7.2 Channel 4K & 3D Pass Through,

Networking Home Theater Receiver with AirPlay®and powered Zone 2

With its vast array of inputs and network functions, the Denon AVR-2313CI 7.2-Channel Integrated Network A/V Receiver puts you in

command. As the mid-level model of the IN-Command Series, this receiver sets a new standard in 3D, Blu-ray, game console, and

other entertainment device integration with six HDMI inputs and dual HDMI outputs. It features seven discrete 105-watt channels of

equal power, dual subwoofer outputs, and multiple high-resolution audio formats for superior surround sound audio performance.

It also includes advanced video circuitry that upscales high-definition (HD) signal to 4K (3840 x 2160 pixel) signal. Enhanced

by digital network audio/photo streaming capabilities, including support for AirPlay, mp3/WMA/WAV and FLAC HD audio, and

Windows 7 compatibility, the AVR-2313CI is a solid foundation for your networked home entertainment system.C4 Certiﬁed.

So much to experience, Connected, Collected.

So easy to command:

Your IN-Command Series™ Integrated Network A/V Receiver is the heart

and brain of your networked home entertainment center.

AVR-2313CI

Denon IN-Comand AV Receiver

™

New Features

• Supports 4K video signals

(video upscaling, video passthrough, GUI overlay)

• The plenty of network capabilities and functions

allow you to enrich your

entertainment world including:

- AirPlay

- DLNA 1.5 certiﬁed

- Windows 7 compatible

- Internet radio

- SiriusXM Internet Radio, Pandora

- Photo streaming

- ﬂickr

- FLAC HD, High-resolution audio ﬁle playback

• Support new “Denon Remote App” to simplify

operation by Android & iOS tablet/smartphone

• Convenient HDMI port on the front for connecting

a camcorder or other device

• Front display with large, easy-to-read characters

State-of-the-art Denon Solutions

for Maximizing Content Quality

• Fully discrete, identical quality and power for all 7

channels (105 W x 7 ch)

• Stable power supply for high-quality sound and

picture playback

• Featuring 3D pass-through technology

• Minimum Signal Path for clear audio and video signal

• High-performance 192kHz/24-bit D/A converters

for all channels

• Digitally transmitted Play function for iPod® and

iPhone® (via USB) for best sound quality

• Denon’s proprietary Compressed Audio Restorer,

to restore sound quality from compressed music

sources

• Audyssey DSX

• Dolby Pro Logic IIz

Connectivity & Future-ready Expandability

• Supports HDMI with 4K, 3D, Audio Return Chan-

nel, Deep Color, x.v.Color, Auto Lipsync and HDMI

control function

• 6 x HDMI in (1 on front panel) / 2 x HDMI out (Si-

multaneous)

• Power Amp Assign function, for versatility in using

the AVR-2313CI for different purposes

• Front panel USB input

• Multi room audio (2 zones 2 sources)

Ease-of-Use

• Setup Assistant, providing easy-to-follow setup

instructions

• Audyssey Dynamic Volume®, for real-time volume

adjustment

• Audyssey DynamicEQ, improves surround effects

during low volume levels

• Audyssey MultEQ XT, automatically sets the

speakers to suit the room’s listening environment

and the speakers’ characteristics

• Comes with simple, easy-to-use remote control

handset

• Sleep Timer, set up to 120 minutes in 10-minute

increments

• Audio level memory, capable of correcting different

signal levels for each input device

• Standby HDMI Pass through

• Auto Standby

• C4 Certied IP Control Capability

Others

• Audio Delay function

• Auto surround mode

• Muting level settings (Full/-40dB/-20dB)

• Audio level memory, capable of correcting different

signal levels for each input device

• Variable subwoofer crossover switching

• Lower power consumption at stand-by 0.1 W

(Standby)

• Remote setup function

• Trigger output (150 mA)

• Picture adjust

• Audyssey Installer Ready

• 3 year warranty

Main Speciﬁcations

Power ampliﬁer section Preampliﬁer section

Rated output *THD ﬁgures are power amp stage values.

Input sensitivity/impedance

200 mV / 47 kohms

Front L/R 105 W + 105 W Frequency response

10 Hz ~100 kHz —+1, –3 dB (DIRECT mode)

(8 ohms, 20 Hz - 20 kHz, THD 0.08 %) S/N Ratio

100 dB (IHF-A weighted, DIRECT mode)

135 W + 135 W

(6 ohms, 1 kHz, THD 0.7%) FM section

Centre 105 W Tuning frequency range 87.5 - 107.9 MHz

(8 ohms, 20 Hz - 20 kHz, THD 0.08 %)

135 W General

(6 ohms, 1 kHz, THD 0.7%) Power supply AC 120 V, 60 Hz

Surround L/R 105 W + 105 W Power consumption

600 W

(8 ohms, 20 Hz - 20 kHz, THD 0.08 %)

(Standby 0.1 W, CEC standby 0.5 W)

135 W + 135 W Dimensions (W x H x D) 17 3/32" x 6 37/64" x 17 3/32"

(6 ohms, 1 kHz, THD 0.7%) 434 x 166 x 379 mm

Surround Back L/R 105 W + 105 W Weight 24 lbs, 11.0 kg

(8 ohms, 20 Hz - 20 kHz, THD 0.08 %)

135 W + 135 W

(6 ohms, 1 kHz, THD 0.7%)

D&M Holdings Inc.

D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,

Kanagawa, 210-8569, Japan

www.denon.com

Denon Electronics (USA), LLC.

D&M Canada

100 Corporate Drive, Mahwah, New Jersey 07430 USA

TEL: 201-762-6500

usa.denon.com

ca.denon.com

*Design and speciﬁcations are subject to change without notice. *“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. *DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc.

*HDMI, the HDMI logo and High-Deﬁnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. *Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

*NSV is a registered trademark of Analog Devices, Inc. *Audyssey MultEQ® XT, Audyssey Dynamic EQ® and Audyssey Dynamic Volume® are registered trademarks of Audyssey Laboratories. *“Made for iPod,” “Made for iPhone,” and mean that an electronic accessory has been

designed to connect speciﬁcally to iPod, or iPhone, respectively, and has been certiﬁed by the developer to meet Apple performance standards. Please note that the use of this accessory with iPod, or iPhone, may affect wireless performance. *Apple is not responsible for the operation

of this device or its compliance with safety and regulatory. *AirPlay, the AirPlay logo, iPhone, iPod, iPod classic, iPod nano, iPod shufﬂe, iPod touch and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries.

Dual HDMI out

Ports

In HDMI (Front: 1) 6

Component (Video) 2

Composite (video) (front: 1) 4

Analog Audio (Front: 1) 6

Digital Audio (Optical) 2

Digital Audio (Coaxial) 2

Out HDMI Monitor 2

Component (Video) Monitor 1

Composite (Video) Monitor 2

Audio Preout (SW) 2 (0.1ch)
