Denon AV SURROUND RECEIVER AVR-5308CI User manual

AV SURROUND RECEIVER
AVR-5308CI
Owner’s Manual
GraphicalUserInterface
Use this manual in combination with the operating
guide displayed on the GUI screen.
GUI Menu Operation (vpage 25)
GUI Menu Map (vpage 26)
Language (vpage 44)
Remote Control Unit Operations (vpage 78)
AVR5308CIEU_100_初校作成中.indd 1 2008/05/26 9:36:32

nSAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCETHE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICINGTO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
SAFETY INSTRUCTIONS
1. Read Instructions – All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions – The safety and operating instructions should be
retained for future reference.
3. Heed Warnings – All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions – All operating and use instructions should be followed.
5. Cleaning – Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners.
6. Attachments – Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture – Do not use this product near water – for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement;
or near a swimming pool; and the like.
8. Accessories – Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only with a cart, stand,
tripod, bracket, or table recommended by the manufacturer, or sold with the
product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
9. A product and cart combination should be moved
with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart
combination to overturn.
10. Ventilation – Slots and openings in the cabinet are provided for ventilation
and to ensure reliable operation of the product and to protect it from
overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been adhered to.
11. Power Sources – This product should be operated only from the type of
power source indicated on the marking label. If you are not sure of the type
of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other
sources, refer to the operating instructions.
12. Grounding or Polarization – This product may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature.
If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug.
13. Power-Cord Protection – Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the product.
15. Outdoor Antenna Grounding – If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size
of grounding conductors, location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode. See
Figure A.
16. Lightning – For added protection for this product during a lightning storm,
or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and power-line surges.
17. Power Lines – An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits, or
where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
18. Overloading – Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
19. Object and Liquid Entry – Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock. Never spill liquid of any kind
on the product.
20. Servicing – Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
21. Damage Requiring Service – Unplug this product from the wall outlet
and refer servicing to qualified service personnel under the following
conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance – this
indicates a need for service.
22. Replacement Parts – When replacement parts are required, be sure the
service technician has used replacement parts specified by the manufacturer
or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
23. Safety Check – Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to determine that the
product is in proper operating condition.
24. Wall or Ceiling Mounting – The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
25. Heat – The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers) that
produce heat.
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL
ELECTRICAL CODE "/5&//"
-&"%*/
8*3&
(306/%
$-".1
&-&$53*$
4&37*$&
&26*1.&/5
"/5&//"
%*4$)"3(&6/*5
/&$4&$5*0/
(306/%*/($0/%6$5034
/&$4&$5*0/
(306/%$-".14
108&34&37*$&(306/%*/(
&-&$530%&4:45&.
/&$"351"35)
/&$/"5*0/"-&-&$53*$"-$0%&
I
AVR5308CIEU_100_初校作成中.indd 2 2008/05/26 9:36:35

• Avoid high temperatures.
Allow for sufficient heat dispersion when
installed in a rack.
• Eviter des températures élevées.
Tenir compte d’une dispersion de chaleur
suffisante lors de l’installation sur une
étagère.
• Handle the power cord carefully.
Hold the plug when unplugging the cord.
• Manipuler le cordon d’alimentation avec
précaution.
Tenir la prise lors du débranchement du
cordon.
• Keep the unit free from moisture, water,
and dust.
• Protéger l’appareil contre l’humidité, l’eau
et la poussière.
• Unplug the power cord when not using the
unit for long periods of time.
• Débrancher le cordon d’alimentation
lorsque l’appareil n’est pas utilisé pendant
de longues périodes.
* (For apparatuses with ventilation holes)
• Do not obstruct the ventilation holes.
• Ne pas obstruer les trous d’aération.
• Do not let foreign objects into the unit.
• Ne pas laisser des objets étrangers dans
l’appareil.
• Do not let insecticides, benzene, and
thinner come in contact with the unit.
• Ne pas mettre en contact des insecticides,
du benzène et un diluant avec l’appareil.
• Never disassemble or modify the unit in
any way.
• Ne jamais démonter ou modifier l’appareil
d’une manière ou d’une autre.
nNOTE ON USE / OBSERVATIONS RELATIVES A L’UTILISATION
II
FCC Information (For US customers)
1. COMPLIANCE INFORMATION
Product Name: AV Surround Receiver
Model Number: AVR-5308CI
This product contains FCC ID: BV2- MPGBR052.
This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
product may not cause harmful interference, and (2) this product must accept any interference received, including
interference that may cause undesired operation.
Denon Electronics (USA), LLC
100 Corporate Drive, Mahwah, NJ 07430-2041
Tel. [phone] (Main)
2. IMPORTANT NOTICE: DO NOT MODIFY THIS PRODUCT
This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements.
Modification not expressly approved by DENON may void your authority, granted by the FCC, to use the product.
3. CAUTION
• To comply with FCC RF exposure compliance requirement, separation distance of at least 20 cm must be
maintained between the antenna of this product and all persons.
• This product and its antenna must not be co-located or operating in conjunction with any other antenna or
transmitter.
4. NOTE
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This product generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this product does cause harmful interference to radio or
television reception, which can be determined by turning the product OFF and ON, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the local retailer authorized to distribute this type of product or an experienced radio/TV technician for
help.
IC Information (For Canadian customers)
1. PRODUCT
This product contains IC 6963A-MPGBR052.
This product complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions:
(1) this product may not cause harmful interference, and (2) this product must accept any interference received,
including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
APPAREIL
Cet appareil contiens IC 6963A- MPGBR052.
Cet appareil est conforme à la norme CNR-210 du Canada. L
’utilisation de ce dispositif est autorisée seulement
aux deux conditions suivantes : (1) il ne doit pas produire de brouillage, et (2) l’utilisateur du dispositif doit être
prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le
fonctionnement du dispositif.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
2. CAUTION
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.
ATTENTION
Afin de réduire le risque d’interférence aux autres utilisateurs, il faut choisir le type d’antenne et son gain de façon à
ce que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne soit pas supérieure au niveau requis pour l’obtention
d’une communication satisfaisante.
AVR5308CIEU_100_初校作成中.indd 3 2008/05/26 9:36:37


