Thank you for purchasing this Denon product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
.
.
. .
Quick Setup Guide CD-ROM
(Owner’s Manual)
Safety Instructions Notes on radio Power cord
.
.
.
.
FM indoor antenna AM loop antenna Remote control unit
(RC-1199)
R03/AAA batteries
Contents Connections Playback Settings Tips Appendix
6
Front/Top
panel Rear panel
Remote control unit Index

Inserting the batteries
ARemove the rear lid in the direction of the arrow and remove it.
.
BInsert two batteries correctly into the battery compartment as indicated.
.
R03/AAA batteries
CPut the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
Approx. 7 m
30°
Contents Connections Playback
Settings Tips Appendix
7
Front/Top
panel Rear panel
Remote control unit Index

Features
Multiple music formats are supported,
all in a compact form factor
0Supports Internet Radio and music streaming Supports
AirPlay® (v p. 64)
You can enjoy a wide variety of content, including listening to Internet
Radio, playing audio files stored on your PC.
This unit also supports Apple AirPlay which lets you stream your music
library from an iPhone®, iPad®, iPod touch® or iTunes®.
0DLNA (Digital Living Network Alliance) ver. 1.5 support for audio
networks
0Supports online music, including Spotify
0Support for High Quality Audio playback
WAV/FLAC/ALAC (Apple Lossless Audio Codec)/AIFF
0Support for Gapless playback
Playback with no gap between music files (for WAV/FLAC/ALAC/AIFF
only)
0Wi-Fi network capability with built-in diversity antenna, and is
certified under WMM (Wi-Fi Multi Media) for efficient wireless
connectivity
0High quality & high power digital amplifier
Easy operation
0Easy wireless connection is possible by pressing the Wi-Fi
CONNECT button (WPS and Wi-Fi Sharing)
See the separate “Quick Setup Guide”.
0Wireless connection with Bluetooth devices can be carried out
easily
You can enjoy music simply by connecting wirelessly with your
smartphone, tablet, PC, etc.
0If the Bluetooth device has NFC function, you can connect easily
to touch to N mark
0iPod auto detect charges your device even after the unit switches
to standby mode
0Denon “Hi-Fi Remote” App is application software that allows you
to perform basic operations with an iPad, iPhone, Android
smartphone or Android tablet such as turning the unit ON/OFF,
controlling the volume, and switching the source.
zDownload the appropriate Denon “Hi-Fi Remote” App for your iOS or Android
devices. This unit needs to be connected to your LAN and the iPad, iPhone,
Android smartphone, Android tablet or other device needs to be connected to
the same network by Wi-Fi (wireless LAN).
0OLED (Organic Light Emitting Diode) display that can display 3
lines
0Auto Standby mode for energy savings
Contents Connections Playback
Settings Tips Appendix
8
Front/Top
panel Rear panel
Remote control unit Index

Part names and functions
Front/Top panel
.
ENTER
VOLUME
uo Q0 yQ1 Q2
rwq et
i
GTop panelH
GFront panelH
Contents Connections Playback
Settings Tips Appendix
9
Front/Top
panel Rear panel
Remote control unit Index

.
ENTER
VOLUME
uy
rwq et
i
GTop panelH
GFront panelH
o
AN mark (Q)
Touch this mark with a Bluetooth device that includes the NFC function
when pairing (registering) with it. (v p. 62)
BVolume up/down buttons (VOLUME df)
Adjusts the volume.
CInput source select button (q)
Selects the input source.
DCursor buttons (uio p)
These select items.
EPlayback/Pause/ENTER button (1/3/ENTER)
Plays back and pauses tracks, and enters the selected content.
FUSB port
Used to connect iPod or USB memory devices. (v p. 22)
GPower operation button (X)
Turns power to this unit on and off (standby).
Power indicator
The power indicator changes as shown below according to the status
of the unit.
0Power on : White
0Normal standby : Off
0When “Network Control” is set to “On” : Red (v p. 91)
0iPod charge standby : Red (v p. 55)
0Alarm standby : Orange (v p. 86)
0Display off: White (v p. 80)
HDisc tray
Tray used to insert a compact disc.
IDisplay
Various information is displayed here.
Contents Connections Playback
Settings Tips Appendix
10
Front/Top
panel Rear panel
Remote control unit Index

