Denon S-102 Administrator guide

13.Dec.2007
V2.0
FORMAT KASEIKYO
SW1 Byte 1 Byte 2
SW2 00101010 01001100
Key No. Name Genre1(D0) Genre 2(D1) DATA Code(D2) Parity(DP)Byte 3 Byte 4 Byte 5 Byte 6
KEY 1 SOURCE POWER
KEY 2 POWER ON/STANDBY SYSTEM(5H) SYSTEM (1H) POWER ON/STANDBY (003H) 61H 00001010 10001100 00000000 10000110
KEY 3 TV INPUT
KEY 4 SUBWOOFER LEVEL- SYSTEM(5H) AMP/RECIEVER (2H) CH(SW)- (0EBH) ECH 00001010 01001101 01110000 00110111
KEY 5 SUBWOOFER LEVEL+ SYSTEM(5H) AMP/RECIEVER (2H) CH(SW)+ (0EAH) FCH 00001010 01000101 01110000 00111111
KEY 6 DVD/CD SYSTEM(5H) VIDEO PLAYER (4H) (FUNCTION)DVD (007H) 24H 00001010 00101110 00000000 00100100
KEY 7 TUNER SYSTEM(5H) TUNER (6H) (FUNCTION)TUNER (007H) 26H 00001010 01101110 00000000 01100100
KEY 8 AUX SYSTEM(5H) AMP/RECIEVER (2H) (FUNCTION)AUX(toggle) (08EH) BAH 00001010 01000111 00010000 01011101
KEY 9 iPod SYSTEM(5H) AMP/RECIEVER (2H) (FUNCTION)iPod (08DH) 8AH 00001010 01001011 00010000 01010001
KEY 10 HDMI SYSTEM(5H) VIDEO PLAYER (4H) HDMI SELECT (050H) 51H 00001010 00100000 10100000 10001010
KEY 11 SLEEP SYSTEM(5H) SYSTEM (1H) SLEEP (031H) 42H 00001010 10001000 11000000 01000010
KEY 12 PLAY SYSTEM(5H) SYSTEM (1H) PLAY (008H) D1H 00001010 10000001 00000000 10001011
KEY 13 STOP/BAND SYSTEM(5H) SYSTEM (1H) STOP(/BAND) (00BH) E1H 00001010 10001101 00000000 10000111
KEY 14 DVS/STEREO SYSTEM(5H) AMP/RECIEVER (2H) DVS/STEREO (0ABH) E8H 00001010 01001101 01010000 00010111
KEY 15 STILL/PAUSE SYSTEM(5H) SYSTEM (1H) PAUSE (009H) C1H 00001010 10001001 00000000 10000011
KEY 16 VOLUME+ SYSTEM(5H) SYSTEM (1H) VOLUME+ (004H) 11H 00001010 10000010 00000000 10001000
KEY 17 |<</CH- SYSTEM(5H) SYSTEM (1H) |<</CH- (047H) 25H 00001010 10001110 00100000 10100100
KEY 18 CH+/>>| SYSTEM(5H) SYSTEM (1H) >>|/CH+ (046H) 35H 00001010 10000110 00100000 10101100
KEY 19 VOLUME- SYSTEM(5H) SYSTEM (1H) VOLUME- (005H) 01H 00001010 10001010 00000000 10000000
KEY 20 <</TU- SYSTEM(5H) SYSTEM (1H) <</TU- (00FH) A1H 00001010 10001111 00000000 10000101
KEY 21 TU+/>> SYSTEM(5H) SYSTEM (1H) >>/TU+ (00EH) B1H 00001010 10000111 00000000 10001101
KEY 22 MUTE SYSTEM(5H) SYSTEM (1H) MUTE (006H) 31H 00001010 10000110 00000000 10001100
KEY 23 TOP MENU SYSTEM(5H) SYSTEM (1H) (SYSTEM)TOP MENU (04AH) F5H 00001010 10000101 00100000 10101111
KEY 24 cursor up SYSTEM(5H) SYSTEM (1H) cursor up (020H) 53H 00001010 10000000 01000000 11001010
KEY 25 MENU/GUIDE SYSTEM(5H) SYSTEM (1H) (SYSTEM)MENU (040H) 55H 00001010 10000000 00100000 10101010
KEY 26 cursor left SYSTEM(5H) SYSTEM (1H) cursor left (022H) 73H 00001010 10000100 01000000 11001110
KEY 27 ENTER SYSTEM(5H) SYSTEM (1H) ENTER (024H) 13H 00001010 10000010 01000000 11001000
KEY 28 cursor right SYSTEM(5H) SYSTEM (1H) cursor right (023H) 63H 00001010 10001100 01000000 11000110
KEY 29 DISPLAY SYSTEM(5H) SYSTEM (1H) ON SCREEN (043H) 65H 00001010 10001100 00100000 10100110
KEY 30 cursor down SYSTEM(5H) SYSTEM (1H) cursor down (021H) 43H 00001010 10001000 01000000 11000010
DENON（3254H）
DENON S-102 IR CODE
DATA CONSTRUCTION 48bit
Maker Code（C0C1）
DVD/CD/TUNER/iPod/NET/USB
1/2

13.Dec.2007
V2.0
SW1 Byte 1 Byte 2
SW2 00101010 01001100
Key No. Name Genre1(D0) Genre 2(D1) DATA Code(D2) Parity(DP)Byte 3 Byte 4 Byte 5 Byte 6
DENON（3254H）
Maker Code（C0C1）