Accessories ·····················································································3
Cautions on Handling·····································································3
Cautions on Installation·································································3
About the Remote Control Unit····················································3
Inserting the Batteries ·······························································3, 4
Operating Range of the Remote Control Unit································ 4
Part Names and Functions ····························································4
Front Panel················································································· 4, 5
Display ···························································································5
Rear Panel······················································································ 6
Remote Control Unit ······································································ 7
Getting Started
Preparations····················································································8
Cables Used for Connections ························································8
Video Conversion Function ····························································9
Speaker Installation ·····································································10
Speaker Layout ············································································10
Speaker Connections ····························································· 10, 11
Connecting Equipment with HDMI connectors························· 12
Connecting the Monitor·······························································13
Connecting the Playback Components ······································ 13
DVD Player··················································································· 13
Record Player··············································································· 14
CD Player ·····················································································14
iPod®····························································································14
TV/CABLE Tuner ··········································································15
Satellite Receiver ·········································································15
Connecting the Recording Components ····································16
Digital Video Recorder ·································································16
Video Cassette Recorder ·····························································17
CD Recorder / MD Recorder / Tape Deck····································17
Connections to Other Devices·····················································18
Components Equipped with a DENON LINK connector ··············18
Video Camera / Game Console ···················································· 18
Component with Multi-channel Output connectors····················· 18
External Power Amplifier ·····························································19
USB Port ······················································································19
XM connector ··············································································20
Antenna terminals ·······································································21
Network Audio ············································································· 22
Multi Zone···················································································· 23
External Controller ·······································································24
Connecting the Power Cord ························································ 24
Once Connections are Completed ·············································· 24
Connections
Preparations··················································································27
Auto Setup····················································································27
aAuto Setup········································································27, 28
Error Messages·······································································29
sOption ·····················································································29
dParameter Check ····································································29
Auto Setup
Source Select
Contents
Surround Mode
Example of the Display of the GUI Mark at a Title···················· 25
Example of Display of Default Values ········································25
Examples of GUI Screen Displays···············································25
Example: Browse Menu (Top Menu) ··········································· 25
Example: Menus with Illustrations (Auto Setup)·························· 25
Cursor Position Display ································································ 25
Operations·····················································································25
GUI Menu Map··············································································26
GUI Menu Operations
Speaker Setup ··············································································30
aSpeaker Configuration·····························································30
sSubwoofer Setup····································································30
dDistance··················································································31
fChannel Level ·········································································31
gCrossover Frequency························································31, 32
hTHX Audio Setup·····································································32
jSurround Speaker ···································································32
HDMI Setup···················································································33
aColor Space·············································································33
sRGB Range ·············································································33
dAuto Lip Sync··········································································33
fAudio·······················································································33
gMonitor Out ············································································33
hHDMI Control··········································································33
Audio Setup ··················································································34
aEXT. IN Setup··········································································34
s2ch Direct/Stereo····································································34
dDownmix Option·····································································34
fAuto Surround Mode ······························································ 34
gManual EQ ··············································································35
Network Setup ·············································································35
aNetwork Setup································································35 ~ 38
sOther·······················································································38
dNetwork Information·······························································38
Zone Setup····················································································39
aZONE2 ····················································································39
sZONE3 ····················································································39
dOSD ························································································39
Option Setup·················································································39
aAmp Assign·············································································40
sVolume Control ·······································································40
Manual Setup
dSource Delete ·········································································40
fGUI··························································································40
gQuick Select Name ·································································40
hTrigger Out 1···········································································41
jTrigger Out 2···········································································41
kTrigger Out 3···········································································41
lTrigger Out 4···········································································41
A0 Transducer Setup····································································41
A1 Digital Out···············································································41
A2 Remote ID···············································································41
A3 2Way Remote·········································································41
A4 Dimmer···················································································42
A5 Setup Lock··············································································42
A6 Maintenance Mode·································································42
A7 Firmware Update ····································································42
A8 Add New Feature····································································42
Language·······················································································43
Input Source Selection·································································43
Settings Related to Playing Input Sources ································ 44
aPlay ·························································································44
sAuto Preset·············································································44
dPreset Skip··············································································44
fPreset Name···········································································44
gVideo·······················································································45
hInput Mode ······································································· 45, 46
jRename···················································································46
kSource Level ···········································································46
lPlayback Mode (iPod)······························································46
A0 Assign ···············································································46, 47
A1 Playback Mode········································································47
A2 Still Picture··············································································47
A3 Antenna Aiming ······································································47
HOME THX CINEMA·····································································48
Surround Playback of 2-channel Sources·····································48
Playing Multi-channel Sources (Dolby Digital, DTS, etc.) ·············48
Standard Playback········································································48
Surround Playback of 2-channel Sources·····································48
Playing Multi-channel Sources (Dolby Digital, DTS, etc.) ·············49
Dolby Headphone ········································································49
DSP Simulation Playback ····························································49
Stereo Playback············································································49
Direct Playback ·············································································50
Playback in the PURE DIRECT Mode··········································· 50
AVR5308CIEU_100_初校作成中.indd 1 2008/05/26 9:36:39