.
Q1 Q2 Q3
GFront panelH
JRemote control sensor
This receives signals from the remote control unit. (v p. 7)
KDisc tray open/close button (5)
Used to open/close the disc tray.
LHeadphones jack (R)
Used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers.
NOTE
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
Contents Connections Playback Settings Tips Appendix
11
Front/Top
panel Rear panel
Remote control unit Index

Rear panel
.
NETWORK
FM AM
COAX.75
LOOP ANT.
SPEAKERS
IMPEDANCE : 4~16
ANALOG IN
L
R
L
R
DIGITAL IN
OPTICAL
CONNECT Wi-Fi
SUB WOOFER
OUT
iOSWPS
1
2
ANTENNA
u i
q w re t y
Contents Connections Playback
Settings Tips Appendix
12
Front/Top
panel Rear panel
Remote control unit Index

.
NETWORK
FM AM COAX.75
LOOP ANT.
SPEAKERS
IMPEDANCE : 4~16
ANALOG IN
L
R
L
R
DIGITAL IN
OPTICAL
CONNECT Wi-Fi
SUB WOOFER
OUT
iOSWPS
1
2
ANTENNA
u i
q w re t y
AAC inlet (AC IN)
Used to connect the supplied power cord. (v p. 29)
BSpeaker terminals (SPEAKERS)
Used to connect speakers. (v p. 18, 20)
CANALOG IN connectors
Used to connect devices equipped with analog audio connectors.
(v p. 21)
DAntenna terminals (ANTENNA)
Used to connect FM room antennas and AM loop antennas.
(v p. 24)
EDIGITAL IN connectors
Used to connect devices equipped with digital audio connectors.
(v p. 21)
FNETWORK connector
Used to connect this unit to the network. (v p. 26)
GSW OUT connector
Used to connect a subwoofer with a built-in amplifier. (v p. 19)
HWi-Fi CONNECT buttons (iOS/WPS)
Used to connect to the wireless LAN.
(See the separate “Quick Setup Guide”.)
Contents Connections Playback Settings Tips Appendix
13
Front/Top
panel Rear panel
Remote control unit Index

Remote control unit
.
CH
CH
TUNER
TUNER
ADD
ADD
CALL
CALL
CD
CD
POWER
POWER
CLOCK
CLOCK
DIMMER
DIMMER
SLEEP
SLEEP
FAVORITES
FAVORITES
TOP MENU
TOP MENU
INFO
INFO
SETUP
SETUP
SEARCH
SEARCH
VOLUME
VOLUME
MODE
MODE
PROGRAM
PROGRAM
REP
REPE
AT
AT
RANDO
RANDOM
MUSIC
MUSIC
SERVER
SERVER
DIGITAL IN
DIGITAL IN
ANALOG IN
ANALOGIN
INTERN
INTERN
ET
ET
RADIO
RADIO
. /
. /
ABC
ABC
a/A
DEF
DEF
GHI
GHI
JKL
JKL
MNO
MNO
PQRS
PQRS
TUV
TUV
WXYZ
WXYZ
*
*
CLEAR
CLEAR
1 2 3
4 5 6
7 8 9
+1
+10 0
SDB
SDB
TONE
TONE
CH
CH
MUTE
MUTE
ENTER
ENTER
TUNE
TUNE
TUNE
TUNE
Blu
Bluetooth
iPo
iPod/
USB
USB
e
w
q
r
t
y
ARemote control signal transmitter
This transmits signals from the remote control unit. (v p. 7)
BCLOCK button
The current time appear on the unit. (v p. 79)
CSLEEP button
This sets the sleep timer. (v p. 79)
DInput source select buttons
These select the input source. (v p. 31)
ESystem buttons
These perform playback related operations. (v p. 33, 36, 43,
54, 57)
0Reverse-skip / Forward-skip buttons (8, 9)
0Play/pause button (1/3)
0Fast-reverse / Fast-forward buttons (6, 7)
0Stop button (2)
Channel buttons (CH +, –)
These operate the Favorite function. (v p. 50)
Tuning buttons (TUNE +, –)
These operate the tuner. (v p. 45)
FSDB/TONE button
Adjusting the tone. (v p. 78)
Contents Connections Playback
Settings Tips Appendix
14
Front/Top
panel Rear panel
Remote control unit Index

