/RW(Audio/MP3/WMA/JPEG/Kodak picture
CD/DivX),
Super Audio CD
Video outputs
Composite Video Output:
1.0 Vp-p (with 75 ohms load)
S-Video Output:
Y; 1.0 Vp-p (with 75 ohms load),
C; 0.286 Vp-p
Component Video Output:
Y, Pb/Cb, Pr/Cr:
Y; 1.0 Vp-p (with 75 ohms load),
Pb/Cb; 0.648 Vp-p (with 75 ohms load),
Pr/Cr; 0.648 Vp-p (with 75 ohms load)
DMI Output
Audio Section
Audio outputs
1Set of Analog Output (L/R)
1 Set of Multi channel
(Front L/R, Centre, Surround L/R, Subwoofer)
1 Optical Digital Output
1 Coaxial Digital Output
1DMI output
Frequency response
DVD 4 z - 22 k z (48k z sampling)
4z - 44 k z (96k z sampling)
4 z - 88 k z (192k z sampling)
CD 4 z - 20 k z
Super Audio CD 4 z - 100 k z
Signal-to-noise ratio 115 dB
Dynamic range
DVD 100 dB
CD 98 dB
Total harmonic distortion
1 k z CD 0.004%
General
Power supply AC 120 V, 60 z
Power Consumption 15 W (Standby: 0.4 W)
Dimensions (W x x D) 17-3/32” x 2-61/61” x 12-13/64” mm
435 x 75 x 310 mm
Weight 5.72 lbs, 2.6 kg
Remote Control Unit RC-1017