Multi-Zone Settings with the Amp Assign Function ········85 ~ 88
Multi-Zone Settings and Operations ··········································89
Multi-Zone Operations·································································90
Turning the Power On and Off·····················································90
Selecting the Input Source···························································90
Adjusting the Volume···································································90
Turning off the Sound Temporarily ··············································90
Amp Assign / Multi-Zone Connections and Operations
Troubleshooting ······························································106 ~ 110
Specifications····································································· 110, 111
Other Information······························································91 ~ 105
List of preset codes ··········································· End of this manual
Audio ·····························································································50
aSurround Parameters······················································50 ~ 52
sTone························································································52
dRoom EQ ················································································53
fDynamic EQ············································································53
gRESTORER ·············································································53
hNight Mode·············································································53
jAudio Delay·············································································54
Picture Adjust ···············································································54
aContrast ··················································································54
sBrightness···············································································54
dChroma Level··········································································54
fHue ·························································································54
gDNR ························································································54
hEnhancer·················································································54
jSharpness ···············································································54
Parameter
Status ····························································································54
aMAIN ZONE············································································54
sZONE2/3/4 ··············································································54
Audio Input Signal········································································55
HDMI Information·········································································55
aSignal Information···································································55
sMonitor1 ·················································································55
dMonitor2 ·················································································55
Auto Surround Mode ··································································· 55
Quick Select ··················································································55
Preset Station ···············································································55
Information
Playback
Main Remote Control Unit ··························································76
Operating DENON Audio Components········································ 76
Presetting·····················································································76
Operating Preset Components ············································76 ~ 78
Setting the Remote ID ································································· 79
Learning Function ········································································79
System Call Function ···································································80
Punch Through Function ······························································ 80
Setting the Time the Backlight Stays Lit······································81
Adjusting the Backlight’s Brightness ···········································81
Resetting the Main Remote Control Unit ····································81
Sub Remote Control Unit Operations ·································· 82, 83
Switching Zones ··········································································84
Setting the Zone for Which the Sub Remote Control Unit is Used
(ZONE SELECT LOCK Mode)·······················································84
Setting the Remote ID ································································· 84
Resetting the Settings ·································································84
Remote Control Unit Operations
Other Operations··········································································71
Playing Super Audio CD ······························································· 71
Recording on an External Device (REC OUT mode) ·············· 71, 72
Convenient Functions ··································································73
HDMI Control Function ································································ 73
Channel Level ··············································································74
Fader Function ·············································································74
Quick Select Function ·································································· 74
Personal Memory Plus Function ·················································· 75
Last Function Memory·································································75
Backup Memory···········································································75
Resetting the Microprocessor ····················································· 75
Other Operations and Functions
Preparations··················································································56
Turning the Power On··································································56
Operations During Playback·························································56
Playing Video and Audio Equipment··········································56
Basic Operation············································································56
Listening to FM/AM Broadcasts ················································· 57
Basic Operation············································································57
Presetting Radio Stations (Preset Memory)································· 57
Listening to Preset Stations·························································58
RDS (Radio Data System) ····························································58
RDS Search·················································································· 58
PTY Search···················································································59
TP Search····················································································· 59
RT (Radio Text)·············································································59
Listening to XM Satellite Radio Programs·································60
Basic Operation············································································60
Checking the XM Signal Strength and Radio ID··························· 60
Searching Categories ··································································· 61
Accessing XM Radio Stations Directly·········································61
Listening to HD Radio Stations···················································61
Basic Operation············································································62
Selecting Audio Programs····························································62
Check the HD Radio Reception Information ································62
iPod®Playback·············································································63
Basic Operation············································································63
Listening to Music ·································································63, 64
Viewing Still Pictures or Videos on the iPod ································64
Playing Network Audio,
USB Memory Devices or Rhapsody······································64, 65
Basic Operation······································································65, 66
Listening to Internet Radio···························································66
Playing Files Stored on a Computer·············································67
Playing Files Stored on USB Memory Devices ······················67, 68
Listening to Rhapsody ···························································68, 69
Operating the AVR-5308CI Using a Browser (Web control) ··69, 70
AVR5308CIEU_100_初校作成中.indd 2 2008/05/26 9:36:40


Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
In addition to the AVR-5308CI, the included main remote control unit
(RC-1067) can also be used to operate the equipment listed below.
q DENON system components
w Non-DENON system components
• By setting the preset memory (vpage 76 ~ 78)
• By using the learn function (vpage 79)
qLift the clasp and remove the rear lid.
ePut the rear cover back on.
(RC-1067) (RC-1070)
(RC-1067) (RC-1070)
LR6/AA
R03/AAA
wLoad the two batteries properly as indicated by the marks in the
battery compartment.
About the Remote Control Unit
Inserting the Batteries
• Before turning the power switch on
Check once again that all connections are correct and that there are
no problems with the connection cables.
• Power is supplied to some of the circuitry even when the unit is
set to the standby mode. When traveling or leaving home for long
periods of time, be sure to unplug the power cord from the power
outlet.
• About condensation
If there is a major difference in temperature between the inside of
the unit and the surroundings, condensation (dew) may form on
the operating parts inside the unit, causing the unit not to operate
properly.
If this happens, let the unit sit for an hour or two with the power
turned off and wait until there is little difference in temperature
before using the unit.
• Cautions on using mobile phones
Using a mobile phone near this unit may result in noise. If so, move
the mobile phone away from this unit when it is in use.
• Moving the unit
Turn off the power and unplug the power cord from the power
outlet.
Next, disconnect the connection cables to other system units before
moving the unit.
• Note that the illustrations in these instructions may differ from the
actual unit for explanation purposes.
Note:
For proper heat dispersal, do not install this unit in a confined
space, such as a bookcase or similar enclosure.
bNote
b
Wall
b
b
Cautions on Handling
Cautions on Installation
Check that the following parts are supplied with the product.
qOwner’s manual ...................................................................... 1
wWarranty (for North America model only)................................ 1
eService station list ................................................................... 1
rPower cord (Cord length: Approx. 5 ft /1.5 m) ........................ 1
tMain remote control (RC-1067) ............................................... 1
yLR6/AA batteries (for RC-1067) ............................................... 2
uSub remote control (RC-1070)................................................. 1
iR03/AAA batteries (for RC-1070)............................................. 2
oFM indoor antenna .................................................................. 1
Q0 AM loop antenna (small, for AM broadcasts) .......................... 1
Q1 AM loop antenna (large, for HD Radio broadcasts) ................. 1
Q2 Dipole antenna (for HD Radio broadcasts) .............................. 1
Q3 Rod antenna for wireless LAN connection.............................. 1
Q4 Setup microphone (Cord length: Approx. 25 ft / 7.6 m) .......... 1
r t u
Q1
o
Q4Q3
Q0
Q2
Thank you for purchasing this DENON product. To ensure proper
operation, please read this owner’s manual carefully before using the
product.
After reading them, be sure to keep them for future reference.
Getting Started
Accessories
Getting Started
AVR5308CIEU_100_初校作成中.indd 3 2008/05/26 9:36:42


Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
For buttons not explained here, see the page indicated in parentheses ( ).
q w e r t
yioQ0
Q1 Q2 Q3 Q4
u
Part Names and Functions
Front Panel
qPower operation button
(ON/STANDBY) ·······································································(56)
wPower indicator ·······································································(56)
ePower switch (hON jOFF) ··················································(56)
rDoor ····························································································(5)
tQUICK SELECT buttons / indicators······································ (74)
yMASTER VOLUME control knob············································(56)
uMaster volume indicator
iDisplay························································································(5)
oRemote control sensor ·····························································(4)
Q0 SOURCE SELECT knob ···························································(43)
Q1 SOURCE button·······································································(43)
Q2 TUNING PRESET button·························································(57)
Q3 ZONE2/3/4 / REC SELECT button····································(71, 90)
Q4 VIDEO SELECT button ····························································(45)
30°
30°
Approx. 23 feet / 7 m
or
(RC-1067)
(RC-1070)
NOTE
• Replace the batteries with new ones if the set does not operate
even when the remote control unit is operated close to the unit.
• The supplied batteries are only for verifying operation.
• When inserting the batteries, be sure to do so in the proper direction,
following the “q” and “w” marks in the battery compartment.
• To prevent damage or leakage of battery fluid:
• Do not use a new battery together with an old one.
• Do not use two different types of batteries.
• Do not attempt to charge dry batteries.
• Do not short-circuit, disassemble, heat or dispose of batteries in
flames.
• If the battery fluid should leak, carefully wipe the fluid off the inside
of the battery compartment and insert new batteries.
• Remove the batteries from the remote control unit if it will not be in
use for long periods.
• When replacing the batteries, have the new batteries ready and
insert them as quickly as possible.
Operating Range of the Remote Control
Unit
Point the remote control unit at the remote sensor when operating it.
NOTE
The set may function improperly or the remote control unit may not
operate if the remote control sensor is exposed to direct sunlight,
strong artificial light from an inverter type fluorescent lamp or infrared
light.
Getting Started
AVR5308CIEU_100_初校作成中.indd 4 2008/05/26 9:36:45


Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
t
uQ4Q8Q9 o iQ1Q0Q6 Q2 Q3Q5Q7 y
wq e r
qInput signal indicators
wInput signal channel indicators
These light when digital signals are input.
eInformation display
The input source name, surround mode, setting
values and other information are displayed
here.
rOutput signal channel indicators
tSurround speaker indicators
These light according to the settings of the
surround A and B speakers.
yMonitor output indicators
These light according to the HDMI monitor
output setting. When set to “Auto (Dual)”, the
indicators light according to the connection
status.
uMaster volume indicator
iAUDYSSEY DYNAMIC EQ indicator
This lights when the Dynamic EQ is selected.
oAUDYSSEY MULTEQ XT indicator
This lights when the room equalizer is selected.
Q0 Recording output source indicator
This lights when the REC OUT mode is
selected.
Q1 NIGHT indicator
This lights when the night mode is selected.
Q2 Multi zone indicators
These light when the power for the respective
zone is turned on.
Q3 RESTORER indicator
This lights when the RESTORER mode is
selected.
Q4 ADVANCED AL24 indicator
This lights when Advanced AL24 Processing is
activated (vpage 95).
Q5 D.LINK indicator
This lights when playing using DENON LINK
connections.
Q6 Input mode indicators
Q7 HDMI indicator
This lights when playing using HDMI
connections.
Q8 Decoder indicators
These light when the respective decoders are
operating.
Q9 Tuner reception mode indicators
These light according to the reception conditions
when the input source is set to “TUNER” or
“HD Radio”.
• AUTO
This lights when in the auto tuning mode.
• RDS
These light when receiving RDS broadcasts.
• STEREO
In the FM mode, this lights when receiving
analog stereo broadcasts.
• TUNED
This lights when the broadcast is properly tuned
in.
Display
qDIRECT/STEREO button ···························· (49)
wHeadphones jack (PHONES)················ (56, 72)
eCINEMA button ·········································· (48)
rRESTORER button······································ (53)
tMUSIC button············································· (48)
yNIGHT button ············································· (53)
uMENU button·············································· (25)
iCH SEL / ENTER button························(25, 74)
oRETURN button ·········································· (25)
Q0 V.AUX INPUT connectors·························· (18)
Q1 ROOM EQ button ······································· (53)
Q2 SETUP MIC jack ·········································· (27)
Q3 DYNAMIC EQ button·································· (53)
Q4 STATUS button ·········································· (55)
Q5 DIMMER button·········································· (42)
Q3Q4Q5Q6Q7Q8Q9W0W1W2W3W4W5W6W7W8W9
q w e r t y u i o Q0 Q1 Q2
GWith the door openH
Q6 SCALE button ············································· (45)
Q7 USB port······················································ (19)
Q8 ZONE4 ON/OFF button······························ (90)
Q9 ZONE3 ON/OFF button······························ (90)
W0 ZONE2 ON/OFF button······························ (90)
W1 AUDIO DELAY button ································ (54)
W2 Cursor buttons (uio p)·························· (25)
W3 GAME button········································ (14, 48)
W4 INPUT MODE button·································· (45)
W5 7CH STEREO button··································· (49)
W6 DSP SIMULATION button·························· (49)
W7 HOME THX CINEMA button ······················ (48)
W8 STANDARD button····································· (48)
W9 PURE DIRECT button ································· (50)
Getting Started
AVR5308CIEU_100_初校作成中.indd 5 2008/05/26 9:36:47


Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
q
W0 W1 W2
w e r t y
ui
oQ0Q1Q2Q3Q4Q5Q6Q7Q8Q9u
qRS-232C connector····································· (24)
wAnalog audio connectors (AUDIO) ··········· (13)
ePRE OUT connectors···························· (19, 23)
rEXT. IN connectors····································· (18)
tAC inlet (AC IN)··········································· (24)
yAC OUTLETS··············································· (24)
uSpeaker terminals (SPEAKERS) ················ (10)
iHD Radio antenna terminals
(DTU ANTENNA) ········································ (21)
oCOMPONENT VIDEO connectors·············· (13)
Q0 Digital audio connectors
(OPTICAL / COAXIAL / BNC) ··············· (13, 23)
Q1 HDMI connectors········································ (12)
Q2 ETHERNET connector ································ (22)
Q3 USB port······················································ (19)
Q4 XM connector (SAT TU)····························· (20)
Q5 WLAN ANTENNA terminal ························ (22)
Q6 FM/AM antenna terminals
(TUNER ANTENNA)···································· (21)
Q7 DENON LINK connector····························· (18)
Rear Panel
Q8 TRIGGER OUT jacks ··································· (24)
Q9 REMOTE CONTROL jacks ·························· (23)
W0 DOCK CONTROL jack ································· (14)
W1 SIGNAL GND terminal ······························· (14)
W2 VIDEO / S-VIDEO connectors···················· (13)
Getting Started
AVR5308CIEU_100_初校作成中.indd 6 2008/05/26 10:17:10


Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
q
i
w
e
r
t
y
u
o
Q1
Q3
Q4
Q2
Q0
Q5
Q6
Q7
Q9
W0
W2
W5
W7
W6
W4
W3
W1
Q8
qSignal transmission indicator ··················· (76)
wMode select buttons ·································· (76)
eQuick select / System call buttons······(74, 80)
rSurround mode buttons ····················(48 ~ 50)
tSystem buttons ·····································(77, 78)
yAudio delay button (A. DL)························ (54)
uTuner system buttons································ (57)
iInput mode button (INPUT)······················· (45)
oMENU button·············································· (25)
Q0 Cursor buttons (uio p)························· (25)
Q1 Parameter / Search button
(PARA / SRCH)·························· (50, 58, 61, 64)
Q2 Monitor select (M. SEL) /
HOME button········································ (33, 76)
Q3 Channel buttons (CH)································· (57)
Q4 Input source select /
Number buttons ··································· (43, 56)
Q5 Remote control signal transmitter ············· (4)
Q6 Device select indicators (DEV1 / DEV2) ··· (76)
Q7 ZONE3 / ZONE4 select indicators
(Z3 / Z4) ······················································· (90)
Q8 RESTORER button (RSTR) ························· (53)
Q9 Night button (NGT) ···································· (53)
W0 Test tone button (TEST) ···························· (31)
W1 Surround speaker select button (SPKR)···· (32)
W2 POWER buttons·········································· (56)
W3 Channel select (CH SEL) /
ENTER button ········································(25, 74)
W4 Return button (RTN) ·································· (25)
W5 Master volume control buttons (VOL) ····· (56)
W6 Muting button (MUTE) ························ (56, 90)
W7 Main remote control unit setup button
(RC SETUP) ················································· (76)
q
r
t
y
i
o
Q0
u
e
w
Q4
Q7
Q8
Q9
W0
Q6
Q5
Q2
Q3
Q1
qZONE indicators ········································· (84)
wAdvanced setup button ····························· (84)
eInput source select buttons······················· (43)
rCHANNEL buttons······································ (57)
tSHIFT button··············································· (57)
yMENU button·············································· (25)
uCursor buttons (uio p)························· (25)
iSEARCH button ······························ (58, 61, 64)
oREPEAT button ··········································· (63)
Q0 RANDOM button ········································ (64)
Q1 Remote control signal transmitter ············· (4)
Q2 ZONE SELECT button ································ (84)
Q3 Zone power on/off buttons
(ZONE ON / ZONE OFF) ····························· (90)
Q4 Master volume control buttons
(VOLUME) ·················································· (56)
Q5 Muting button (MUTE) ························ (56, 90)
Q6 ENTER button ············································· (25)
Q7 RETURN button ·········································· (25)
Q8 System buttons ·······························(57, 82, 83)
Q9 ALL MUSIC/FAVORITES
(DIRECT PLAY) button ······························ (82)
W0 USB (DIRECT PLAY) button······················· (82)
nMain remote control unit (RC-1067) nSub remote control unit (RC-1070)
The time for which the backlight stays on can
be changed (vpage 81 “Setting the Time the
Backlight Stays Lit”).
Remote Control Unit
NOTE
The ZONE2 mode QUICK SELECT (1 ~ 3), A. DL,
RSTR, NGT, INPUT, SPKR, TEST and surround
mode buttons cannot be used.
NOTE
The AUX-1, AUX-2, AUX-3 and OPTION buttons
cannot be used.
Getting Started
AVR5308CIEU_100_初校作成中.indd 7 2008/05/26 9:36:56


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
Audio cables Video cables
Coaxial digital connections
(Orange)
Coaxial digital (75 Ω/ohms pin-plug) cable
Optical digital connections
Optical cable
BNC digital connections
BNC (75 Ω/ohms) cable
Analog connections (stereo)
(White)
(Red)
R
L
R
L
Stereo pin-plug cable
Analog connections (monaural, for subwoofer)
(Black)
Pin-plug cable
DENON LINK connections
DENON LINK cable
Speaker connections
Speaker cables
Network connections (wired LAN)
Ethernet cable
Component video connections
(Green)
(Blue)
(Red)
(Y)
(PB/CB)
(PR/CR)
Component video cable
(Green)
(Blue)
(Red)
(Y)
(PB/CB)
(PR/CR)
BNC (75 Ω/ohms) cable
S-Video connections
S-Video cable
Video connections
(Yellow)
75 Ω/ohms pin-plug video cable
Audio and video cables
HDMI connections
19-pin HDMI cable
Signal direction
Audio signal: Video signal:
Output
Input
Input
Output
Output
Input
Input
Output
Connections
NOTE
• Do not plug in the power cord until all connections have been
completed.
• When making connections, also refer to the operating instructions of
the other components.
• Be sure to connect the left and right channels properly (left with left,
right with right).
• Do not bundle power cords together with connection cables. Doing
so can result in humming or noise.
Connections for all compatible audio and video signal formats are
described in these operating instructions. Please select the types
of connections suited for the equipment you are connecting.
With some types of connections, certain settings must be made
on the AVR-5308CI. For details, refer to the instructions for the
respective connection items below.
Cables Used for Connections
Select the cables according to the equipment being connected.
Preparations
Connections
AVR5308CIEU_100_初校作成中.indd 8 2008/05/26 9:37:04