.
CH
CH
TUNER
TUNER
ADD
ADD
CALL
CALL
CD
CD
POWER
POWER
CLOCK
CLOCK
DIMMER
DIMMER
SLEEP
SLEEP
FAVORITES
FAVORITES
TOP MENU
TOP MENU
INFO
INFO
SETUP
SETUP
SEARCH
SEARCH
VOLUME
VOLUME
MODE
MODE
PROGRAM
PROGRAM
REP
REPE
AT
AT
RANDO
RANDOM
MUSIC
MUSIC
SERVER
SERVER
DIGITAL IN
DIGITAL IN
ANALOG IN
ANALOGIN
INTERN
INTERN
ET
ET
RADIO
RADIO
. /
. /
ABC
ABC
a/A
DEF
DEF
GHI
GHI
JKL
JKL
MNO
MNO
PQRS
PQRS
TUV
TUV
WXYZ
WXYZ
*
*
CLEAR
CLEAR
1 2 3
4 5 6
7 8 9
+1
+10 0
SDB
SDB
TONE
TONE
CH
CH
MUTE
MUTE
ENTER
ENTER
TUNE
TUNE
TUNE
TUNE
Blu
Bluetooth
iPo
iPod/
USB
USB
u
i
Q1
Q2
Q0
o
Q3
Q4
GFAVORITES ADD / CALL buttons
0To add radio stations or files to the favorite list, press ADD button.
(v p. 51)
0To call up a radio station or file registered in the favorite list, press
CALL button. (v p. 51)
HTOP MENU button
To back to the top of the menu. (v p. 83)
IENTER button
This determines the selection. (v p. 83)
JCursor buttons (uio p)
These select items. (v p. 83)
KSEARCH button
This displays the search menu. (v p. 39, 43, 46, 57)
LNumber buttons (0 – 9, +10)
These enter letters or numbers into the unit. (v p. 84)
MRANDOM button
Switches the random playback. (v p. 33, 36, 43, 54, 57)
NREPEAT button
Switches to the repeat playback. (v p. 33, 36, 43, 54, 57)
Contents Connections Playback
Settings Tips Appendix
15
Front/Top
panel Rear panel
Remote control unit Index

