Denon AVR-X5200W User manual

.
AVR-X5200W
INTEGRATED NETWORK AV RECEIVER
Owner’s Manual
You can print more than one page of a PDF onto a single sheet of paper.
Contents Connections Playback Settings Tips Appendix
1
Front panel Display Rear panel Remote Index

Upgrade 8
Accessories 9
Inserting the batteries 10
Operating range of the remote control unit 10
Features 11
High quality sound 11
High performance 13
Easy operation 16
Part names and functions 17
Front panel 17
Display 21
Rear panel 23
Remote control unit 26
Connections
Connecting speakers 30
Speaker installation 30
Speaker connection 40
Speaker configuration and “Amp Assign” settings 43
Connecting a TV 62
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) 63
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) 64
Connection 3 : TV equipped without an HDMI connector 65
Connecting a playback device 66
Connecting a set-top box (Satellite tuner/cable TV) 67
Connecting a DVD player or Blu-ray Disc player 68
Connecting a Blu-ray Disc player compatible with the Denon Link
HD function 69
Connecting a video camcorder or game console 70
Connecting a turntable 71
Connecting an iPod or USB memory device to the USB port 72
Connecting an HD Radio receiver 74
Connecting to a home network (LAN) 76
Wired LAN 76
Wireless LAN 77
Connecting an external control device 78
REMOTE CONTROL jacks 78
TRIGGER OUT jacks 79
Connecting the power cord 80
Contents Connections Playback Settings Tips Appendix
Contents
2
Front panel Display Rear panel Remote Index

Playback
Basic operation 82
Turning the power on 82
Selecting the input source 82
Adjusting the volume 83
Turning off the sound temporarily (Muting) 83
Playback a DVD player/Blu-ray Disc player 83
Playing an iPod 84
Listening to music on an iPod 85
iPod Browse Mode settings 86
Performing repeat playback 88
Performing random playback 88
Playing a USB memory device 89
Playing files stored on USB memory devices 90
Listening to music on a Bluetooth device 92
Pairing with a Bluetooth device 93
Playing a Bluetooth device 94
Pairing with the Pairing Mode 96
Listening to an HD Radio™ stations 97
Listening to an HD Radio broadcast 99
Tuning in by entering the frequency (Direct Tune) 101
Changing the tune mode (Tune Mode) 101
Selecting an audio program 102
Tuning in to stations and presetting them automatically (Auto
Preset Memory) 102
Presetting the current broadcast station (Preset Memory) 103
Listening to preset stations 103
Specify a name for the preset broadcast station (Preset Name) 104
Skipping preset broadcast stations (Preset Skip) 105
Cancelling Preset Skip 106
Checking the HD Radio reception information 107
Listening to Internet Radio 108
Listening to Internet Radio 109
Playing the last played Internet Radio station 110
Using vTuner to add Internet Radio stations to favorites 111
Playing back files stored on a PC and NAS 112
Applying media sharing settings 113
Playing back files stored on a PC and NAS 114
Contents Connections Playback Settings Tips Appendix
3
Front panel Display Rear panel Remote Index

Viewing photographs on the Flickr site 116
Viewing photographs shared by particular users 117
Viewing all photographs on Flickr 119
Listening to Pandora®120
Listening to Pandora®121
Creating a new station 123
Listening to an existing station 124
Listening to created radio stations at random 124
Giving feedback and managing stations 125
Sign Out 126
Listening to SiriusXM Internet Radio 127
Listening to SiriusXM Internet Radio 128
Sign Out 129
AirPlay function 130
Playing songs from your iPhone, iPod touch or iPad 131
Playing iTunes music with this unit 131
Selecting multiple speakers (devices) 132
Perform iTunes playback operations with the remote control unit
of this unit 132
Spotify Connect function 133
Playing Spotify music with this unit 133
Convenience functions 134
Performing repeat playback 135
Performing random playback 135
Registering to Favorites 136
Playing back content added to the “Save to Favorites” 136
Deleting content added to favorites 137
Searching content with keywords (Text Search) 137
Playing back music and a favorite picture at the same time
(Slideshow) 138
Setting the Slideshow Interval 139
Adjusting the audibility of dialog and vocals (Dialog Enhancer) 139
Adjusting the volume of each channel to match the input source
(Channel Level Adjust) 140
Adjusting the tone (Tone) 141
Displaying your desired video during audio playback (Video
Select) 142
Adjusting the picture quality for your viewing environment (Picture
Mode) 143
Playing the same music in all zones (All Zone Stereo) 144
Contents Connections Playback Settings Tips Appendix
4
Front panel Display Rear panel Remote Index