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
GFlow of video signals for ZONE2H
• This function automatically converts various formats of video signals input to the AVR-5308CI into the
format used to output the video signals from the AVR-5308CI to a monitor.
• The AVR-5308CI’s video input/output circuitry is compatible with the following four types of video
signals:
Digital video signals: HDMI
Analog video signals: Component video, S-Video and Video
Video Conversion Function
GFlow of video signals inside the AVR-5308CIH
MAIN ZONE
High picture
quality playback HDMI connector
Component video
connectors
S-Video connector
Video connector
Monitor
HDMI connector
Component video
connectors
S-Video connector
Video connector
Video inputs Video outputs
: When 480i/576i signals are input
Component video
connectors
S-Video connector
Video connector
Component video
connectors
Video connector
Video inputs Video outputs
ZONE2
NOTE
• For optimum video performance, THX recommends that you set the conversion mode to “OFF” to use
video signals pass through system without up conversion.
Example: The video input signals from the component video can be enjoyed through the video output
signals from the component video.
• HDMI signals cannot be converted into analog signals.
• 1080p component input video signals cannot be output to anything other than component video
connectors.
• 480p/576p, 1080i and 720p component video input signals cannot be converted into S-Video or Video
format.
• When using the component video output connectors for connection to the ZONE2 monitor, the ZONE2’s
on-screen display is not displayed.
• When a non-standard video signal from a game machine or some other source is input, the video
conversion function might not operate.
• When not using this function, connect a monitor output with the same type of connector as the video
input connector.
• The resolution of the HDMI input-compatible monitor connected to the AVR-5308CI can be checked at
GUI menu “Information” – “HDMI Information” – “Monitor1” or “Monitor2” (vpage 55).
High picture
quality playback
ZONE2
monitor
GFlow of video signals for ZONE3H
S-Video connector
Video connector Video connector
Video inputs Video outputs
ZONE3
High picture
quality playback ZONE3
monitor
S-Video connector
Connections
AVR5308CIEU_100_初校作成中.indd 9 2008/05/26 9:37:07

0
Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
Speaker Installation
(L)
(R)
w q w q
*/
(L)
(R)
(R) (L) (R) (R)
(L)
(L)
w q w q w q
w q
w q w q w q w q
w q
*/ */
The illustration below shows a basic example of installation of the amplifier combined with 8 speakers and
a monitor.
Speaker Layout
Subwoofer Center speaker
Surround speakers
Front speakers
Place the front speakers to the
sides of the monitor or screen and
as flush with the screen surface as
possible.
Surround back speakers
The table below shows a typical speaker configuration for the AVR-5308CI.
FRONT CENTER
SURROUND
A
SURROUND
BSURROUND BACK SUBWOOFER
(b)
L R L R L R L R 1 only
9.1-channels S S S S S S S S S –S
7.1-channels S S S S S – – S S –S
6.1-channels S S S S S – – – – S S
5.1-channels S S S S S – – – – – S
3.1-channels S S S – – – – – – – S
2.1-channels S S – – – – – – – – S
2-channels S S – – – – – – – – –
Speaker Connections
Example: 9.3-channels and ZONE2 use
Front speaker (R) Center speaker Subwoofer 1
Subwoofer
with built-in
amplifier
Surround
speaker-
A (R)
Surround
speaker-
B (R)
ZONE2 speakers
ZONE2
When using just one surround back speaker, connect it to the left channel (SBL).
NOTE
By default, the AVR-5308CI’s “Amp Assign” setting is set to “ZONE2”, so sound is not output simply by
connecting a speaker to the surround back terminal. To use as the surround back speaker for the MAIN
ZONE, either turn the ZONE2 power off or change the “Amp Assign” setting (vpage 85 ~ 88).
bL : Left
R : Right
Two surround back speakers are required to use the THX Ultra2 Cinema,THX Music mode and THX Games
mode.
Set the surround back speakers so that the distance to the listening position is the same for both the left
and right speakers. It is also recommended that the deviations of the distance from the listening position
to L and R channel speakers (front left (FL) and front right (FR), surround left (SL) and surround right (SR),
surround back left (SBL) and surround back right (SBR)) is less than 2 ft (60 cm).
Front speaker (L)
Surround
back
speaker
(R)
Surround
speaker-
B (L)
Surround
speaker-
A (L)
b The AVR-5308CI can be connected to a maximum of 3 subwoofers.
Connections
Subwoofer with built-in
amplifier
Surround
back
speaker
(L)
Subwoofer 3 Subwoofer 2
AVR5308CIEU_100_初校作成中.indd 10 2008/05/26 9:37:17


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
Connecting the Speaker Cables
Carefully check the left (L) and right (R) channels and + (red) and –
(black) polarities on the speakers being connected to the AVR-5308CI,
and be sure to interconnect the channels and polarities correctly.
1Peel off about 0.03 ft/10 mm of sheathing from the tip of the speaker cable, then
either twist the core wire tightly or
terminate it.
2Turn the speaker terminal counterclockwise to loosen it.
3Insert the speaker cable’s core wire to the hilt into the speaker terminal.
4Turn the speaker terminal clockwise to tighten it.
When using a banana plug
Tighten the speaker terminal firmly before
inserting the banana plug.
NOTE
• Use speakers with an impedance of 6 to 16 Ω/ohms. When using
surround A and B speakers simultaneously, use speakers with an
impedance of 8 to 16 Ω/ohms.
• Connect the speaker cables in such a way that they do not stick out
of the speaker terminals. The protection circuit may be activated if
the core wires touch the rear panel or if the + and – sides touch each
other (v“Protection circuit”).
• Never touch the speaker terminals while the power supply is
connected. Doing so could result in electric shock.
Protection circuit
If speakers with an impedance lower than specified (for example
4 Ω/ohms speakers) are used for an extended period of time with
the volume turned up high, the temperature may rise, activating the
protection circuit.
When the protection circuit is activated, the speaker output is shut
off and the power indicator flashes red. If this happens, unplug
the power cord, then check the speaker cable and input cable
connections. If the set is extremely hot, wait for it to cool off and
improve ventilation around it. Once this is done, plug the power cord
back in and turn the set's power back on.
If the protection circuit is activated again even though there are no
problems in the ventilation around the set nor in the connections,
the set may be damaged. Turn the power off, then contact a DENON
service center.
Connections
AVR5308CIEU_100_初校作成中.indd 11 2008/05/26 9:37:20


