Dension AVR-9202-3 User manual

3. Connect the 12-way microt connector from the interface loom
to the CAR port of AVR.
4. Insert the 9 pin male DIN from the AVR into the GW500 iPod port.
5. Connect the iPod loom from the GW500 to the female 9 pin DIN
port on the AVR.
6. Remove the cable from the green Video-In Fakra connector
of the radio and connect it to the yellow Video-In phono of AVR
using the given Fakra-RCA converter cable.
7. Then connect the Video cable of “AV OUT TO HU”video output
from the 6-way microt back into the radio using the other Fakra-
RCA converter cable.
8. Connect all remaining connections (Rear Seat displays, DVD,
Cameras, handbrake detect etc.) as per section 4.
9. In some cases with the NTG1 vehicles there may not be a Quad
lock style connector on the rear of the head unit. In this case you
will need to use the universal harness for connectivity. (Universal
harness)
10. This 12 way micro-t connector consists on a 4 wire
installation.
11. Red -12V permanent power in, Black – Ground, Green – Reverse
gear detect (12v trigger), Red/White – Hand brake (neg trigger)
If you wish to use the factory TV-Tuner, please set the Gateway 500
to bypass mode. In this case all Gateway and AVR functionalites will
be disabled.
Depending on headunit capabilities the Video format of input/
output signals can be set to NTSC or PAL using a USB cong le.
In most countries when the car is moving video is not permitted
by law on the head unit (this is the default, recommended
conguration of AVR).
Pending local regulations and user liability, the Video in Motion
support may be enabled on AVR using a USB cong le.
Please see more details on the USB conguration les on the
Dension website.
4Options
BMW
3
1. Carefully remove your vehicle’s head unit as per the factory
instructions and using the correct tools.
2. Connect the AVR interface loom between the head unit and the
vehicle harness.
3. Connect the 12-way microt connector from the interface loom
to the AVR.
4. Insert the 9 pin male DIN from the AVR into the GW500 iPod
port.
5. Connect the iPod loom from the GW500 to the female 9 pin DIN
port on the AVR.
6. On the 12-way microt harness there is a break out for the video
input in the vehicle. The Vehicle side will connect into the (yellow)
Video-In phono RCA input of AVR. The return video must be then
connected into the head unit harness. All connections are on the
supplied harness.
7. Connect all remaining connections (Rear Seat displays, DVD,
Cameras, handbrake detect etc.) as per section 4.
Introduction
Warning! Always make sure that your vehicle’s battery is
disconnected before beginning installation and that you have
your head unit’s (radio’s) security code (if applicable).
The Dension AVR will enable you to access audio and visual data from
a seperate, aftermarket source (iPod, DVD etc.) and view it on your
vehicle’s original head unit (radio) via a Gateway (GW) 500 module.
Please note that TV-Tuner activation may be required to enable the
AV input. Contact your dealer for more information. There are also
various options that will allow you to connect your aftermarket
source that would not be possible with the OE system (cameras/rear
seat entertainment etc.). Check the user guide for all functions.
All photos/illustrations are for representation purposes only and may dier
visually from the equipment in your vehicle. Information correct at time of
going to print E. & O. E. Dension Audio Sytems Ltd. and it’s registered partners
cannot be held liable for any damages caused by the incorrect installation of
any Dension product.
Porsche PCM2.1 Cayenne n/a 2005-2008 Standard AVRG5P1
CL C215 2005-2006
CL C216 2006-
CLS W219 2004-
E W211 2003-
S W220 2003-2005
S W221 2006-
SL R230 2005-
SLK R171 2004- Universal Harness
A W169 2005-
B W245 2005-
C W203 2004-2007
CLK W209 2005-
G W463 2005-
M W164 2005-
R V251 2006-
1 Series E87 2004-
3 Series E90/E91 2005-
BMW 5 Series E60/E61 2004-
6 Series E63/E64 2004-
7 Series E65/E66 2004-
ClassHU
AVRG5M1
Product Part numberLoom requiredMYType Code
AVRG5B1
Comand
NTG1
Comand
NTG2 Standard
i-Drive
CCC,8.8"
Professional
Standard
AVRG5M2
Mercedes
Standard
Standard
Universal Harness
Car compatibility
1
1. Carefully remove your vehicle’s head unit as per the factory
instructions and using the correct tools.
2. Connect the AVR interface loom between the head unit and the
vehicle harness.
Porsche and Mercedes
2

Dension AVR installation guide
AV out to HU: Connects to the Video input on the OE head unit.
Audio outputs are left unconnected in case of Gateway 500.
Video In: The original video signal from factory TV-Tuner or factory
rear view camera is connected here. This signal is routed to the
head unit when the Gateway is in Bypass mode.
AV out to RSE: This is an output for rear seat entertainment, i.e.
an extra screen. This is to be connected as per the manufacturer’s
guidelines. The input can alternate between DVD, iPod and AUX
inputs.
Handbrake trigger: This must be connected to the control switch
of the handbrake (a relay may be required if the switch has a
positive trigger).
Reverse Camera: This camera video input allows three aftermarket
cameras to be connected to your OEM system. If one camera is
used, the connector labelled as Center is used. In case of BMW only
one camera is supported.
Aftermarket connections
5
Reverse Gear detect: If rear view cameras are connected usually
the AVR can detect reverse gear through CAN bus. In this case this
wire is left unconnected.
If for some reason the reverse gear cannot be detected this wire
should be connected to the reverse gear switch (positive trigger).
AV IN 1 input: Allows you to connect an aftermarket DVD source
to the OEM system. The connections consist of an Audio Left /
Right with a Video input. An IR remote output is available if your
aftermarket equipment supports this.
Optional IR eye: Enables you to control a DVD player via the
original remote control (model specic).
AV IN 2 input: Allows you to connect any media source with
composite video output to your vehicle’s OEM system, for example
a digital camera or a gaming console. Connections: Female phono
Audio Left / Right with a Video input.
Need more help? Visit www.dension.com/support
AVR-9202-3
AVR
+12V switched power
output for cameras
+12V Power in
Reverse Gear
detect (Green)
REVERSE
CAMERA
IR
AV IN 2
AV IN 1
Optional remote control to DVD
(Yellow, Blue)
DVD Player
Optional +12V switched
power output for DVD
Optional IR eye
iPod
iPod
VIDEO IN
GW
CAR
MOST
ring Gateway 500
USB
Head Unit
Radio
AV OUT
TO RSE
AV OUT
TO HU
RSE
Screen & Audio
MOST
ring
Centre (White)
Left (Yellow)
Right (Red)
Handbrake
trigger
(Red/White)
Optinal External
remote
(White, Yellow)