Selecting a sound mode 145
Selecting a sound mode 146
Direct playback 147
Pure Direct playback 147
Auto surround playback 148
HDMI control function 161
Setting procedure 161
Sleep timer function 162
Using the sleep timer 163
Quick select plus function 164
Calling up the settings 165
Changing the settings 166
Web control function 167
Controlling the unit from a web control 167
Playback in ZONE2/ZONE3 (Separate room) 169
Connecting ZONE 169
Playback in ZONE2/ZONE3 174
Settings
Menu map 176
Menu operations 179
Inputting characters 180
Using the keyboard screen 181
Using the number buttons 181
Audio 182
Subwoofer Level Adjust 182
Surround Parameter 182
Restorer 188
Audio Delay 189
Volume 189
Audyssey 190
Graphic EQ 194
Video 196
Picture Adjust 196
HDMI Setup 198
Output Settings 202
Component Video Out 206
On Screen Display 207
TV Format 208
Contents Connections Playback Settings Tips Appendix
5
Front panel Display Rear panel Remote Index

Inputs 209
Input Assign 209
Source Rename 211
Hide Sources 211
Source Level 211
Input Select 212
Speakers 213
Audyssey® Setup 213
Procedure for speaker settings (Audyssey® Setup) 215
Error messages 221
Retrieving Audyssey® Setup settings 223
Manual Setup 224
Amp Assign 224
Speaker Config. 241
Distances 246
Levels 247
Crossovers 248
Bass 249
Front Speaker 250
2ch Playback 250
Network 253
Information 253
Connection 253
Wi-Fi Setup 254
Settings 256
IP Control 257
Friendly Name 258
Diagnostics 258
Maintenance Mode 259
General 260
Language 260
ECO 260
ZONE2 Setup / ZONE3 Setup 262
Zone Rename 264
Quick Select Names 264
Trigger Out 1 / Trigger Out 2 264
Front Display 265
Information 265
Usage Data 267
Firmware 268
Setup Lock 270
Contents Connections Playback Settings Tips Appendix
6
Front panel Display Rear panel Remote Index

Operating external devices with the remote control unit 271
Registering preset codes 272
Operating devices 274
Initializing registered preset codes 277
Specifying the operating zone with the remote control 277
Resetting the remote control unit 277
Tips
Tips 279
Troubleshooting 281
Resetting factory settings 299
Appendix
About HDMI 300
Video conversion function 303
Playing back a USB memory devices 305
Playing back a Bluetooth device 306
Playing back a file saved on a PC or NAS 307
Playing back Internet Radio 308
Personal memory plus function 308
Last function memory 308
Sound modes and channel output 309
Sound modes and surround parameters 311
Types of input signals, and corresponding sound modes 315
Explanation of terms 319
Trademark information 331
Specifications 334
Index 340
List of preset codes 343
License 354
Contents Connections Playback Settings Tips Appendix
7
Front panel Display Rear panel Remote Index

Upgrade
Upgrade (Auro-3D)
Auro-3D
Features
High quality sound 12
Connecting speakers
Speaker installation 32, 35
Layout including height speakers and top speakers 39
Speaker configuration and “Amp Assign” settings 43
Auro-3D 9.1/10.1-channel system 60
Selecting a sound mode
Description of sound mode types Auro-3D sound mode 151
Sound mode that can be selected for each input signal 159
Audio
Auro-Matic 3D Preset 184
Auro-Matic 3D Strength 184
Inputs
Decode Mode 212
Manual Setup
Amp Assign 226, 227, 228, 240
Speaker Config. 245
Appendix
Sound modes and channel output 310
Sound mode and surround parameters 313
Types of input signals, and corresponding sound modes 317
Explanation of terms 320
Trademark information 333
Upgrade (Auro-3D)
The text marked with this symbol that will enable after the upgrade of the Auro-3D.
You can experience the best performance of Auro-3D if you install front height and surround height in addition to standard 5.1ch. The Setup Assistant
will lead you to this setting.
AVR also can play Auro-3D using standard 5.1ch and front height speakers. If you install any height speakers instead of surround height speakers, you
can set the speaker configuration in Setup Menu.
Contents Connections Playback Settings Tips Appendix
8
Front panel Display Rear panel Remote Index

Thank you for purchasing this Denon product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
.
. . .
Quick Start Guide CD-ROM
(Owner’s Manual) Safety Instructions Notes on radio Warranty (for North America model only)
. . . . .
Cable labels Power cord FM indoor antenna AM loop antenna Sound calibration
microphone
(ACM1HB)
. .
.
.
Sound calibration
microphone stand Remote control unit (RC-1193) R6P/AA batteries External antennas for Bluetooth/wireless
connectivity
Contents Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Inserting the batteries
1Slide the rear cover off the remote control unit in the
arrow direction.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
R6P/AA batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
Approx. 23 ft/7 m
30°
Contents Connections Playback Settings Tips Appendix
10
Front panel Display Rear panel Remote Index