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
With HDMI connections, the video and audio signals can be transferred
with a single cable.
065
)%.*
*/
)%.*
Compatible audio
format Details Discs (examples)
2-channel linear PCM 2ch 32-192 kHz
16/20/24 bits
CD, DVD-Video,
DVD-Audio
Multi-channel linear
PCM
8ch 32-192 kHz
16/20/24 bits DVD-Audio
Dolby Digital, DTS Bitstream DVD-Video
DSD
2/5.1ch
2.8224 MHz
1 bit
SACD
Dolby Digital Plus,
Dolby TrueHD,
DTS-HD
Bitstream HD DVD,
Blu-ray Disc
MonitorDVD player
bThe AVR-5308CI is supported to the feature of HDMI listed below.
• 30 and 36 bit Deep Color
• xvYCC
• Auto Lipsync Correction
Copyright protection system (HDCP)
In order to play the digital video and audio signals of a DVD- Video or
DVD-Audio disc using HDMI/DVI connections, both the connected
DVD player and monitor must be equipped for a copyright protection
system called “HDCP” (High-bandwidth Digital Content Protection).
HDCP is a copy protection technology consisting of data encoding
and mutual identification of the devices.
The AVR-5308CI is HDCP-compatible. For details on the DVD player
or monitor you are using, refer to its operating instructions.
• When the AVR-5308CI and DVD player are connected using an HDMI
cable, also connect the AVR-5308CI and monitor using an HDMI
cable.
• If the connected monitor or DVD player only has a DVI-D connector,
use an HDMI/DVI converter cable. When using a DVI cable, no audio
signals are transmitted.
• Use a Deep Color compatible cable for connection to Deep Color
compatible devices.
When connecting with an HDMI/DVI converter cable
(adapter)
• HDMI video signals are theoretically compatible with the DVI
format.
When connecting to a monitor, etc., equipped with a DVI-D
connector, connection is possible using an HDMI/DVI converter
cable, but depending on the combination of components in some
cases the video signals will not be output.
• When connecting using an HDMI/DVI converter adapter, the video
signals may not be output properly due to poor connections with
the connected cable, etc.
• By default, the HDMI audio signals are output from the speakers
connected to the AVR-5308CI.
• To output the sound from the TV, make the settings at GUI menu
“Manual Setup” – “HDMI Setup” – “Audio” – “TV” (vpage 33).
NOTE
• Use a CPPM-compatible DVD player to play DVD-Audio discs that are
copyright-protected by CPPM.
• The audio signals output from the HDMI connector (sampling
frequency, bit rate, etc.) may be restricted by the connected device.
• Video signals are not output properly when using devices that are
not HDCP-compatible.
• Video signals are not output if the input video signals do not match
the monitor’s resolution. In this case, switch the DVD player’s
resolution to a resolution with which the monitor is compatible.
• If the GUI menu “Manual Setup” – “HDMI Setup” – “Audio” setting
(vpage 33) is set to “Amp”, the sound may be interrupted when the
monitor’s power is turned off.
• Use a cable on which the HDMI logo is indicated (a certified HDMI
product) for connection to the HDMI connector. Normal playback
may not be possible when using a cable other than one on which the
HDMI logo is indicated (a non-HDMI-certified product).
• If the monitor or DVD player does not support Deep Color, Deep
Color signal transfer is not possible.
• If the monitor or DVD player does not support xvYCC, xvYCC signal
transfer is not possible.
• If the monitor does not support “Auto Lipsync Correction” function,
this function will not work.
• The AVR-5308CI is compatible with the HDMI’s CEC (Consumer
Electronics Control) function. Please note the following.
•It may not work depending on the device it is connected to and its
setup.
•It does not operate with televisions or players that are not
compatible with HDMI’s CEC.
Connecting Equipment with HDMI
connectors
Connections
AVR5308CIEU_100_初校作成中.indd 12 2008/05/26 9:37:23


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
• Connect the cables to be used (vpage 9 “Video Conversion Function”).
• With HDMI connections, the video and audio signals can be transferred with a single cable.
• To output the audio signals to the monitor with HDMI connections, set GUI menu “Manual Setup”
– “HDMI Setup” – “Audio” to “TV” (vpage 33).
Connecting the Monitor
47*%&0
*/
7*%&0
$0.10/&/57*%&0
: 1#13
7*%&0
*/
)%.*
*/ */
47*%&0
065
"6%*07*%&0
$0.10/&/57*%&0
: 1#13
7*%&0
065 065
"6%*0
$0"9*"-
065
3-
065065
)%.*
R
L
R
L
Monitor
Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect
correctly.
Connecting the Playback Components
DVD Player
• Connect the cables to be used.
• With HDMI connections, the video and audio signals can be transferred with a single cable.
DVD player
NOTE
• The component video connectors may be indicated differently on your monitor. For details, see the
monitor’s operating instructions.
• The audio signals output from the HDMI connectors are only the HDMI input signals.
• Connect an HDP (High-Definition Player) in the same way.
• When using an optical cable or a BNC cable for the digital audio connection, make the settings at GUI
menu “Source Select” – “DVD” – “Assign” – “Digital” (vpage 46).
• When using a BNC cable for the component video connection, make the settings at GUI menu “Source
Select” – “DVD” – “Assign” – “Component” (vpage 47).
Connections
AVR5308CIEU_100_初校作成中.indd 13 2008/05/26 9:37:31