.
CH
CH
TUNER
TUNER
ADD
ADD
CALL
CALL
CD
CD
POWER
POWER
CLOCK
CLOCK
DIMMER
DIMMER
SLEEP
SLEEP
FAVORITES
FAVORITES
TOP MENU
TOP MENU
INFO
INFO
SETUP
SETUP
SEARCH
SEARCH
VOLUME
VOLUME
MODE
MODE
PROGRAM
PROGRAM
REP
REPE
AT
AT
RANDO
RANDOM
MUSIC
MUSIC
SERVER
SERVER
DIGITAL IN
DIGITAL IN
ANALOG IN
ANALOGIN
INTERN
INTERN
ET
ET
RADIO
RADIO
. /
. /
ABC
ABC
a/A
DEF
DEF
GHI
GHI
JKL
JKL
MNO
MNO
PQRS
PQRS
TUV
TUV
WXYZ
WXYZ
*
*
CLEAR
CLEAR
1 2 3
4 5 6
7 8 9
+1
+10 0
SDB
SDB
TONE
TONE
CH
CH
MUTE
MUTE
ENTER
ENTER
TUNE
TUNE
TUNE
TUNE
Blu
Bluetooth
iPo
iPod/
USB
USB
Q7
Q9
W0
Q8
W1
W2
W3
Q6
Q5
ODIMMER button
Adjust the display brightness of this unit. (v p. 80)
PPOWER button (X)
This turns the power on/standby. (v p. 31)
QVOLUME buttons (df)
These adjust the volume level. (v p. 32)
RInformation button (INFO)
This switches display items such as the elapsed time, album name and
title name in the playback screen.
(v p. 34, 36, 39, 43, 54, 57)
SMUTE button (:)
This mutes the output audio. (v p. 32)
TSETUP button
The setting menu is displayed on the display. (v p. 83)
UCLEAR button
This cancels the settings. (v p. 34, 51, 85)
VMODE button
This switches the operation mode. (v p. 36, 46, 54)
WPROGRAM button
This sets program playback. (v p. 34)
Contents Connections Playback
Settings Tips Appendix
16
Front/Top
panel Rear panel
Remote control unit Index

oContents
Speaker connection 18
Connecting an analog device 21
Connecting a digital device 21
Connecting an iPod or USB memory device to the USB port 22
Connecting an FM/AM antenna 24
Connecting to a home network (LAN) 26
Connecting the power cord 29
NOTE
0Do not plug in the power cord until all connections have been completed.
0Do not bundle power cords with connection cables. Doing so can result in noise.
oCables used for connections
Provide necessary cables according to the devices you want to connect.
Speaker cable
.
Subwoofer cable
.
Optical cable
.
Audio cable
.
R
L
R
L
LAN cable
.
Contents Connections Playback Settings Tips Appendix
Connections
17
Front/Top
panel Rear panel
Remote control unit Index

Speaker connection
Here we connect the speakers in the room to this unit.
This section explains how to connect them using typical examples.
NOTE
0Disconnect this unit’s power plug from the power outlet before connecting the
speakers. Also, turn off the subwoofer.
0Connect so that the speaker cable core wires do not protrude from the speaker
terminal. The protection circuit may be activated if the core wires touch the rear
panel or if the + and - sides touch each other. “Protection circuit” (v p. 128)
0Never touch the speaker terminals while the power cord is connected. Doing so
could result in electric shock.
0Use speakers with an impedance of 4 – 16 Ω/ohms.
Connecting the speaker cables
Connect the speaker cable with a rubber tube (red) to the + speaker
terminal (red), and the other cable to the - speaker terminal (black).
1Peel off about 10 mm of sheathing from the tip of the
speaker cable, then twist the core wire tightly.
.
2Push the speaker terminal and insert the speaker cable
into the cable insertion slot.
.
3Release your finger from the speaker terminal to fix the
speaker cable.
.
Contents Connections Playback
Settings Tips Appendix
18
Front/Top
panel Rear panel
Remote control unit Index

NOTE
Ensure that only the core wire part of the speaker cable is inserted. If the covered
part is inserted, sound may not be output.
.
Connecting the subwoofer
Use a subwoofer cable to connect the subwoofer.
.
NETWORK
SPEAKERS
IMPEDANCE : 4~16
ANALOG IN
L
R
L
R
DIGITAL IN
OPTICAL
CONNECT Wi-Fi
iOSWPS
1
2
SUB WOOFER
OUT
SW
Contents Connections Playback
Settings Tips Appendix
19
Front/Top
panel Rear panel
Remote control unit Index

Connecting speakers
.
NETWORK ANALOG IN
L
R
DIGITAL IN
OPTICAL
CONNECT Wi-Fi
SUB WOOFER
OUT
iOSWPS
1
2
SPEAKERS
IMPEDANCE : 4~16
L
R
wqwq
RL
Contents Connections Playback
Settings Tips Appendix
20
Front/Top
panel Rear panel
Remote control unit Index