DVD/CD/TUNER/iPod/NET/USB
KEY 31 RETURN SYSTEM
(
5H
)
SYSTEM (1H) BACK(/RETURN) (025H) 03H 00001010 10001010 01000000 11000000
KEY 32 HOME SYSTEM
(
5H
)
SYSTEM (1H) HELP(HOME) (042H) 75H 00001010 10000100 00100000 10101110
KEY 33 AUDIO/RDS SYSTEM
(
5H
)
SYSTEM (1H) AUDIO(/GENRE) (050H) 54H 00001010 10000000 10100000 00101010
KEY 34 SUBTITLE/PTY SYSTEM
(
5H
)
SYSTEM (1H) SUBTITLE(/ARTIST) (051H) 44H 00001010 10001000 10100000 00100010
KEY 35 ANGLE/CT SYSTEM
(
5H
)
SYSTEM (1H) ANGLE(/ALBUM) (052H) 74H 00001010 10000100 10100000 00101110
KEY 36 ZOOM/RT SYSTEM
(
5H
)
SYSTEM (1H) ZOOM(/P.LIST) (053H) 64H 00001010 10001100 10100000 00100110
KEY 37 1 SYSTEM
(
5H
)
SYSTEM (1H) 1 (011H) 40H 00001010 10001000 10000000 00000010
KEY 38 2 SYSTEM
(
5H
)
SYSTEM (1H) 2(ABC) (012H) 70H 00001010 10000100 10000000 00001110
KEY 39 3 SYSTEM
(
5H
)
SYSTEM (1H) 3(DEF) (013H) 60H 00001010 10001100 10000000 00000110
KEY 40 4 SYSTEM
(
5H
)
SYSTEM (1H) 4(GHI) (014H) 10H 00001010 10000010 10000000 00001000
KEY 41 5 SYSTEM
(
5H
)
SYSTEM (1H) 5(JKL) (015H) 00H 00001010 10001010 10000000 00000000
KEY 42 6 SYSTEM
(
5H
)
SYSTEM (1H) 6(MNO) (016H) 30H 00001010 10000110 10000000 00001100
KEY 43 7 SYSTEM
(
5H
)
SYSTEM (1H) 7(PQRS) (017H) 20H 00001010 10001110 10000000 00000100
KEY 44 8 SYSTEM
(
5H
)
SYSTEM (1H) 8(TUV) (018H) D0H 00001010 10000001 10000000 00001011
KEY 45 9 SYSTEM
(
5H
)
SYSTEM (1H) 9(WXYZ) (019H) C0H 00001010 10001001 10000000 00000011
KEY 46 CLEAR SYSTEM
(
5H
)
SYSTEM (1H) CLEAR (02FH) A3H 00001010 10001111 01000000 11000101
KEY 47 0 SYSTEM
(
5H
)
SYSTEM (1H) 0(/10) (01BH) E0H 00001010 10001101 10000000 00000111
KEY 48 +10 SYSTEM
(
5H
)
SYSTEM (1H) +10 (01CH) 90H 00001010 10000011 10000000 00001001
KEY 49 CALL SYSTEM
(
5H
)
SYSTEM (1H) CALL (02EH) B3H 00001010 10000111 01000000 11001101
KEY 50 PROGRAM SYSTEM
(
5H
)
SYSTEM (1H) PROGRAM (029H) C3H 00001010 10001001 01000000 11000011
KEY 51 RANDOM SYSTEM
(
5H
)
SYSTEM (1H) RANDOM (02AH) F3H 00001010 10000101 01000000 11001111
KEY 52 REPEAT SYSTEM
(
5H
)
SYSTEM (1H) REPEAT (02BH) E3H 00001010 10001101 01000000 11000111
KEY 53
KEY 54 STATUS SYSTEM
(
5H
)
SYSTEM (1H) STATUS (049H) C5H 00001010 10001001 00100000 10100011
KEY 55 cursor up SYSTEM
(
5H
)
SYSTEM (1H) cursor up (020H) 53H 00001010 10000000 01000000 11001010
KEY 56 TONE SYSTEM
(
5H
)
SYSTEM (1H) TONE(/SDB) (030H) 52H 00001010 10000000 11000000 01001010
KEY 57
KEY 58 cursor left SYSTEM
(
5H
)
SYSTEM (1H) cursor left (022H) 73H 00001010 10000100 01000000 11001110
KEY 59 ENTER SYSTEM
(
5H
)
SYSTEM (1H) ENTER (024H) 13H 00001010 10000010 01000000 11001000
KEY 60 cursor right SYSTEM
(
5H
)
SYSTEM (1H) cursor right (023H) 63H 00001010 10001100 01000000 11000110
KEY 61
KEY 62
KEY 63 cursor down SYSTEM
(
5H
)
SYSTEM (1H) cursor down (021H) 43H 00001010 10001000 01000000 11000010
KEY 64 RETURN SYSTEM
(
5H
)
SYSTEM (1H) BACK(/RETURN) (025H) 03H 00001010 10001010 01000000 11000000
KEY 65
KEY 66 SURROUND SYSTEM
(
5H
)
AMP/RECIEVER (2H) SURROUND (09FH) ABH 00001010 01001111 10010000 11010101
KEY 67 SURROUND PARAMETER SYSTEM
(
5H
)
AMP/RECIEVER (2H) SURROUND PARAMETER (09EH) BBH 00001010 01000111 10010000 11011101
KEY 68 MEMO SYSTEM(5H) TUNER (6H) MEMO (029H) C4H 00001010 01101001 01000000 00100011
2/2