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
Record Player
• When connecting a record player with an MC cartridge, use a
commercially available MC head amplifier or a step-up transformer.
• Induction humming (a booming sound) may be produced from the
speakers if the volume is raised with no record player connected.
• With some record players, noise may be generated when the ground
wire is connected. If so, disconnect the ground wire.
(/%
"6%*0
065
R
L
Turntable (MM cartridge)
NOTE
The AVR-5308CI’s SIGNAL GND terminal is meant to reduce noise
when a record player is connected. This is not a safety ground
terminal.
R
L
R
L
"6%*0
"6%*0 $0"9*"-
065
3-
065
CD Player
Connect the cables to be used.
CD player
iPod®
Example :
RL
RL
"4%3
iPod
When using an optical cable or a BNC cable for the digital audio
connection, make the settings at GUI menu “Source Select” – “CD”
– “Assign” – “Digital” (vpage 46).
• With the default settings, the iPod can be used connected to the VCR
(iPod) connector.
• To assign the iPod to a connector other than VCR (iPod), make the
settings at GUI menu “Source Select” – “(input source to which iPod
dock assigned)” – “Assign” – “iPod dock” (vpage 47).
Use a DENON Control Dock for iPod (ASD-1R, sold separately) to
connect the iPod to the AVR-5308CI. For instructions on the Control
Dock for iPod settings, refer to the Control Dock for iPod’s operating
instructions.
Connections
AVR5308CIEU_100_初校作成中.indd 14 2008/05/26 9:37:41


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
47*%&0
065
"6%*07*%&0
$0.10/&/57*%&0
: 1#13
7*%&0
065 065
"6%*0
3-
065065
R
L
R
L
015*$"-
TV/CABLE Tuner
Connect the cables to be used.
TV tuner
• When using a coaxial digital cable or a BNC cable for the digital audio connection, make the settings at
GUI menu “Source Select” – “TV/CBL” – “Assign” – “Digital” (vpage 46).
• When using a BNC cable for the component video connection, make the settings at GUI menu “Source
Select” – “TV/CBL” – “Assign” – “Component” (vpage 47).
Satellite Receiver
Connect the cables to be used.
47*%&0
065
"6%*07*%&0
$0.10/&/57*%&0
: 1#13
7*%&0
065 065
"6%*0
3-
065
R
L
R
L
065
)%.* $0"9*"-
065
DBS / BS tuner
• When using an optical cable or a BNC cable for the digital audio connection, make the settings at GUI
menu “Source Select” – “SAT” – “Assign” – “Digital” (vpage 46).
• When using a BNC cable for the component video connection, make the settings at GUI menu “Source
Select” – “SAT” – “Assign” – “Component” (vpage 47).
Connections
AVR5308CIEU_100_初校作成中.indd 15 2008/05/26 9:37:51


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect correctly.
Connecting the Recording Components
Digital Video Recorder
Connect the cables to be used.
R
L
R
L
R
L
R
L
47*%&0 47*%&0
*/
3-3-
*/
*/
"6%*0 "6%*07*%&0 7*%&0
*/065
015*$"- 015*$"-
065
"6%*0 "6%*0
065
7*%&0 7*%&0
065 065
)%.*
$0.10/&/57*%&0
: 1#13
065
Digital video recorder
NOTE
• Do not connect the output of the component connected to the AVR-
5308CI’s OPTICAL2 output connector to any input connector other
than OPTICAL2.
• Do not connect the output of the component connected to the AVR-
5308CI’s OPTICAL3 output connector to any input connector other
than OPTICAL3.
• Make analog connections if you wish to record analog audio signals.
• When recording to a digital video recorder, it is necessary that the
type of cable used with the playback source equipment be the same
type that is connected to the AVR-5308CI DVR-1 OUT connector.
Example: TV IN →S-Video cable : DVR-1 OUT →S-Video cable
TV IN →Video cable : DVR-1 OUT →Video cable
• Connect a DVR-2 in the same way.
• When using a component video cable or a BNC cable for the
component video connection, make the settings at GUI menu
“Source Select” – “DVR-1” or “DVR-2” – “Assign” – “Component”
(vpage 47).
Connections
AVR5308CIEU_100_初校作成中.indd 16 2008/05/26 9:37:58


Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting
R
L
R
L
R
L
R
L
47*%&0 47*%&0
*/
3-3-
*/
*/
065
"6%*0 "6%*07*%&0 7*%&0
*/065
015*$"- 015*$"-
065
"6%*0 "6%*07*%&0 7*%&0
065 065
)%.*
Video Cassette Recorder
Connect the cables to be used.
Video cassette recorder
• When recording to a VCR, it is necessary that the type of cable used with the playback source equipment
be the same type that is connected to the AVR-5308CI VCR OUT connector.
Example: TV IN →S-Video cable : VCR OUT →S-Video cable
TV IN →Video cable : VCR OUT →Video cable
• When using a component video cable or a BNC cable for the video connection, make the settings at GUI
menu “Source Select” – “VCR” – “Assign” – “Component” (vpage 47).
NOTE
Do not connect the output of the component connected to the AVR-5308CI’s OPTICAL4 output connector
to any input connector other than OPTICAL4.
3-3-
*/ */065
015*$"- 015*$"-
065
"6%*0"6%*0
"6%*0
R
L
R
L
R
L
R
L
CD Recorder / MD Recorder / Tape Deck
Make analog connections if you wish to record analog audio signals, or digital connections if you wish to
record digital audio signals, depending on the types of connectors on the components being used.
CD recorder /
MD recorder / Tape deck
NOTE
Do not connect the output of the component connected to the AVR-5308CI’s OPTICAL4 output connector
to any input connector other than OPTICAL4.
Connections
AVR5308CIEU_100_初校作成中.indd 17 2008/05/26 9:38:07
